2ABLPRX3000Blackbird Ka-Band Transceiver

Blackbird Ka-Band Transceiver RX3000 Field Installation Manual Prepared by: Viasat, Inc. 2040 E Technology Circle Tempe, AZ 85284 Phone: (480) 503-5500 Fax: (480) 503-5501 Viasat Proprietary This document contains commercial information or trade secrets of Viasat, Inc., which are confidential and exempt from disclosure to the public under the Freedom of Information Act, 5 U.S.C.552(b)(4), and unlawful disclosure thereof is a violation of the Trade Secrets Act, 18 U.S.C. 1905. Public disclosure of any such information or trade secrets shall not be made without the written permission of Viasat, Inc. © Viasat, Inc. 2022. This technical data is subject to the United States (U.S.) Export Administration Regulations (EAR). Diversion contrary to U.S. law is prohibited. Viasat Document No.: 1422648 Rev. 002 NOTICES Distribution Viasat® Proprietary – Information, specifications, and features contained in this document are subject to change without notice and should not be construed as a commitment by Viasat Inc. This document is proprietary to Viasat Inc. and shall be protected by a receiving party in accordance with the terms of its contracts and agreements with Viasat Inc., covering all Viasat products. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of Viasat Inc. The Blackbird Ka-Band Transceiver user terminal will be used to provide residential and business users high speed access to the Viasat broadband satellite system. The user terminal consists of an Indoor Unit (IDU) and an Outdoor Unit (ODU). Trademark Viasat® and the Viasat logo are registered trademarks of Viasat Inc. in the United States and other countries. All other trademarks, and registered trademarks, are the property of their respective owners. Copyright © Copyright 2022, Viasat Inc. All rights reserved. Ka-Band operation provides access to Viasat’s broadband satellite system under the terms & conditions of Viasat’s spectrum license(s) held with ISED Canada” Publication Information Revision Date Released Comments 001 See Agile Initial Release 002 See Agile Updated FCC Statements per D. Hunter (FCC SME) inputs 003 See Agile Minor updates as per BV Labs request on FCC/ISED Compliance Statements Viasat, Inc. Corporate Headquarters 6155 El Camino Real Carlsbad, CA 92009-1699 Phone: (760) 476-2200 Fax: (760) 929-3941 www.viasat.com 格式化: 字色彩: 紅色 Blackbird Ka-Band Transceiver RX3000 Field Installation Manual 14226481422648, Rev. 002002 Viasat Proprietary Information i Dissemination restricted as described on cover and notices pages. Table of Contents SCOPE/SUMMARY ................................................................................................................................................ 1 OUTDOOR UNIT .................................................................................................................................................... 1 INDOOR UNIT ....................................................................................................................................................... 2 VIASAT NETWORK POWER ADAPTER PLACEMENT .................................................................................................................. 3 VIASAT WIRELESS GATEWAY ............................................................................................................................................. 3 POWER SUPPLIES FOR VIASAT WIFI GATEWAY 3 ................................................................................................................... 4 CONNECTING THE ODU AND THE IDU .................................................................................................................... 5 NOTES REGARDING DC POWER ............................................................................................................................. 5 ACCRONYMS AND ABBREVIATIONS ....................................................................................................................... 6 List of Figures Figure 1: Blackbird Unit ............................................................................................................................................................... 1 Figure 2: Outdoor Unit Components ........................................................................................................................................... 2 Figure 3: Viasat Network Power Adapter .................................................................................................................................... 3 Figure 4: Viasat Wireless Gateway............................................................................................................................................... 4 Figure 5: Power Supply Adapters per Region .............................................................................................................................. 4 Figure 6: Assembled and Installed ODU and IDU ......................................................................................................................... 5 Blackbird Ka-Band Transceiver RX3000 Field Installation Manual 14226481422648, Rev. 002002 Viasat Proprietary Information ii Dissemination restricted as described on cover and notices pages. FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio f…

Text truncated - open the document above for the full version.

