Date: 2015-01-06 Report No.: 60.870.14.021.02S Model No.:Zcan Wireless Page 1 of 1 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. SAR Evaluation Exemption Compliance Information The device has a standalone transmission. According to KDB 447498 section 4.3.1, the 1-g SAR test exclusion thresholds at test separation distances ” 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[ ¥f(GHz)] ” 3.0 The maximum tune-up limit power is 0.321mW @ 2.479GHz For the head and body SAR, use 50mm as the conservative minimum test separation distance, [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[ ¥f(GHz)] = 0.004 ” 3.0 So standalone SAR measurements are not required for both head and body

TEST REPORT Date: 2014-12-24 Report No.: 60.870.14.021.01F Page 1 of 19 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. Applicant: Systech Electronics Ltd. 26/F Lever Tech Centre, 69-71 King Yip Street, Kwun Tong, Kowloon, Hong Kong. Description of Samples:Model name: Wireless Scanner Mouse (USB Dongle) Brand name: Model no.: Zcan Wireless FCCID:2ABQ3-SSM003R Date Samples Received:2014-11-24 Date Tested:2014-11-24 to 2014-12-24 Investigation Requested:FCC Part 15 Subpart C, Section 15.249 Conclusions:The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remarks:---- Checked by:Approved by:- Ray CheungJeff Pong Project EngineerOperation Manager Wireless & Telecom departmentWireless & Telecom department ReportNo.: 60.870.14.021.01F Page 2 of 19 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. CONTENT: Cover Page 1 of 19 Content Page 2 of 19 1.0General Details 1.1Test Laboratory Page 3 of 19 1.2Applicant Details Page 3 of 19 1.3Equipment Under Test [EUT] Page 4 of 19 1.4 Equipment Modification Page 4 of 19 1.5 Related Submittal(s) Grants Page 4 of 19 2.0Technical Details 2.1Investigations Requested Page 5 of 19 2.2Test Standards and Results Summary Page 5 of 19 3.0Test Methodology 3.1Radiated Emission Page 6 of 19 3.2Field Strength Calculation Page 6 of 19 3.3Conducted Emission Page 6 of 19 4.0Test Results 4.1Field Strength ofFundamentaland Harmonics Page 7-9 of 19 4.2Spurious Radiated Emission Page 10-12 of 19 4.3Out of Band Emissions Page 13-14 of 19 4.4Bandwidth Measurement Page 15-17 of 19 4.5Conducted Emission Page 18 of 19 5.0List of Measurement Equipments Page 19 of 19 Appendix A Photos of Test Setup Appendix B External EUT Photos Appendix C Internal EUT Photos ReportNo.: 60.870.14.021.01F Page 3 of 19 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. 1.0General Details 1.1Test Laboratory STC (Dongguan) Company Ltd. 68 Fumin Nan Rd, Dalang, Dongguan, Guangdong, PRC. Tested by: John Zhi 1.2Applicant Details Applicant Systech Electronics Ltd. 26/F Lever Tech Centre, 69 – 71 King Yip Street, Kwun Tong, Kowloon, Hong Kong. Manufacturer K-Mark Industrial Ltd. Flat A, 7/F., Mai On Ind. Bldg., 17 – 21, Kung Yip Sy., Kwai Chung, Hong Kong. ReportNo.: 60.870.14.021.01F Page 4 of 19 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. 1.3Equipment Under Test [EUT] Description of EUT Model Name:Wireless Scanner Mouse (USB Dongle) Brand Name: Model No:Zcan Wireless FCC ID: 2ABQ3-SSM003R Rating: DC 5.0V by USB Port Antenna Type:PCB Antenna Antenna Gain:0 dBi Operated Frequency:2402 MHz to 2479 MHz Modulation:DSSS No. of Channel:78 Channel Separation:1 MHz Channel List:2402; 2403; 2404; 2405; 2406; 2407; 2408; 2409; 2410; 2411; 2412; 2413; 2414; 2415; 2416; 2417; 2418; 2419; 2420; 2421; 2422; 2423; 2424; 2425; 2426; 2427; 2428; 2429; 2430; 2431; 2432; 2433; 2434; 2435; 2436; 2437; 2438; 2439; 2440; 2441; 2442; 2443; 2444; 2445; 2446; 2447; 2448; 2449; 2450; 2451; 2452; 2453; 2454; 2455; 2456; 2457; 2458; 2459; 2460; 2461; 2462; 2463; 2464; 2465; 2466; 2467; 2468; 2469; 2470; 2471; 2472; 2473; 2474; 2475; 2476; 2477; 2478; 2479 Accessories and Auxiliary Equipment:ThinkPad Notebook EUT Exercising Software:None General Operation of EUT The Equipment Under Test (EUT) is a USB Dongle of the Wireless Mouse System which operated at 2.4GHz. 1.4Equipment Modification No modification was made to the tested unit by TÜV SÜD Hong Kong Ltd. 1.5Related Submittal(s) Grants This is a single application of certification for this transmitter. ReportNo.: 60.870.14.021.01F Page 5 of 19 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. 2.0Technical Details 2.1Investigations Requested Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2012 and ANSI C63.4: 2009. 2.2Test Standards and Results Summary Tables EMISSION Results Summary Test ConditionFCC TestTest Result RequirementPassFailedN/A Field Strength of Fundamental and Harmonics Part 15.249 (a),(e) Spurious Radiated Emission Part 15.249 (d) Part 15.209 Part 15.205 Out of Band EmissionsPart 15.249 (d) Bandwidth Measurement Part 15.215 (c) Conducted EmissionPart 15.207 Note: N/A - Not Applicable ReportNo.: 60.870.14.021.01F Page 6 of 19 TÜV SÜD Hong Kong Ltd. 3/F, West Wing, Phase 2, 10 Science Park West Avenue, Shatin, Hong Kong. 3.0Test Methodology 3.1Radiated Emission The sample was placed 0.8m above the ground plane on a standard emission test site *. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating interconnecting cables, rotating turntable, varying antenna height from 1m to 4m in both horizontal and vertical polarizations. The emissions worst-case are shown in Test Results of the following pages. 3.2Field Strength Calculation The field strength at 3 m was established by adding the meter reading of the spectrum analyzer to the factors associated with antenna correction factor, cable loss, preamplifiers and filter attenuation. The equation is expressed as follow: FS = R + System Factor System Factor = AF + CF + FA – PA Where FS = Net Field Strength in dBuV/m at 3 meters. R = Reading of Spectrum Analyzer / Test Receiver in dBuV. AF = Antenna Factor in dB. CF = Cable Attenuation Factor in dB. FA = Filter Attenuation Factor in dB. PA = Preamplifier Factor in dB. FA and PA are only be used for the measuring frequency above 1 GHz. 3.3Conducted Em…
