2ABO6-1210Tablet PC

Table of Contents Welcome! Prior to Using Your Device The Device Interface Device Content Acquiring Content Customizing Your Device Settings Finding Additional Assistance Product Information -1- Welcome! Your Device is designed to let you to read, watch videos, listen to music, play games, run apps, browse the Internet, and stay connected–all on one device. This short, informative guide will familiarize you with many Device features, and can generally be read in less than 15 minutes. Additional help is available on the Device Support website at [INCLUDE URL]. -2- Prior to using your Device Before you use your Device, do the following:  Charge the battery  Unlock your Device The following sections walk you through the above actions in addition to providing information about the Devic e interface. Charging the ba ttery To charge your Device, connect it to a power outlet using the included power adapter. The indicator light on the bottom edge of the device will turn amber while charging and green when the battery is fully charged. When your Device is on, a lightning bolt will appear on the battery indi cator at the top of the screen. If the indicator light does not turn green, make sure that the power cable is full y inserted into your Device and that the power adapter is securely inserted into the power outlet. If your Device is still not charging, try another electrical outlet. Fully charging your Device should take 4 hours. When fully charged, the battery indicator will appear filled. Unlocking your Device To unlock your Device, press the power button to wake it up and display the unlock screen, then press the orange ribbon and swipe your finger to the left across the screen. Setting up & registering your Device If you’re reading this guide, you’ve probably completed the Device setup process. This includes connecting to a Wi-Fi network and registering your Device to a Company account. If your W i-Fi is not connected, [DESCRIBE] To verify that your Device is registered and ready to use, [DESCRIBE]. To register, [DESCRIBE] -3- Basics Speakers: The top edge of your Device contains stereo speakers for audio content. Headphone jack: Plug in headphones or your own external speakers. Plugging in headphones or external speakers will turn off the built-in speakers. Micro-USB/power port: To charge your Device from a power outlet, connect it to a power outlet using the included power adapter. You can use a USB cable (not included) to connect your Device to a computer for transferring files. Power button: To turn on your Device, press the power button. To put your Device in sleep mode, press and release the power button. If you need to turn off the Device completely, such as when traveling on an airplane, press and hold the power button for seven seconds until the screen goes blank. If your Device does not power on or is unresponsive during use, you can do a hard restart by pr essing and holding the power button for 20 seconds. The power button has a charge indicator light that is amber when your Device is charging and will turn off when the battery is fully charged. Touchscreen actions Your Device features a touchscreen interface that allows you to perform many tasks with a few gestures. To select an item, simply tap it. To turn a page or advance through your content libraries, simply swipe your finger left or right. Swipe your finger up or down to navigate your content. -4- Chapter 1 The Device Interface Status Bar The Device Status Bar is located at the top of the screen and displays the Home icon, Quick Settings icon, Wi-Fi indicator, battery indicator, and the time. Home Button: Tap the Home button from anywhere on your Device to return to the Home screen. Notifications: Messages generated by games and applications. You can select a sound to alert you of incoming notifications in Settings. Quick Settings: Select to display settings for the most commonly performed tasks including, locking and unlocking your Device’s screen rotation, adjusting volume, setting display brightness, accessing Wi-Fi settings, and syncing. Tap the More to bring up more Device Settings. Wi-Fi Indicator: The number of bands represents the strength of the Wi-Fi signal at your current location. Battery Indicator: The degree to which the battery is filled represents the remaining charge in the battery. Searching The search field is located at the top the Home screen and content pages. Tap the search field to bring up the onscree n keyboard. After you enter your search criteria, tap the Search key on the keyboard. You can enter a letter in the search field, and search for content beginning with that letter. Tabs Tabs on the Home screen represent the major content types: Books, Newsstand, Docs, Music, Video, and Web. Select a tab to view all of the stored content in that category either on the device or in the cloud. For example, selecting Newsstand displays all magazines and newspapers including individual issues and subscriptions. -5- Content is displayed on “shelves” in either a grid or list view for books, newsstand, docs, and web. To scroll, drag your finger anywhere in the content item. To quick scroll, flick your finger. To sort content, tap and release the sort control menu. Sorting options differ depending upon content type. For example, you can sort your books by most recent (default), author, or title. Home Screen The Home screen contains all of the content on your device in a home screen view. To advance the home screeen, swipe your finger across the screen. Each item will appear once in the home screeen. An item’s position is determined by when it was most recently accessed. Newly purchased items are marked with a “New” badge. Favorites You can designate any item on your Device as a Favorite. Favorites are located below the home screen, and can be added in two ways:  Tap and hold to drag an item from the home screen to the Favorites section.  Tap and hold an item to display the context menu and select “Add to…

Text truncated - open the document above for the full version.

