2AAZRHSD8012DICUBE BLUETOOTH SPEAKER

Instruction Manual Welcome to choose my company product Bluetooth audio magic sound box. The product is a portable audio with Bluetooth receiver. You can store the songs in mobile phone or device with Bluetooth playback, and then transmit to this product for music playback via Bluetooth. Read the instruction manual quickly before use. Main Features & Technical Parameters 1. Bluetooth audio player 2. Stereo speaker 3. Φ 3.5mm Audio input interface 4. 7 sensor touch keys 5. Audio maximum power:2W*2 6. Frequency response: 20Hz-20KHz 7. Power supplied: Built-in rechargeable lithium battery 8. Connect external USB 5VDC power source to charge product 9. Charging time of about 3 - 4 hours 10. Continue play music about 2-3 hours when built-in lithium battery is fully charged 11. LED panel backlight with Bluetooth indicator, audio indicator, full power indicator, power charge indicator Product Illustration Function of the Keys Key Name Operation Mode Functional Description Power Switch Turn on or off the main power Main power switch Power Key Long sensor touch to turn on or off Product in switch on or standby mode Switch Mode Key Sensor touch during music playback Switch between Bluetooth and audio input source, corresponding indicator light will be lift up Track Backward Sensor touch during music playback Bluetooth playback previously track Play/Pause Sensor touch during playback or pause Continuous Bluetooth playback music or pause music playback Track Forward Sensor touch during music playback Bluetooth playback next track Sensor touch Increase one Bluetooth volume level Volume + Long sensor touch Increase Bluetooth volume level continuously and a prompted sound when reaching max. volume level Sensor touch Reduce one Bluetooth volume level Volume - Long sensor touch Reduce Bluetooth volume level continuously Bluetooth Playback 1. Push the power switch to “ON” position, long touch power key to turn on this sound box, panel backlight on and produces a sound, reminder Bluetooth indicator light flashes quickly. 2. Turn on Bluetooth function in mobile phone or Bluetooth device; search the equipment in the Bluetooth menu. 3. When “Hiting” appear on Bluetooth equipment list, select “Hiting” to establish pairing and connection (if pass code requested, enter 0000). When the pairing and connection is successful, this product will be produced a sound reminder, the Bluetooth indicator flashes rapidly become slow flash, you can use this product to playback your device’s music. 4. If the pairing timeout or the Bluetooth indicator stops flashing, repeat steps 1-3 for pairing connection. Audio Input Playback 1. Touch the switch mode key(M) to switch the audio source to the audio input playback status, audio indicator light on. 2. Connect the audio cable between the audio input jack and MP3, iPod, cell phone or other audio source, playback audio source music, adjust the volume level of the audio source output to achieve the optimal sound. Remark: When audio input playback, the keys of Track backward, Track forward, Play/Pause, Volume +, Volume – are no function. Use the control keys from your audio source. USB and built-in rechargeable lithium battery power supply 1. Use USB power cable to connect product’s USB power jack and computer or DC5V power adapter for power supply and charging the built-in rechargeable lithium battery synchronously, the power charging indicator light on at this status, and the full power indicator light on when battery full charged. 2. When the product have no power supplied by USB power, it will supplied by built-in rechargeable lithium battery. Troubleshooting Failure Manifest Solution Bluetooth playback interrupt and produced “du du” sound The battery is too low, please charge. Music intermittent in Bluetooth playback Try to move the Bluetooth device close to product or change the audio or equipment location. Charge the battery if it is too low. Move the Bluetooth device close to product. Switch off and restart the product to wake it up. Check the device or computer has Bluetooth function or not? Repeat this product’s Bluetooth playback setting steps. This product only playback one device music per time, the cancelled device and not use pairing (please see the device documentation for assistance), need to pair new device in accordance with the setup steps. Equipment cannot pair with Bluetooth audio connection If it is paired with the computer, specify “Hiting” for portable audio as the computer’s audio output device. Charge the battery if it is too low. Touchkey failure Move the Bluetooth device close to product. Speaker volume too low Touch “Volume +” key to appropriate level. Package Contents 1. Each 1pc of USB power cable and audio cable. 2. 1pc of power adapter (optional). 3. Instruction Manual. Caution: 1. The product avoids rain and damp, in order to avoid damage. 2. The product should be kept away from fire, high temperature environment to avoid the product does not work normally and explosion. 3. Do not use the hand touching the speaker or impact with other objects to avoid damage. 4. Use DC5V power supply with current output 1A above. 5. Switch the power to “ON” position when you stop playing for saving energy power. 6. When disposing of this product’s rechargeable lithium battery, classification recycling if possible to avoid environmental pollution. 7. It is recommended the battery is fully charged when first time use the product. FCC Certification Requirements Caution: Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. The manufacturer is not responsible for any…

Text truncated - open the document above for the full version.

