Page 1o f12 Revision 1.0 Date 17Mar2014 Wisepad User Guide Page 2o f12 Revision 1.0 Date 17Mar2014 Switch on Wisepad. Standby can be seen on LCD. Then press the Bluetooth button on red circle on figure shown, blue light is flashing. That means the Bluetooth module is ready to be paired. Page 3o f12 Revision 1.0 Date 17Mar2014 Page 4o f12 Revision 1.0 Date 17Mar2014 2. Open the App for using wisepad, and press the selection key on the bottom, there are 4 options could be seen. Upper left corner: Scan Bluetooth Upper right corner: Paired Device Lower left corner: Stop Bluetooth Lower right corner: Unpair All Press Scan Bluetooth to connect Wisepad Page 5o f12 Revision 1.0 Date 17Mar2014 3 After connected Bluetooth, Bluetooth connected and MAC Address will be displayed on the APP, and Wisepad Ready will be shown on LCD. Blue light LED will keep on. Page 6o f12 Revision 1.0 Date 17Mar2014 Upper left corner Get Device info Middle left: Check Card Lower left corner: Set Amount Upper right corner: Clear Log Middle right: Cancel Check Card Lower right corner: Start EMV 1. Wisepad info and status could be get after press Get Device info. The display log can be cleared by pressing Clear log. Page 7o f12 Revision 1.0 Date 17Mar2014 2. User can perform swipe card or insert ICC card after press Check Card button Page 8o f12 Revision 1.0 Date 17Mar2014 2.1 The following example is after a successful swipe card Page 9o f12 Revision 1.0 Date 17Mar2014 2.2 Further details could be checked with sliding middle log. Page 10o f12 Revision 1.0 Date 17Mar2014 2.3 ICC Card Inserted will be shown after inserted an ICC card successfully Page 11o f12 Revision 1.0 Date 17Mar2014 3. User could perform a simulated EMV transaction after press Start EMV.. 4. Press Disconnect Bluetooth to disconnect the device, and Bluetooth disconnected will be shown. Wisepad will reset to Standby. Page 12o f12 Revision 1.0 Date 17Mar2014 FCC Requirement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. M/N: WisePad FCC ID: 2AB7XWISEPAD This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

DATE : 2014-04-09 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AB7XWISEPAD Product Name: WisePad Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Day of 20 A gency agreement expiration date:2014-04-09 to 2015-04-08 By: Stacey Zhang Signature Printed Title: manager On behalf of : BBPOS Limited Telephone: 0769-81896355

FCC label information:

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05r02 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2441MHz 0.47dBm（1.1143mW） output power] (1.1143 mW /5mm) ·[√2.441 (GHz)]= 0.35 <3.0 for 1-g SAR Then SAR evaluation is not required

Report No. : EESZG03100008-2 Page 1 of 40 TEST REPORT Product : WisePad Trade mark : N/A Model/Type reference : WisePad Serial number : N/A Ratings : Input: 5V , 500mA (Battery: 3,7V 320mAh), Class III, IPX0 FCC ID : 2AB7XWISEPAD Report number : EESZG03100008-2 Date : Apr. 08, 2014 Regulations : See below Test Standards Results 47 CFR FCC Part 15 Subpart C 15.247: 2013 PASS Prepared for: BBPOS Limited RM812, 8/F., Grand City Plaza, No. 1 Sai Lau Kok Road, Tsuen Wan, N.T., Hong Kong Prepared by: Centre Testing International (Shenzhen) Corporation Hongwei Industrial Zone, 70 Area, Bao’an District, Shenzhen, Guangdong, China TEL: +86-755-3368 3668 FAX: +86-755-3368 3385 Tested by: Reviewed by: Approved by: Date: Apr. 08, 2014 Jimmy Li Lab manager Check No.: 1702064607 Report No. : EESZG03100008-2 Page 2 of 40 TABLE OF CONTENTS 1. GENERAL INFORMATION ............................................................................................ 4 2. PRODUCT INFORMATION ............................................................................................ 4 3. TEST SUMMARY ........................................................................................................... 5 4. MEASUREMENT UNCERTAINTY ................................................................................. 5 5. SYSTEM TEST CONFIGURATION ................................................................................. 5 5.1 JUSTIFICATION ...................................................................................................... 5 5.2 PRODUCT EXERCISING SOFTWARE .................................................................. 6 6. TABLE OF TEST MODE ................................................................................................ 6 7. TEST EQUIPMENT LIST ............................................................................................... 6 8. SUPPORT EQUIPMENT LIST ....................................................................................... 7 9. CONDUCTED EMISSION TEST .................................................................................... 7 9.1. LIMITS ..................................................................................................................... 8 9.2. BLOCK DIAGRAM OF TEST SETUP ..................................................................... 8 9.3. PROCEDURE OF CONDUCTED EMISSION TEST ............................................... 8 9.4. GRAPHS AND DATA ............................................................................................. 9 10. 20DB BANDWIDTH OCCUPIED BANDWIDTH MEASUREMENT .......................... 11 10.1. LIMITS ................................................................................................................... 11 10.2. BLOCK DIAGRAM OF TEST SETUP ................................................................... 11 10.3. TEST PROCEDURE ............................................................................................. 11 10.4. TEST RESULT ...................................................................................................... 11 11. CARRIER FREQUENCY SEPARATION .................................................................. 13 11.1. LIMITS ................................................................................................................... 13 11.2. BLOCK DIAGRAM OF TEST SETUP ................................................................... 13 11.3. TEST PROCEDURE ............................................................................................. 13 11.4. TEST RESULT ...................................................................................................... 13 12. NUMBER OF HOPPING FREQUENCY ................................................................... 15 12.1. LIMITS ................................................................................................................... 15 12.2. BLOCK DIAGRAM OF TEST SETUP ................................................................... 15 12.3. TEST PROCEDURE ............................................................................................. 15 12.4. TEST RESULT ...................................................................................................... 15 Report No. : EESZF12050020 Page 3 of 40 13. TIME OF OCCUPANCY (DWELL TIME) .................................................................. 16 13.1. LIMITS ................................................................................................................... 16 13.2. BLOCK DIAGRAM OF TEST SETUP ................................................................... 16 13.3. TEST PROCEDURE ............................................................................................. 16 13.4. TEST RESULT ...................................................................................................... 16 14. MAXIMUM PEAK CONDUCTED OUTPUT POWER MEASUREMENT ................... 22 14.1. LIMITS ................................................................................................................... 22 14.2. BLOCK DIAGRAM OF TEST SETUP ................................................................... 22 14.3. TEST PROCEDURE ............................................................................................. 22 14.4. TEST RESULT ...................................................................................................... 22 15. BAND EDGE EMISSION MEASUREMENT ............................................................. 24 15.1. LIMITS ................................................................................................................... 24 15.2. BLOCK DIAGRAM OF TEST SETUP ................................................................... 24 15.3. TEST PROCEDURE ............................................................................................. 24 15.4. TEST RESULT ..............................................................…