720510

Model GPZ45RW FCC ID: 2ABO6-1210 Location of this label – on the bottom back of the device

720510 720510 720510 720510 720510

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2014/5/5 System Check_Body_2450MHz_140505 DUT: D2450V2-924 Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: MSL_2450_140505 Medium parameters used: f = 2450 MHz; σ = 1.957 S/m; ε r = 53.837; ρ = 1000 kg/m 3 23.5 22.5 DASY5 Configuration: - Probe: ES3DV3 - SN3270; ConvF(4.28, 4.28, 4.28); Calibrated: 2013/9/24; - Sensor-Surface: 3mm (Mechanical Surface Detection) - Electronics: DAE4 Sn778; Calibrated: 2013/8/21 - Phantom: ELI 4.0_Front; Type: QDOVA001BB; Serial: 1026 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Configuration/Pin=250mW/Area Scan (61x61x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 16.5 W/kg Configuration/Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 89.000 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 24.0 W/kg SAR(1 g) = 11.6 W/kg; SAR(10 g) = 5.45 W/kg Maximum value of SAR (measured) = 15.0 W/kg 0 dB = 15.0 W/kg = 11.76 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2014/7/24 System Check_Body_2450MHz_140724 DUT: D2450V2-924 Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: MSL_2450_140724 Medium parameters used: f = 2450 MHz; σ = 2.005 S/m; ε r = 53.959; ρ = 1000 kg/m 3 23.6 22.6 DASY5 Configuration: - Probe: EX3DV4 - SN3954; ConvF(7.34, 7.34, 7.34); Calibrated: 2013/11/4; - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1425; Calibrated: 2014/3/3 - Phantom: ELI 4.0_Front; Type: QDOVA001BB; Serial: 1029 - Measurement SW: DASY52, Version 52.8 (7);SEMCAD X Version 14.6.10 (7164) Configuration/Pin=250mW/Area Scan (61x61x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 21.8 W/kg Configuration/Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 105.0 V/m; Power Drift = -0.15 dB Peak SAR (extrapolated) = 24.8 W/kg SAR(1 g) = 12.7 W/kg; SAR(10 g) = 6.04 W/kg Maximum value of SAR (measured) = 18.9 W/kg 0 dB = 18.9 W/kg = 12.76 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2014/7/30 System Check_Body_2450MHz_140730 DUT: D2450V2-924 Communication System: CW ; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: MSL_2450_140730 Medium parameters used: f = 2450 MHz; σ = 1.93 S/m; ε r = 53.269; ρ = 1000 kg/m 3 23.3 22.3 DASY5 Configuration - Probe: EX3DV4 - SN3931; ConvF(7.24, 7.24, 7.24); Calibrated: 2013/9/10; - Sensor-Surface: 2mm (Mechanical Surface Detection) - Electronics: DAE3 Sn577; Calibrated: 2014/5/15 - Phantom: ELI v4.0; Type: QDOVA001BB; Serial: 1173 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Configuration/Pin=250mW/Area Scan (61x61x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 19.4 W/kg Configuration/Pin=250mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 98.334 V/m; Power Drift = 0.05 dB Peak SAR (extrapolated) = 26.0 W/kg SAR(1 g) = 12.6 W/kg; SAR(10 g) = 5.88 W/kg Maximum value of SAR (measured) = 19.2 W/kg 0 dB = 19.2 W/kg = 12.83 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2014/5/6 System Check_Body_5200MHz_140506 DUT: D5GHzV2-1128 Communication System: CW; Frequency: 5200 MHz;Duty Cycle: 1:1 Medium: MSL_5G_140506 Medium parameters used: f = 5200 MHz; σ = 5.084 S/m; ε r = 48.917; ρ = 1000 kg/m 3 23.3 22.3 DASY5 Configuration: - Probe: EX3DV4 - SN3935; ConvF(4.61, 4.61, 4.61); Calibrated: 2013/11/4; - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1338; Calibrated: 2013/11/5 - Phantom: ELI 4.0_Front; Type: QDOVA001BB; Serial: 1026 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Configuration/Pin=100mW/Area Scan (71x71x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 18.6 W/kg Configuration/Pin=100mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 65.380 V/m; Power Drift = 0.01 dB Peak SAR (extrapolated) = 29.3 W/kg SAR(1 g) = 7.36 W/kg; SAR(10 g) = 2.07 W/kg Maximum value of SAR (measured) = 18.4 W/kg 0 dB = 18.4 W/kg = 12.65 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2014/5/7 System Check_Body_5200MHz_140507 DUT: D5GHzV2-1128 Communication System: CW; Frequency: 5200 MHz;Duty Cycle: 1:1 Medium: MSL_5G_140507 Medium parameters used: f = 5200 MHz; σ = 5.279 S/m; ε r = 48.534; ρ = 1000 kg/m 3 23.3 22.3 DASY5 Configuration: - Probe: EX3DV4 - SN3954; ConvF(4.52, 4.52, 4.52); Calibrated: 2013/11/4; - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1279; Calibrated: 2014/1/30 - Phantom: ELI 4.0_Front; Type: QDOVA001BB; Serial: 1026 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Configuration/Pin=100mW/Area Scan (71x71x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 18.0 W/kg Configuration/Pin=100mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 66.452 V/m; Power Drift = -0.15 dB Peak SAR (extrapolated) = 31.0 W/kg SAR(1 g) = 7.37 W/kg; SAR(10 g) = 2.01 W/kg Maximum value of SAR (measured) = 18.4 W/kg 0 dB = 18.4 W/kg = 12.65 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2014/4/17 System Check_Body_5300MHz_140417 DUT: D5GHzV2-1128 Communication System: CW ; Frequency: 5300 MHz;Duty Cycle: 1:1 Medium: MSL_5G_140417 Medium parameters used: f = 5300 MHz; σ = 5.457 S/m; ε r = 47.597; ρ = 1000 kg/m 3 23.3 22.3 DASY5 Configuration: - Probe: EX3DV4 - SN3935; ConvF(4.18, 4.18, 4.18); Calibrated: 2013/11/4; - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1338; Calibrated: 2013/11/5 - Phantom: ELI 4.0_Front; Type: QDOVA001BB; Serial: 1026 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Versio…

