2ABC64CH58AP000Wireless Charger

User Manual CHARGER ASSY-WIRELESS QF 4CH58-AP000/010 *This product was designed for Kia Motors’ OPTIMA(QF).pgQ *Only Qi-certified device can be charged on this product. Thank you for purchasing this wireless vehicle charger for Kia Motors’ OPTIMA(QF). ldh lflldhdflPlease read the user manual carefully and use the product safely. Description of parts Power LED No Coins No Smart key QI Logo Charge LED NOTE Qi Logo: This product is Qi-certified wireless charger. No Smart Key: Do not put a smart key on this product. No Coins: Do not put the coins on this product. Rubber Pad No Coins: Do not put the coins on this product. Ht 1. Turn on the engine, and see if the product's power LED(right) is lit. 2. Place the device that has the Qi logo on the middle of the charging pad. (Is better to align the device to the center of the pad) 3. The Charge LED starts to light on in red as charging begins. 4. When the charging is finished, the LED will turn green. How to use • If it is not charging well make sure to align the device to the center and recharge. • Some smartphones or cases do not send the full charging signal to wireless charger, in this case, the charge LED will remain in red. Troubleshooting The device is not charging - Make sure the device is qi standard. - Relocate the device location. - Make sure the device being charged is full. - Make sure that somethin g is on the wireless charger. Troubleshooting gg The charge LED is blinking fast or not lit - Make sure you have properly connected your device with the appropriate wireless charging case, or foreign objects are inserted between receiver and transmitter. - Relocate the device location. Do not put a smart keyor coinson this product. Dtit tithtthli id Caution, Service Do not insert or wet with wateror any other liquid. Do not take it part or make alterations. Keep away from any mechanical device that could be affected by a magnetic field. 1. Put a mobile phone in the middle of the product to charge. If the mobile phone is placed in other position, it may cause charge malfunctionmalfunction. 2. The use of original Rx Case is recommended for this equipment. If any abnormal RX Case is used, it may cause malfunction or damage of the equipment. 3. If there are any metal materials like coins between chargers, you may suffer physical injuries including burns due to heat. If you encounter problems or abnormalities during the use pleaseIf you encounter problems or abnormalities during the use please stop using the product and contact the store where the purchase was made. Cli S FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : Compliance Statement subject to the following two conditions : (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the lim its for a Class B digital device, pursuant to Part 15 of the FCC Rule s. These limits are desi gned to provide reasonable protection agaigpp g nst harmful interference in a residential installation. This equipmen t generates uses and can radiate radio frequency energy and, if no t installed and used in accordance with the instructions, may caus e harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful inter ference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to tr y to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Clhdliddi/TVhilfhl–Consult the dealer or an experienced radio/TV technical for help. Cli S IC Compliance Statement This device complies with Industry Canada license-exempt RSS standard(s). Compliance Statement standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil est conforme avec Industrie Canada exempts de licen ce standard RSS (s). L'opération est soumise aux deux conditions s()p uivantes: (1) cet appareil ne peut causer d'interférences, et (2) cet appareil doit accepter toute interférence, y compris les interférenc es quipeuvent causer un mauvais fonctionnement de l'appareil. User’s Caution Statement Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. Toute changé ou modifications non expressément approuvés par la partie responsable de la conformité pourraient annuler l'utilisateur `autorité de faire fonctionner cet équipement.

MCNEX CO., LTD. Hanshin IT Tower II, 11F, 60-18, Gasan-dong, Geumcheon-gu, Seoul, KOREA Date: December 10, 2013 Declaration Letter Vehicle's wireless charger specifications is below : a) Power transfer frequency is less than 1MHz → The power transfer frequency of DUT(Device Under Test) is between 112KHz and 205KHz. b) Output power from each primary coil is less than 5 watts → Output power from each coils are Max. 5 watts. c) The transfer system includes only single primary and second coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils → The DUT are consist of 3 charging coils using A6 coils as below so the DUT can detect and allow coupling only between individual pairs of coils. d) Client device is inserted in or placed directly in contact with transmitter →When the client device is placed directly in contact with transmitter, then charging is able to start. e) The maximum coupling surface area of the transmit (charging) device is between 60 ㎠ and 400㎠ → The Maximum coupling surface area of the charging transmit is 75㎠. Maximum coupling surface area(15 Cm X 5 Cm) f) Aggregate leakage fields at 10㎠ surrounding the device from all simultaneous transmitting coils are demonstrated to be less than 30% of the MPE limit. → The highest leakage filed is less than 30 % of the MPE limit. g) The similarity and difference between two models → The difference between two models is the voltage input method. The one is fixed type car component into vehicle and using car wiring harness for voltage input. The other is using cigar jack for voltage input and movable type . Sincerely, Manager Gi-ho, Kim