6155 El Camino Real Carlsbad, CA 92009, United States A G E N C Y A U T H O R I Z A T I O N L E T T E R Date: 2022/07/11 FCC ID: 2ABLPRX3000 To whom it may concern: We, the undersigned, hereby authorize Amanda Wu / Senior Specialist of Bureau Veritas Consumer Prod ucts Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all manners re lating to FCC application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Amanda Wu of BV CPS Taoyuan on our behalf shall have the same effect as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours,

Reference No.: BEOO-WTW-P22050897_EXT Page 1/3 CONSTRUCTION PHOTOS OF EUT BT Antenna Reference No.: BEOO-WTW-P22050897_EXT Page 2/3 Reference No.: BEOO-WTW-P22050897_EXT Page 3/3

LABEL & Label LOCATION The label will be permanently affixed at a conspicuous location on the device. FCC ID : 2ABLPRX3000 IC : 20546-RX3000 Top of EUT

Reference No.: BEOO-WTW-P22050897_INT Page 1/8 CONSTRUCTION PHOTOS OF EUT Reference No.: BEOO-WTW-P22050897_INT Page 2/8 Reference No.: BEOO-WTW-P22050897_INT Page 3/8 Reference No.: BEOO-WTW-P22050897_INT Page 4/8 Reference No.: BEOO-WTW-P22050897_INT Page 5/8 Reference No.: BEOO-WTW-P22050897_INT Page 6/8 Reference No.: BEOO-WTW-P22050897_INT Page 7/8 Reference No.: BEOO-WTW-P22050897_INT Page 8/8

Report No.: MFBEOO-WTW-P22050897 Page No. 1 / 7 Report Format Version: 6.1.1 RF Exposure Report Report No.: MFBEOO-WTW-P22050897 FCC ID: 2ABLPRX3000 Test Model: RX3000 Received Date: 2022/5/29 Test Date: 2022/6/30 Issued Date: 2022/7/18 Applicant: Viasat, Inc. Address: 6155 El Camino Real Carlsbad, CA 92009, United States Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan Test Location: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan FCC Registration / Designation Number: 723255 / TW2022 This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Report No.: MFBEOO-WTW-P22050897 Page No. 2 / 7 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 2.4 Antenna Gain ...................................................................................................................................... 6 2.5 Calculation Result ............................................................................................................................... 7 Report No.: MFBEOO-WTW-P22050897 Page No. 3 / 7 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued MFBEOO-WTW-P22050897 Original release. 2022/7/18 Report No.: MFBEOO-WTW-P22050897 Page No. 4 / 7 Report Format Version: 6.1.1 1 Certificate of Conformity Product: Blackbird Ka-Band Transceiver Brand: Viasat Test Model: RX3000 Sample Status: Engineering sample Applicant: Viasat, Inc. Test Date: 2022/6/30 FCC Rule Part: FCC Part 2 (Section 2.1091) Standards: KDB 447498 D01 General RF Exposure Guidance v06 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. Prepared by : , Date: 2022/7/18 Vivian Huang / Specialist Approved by : , Date: 2022/7/18 May Chen / Manager Report No.: MFBEOO-WTW-P22050897 Page No. 5 / 7 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 f = Frequency in MHz ; *Plane-wave equivalent power density 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: MFBEOO-WTW-P22050897 Page No. 6 / 7 Report Format Version: 6.1.1 2.4 Antenna Gain Antenna No. Brand Model Antenna Gain (dBi) Frequency Range (GHz) Antenna Type Connector Type BT Ant. Kyocera 1004848 2.95 2.4~2.4835 External Monopole Antenna spring pin Note: The above Antenna information is declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the labo…

Text truncated - open the document above for the full version.