Text truncated - open the document above for the full version.

Report Number : FA432436-07 Report Version : Rev. 01 Page Number : 1 of 38 FCC SAR Test Report APPLICANT : Nyle Oswind Parry Limited Liability Company EQUIPMENT : Tablet PC MODEL NAME : GPZ45RW FCC ID : 2ABO6-1210 STANDARD : FCC 47 CFR Part 2 (2.1093) ANSI/IEEE C95.1-1992 IEEE 1528-2003 We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and had been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Approved by: Jones Tsai / Manager Reviewed by: Eric Huang / Deputy Manager Report Number : FA432436-07 Report Version : Rev. 01 Page Number : 2 of 38 Table of Contents 1. Statement of Compliance ............................................................................................................................................. 4 2. Administration Data ...................................................................................................................................................... 4 3. Guidance Standard ....................................................................................................................................................... 5 4. Equipment Under Test (EUT) ....................................................................................................................................... 5 4.1 General Information ............................................................................................................................................... 5 4.2 Maximum Tune-up Limit ......................................................................................................................................... 5 5. RF Exposure Limits....................................................................................................................................................... 6 5.1 Uncontrolled Environment ...................................................................................................................................... 6 5.2 Controlled Environment .......................................................................................................................................... 6 6. Specific Absorption Rate (SAR) ................................................................................................................................... 7 6.1 Introduction ............................................................................................................................................................ 7 6.2 SAR Definition ........................................................................................................................................................ 7 7. System Description and Setup .................................................................................................................................... 8 8. Measurement Procedures ............................................................................................................................................ 9 8.1 Spatial Peak SAR Evaluation ................................................................................................................................. 9 8.2 Power Reference Measurement............................................................................................................................10 8.3 Area Scan .............................................................................................................................................................10 8.4 Zoom Scan ............................................................................................................................................................ 11 8.5 Volume Scan Procedures ...................................................................................................................................... 11 8.6 Power Drift Monitoring ........................................................................................................................................... 11 9. Test Equipment List .....................................................................................................................................................12 10. System Verification ....................................................................................................................................................13 10.1 Tissue Verification ...............................................................................................................................................13 10.2 System Performance Check Results ...................................................................................................................14 11. RF Exposure Positions ..............................................................................................................................................14 11.1 SAR Testing for Tablet .........................................................................................................................................14 12. Conducted RF Output Power (Unit: dBm) ................................................................................................................15 13. Exposure Position Conditions ..................................................................................................................................27 14. SAR Test Results .......................................................................................................................................................29 14.1 Body SAR ...........................................................................................................…

Text truncated - open the document above for the full version.

