2ABGW-AM2308GMID

Thank you for using *** serial products! This user manual is provided to help you to get start quickly with the tablet PC. Please read it carefully before using it, and keep it for future use. 1 Introduction 1.1 Acknowledgement Thanks for your purchase of our product. This model is high definition tablet PC. Its MTK8312 Cortex-A9 Dual core 1GHz CPU, is based on the Android 4.2.2 operating system, dual sim, double standby support 3G. The product is designed with various features, including 2G, 3G, WiFi, BlueTooth, GPS, FM radio, voice call functions, SMS sending/receiving and so on. With the tablet it is very easy to achieve wireless communication and internet, as you can access/surf the internet anytime and anywhere. It also has a built-in high-accuracy GPS module, that can be used for navigating through installed map and navigation software. There are many sensors that will offer you brand-new operation and entertainment. For the shutterbugs, it has built-in camera sensors for capturing those precious moments. This user manual introduces the functions, techniques and tips in the proper use of the tablet. Please read this manual carefully before using the device. 1.2 Announcements Proper maintenance z Please always keep the device dry to avoid corrosion and electric short. Please keep the device, battery and charger away from water and moisture. Don’t operate the device or charger when you have a wet hand. z To avoid failure of device, battery and charger, please do not violently shake or short-circuit. z To avoid failure of device, battery and charger, please prevent the device, battery, charger from over heating or getting exposed into cold temperatures z Never short circuit, throw, prod, drop, or bend the device. z Never disassemble the device and accessories, otherwise the warranty of the device and accessories will be void. 1.3 Safety Instruction Before operation of the device, please read this chapter. For further details, please refer to the safety instructions and announcement. z Never use the device when driving a car, in order to ensure safe driving. z Whenever near medical areas, please abide by related rules and regulations. Please shut down the device when it is near medical equipments. z To avoid the wireless signal to interrupt plane controls and communication, please shut down the device or switch to airplane mode when you are boarding a flight, z To avoid electronic equipment failure, please shut down the device whenever near the vicinity of high-accuracy electronic equipments. z Please don’t disassemble the device and accessories. Only authorized agents/technicians are allowed to service the device. z Please keep the device away from magnetic equipments, the radiation from the device may erase the data stored in magnetic equipments. z Never use the device whenever near the vicinity of areas exposed to high temperature, or inflammable gas (ex. gas stations). z Protect the device and its accessories from kids reach, and avoid the kids to use the device without parents’ supervision. z Please comply with related rules and regulations, and respect others’ privacy and legal rights while using the device. z Please strictly adhere to related instructions in the manual when using USB cable to ensure safety of use of the device or PC. z Never use the device in bathroom or other humid/wet environment, and please protect the device from liquid damage. 2 device Introduction 2.1 device Operation and Preparation Battery Charging If this is the first time that the device will be used, please use supplied charger/adaptor to fully charge it. 1. Insert the power adaptor on the charging port to charge the device. 2.2 device Status and Reminder Reminder icons When some reminder message appears in your reminder window, please click column and slide the screen to open the reminder list. Choose the menu you need, and confirm the information. Then you can close the reminder window through clicking the column and slide up. Please refer to the status icons below: New message received Airplane Mode on USB connected USB debugging connected Return button Downloading Display recently-used applications Home button Current battery level WIFI connected, internet is available 3 Quick Start Guide 3.1 Keys Function Keys Functions Description： Power button Short press to sleep/wake up, long press to startup and shutdown Volume +（up） Increase the volume Volume -（down） Decrease the volume HOME button Click in any interface to return to main interface / home screen Back button Click in any interface to return to previous menu/page Menu button Display menu interface Display recently-used application Display recently browsed history 3.2 Startup and Shutdown Startup Long press POWER button for three seconds, then the device will enter into startup mode. Shutdown 1．Long press POWER, the shutdown window will pop-up. 2．Shutdown window contains three options: mute mode, airplane mode and shutdown 3．Choose Shutdown 3.3 Open and Close/Sleep the Screen Screen will be sleep on its own when there is no device use/operation for a specific span of time 1. Screen will sleep on its own if no operation happens for some time to save battery power 2. When screen is open, press POWER button, the screen will sleep immediately. Open the screen when it is closed. If the screen is closed/asleep, short press the POWER button to wake-up the screen. The screen will wake up, but locked. It will show the picture as shown below, slide left to enter into camera, slide right towards the unlock icon to unlock the screen. Picture 3.1 3.4 Usage of Touch Screen device operating methods There are methods to view the main screen, menu and application procedure in your device . Click When you want to use the screen for keyboard typing or to choose an application in the main interface, you only need to touch it with your finger. Press on If you want to open some item (text box or the link in the webpage) or shortcut, just press directly on that spec…

Text truncated - open the document above for the full version.