MCNEX CO., LTD. Hanshin IT Tower 2, 60-18, Gasan-dong, Geumcheon-gu, Seoul, Korea Date: December 10, 2013 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. Claire Hoque/Application Examiner of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. Claire Hoque of CCS on our behalf shall have the same effect as acts of our own. In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards;

MCNEX CO., LTD. Hanshin IT Tower 2, 60-18, Gasan-dong, Geumcheon-gu, Seoul, Korea Date: December 10, 2013 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA LETTER OF AUTHORIZATION We, the undersigned, hereby authorize Harvey Sung of Digital EMC Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: 2ABC64CH58AP000 including signing of all documents relating to these matters. Any and all acts carried out by Harvey Sung of Digital EMC Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from MCNEX CO., LTD. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Manager Gi-ho, Kim

MCNEX CO., LTD. Hanshin IT Tower II, 11F, 60-18, Gasan-dong, Geumcheon-gu, Seoul, KOREA Date: December 10, 2013 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA RE: Request of Confidentiality for FCC ID: 2ABC64CH58AP000 To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, MCNEX CO., LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give MCNEX CO., LTD.. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Operational Description 3 Schematics 4 Part Lists SHORT-TERM 5 External Photos 6 Internal Photos 7 Test-Setup Photos 8 Users Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Manager Gi-ho, Kim

FCCID: 2ABC64CH58AP000 Copyright Ⓒ 2013, Digital EMC Co., Ltd. Page1 / 3 View 1 FCCID: 2ABC64CH58AP000 Copyright Ⓒ 2013, Digital EMC Co., Ltd. Page2 / 3 View 2 FCCID: 2ABC64CH58AP000 Copyright Ⓒ 2013, Digital EMC Co., Ltd. Page3 / 3 View 2

FCC ID: 2ABC64CH58AP000 Copyright Ⓒ 2013, Digital EMC Co., Ltd. FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included on this label. - The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the user's manual.

FCCID: 2ABC64CH58AP000 Copyright Ⓒ 2013, Digital EMC Co., Ltd. Page1 / 3 View 1 FCCID: 2ABC64CH58AP000 Copyright Ⓒ 2013, Digital EMC Co., Ltd. Page2 / 3 View 2 FCCID: 2ABC64CH58AP000 Copyright Ⓒ 2013, Digital EMC Co., Ltd. Page3 / 3 View 3

