2ABS7-ARMIMI915Transceiver unit

MITO Industrial radio remote control AT MITO-VETTA-915 Transmitting Unit AR MITO-MINI-915 Receiving Unit ELCA S.r.l. Via del Commercio, 7/b - 36065 Mussolente (VI) ITALY www.elcaradio.com tel. +39 0424 578500 fax +39 0424 578520 MULTI man MITO-VETTA 915 00 0408MA000557 User manual ENGLISH User manual ENG man MITO-VETTA 915 00 Radio Remote Control System MITO-VETTA-915 - Page I - ENGLISH INDEX a. FEDERAL COMMUNICATIONS COMMISSION (FCC) CONFORMITY AND FREQUENCIES .II a.1 CONFORMITY ...................................................................................................................................................II a.2 FCC CONFORMITY STATEMENT ...............................................................................................................II a.3 FREQUENCIES .................................................................................................................................................II a.4 MARKET ..............................................................................................................................................................II 1. USER MANUAL ..................................................................................................................................................1 2. USE INSTRUCTIONS ........................................................................................................................................2 2.1 GENERAL INFORMATION .............................................................................................................................2 2.2 APPLICATIONS AND USE CONDITIONS NOT PERMITTED ............................................................2 2.3 INSTRUCTIONS FOR PROPER AND SAFE USE ..................................................................................3 2.4 TRANSMITTING UNIT AT MITO-VETTA-915 ...........................................................................................4 2.5 RECEIVING UNIT AR MITO-MINI-915 .......................................................................................................5 2.6 STORING ACCESS CODES .........................................................................................................................6 2.7 INFORMATION FOR MAINTENANCE .......................................................................................................8 2.8 INFORMATION FOR THE PROPER INSTALLATION OF THE RADIO REMOTE CONTROL SYSTEM ........................................................................................................................................................................8 2.9 WARRANTY ........................................................................................................................................................9 2.10 DISPOSAL INFORMATION ............................................................................................................................9 3. PROGRAMMABLE FUNCTIONS ................................................................................................................10 3.1 ACCESS TO PROGRAMMING MODE .....................................................................................................10 3.2 FREQUENCY RANGE PROGRAMMING ................................................................................................10 3.3 AUTO-SHUTDOWN TIME PROGRAMMING ..........................................................................................11 3.4 PIN CODE PROGRAMMING ........................................................................................................................11 3.5 LATCHED CONTROL PROGRAMMING ..................................................................................................12 4. BATTERY CHARGER......................................................................................................................................13 4.1 OPERATING INSTRUCTION.......................................................................................................................13 5. TROUBLESHOOTING ....................................................................................................................................14 5.1 TYPE OF TROUbLE ......................................................................................................................................14 5.2 FUNCTIONAL TESTING OF TRANSMITTING UNIT ...........................................................................15 5.3 FUNCTIONAL TESTING OF RECEIVING UNIT ....................................................................................16 5.4 FUNCTIONAL TESTING OF CHARGING CYCLE ................................................................................17 6. TECHNICAL FEATURES ...............................................................................................................................18 6.1 GENERAL ............................................................................................................................................................18 6.2 FEATURES OF TRANSMITTING UNIT ......................................................................................................18 6.3 FEATURES OF RECEIVING UNIT ..............................................................................................................18 6.4 CHARGING SYSTEM FEATURES ..............................................................................................................19 ANNEX A .............................................................................................................................................................21 ENG man MITO-VETTA 915 00 Radio Remote Control System MITO-VETTA-915 - Page II - Each MITO-VETTA-915 series’ radio remote control working in the frequency band 920.000 - 921.150 MHz complies with Part 15 of standards FCC. Transmitting Unit AT MITO-VETTA-915 FCC ID: 2AbS7-ATMIVE915 Receiving Unit AR MITO-MINI-915 FCC ID: 2AbS7-ARM…

Text truncated - open the document above for the full version.