Shenzhen Highstar Electrical Co.,Ltd Building 6, Highstar Industrial zone, Gangtou, Bantian Street, Longgang District, ShenZhen Confidentiality Request Letter Page 1 of 1 Rev 2.0 September 12, 2013 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Permanent Confidentiality Request Confidentiality Request regarding application for certification of FCC ID: 2AAZRHSD8012D We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematic The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title: Susanne Luk / Sale Manager Contact information / address: Building 6, Highstar Industrial zone, Gangtou, Bantian Street,Longgang District,ShenZhen TEL: 852-24091119 FAX: 852-24091129 E-mail: [email protected]

External Photo

FCC Certification Label FCC ID: 2AAZRHSD8012D THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. Label Location on EUT EUT Bottom View/ FCC ID Label Location

Internal Photo Antenna

FCC PART 15.249 EMI MEASUREMENT AND TEST REPORT For Shenzhen Highstar Electrical Co.,Ltd Building 6, Highstar Industrial zone, Gangtou, Bantian Street, Longgang District, ShenZhen FCC ID: 2AAZRHSD8012D September 24, 2013 This Report Concerns: Original Report Equipment Type: ICUBE BLUETOOTH SPEAKER Test Engineer: Lisa Chen Report No.: BSL13094750Y-1ER-3 Receive EUT Date/Test Date: Sep. 13, 2013 / Sep 03-24, 2013 Reviewed By: Sky Zhang Prepared By: BSL Testing Co.,LTD. NO. 24, ZH Park, Nantou, Shenzhen, 518000 China Tel: 86- 755-26508703 Fax: 86- 755-26508703 Note: The test report is specially limited to the above company and this particular sample only. It may not be duplicated without prior written consent of BSL Testing Co.,LTD. This report must not be used by the client to claim product certification,approval,or endorsement by NVLAP, NIST or any agency of the US Government. FCC ID: 2AAZRHSD8012D BSL13094750Y-1ER-3 Page 2/32 TABLE OF CONTENTS 1. GENERAL INFORMATION ....................................................................................................3 1.1. Report information ............................................................................................................3 1.2. Measurement Uncertainty .................................................................................................3 2. PRODUCT DESCRIPTION ......................................................................................................4 2.1. EUT Description ...............................................................................................................4 2.2. Block Diagram of EUT Configuration..............................................................................5 2.3. Support Equipment List ....................................................................................................5 2.4. Test Conditions .................................................................................................................5 3. TEST RESULTS SUMMARY ...................................................................................................6 Modifications ................................................................................................................................6 4. TEST EQUIPMENT USED .......................................................................................................7 5. ANTENNA REQUIREMENT ...................................................................................................8 5.1. Standard Applicable..........................................................................................................8 5.2. Antenna Connected Construction .....................................................................................8 5.3. Result ................................................................................................................................8 6. CONDUCTED POWER LINE TEST .......................................................................................9 6.1. Test Equipment .................................................................................................................9 6.2. Test Procedure ..................................................................................................................9 6.3. Test Setup..........................................................................................................................9 6.4. Conducted Power line Emission Limits............................................................................9 6.5. Conducted Power Line Test Result.................................................................................10 7. RADIATED EMISSION TEST ...............................................................................................12 7.1. Test Equipment ...............................................................................................................12 7.2. Test Procedure ................................................................................................................12 7.3. Radiated Test Setup ........................................................................................................12 7.4. Radiated Emission Limit.................................................................................................14 7.5. Radiated Emission Test Result .......................................................................................15 8. BAND EDGE .............................................................................................................................20 8.1. Test Equipment ...............................................................................................................20 8.2. Test Procedure ................................................................................................................20 8.3. Band Edge FCC 15.249(d) Limit ....................................................................................20 8.4. Band Edge Test Result ....................................................................................................21 9. 20-DB BANDWIDTH ...............................................................................................................29 9.1. Test Equipment ...............................................................................................................29 9.2. Test Procedure ................................................................................................................29 9.3. Limit................................................................................................................................29 9.4. Test Result /Plots ............................................................................................................29 FCC ID: 2AAZRHSD8012D BSL13094750Y-1ER-3 Page 3/32 1. GENERAL INFORMATION 1.1. Report information 1.1.1.This report is not a certificate of quality; it only applies to the sample of the specific product/eq…

Text truncated - open the document above for the full version.

Radiated emissions test Conducted Emission