DEMC1310-03224 & DEMC1310-03236 FCC ID : 2ABC64CH58AP000 DRTFCC1312-1220 IC : 11570A-4CH58AP000 TRF-RF-204(01)110221 Page 2 / 13 Copyright ○ C 2013, Digital EMC Co., Ltd. Test Report Version Test Report No. Date Description DRTFCC1312-1220 Dec. 27, 2013 Initial issue DEMC1310-03224 & DEMC1310-03236 FCC ID : 2ABC64CH58AP000 DRTFCC1312-1220 IC : 11570A-4CH58AP000 TRF-RF-204(01)110221 Page 3 / 13 Copyright ○ C 2013, Digital EMC Co., Ltd. CONTENTS 1. Equipment information ............................................................. 4 1.1 Equipment description ............................................................ 4 1.2 Support equipments ............................................................... 4 2. Information about test items .................................................... 5 2.1 Test mode ............................................................................... 5 2.2 Tested environment ................................................................ 5 2.3 EMI Suppression Device(s)/Modifications .............................. 5 3. FACILITIES AND ACCREDITATIONS ........................................ 6 3.1 FACILITIES ............................................................................ 6 3.2 EQUIPMENT .......................................................................... 6 4. Test Report ................................................................................ 7 4.1 Summary of tests ................................................................... 7 4.2 Transmitter requirements........................................................ 8 4.2.1 20dB Bandwidth ................................................................. 8 4.2.2 Radiated Emissions ........................................................... 9 4.2.3 AC Line Conducted Emissions .......................................... 11 APPENDIX I ................................................................................. 12 DEMC1310-03224 & DEMC1310-03236 FCC ID : 2ABC64CH58AP000 DRTFCC1312-1220 IC : 11570A-4CH58AP000 TRF-RF-204(01)110221 Page 4 / 13 Copyright ○ C 2013, Digital EMC Co., Ltd. 1. Equipment information 1.1 Equipment description FCC Equipment Class Part 15 Low Power Transmitter Below 1705 kHz (DCD) Equipment type Wireless Charger Equipment model name 4CH58AP000 Equipment add model name 4CH58AP010 Equipment serial no. Identical prototype Frequency band 112 ~ 205kHz Output power Max : 5 W Power DC 12V Antenna type Coil Antenna X 3ea Note Note: This device has 3 coil antennas but only one antenna is used for transmitting at a time after selection of the best coil antenna,. 1.2 Support equipments Equipment Model No. Serial No. Manufacturer Note Wireless Charging Cover MWC-R525T N/A M.Cloud - Mobile Phone GT-I9505 -I9505GSMH SAMSUNG FCC ID : A3LGTI9505 Note: The above equipments were supported by manufacturer. DEMC1310-03224 & DEMC1310-03236 FCC ID : 2ABC64CH58AP000 DRTFCC1312-1220 IC : 11570A-4CH58AP000 TRF-RF-204(01)110221 Page 5 / 13 Copyright ○ C 2013, Digital EMC Co., Ltd. 2. Information about test items 2.1 Test mode This device has been tested in all the configurations of charging mode with each coil antenna. Mode Charging Current Support Equipment 1 300mA Wireless Charging Cover (M/N: MWC-R525T) 2 600mA 3 1000mA(Max) 4 @ < 1% battery status Mobile Phone(M/N: GT-I9505) 5 @ 50% battery status 2.2 Tested environment Temperature : 23 ~ 24 o C Relative humidity content : 35 ~ 41 % R.H. Details of power supply : DC 12 V 2.3 EMI Suppression Device(s)/Modifications EMI suppression device(s) added and/or modifications made during testing → None DEMC1310-03224 & DEMC1310-03236 FCC ID : 2ABC64CH58AP000 DRTFCC1312-1220 IC : 11570A-4CH58AP000 TRF-RF-204(01)110221 Page 6 / 13 Copyright ○ C 2013, Digital EMC Co., Ltd. 3. FACILITIES AND ACCREDITATIONS 3.1 FACILITIES The semi anechoic chamber and conducted measurement facility used to collect the radiated and conducted test data are located at the 683-3, Yubang-Dong, Yongin-Si, Gyunggi-Do, 449-080, South Korea. The site is constructed in conformance with the requirements. - Semi anechoic chamber registration Number : FCC(678747), IC(5470A-2) 3.2 EQUIPMENT Radiated emissions are measured with one or more of the following types of antennas: loop, tuned dipole, bi-conical, log periodic, bi-log, and/or ridged waveguide horn. Spectrum analyzers with pre-selectors and peak, quasi-peak detectors are used to perform radiated measurements. Conducted emissions are measured with Line Impedance Stabilization Networks and EMI Test Receivers. Calibrated wideband preamplifiers, coaxial cables, and coaxial attenuators are also used for making measurements. All receiving equipment conforms to CISPR Publication 16-1, “Radio Interference Measuring Apparatus and Measurement Methods.” DEMC1310-03224 & DEMC1310-03236 FCC ID : 2ABC64CH58AP000 DRTFCC1312-1220 IC : 11570A-4CH58AP000 TRF-RF-204(01)110221 Page 7 / 13 Copyright ○ C 2013, Digital EMC Co., Ltd. 4. Test Report 4.1 Summary of tests FCC Part Section(s) RSS Section(s) Parameter Limit Test Condition Status Note 1 Test Items 2.1049 N/A 20 dB Bandwidth N/A Radiated C 15.209 RSS-Gen [7.2.5] Radiated Emission FCC 15.209 limits C 15.207 RSS-Gen [7.2.4] AC Conducted Emissions FCC 15.207 limits AC Line Conducted NA Note2 Note 1: C=Comply NC=Not Comply NT=Not Tested NA=Not Applicable Note 2: The supplying power of this device is DC 12V from a Car Battery. The sample was tested according to the following specification: ANSI C-63.4 2009 DEMC1310-03224 & DEMC1310-03236 FCC ID : 2ABC64CH58AP000 DRTFCC1312-1220 IC : 11570A-4CH58AP000 TRF-RF-204(01)110221 Page 8 / 13 Copyright ○ C 2013, Digital EMC Co., Ltd. 4.2 Transmitter requirements 4.2.1 20dB Bandwidth - Procedure: The 20 dB bandwidth is measured with a spectrum analyzer connected via a receiving antenna placed near the EUT while the EUT is operating. - Measurement Data: Coil3 & Charging Current 1000 mA DEMC1310-03224 & DEMC1310-03236 FCC ID : 2ABC64CH58AP000 DRTFCC131…
