Size: 148.5(W) x 210(H)mm (A5) LIMITED WARRANTY LIMITED WARRANTY 1. Main Unit 2. Remote Sensor 3. swercS 4. Speaker with Decorative Lights 5. Wooden Base 6. Control Buttons (On the top) 7. Front Decorative Lights 8. Bass Duct 3 Insert the small plug from the supplied AC/DC Adaptor to the DC IN Jack on the rear of unit. Connect the AC/DC adaptor to a wall outlet having AC 100-240 V~, 50/60 Hz NOTE: This AC/DC Adpator is intended to be correctly orientated POWER SOURCE LOCATIONS OF CONTROLS L R 6 2 4 1 7 8 ............ 5 3 LOCATION OF CONTROL 4 1. ANT (FM Antenna) 2. POWER ON/OFF Switch 3. DC IN Jack 4. LINE IN Jack 5. AU X IN Jack 6. (Standby On/O k) Button 7. INDICATOR 8. L E D Button 9. SOURCE Button 1 0. VOL - ( V o lum e Do wn) But t on 11. VOL + (Volume Up) Button 12. 13. 1 T U N E + / B u t t o n T U N E - / B u t t o n LINE IN 5V 2.5A LOCATION OF CONTROL (REMOTE CONTROL) 1. (Standby On/Off) Button 2. LED ON/OFF Button 3 (Mute) Button 4. SOURCE Button 5. RESET Button 6. TUNE - / Button 6 7. (Play / Pause) Button 8. TUNE + / Button 9. VOL (Volume) +/- Buttons 10. TREBLE +/- Buttons 11. BASS +/- Buttons ASSMBLING METHOD 6 ASSEMBLING METHOD Supplied screwdriver Assembly the two wooden bases to the bottom of unit by the supplied assembly screws and screwdriver as the illustrated above. BUTTON CELL INSTALL/REPLACE (REMOTE CONTROL) BATTERY PRECAUTIONS EFFECTIVE DISTANCE OF REMOTE TRANSMITTER Follow these precautions when using a battery in this device: 2. Be sure to the follow the correct polarity when installing the battery as indicated in the battery compartment. A reversed battery may cause damage to the device. 4. If the batteries in the device are consumed or the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from possible battery leakage. 5. Do not try to recharge the battery not intended to be recharged; it can overheat and rupture. (Follow battery manufacturer's instructions.) 7. Clean the battery contacts and also those of the device prior to battery installation. 8. This product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burn in just 2 hours and can lead to death. Keep new and used batteries away from children. If the battery compartment does not close securely, stop using the product and keep it away from children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention. 1. When there is an obstacle between the unit and the transmitter, the transmitter may not operate. 2. When direct sunlight, an incandescent lamp, shines on the REMOTE SENSOR of the unit, the unit remote operation may be unstable. ~ Replacing the button cell for the remote control if it is drained: 1. Push then slide out the battery tray as the illustrated below. 2. Replace the button cell by a new CR2025 button cell with the polarity "+" face up as the illustrated below and the makings on the rear of remote control. 3. Close the battery tray 1. 2. Remote sensor 16 Feet (5 Meter) GENERAL OPERATION: 1. Connected the unit to AC power as instructed earlier. 2. Slide the POWER ON/OFF Switch on the rear of unit to ON position to turn the unit to Standby Mode, the Red Indicator on top of unit will illuminate. 3. Press and hold the Button on the top of unit or press the Button on the Remote Control to power on the unit from Standby Mode. The Decorative LED Lights will illuminate and the color of the indicator on the top of unit will turns to correspondence color as the playback source. 4. Press the SOURCE Button on the unit or press the SOURCE Button on the Remote Control repeatedly to switch to the desired playback mode. The color of the indicator will turn to correspondent color with your selection (see list below): Color of Indicator: Playback Source/Mode: Blue BT (Bluetooth) Teal FM Radio Purple LINE IN Green AUX IN 5. Press the VOL +/- Buttons on the unit or Remote Control to adjust volume level as desire. 6. Press the TREBLE +/- Buttons on the Remote Control to adjust the treble (high audio frequency) level as desire. 7. Press the BASS +/- Buttons on the Remote Control to adjust the bass (low audio frequency) level as desire. on speakers or front of unit. Control to turn the unit to Standby Mode. The color of the indicator will turns to Red. 12. For saving energy, if you will not use the unit for an extended period of time. Slide the POWER ON/OFF Switch BT MODE: BT (Bluetooth) pairing: First time use or re-pairing the unit to a new BT Device, pair as follows: 1. Power on the unit and enter to BT (Bluetooth) mode as the instructed earlier. The color of the indicator on the top of unit will turns to Blue and blink. 2. Power on the external BT Device and enter to BT searching mode. Start pairing following the on screen instructions from the external BT Device. When paired, the Blue BT Indicator will stop blinking. 3. If pairing is complete you may now play music with your external BT Device. 4. During playback: z Press the Button on the unit or the Button on Remote Control to pause, press again to resume normal playback. Press the TUNE -/ or TUNE +/ Buttons on the unit or Remote Control to Skip tracks. Notes: zWhen the external BT Device searched the unit, the model number “CHT894” will appear on the display of external BT Device. zIf while pairing you are asked for a code please try "0000" or "1234". Normal operation after pairing: 1. Power on the external BT Device and enter to BT playback mode. 2. Power on the unit and enter to BT (Bluetooth) mode as the instructed earlier. The color of the indicator on the top of unit will turns to Blue and blink. 3. Wait a few seconds until the unit is automatically paired to the external BT Device. The blue indicator will stop blinking. 4. After pairing is complete you may now play music with your external BT Device. z OPERATION 9. Pr 10 11. RADIO: 1. Power on the unit and enter to Radio m…