ENG man MITO-VETTA 915 00 Radio Remote Control System MITO-VETTA-915 - Page 9 - ENGLISH The ELCA Radio Remote Control System MITO is covered by a 24-month warranty starting from date of purchase as evidenced by the way bill, that must also state the serial number of the Radio Remote Control System. Warranty covers defects of manufacture of the radio remote control system and its components, when such defects have been determined to exist at ELCA’s sole discretion. User shall arrange the delivery to / collection from ELCA authorised service centres and defective parts shall be replaced at no additional charge. In the event of on-site servicing/repair, travel and personnel expenses shall be charged to the user, whereas the replacement of any defective parts shall be free of charge. Servicing/repair by unauthorised persons, improper use or improper installation shall make the warranty null and void. Warranty does not cover transport damage or loss. ELCA shall not be held liable for damage to property or persons. ELCA shall not be liable for machine down time, and it is the user’s responsibility to provide manual or wire control for each machine. Any disputes shall be submitted to the Court of Vicenza, Italy. 2.9 WARRANTY The radio remote control must be delivered to separate collection at end of life. DISPOSAL OF bATTERIES, Directive 2006/66/EC and subsequent amendments. batteries may release toxic substances harmful to humans, animals and plants and contaminate the environment. They should be not disposed of with municipal solid waste but delivered to authorised collection centres for battery recycling and treatment. Users’ contribution to collect and recycle batteries is critical to minimising the potential impact of the contaminants used in these components on the environment and human health. The European Union has set up different battery collection and recycling systems. For information on the method adopted in your area, contact your local authorities. The crossed-out wheeled bin symbol on the batteries means that batteries must be disposed of separately from household waste in compliance with Directive 2006/66/EC and subsequent amendments and with local regulations. 2.10 DISPOSAL INFORMATION - do not install the receiving unit inside metal casings that could affect its operation; - ensure that there are no obstacles that could affect transmission between transmitting and receiving units: where any obstacles cannot be eliminated, use the optional external antenna (special kit available) to ensure proper radio communication; - use cables with suitable cross-section area for wiring connections; - be sure to connect power supply to the proper terminal; - check for proper operation after installation. ENG man MITO-VETTA 915 00 Radio Remote Control System MITO-VETTA-915 - Page 10 - 3. PROGRAMMABLE FUNCTIONS 3.1 ACCESS TO PROGRAMMING MODE Outlined below are certain programmable functions that can be set by the user ONLY in certain versions. Only the