ElectricalSpecifications Typical characteristics measured 84mm x 198mm ground plane above 155mmx 230mmmetal box DATASHEET PartNo.1004848 Product:GNSS/BT AntennaAssembly 7/8/2022Proprietary www.KYOCERA-AVX.com MechanicalSpecifications&OrderingPartNumber KEYBENEFITS ReducedCosts& Time-to-Market Standard antennas eliminate design fees, redesign cycle time and minimize risk associated with customersolution.Quickertimeto market. QuickerTime-to-Market By optimizing antenna size, performance and emissions, customerandregulatory specificationsaremoreeasilymet. Reliability Products are the latest RoHS versioncompliant. APPLICATIONS •Embedded design •POS, Headsets, Tablets •Gateway, Access Point •Telematics •Tracking •Healthcare •M2M, Industrial devices •SmartGrid •OBD-II PartNo.1004848 GNSS/ BTAntennaAssembly 1.561GHz,1.575GHz,1.603GHz,2400-2485MHz Supports:Tracking,SmartHome,Agriculture,Healthcare,IndustrialDevices GNSS/ BTAntenna Assembly 1.561GHz,1.575GHz,1.603 GHz,2400-2485MHz KYOCERAAVXantennasdeliveronthekeyneedsofdevicedesigners forhigherfunctionalityandperformanceinasmallformfactor.These innovativeantennasprovidecompellingadvantagesforGNSS/BT enableddevices,suchashavingadirectconnectiontothePCBwhich avoidstheuseofconnectorsandcables. OrderingPart#1004848 Dimensions(mm)61.13x12.63x17.18 MountingTypeScrewMount ColorBlack Weight(g)6 Standard(s)ComplianceRoHS Frequency (GHz)1.575 1.559 - 1.591 1.593 - 1.610 2.400 - 2.485 BandsGPSGalileoGLONASSBT Peak Gain3.53 dB3.59 dB3.42 dB2.95 dB Average Efficiency53%54%54%43% VSWR Match1.3:11.3:11.3:11.65:1 Feed Point Impedance50 Ω unbalanced Antenna TypeExternal Monopole Antenna © 2022 KYOCERA AVX tel+(1) 858.550.3820 email: [email protected] 1 AvxBlvd, Fountain Inn, SC 29644 DATASHEET|PartNo. 1004848 GNSS/ BTAntennaAssemblySpecifications KYOCERA AVX producesawidevariety ofstandardandcustomantennastomeetuserneeds. Typical ReturnLoss, VSWR, Efficiency, Peak Gain Plots Typical performanceon84mmx 198mmgroundplaneabove155mm x230mmmetalbox VSWR-GPS,Galileo,GLONASS VSWR-BT Efficiency-GPS,Galileo,GLONASS Efficiency-BT PeakGain-GPS,Galileo,GLONASS PeakGain-BT © 2022 KYOCERA AVX tel+(1) 858.550.3820 email: [email protected] 1 AvxBlvd, Fountain Inn, SC 29644 DATASHEET|PartNo. 1004848 GNSS/ BTAntennaAssemblySpecifications KYOCERA AVX producesawidevariety ofstandardandcustomantennastomeetuserneeds. AntennaRadiationPatterns Typicalperformanceon84mmx198mmgroundplaneabove155mmx230mmmetalbox Measured@ 1.561GHz,1.575GHz,1.603GHz,2400-2485MHz © 2022 KYOCERA AVX tel+(1) 858.550.3820 email: [email protected] 1 AvxBlvd, Fountain Inn, SC 29644 DATASHEET|PartNo. 1004848 GNSS/ BTAntennaAssemblySpecifications KYOCERA AVX producesawidevariety ofstandardandcustomantennastomeetuserneeds. AntennaRadiationPatternsCont. Typicalperformanceon84mmx198mmgroundplaneabove155mmx230mmmetalbox Measured@ 1.561GHz,1.575GHz,1.603GHz,2400-2485MHz © 2022 KYOCERA AVX tel+(1) 858.550.3820 email: [email protected] 1 AvxBlvd, Fountain Inn, SC 29644 DATASHEET|PartNo. 1004848 GNSS/ BTAntennaAssemblySpecifications KYOCERA AVX producesawidevariety ofstandardandcustomantennastomeetuserneeds. AntennaLayout Typical Layout Dimensions (mm) Pin#Description 1 BT Pin 2 GNSS Pin PinDescriptions P1 P2 © 2022 KYOCERA AVX tel+(1) 858.550.3820 email: [email protected] 1 AvxBlvd, Fountain Inn, SC 29644 DATASHEET|PartNo. 1004848 GNSS/ BTAntennaAssemblySpecifications KYOCERA AVX producesawidevariety ofstandardandcustomantennastomeetuserneeds. MechanicalDimensions Typicalantenna dimensions,inmm. PartNumberDescriptionABC 1004848GNSS / BT Antenna Assembly 61.1312.6317.18 A B C GNSS PINBT PIN © 2022 KYOCERA AVX tel+(1) 858.550.3820 email: [email protected] 1 AvxBlvd, Fountain Inn, SC 29644 DATASHEET|PartNo. 1004848 GNSS/ BTAntennaAssemblySpecifications KYOCERA AVX producesawidevariety ofstandardandcustomantennastomeetuserneeds. Mounting Recommendations © 2022 KYOCERA AVX tel+(1) 858.550.3820 email: [email protected] 1 AvxBlvd, Fountain Inn, SC 29644 DATASHEET|PartNo. 1004848 GNSS/ BTAntennaAssemblySpecifications KYOCERA AVX producesawidevariety ofstandardandcustomantennastomeetuserneeds. Mounting Recommendations Cont. FOR WATERTIGHT REQUIREMENTS WE RECOMMEND TO USE GROOVE & FLAP SEALANT FEATURES + RTV