775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 Hong Kong Topsky Technology Limited SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2014/5/9 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We,Hong Kong Topsky Technology Limited hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product： MID Trade Name： ARTAB Model Name： AM2308G Serial Model： AM7001G FCC ID： 2ABGW-AM2308G We affirm that between SIEMIC and ___ Hong Kong Topsky Technology Limited ____ , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Signature Name: Alex Zhao Title: EM Tel: 0755-61156511

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Hong Kong Topsky Technology Limited 2014/5/9 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ABGW-AM2308G We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - BOM - Tune up procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Name: Alex Zhao Title: EM Address: Unit 5, 27/F., Richmond Commercial Building, 109 Argyle Street, Mongkok, Kowloon, Hong Kong

Hong Kong Topsky Technology Limited Model Difference FCC ID: 2ABGW-AM2308G Model : AM2308G, AM7001G All the model are the same circuit and RF module,except the model name and colour.Regards, Client’s signature Name: Alex Zhao Title : EM Address: Unit 5, 27/F., Richmond Commercial Building, 109 Argyle Street, Mongkok, Kowloon, Hong Kong

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID LABELING AND LOCATION FCC ID Label MID Model NO.: AM2308G ARTAB Input Rating: DC 5V/ 1500mA FCC ID: 2ABGW-AM2308G Hong Kong Topsky Technology Limited. Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 BT/WIFI ANT GSM/WCDMA ANT Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8

Page 1 of 21 Report No.: NTEK-2014NT0416547F5 FCC Test Report FCC ID: 2ABGW-AM2308G Product： MID Trade Name： ARTAB Model Number： AM2308G Serial Model： AM7001G Report No.： NTEK-2014NT0416547F5 Prepared for Hong Kong Topsky Technology Limited. Unit 5, 27/F., Richmond Commercial Building,109 Argyle Street, Mongkok, Kowloon,Hong Kong Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website: www.ntek.org.cn Page 2 of 21 Report No.: NTEK-2014NT0416547F5 TEST RESULT CERTIFICATION Applicant’s name ................. : Hong Kong Topsky Technology Limited. Address ................................. : Unit 5, 27/F., Richmond Commercial Building,109 Argyle Street, Mongkok, Kowloon,Hong Kong Manufacturer's Name .......... : Hong Kong Topsky Technology Limited. Address ................................. : Unit 5, 27/F., Richmond Commercial Building,109 Argyle Street, Mongkok, Kowloon,Hong Kong Product description Product name ........................... : MID Model and/or type reference : AM2308G Standards ............................. : FCC Part15B:2012 ANSI C63.4:2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with Part 15 of FCC Rules. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 16 Apr. 2014 ~23 Apr. 2014 Date of Issue ........................................... : 23 Apr. 2014 Test Result ............................................... : Pass Testing Engineer : (Apple Huang) Technical Manager : (Brown Lu) Authorized Signatory : (Bovey Yang) Page 3 of 21 Report No.: NTEK-2014NT0416547F5 Table of Contents Page 1 . TEST SUMMARY 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST SETUP 8 2.3 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 9 2.4 MEASUREMENT INSTRUMENTS LIST 10 3 . EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.1.1 POWER LINE CONDUCTED EMISSION 11 3.1.2 TEST PROCEDURE 12 3.1.3 TEST SETUP 12 3.1.4 EUT OPERATING CONDITIONS 12 3.1.5 TEST RESULTS 13 3.2 RADIATED EMISSION MEASUREMENT 15 3.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 15 3.2.2 TEST PROCEDURE 15 3.2.3 TEST SETUP 16 3.2.4 EUT OPERATING CONDITIONS 16 3.2.5 TEST RESULTS 17 3.2.6 TEST RESULTS(Above 1GHz) 19 4 . EUT TEST PHOTO 20 Page 4 of 21 Report No.: NTEK-2014NT0416547F5 1. TEST SUMMARY Test procedures according to the technical standards: EMC Emission Standard Test Item Limit Judgment Remark FCC Part15B:2012 ANSI C63.4: 2003 Conducted Emission Class B PASS Radiated Emission Class B PASS NOTE: (1) ’N/A’ denotes test is not applicable in this Test Report (2) For client’s request and manual description, the test will not be executed. Page 5 of 21 Report No.: NTEK-2014NT0416547F5 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration Number:238937; IC Registration Number:9270A-1 CNAS Registration Number:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %. A. Conducted Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE NTEKC01 ANSI150 KHz ~ 30MHz 3.2 B. Radiated Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE NTEKA01 ANSI30MHz ~ 1000MHz 4.7 1GHz ~6GHz 5.0 Page 6 of 21 Report No.: NTEK-2014NT0416547F5 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment MID Model Name AM2308G Additional Model Number(s) AM7001G Model Difference All the model are the same circuit and RF module, except the model name and colour. Product Description The EUT is a MID. Operating frequency:2402~2480 MHz Connecting I/O port:USB Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Power Source DC Voltage Adapter Mode: FLD710-5.0V1.5 A Input: 100-240V~,50/60Hz,0.3AMAX Output: 5.0V , 1.5A Battery DC 3.7V, 2800mAh Page 7 of 21 Report No.: NTEK-2014NT0416547F5 2.1.1 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 Downloading For Conducted Test Final Test Mode Description Mode 1 Downloading For Radiated Test Final Test Mode Description Mode 1 Downloading Page 8 of 21 Report No.: NTEK-2014NT0416547F5 2.2 DESCRIPTION OF TEST SETUP AC Plug C-1 E-1 EUT E-2 Adapter E-3 earphone C-2 Page 9 of 21 Report No.: NTEK-2014NT0416547F5 2.3 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Item Equipment Brand Model/Type No. Series No. Note E-1 MID ARTAB N/A N/A EUT E-2 ADAPTER N/A FLD710-5.0V1.5A N/A E-3 earphone N/A 2688 N/A Item Shielded Type Ferrite CoreLength Note C-1 NO NO 0.8m C-2 NO NO 1.2m Note: (1) The…

Text truncated - open the document above for the full version.

Page 20 of 21 Report No.: NTEK-2014NT0416547F5 4. EUT TEST PHOTO Radiated Measurement Photos Page 21 of 21 Report No.: NTEK-2014NT0416547F5 Conducted Measurement Photos