frequency range programming is always available. WARNING! be careful when programming functions other than the original ones in customised radio remote controls or units that are already installed on a machine, as the new functions might lead to abnormal operation of the machine. We advise against programming or making programming tests on radio remote controls that are already installed on a machine. CHANGE FREQUENCY GROUP (submenu1) T4 and/or T9 and/or T10 and/or T11 FROM MAIN MENU ACTIVATE T2 SUBMENU ACCESSED. HERE YOU CAN SET A FREQUENCY GROUP AS SPECIFIED BELOW. IF NO SELECTION IS MADE WITHIN 10 SECONDS, SYSTEM RETURNS TO MAIN MENU. GROUP 1 869.7125 MHz 869.8125 MHz 869.9375 MHz FROM SUB-MENU1 ACTIVATE T4 e T10 IN SEQUENCE SET FREQUENCY RANGE: 869.7125 - 869.8125 - 869.9375 MHz. AUTOMATIC RETURN TO MAIN MENU; WAIT 10 SECONDS AND SYSTEM EXITS MAIN MENU. GROUP 2 869.7625 MHz 869.8625 MHz 869.9875 MHz FROM SUBMENU1 ACTIVATE T4 e T11 IN SEQUENCE SET FREQUENCY RANGE: 869.7625 - 869.8625 - 869.9875 MHz. AUTOMATIC RETURN TO MAIN MENU; WAIT 10 SECONDS AND SYSTEM EXITS MAIN MENU. GROUP 3 (default) 869.7375 MHz 869.8375 MHz 869.9625 MHz FROM SUBMENU1 ACTIVATE T9 e T11 IN SEQUENCE SET FREQUENCY RANGE: 869.7375 - 869.8375 - 869.9625 MHz. AUTOMATIC RETURN TO MAIN MENU; WAIT 10 SECONDS AND SYSTEM EXITS MAIN MENU. T2 T4 T10 T4 T11 T9 T11 (depending on group) CHANNELS TO BE USED WHAT TO DO CHECK LIGHT BLINKS 3 TIMES AT 1Hz BLINKS 2 QUICK BLINKS WITHIN 1 SEC. BLINKS 3 TIMES AT 1Hz BLINKS 3 TIMES AT 1Hz AUTOMATIC INCREMENT OF FREQUENCY GROUP (1,2...) FROM SUBMENU1 ACTIVATE T1 (STOP BUTTON) SET NEXT FREQUENCY GROUP. TRANSMITTING UNIT SWITCH OFF. BLINKS AT 1Hz AND THEN SWITCH OFF T1 3.2 FREQUENCY RANGE PROGRAMMING ACCESS TO PROGRAMMING MODE (main menu) CHANNELS TO BE USED WHAT TO DO CHECK LIGHT WITH AT OFF, ACTIVATE T12 AND THEN T11 WITHIN 1SEC ACCESS TO MAIN MENU CONFIRMED, CHECK LIGHT ON STEADY. TX SENDS NO COMMANDS. DEPENDING ON RADIO REMOTE CONTROL CONFIGURATION, IT IS POSSIBLE TO ACCESS TO 4 DIFFERENT PROGRAMMING SUBMENUS: WITH T12 AND T11 ACTIVE, 1Hz BLINKING FOR 5 secs THEN STEADY ON - FREQUENCY RANGE (always available) - AUTO-SHUTDOWN TIME - PIN CODE - CHANNEL LATCHING NOTE: system exits main menu and transmitter (AT) shuts down after 10sec of inactivity. T11 T12 IF NO SELECTION IS MADE WITHIN 10 SECONDS, SYSTEM RETURNS TO MAIN MENU. STOP ON / OFF CHECK CHARGE TA02 T9 T4 T10 T3 T7 T5 T11 T2 T12 T8 T1 LAYOUT COMMAND ENG man MITO-VETTA 915 00 Radio Remote Control System MITO-VETTA-915 - Page 11 - ENGLISH 3.3 AUTO-SHUTDOWN TIME PROGRAMMING AUTO-SHUTDOWN TIME (submenu2) and T2 or T3 or T4 or T9 or T10 or T11 FROM MAIN MENU ACTIVATE T3 SUBMENU ACCESSED. HERE YOU CAN SET 6 DIFFERENT AUTO-SHUTDOWN TIMES AS SPECIFIED BELOW. IF NO SELECTION IS MADE WITHIN 10 SECONDS, SYSTEM RETURNS TO MAIN MENU. FROM SUBMENU2 ACTIVATE T9 10min (default) FOR CT ONLY (*) Disabling auto-shutdown FOR CT ONLY (*) 3min FOR CT ONLY (*) NOTE: (*) Continuous Transmission (CT) AUTO-SHUT…