Report No.: RFBEOO-WTW-P22050897 Page No. 1 / 41 Report Format Version: 7.1.0 Reference No.: BEOO-WTW-P22050897 TEST REPORT CERTIFICATE OF CONFORMITY Standard: 47 CFR FCC Part 15, Subpart C (Section 15.247) Report No.: RFBEOO-WTW-P22050897 FCC ID: 2ABLPRX3000 Model No.: RX3000 Received Date: 2022/5/29 Test Date: 2022/6/17 ~ 2022/6/29 Issued Date: 2022/7/18 Applicant: Viasat, Inc. Address: 6155 El Camino Real Carlsbad, CA 92009, United States Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan Test Location: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan FCC Registration / Designation Number: 723255 / TW2022 Approved by: , Date: 2022/7/18 May Chen / Manager This test report consists of 41 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. Prepared by : Vivian Huang / Specialist This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our- business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Report No.: RFBEOO-WTW-P22050897 Page No. 2 / 41 Report Format Version: 7.1.0 Reference No.: BEOO-WTW-P22050897 Table of Contents Release Control Record ....................................................................................................................................................... 4 1 Certificate .................................................................................................................................................................... 5 2 Summary of Test Results .......................................................................................................................................... 6 2.1 Measurement Uncertainty ........................................................................................................................................ 6 2.2 Supplementary Information ...................................................................................................................................... 6 3 General Information ................................................................................................................................................... 7 3.1 General Description .................................................................................................................................................. 7 3.2 Antenna Description of EUT ..................................................................................................................................... 8 3.3 Channel List .............................................................................................................................................................. 9 3.4 Test Mode Applicability and Tested Channel Detail ................................................................................................ 10 3.5 Duty Cycle of Test Signal ........................................................................................................................................ 11 3.6 Test Program Used and Operation Descriptions .................................................................................................... 12 3.7 Connection Diagram of EUT and Peripheral Devices ............................................................................................ 12 3.8 Configuration of Peripheral Devices and Cable Connections ................................................................................ 13 4 Test Instruments ...................................................................................................................................................... 14 4.1 RF Output Power .................................................................................................................................................... 14 4.2 Power Spectral Density .......................................................................................................................................... 14 4.3 6 dB Bandwidth ...................................................................................................................................................... 14 4.4 Con…

Text truncated - open the document above for the full version.

Reference No.: BEOO-WTW-P22050897_TSup Page 1/5 PHOTOGRAPHS OF THE TEST CONFIGURATION AC Power Conducted Emissions Reference No.: BEOO-WTW-P22050897_TSup Page 2/5 Unwanted Emissions below 1 GHz Reference No.: BEOO-WTW-P22050897_TSup Page 3/5 Reference No.: BEOO-WTW-P22050897_TSup Page 4/5 Unwanted Emissions above 1 GHz Reference No.: BEOO-WTW-P22050897_TSup Page 5/5