Report No. : FR432436-09A Report Version : Rev. 01 Page Number : 1 of 67 Report Template No.: BU5-FR15CBT Version 1.0 FCC RF Test Report APPLICANT : Nyle Oswind Parry Limited Liability Company EQUIPMENT : Tablet PC MODEL NAME : GQY56XZ FCC ID : 2ABO6-0725 STANDARD : FCC Part 15 Subpart C §15.247 CLASSIFICATION : (DSS) Spread Spectrum Transmitter The testing completed on Aug. 15, 2014. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Joseph Lin / Supervisor Approved by: Jones Tsai / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Report No. : FR432436-09A Report Version : Rev. 01 Page Number : 2 of 67 Report Template No.: BU5-FR15CBT Version 1.0 TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ............................................................................................................................................ 5 1.2 Product Feature of Equipment Under Test ........................................................................................ 5 1.3 Product Specification subjective to this standard .............................................................................. 5 1.4 Modification of EUT ........................................................................................................................... 5 1.5 Testing Location ................................................................................................................................ 6 1.6 Applicable Standards ......................................................................................................................... 6 2 TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 7 2.1 Descriptions of Test Mode ................................................................................................................. 7 2.2 Test Mode .......................................................................................................................................... 8 2.3 Connection Diagram of Test System ................................................................................................. 9 2.4 Support Unit used in test configuration and system ........................................................................ 10 2.5 EUT Operation Test Setup .............................................................................................................. 11 2.6 Measurement Results Explanation Example ................................................................................... 11 3 TEST RESULT .......................................................................................................................................... 12 3.1 Number of Channel Measurement .................................................................................................. 12 3.2 Hopping Channel Separation Measurement ................................................................................... 14 3.3 Dwell Time Measurement ................................................................................................................ 21 3.4 20dB Bandwidth Measurement ....................................................................................................... 23 3.5 Peak Output Power Measurement .................................................................................................. 30 3.6 Conducted Band Edges Measurement............................................................................................ 32 3.7 Conducted Spurious Emission Measurement ................................................................................. 39 3.8 Radiated Band Edges and Spurious Emission Measurement ........................................................ 49 3.9 AC Conducted Emission Measurement........................................................................................... 60 3.10 Antenna Requirements .................................................................................................................... 65 4 LIST OF MEASURING EQUIPMENT ........................................................................................................ 66 5 UNCERTAINTY OF EVALUATION ........................................................................................................... 67 Report No. : FR432436-09A Report Version : Rev. 01 Page Number : 3 of 67 Report Template No.: BU5-FR15CBT Version 1.0 REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FR432436-09A Rev. 01 Initial issue of report Aug. 15, 2014 Report No. : FR432436-09A Report Version : Rev. 01 Page Number : 4 of 67 Report Template No.: BU5-FR15CBT Version 1.0 SUMMARY OF TEST RESULT Report Section FCC Rule Description Limit Result Remark 3.1 15.247(a)(1) Number of Channels ≥ 15Chs Pass - 3.2 15.247(a)(1) Hopping Channel Separation ≥ 2/3 of 20dB BW Pass - 3.3 15.247(a)(1) Dwell Time of Each Channel ≤ 0.4sec in 31.6sec period Pass - 3.4 15.247(a)(1) 20dB Bandwidth NA Pass - 3.5 15.247(b)(1) Peak Output Power ≤ 125 mW Pass - 3.6 15.247(d) Conducted Band Edges ≤ 20dBc Pass - 3.7 15.247(d) Conducted Spurious Emission ≤ …

Text truncated - open the document above for the full version.

<Conducted Emission> Mode 2 <Radiated Emission> X Plane LF HF

Bottom -Slant of Edge 1 Bottom -Slant of Edge 4 The additional separation introduced by such protrusions between the outer housing on a flat phantom is < 5 mm Rear camera region Rear camera region Bottom Face, Test Separation 0 cm Bottom - Slant of Edge1, Test Separation 0 cm Bottom - Slant of Edge 4, Test Separation 0 cm Edge 1, Test Separation 0 cm Edge 4, Test Separation 0 cm