Text truncated - open the document above for the full version.

FCC ID 2ABS7-ARMIMI915 Page 1 of 1 Receiving Unit AR MITO-MINI-915 85,0 mm 44,0 mm LABEL DIMENSIONS AND POSITION AR MITO-MINI-915 1. Label contents and dimensions 2. Label position Position of label with FCC ID

FCC ID 2ABS7-ARMIMI915 Page 1 of 4 Receiving Unit AR MITO-MINI-915 INTERNAL PHOTOS AR MITO-MINI-915 FCC ID 2ABS7-ARMIMI915 Page 2 of 4 Receiving Unit AR MITO-MINI-915 FCC ID 2ABS7-ARMIMI915 Page 3 of 4 Receiving Unit AR MITO-MINI-915 FCC ID 2ABS7-ARMIMI915 Page 4 of 4 Receiving Unit AR MITO-MINI-915

CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) – ITALY Tel./Fax +39 0445 367702 www.cmclab.it - [email protected] Independent Testing Laboratory Accredited by ACCREDIA according to UNI CEI EN ISO/IEC 17025 cert. nr. 0168 Test report R15093901 Rev. 1.0 Order M150939 page 1 of 43 LAB N° 0168 TEST REPORT nr. R15093901 Federal Communication Commission (FCC) Test item Description ........................ : TRANSCEIVER UNIT Trademark ......................... : ELCA Model/Type ...................... : AR MITO-MINI 915 FCC ID ................................ : 2ABS7-ARMIMI915 Test Specification Standard ........................... : FCC Rules & Regulations, Title 47:2014 Part 15 paragraph(s): 203, 204, 207, 209 and 249 Client’s name .............. : ELCA S.r.l. Address .............................. : Via del Commercio, 7/B – 36065 Mussolente (VI) – ITALY Manufacturer’s name : Same as client Address .............................. : -- Report Tested by ........................... : A. Bertezzolo – Technician Approved by .................... : R. Beghetto – Laboratory Manager Date of issue ..................... : 04.08.15 Contents ............................ : 43 pages This test report shall not be reproduced except in full without the written approval of CMC. The test results presented in this report relate only to the item tested. CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) Test report R15093901 Rev. 1.0 Order M150939 page 2 of 43 LAB N° 0168 Index 1. SUMMARY ..................................................................................................................................................3 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) .....................................................................................4 2.1 TEST SITE .................................................................................................................................................... 4 3. TESTING AND SAMPLING ..........................................................................................................................4 4. OPERATIVE CONDITIONS ..........................................................................................................................4 5. PHOTOGRAPH(S) OF EUT ..........................................................................................................................5 5.1 PHOTOGRAPH(S) OF EUT ........................................................................................................................... 5 6. EQUIPMENT LIST .........................................................................................................................................6 7. MEASUREMENT UNCERTAINTY ..................................................................................................................7 8. REFERENCE DOCUMENTS..........................................................................................................................8 9. DEVIATION FROM TEST SPECIFICATION ...................................................................................................9 10. TEST CASE VERDICTS .............................................................................................................................9 11. RESULTS ................................................................................................................................................10 11.1 ANTENNA REQUIREMENTS ......................................................................................................................... 11 11.2 CONDUCTED EMISSIONS ........................................................................................................................... 12 11.3 RADIATED EMISSIONS ................................................................................................................................ 16 11.4 PEAK OUTPUT POWER .............................................................................................................................. 28 11.5 BAND EDGE ............................................................................................................................................. 33 11.6 SPURIOUS EMISSION ................................................................................................................................. 39 CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) Test report R15093901 Rev. 1.0 Order M150939 page 3 of 43 LAB N° 0168 1. Summary Standard: FCC Rules & Regulations, Title 47:2014 Part 15 paragraph(s): 203, 204, 207, 209 and 249 Test specifications Environmental Phenomena Tests sequence Result Part 15.203 Antenna requirements 1 Complies Part 15.207 Conducted emissions 2 Complies Part 15.209 Radiated emissions 3 Complies Part 15.209 and 15.249 Peak Output Power 4 Complies Part 15.249 (d) Band edge 5 Complies Part 15.209 Spurious emission 6 Complies The Test Report was given to the Client representatives for necessary documentation of ratification of the tested equipment and it is valid for the FCC certification CMC Centro Misure Compatibilità S.r.l. Via dell’Elettronica, 12/C 36016 Thiene (VI) Test report R15093901 Rev. 1.0 Order M150939 page 4 of 43 LAB N° 0168 2. Description of Equipment under test (EUT) Power supply .................................................................. : 12/24 Vdc Serial Number ................................................................. : -- Type of equipment ..................................................... :  Transmitter Unit  Receiver Unit Type of station .............................................................. :  Fixed station  Portable station  Mobile station Nominal frequency ....................................................... : 920,575 MHz 2.1 Test Site Company ........................................................................ : CMC Centro Misure Compatibilit…
