BRAVO_FUNK+_915_00_EN_FR OTHER LANGUAGES USER MANUAL BRAVO BRAVO-FUNK+ 915 https://qrcode.elcaradio.biz/man/751d329b511fd3d4b4934de51c4b16ed MANUEL DE L’UTILISATEUR This manual, including all its parts, and all the instructions contained in it must be read carefully and understood before each installation, use, maintenance or reparation of the ELCA radio remote control. Ce manuel, y comprises toutes les parties qui le composent, et toutes les instructions y contenues doivent être lus attentivement et comprises avant toute opération d'installation, utilisation, entretien ou réparation de la radiocommande ELCA. 0408MA001356 USER MANUAL Instructions translated from the original This manual, including all its parts, and all the instructions contained in it must be read carefully and understood before each installation, use, maintenance or reparation of the ELCA radio remote control. BRAVO BRAVO-FUNK+ 915 BRAVO_FUNK+_915_00_EN OTHER LANGUAGES https://qrcode.elcaradio.biz/man/751d329b511fd3d4b4934de51c4b16ed 0408MA001356 WARNING en THIS MANUAL, INCLUDING ALL ITS PARTS, AND ALL THE INSTRUCTIONS CONTAINED IN IT MUST BE READ CAREFULLY AND UNDERSTOOD BEFORE EACH INSTALLATION, USE, MAINTENANCE OR REPARATION OF THE ELCA RADIO REMOTE CONTROL. FAILURE TO READ THE MANUAL AND COMPLY WITH ALL THE APPLICABLE WARNINGS AND INSTRUCTIONS, OR ANY RESTRICTION PROVIDED IN THIS MANUAL CAN CAUSE SERIOUS PHYSICAL INJURIES OR DEATH AND/OR DAMAGE TO PROPERTY. THE ELCA RADIO REMOTE CONTROL IS NOT AN INDEPENDENT PRODUCT AND IS EXCLUSIVELY A COMPONENT OF A MACHINE THAT: • PERMITS A RADIO REMOTE CONTROL TO BE USED IN AN APPROPRIATE MANNER, • CAN BE OPERATED SAFELY AND IN COMPLIANCE WITH ALL LEGAL PROVISIONS, REGULATIONS AND STANDARDS APPLICABLE TO THIS RADIO REMOTE CONTROL. ACCORDINGLY, IT IS THE RESPONSIBILITY OF THE MANUFACTURER AND THE DESIGNERS OF THE MACHINE ON WHICH YOU INTEND TO INSTALL THE ELCA RADIO REMOTE CONTROL to carry out a careful and in-depth risk assessment to determine whether the Elca radio remote control is suitable for the safe and efficient use of the Machine, taking into account the conditions of use and the intended uses, and that the installation, maintenance and use of the Elca radio remote control and all its components are carried out only and entirely in accordance with this Manual and in compliance with all local safety rules, standards and regulations (referred to herein as "Laws, Regulations and Standards"). With reference to the US market, the Laws, regulations and Standards include all regulations and standards of the Occupational Safety & Health Administration (OSHA) (http:// www.osha.gov), all federal, state and local laws and provisions, the construction and electric devices codes and all applicable standards, including, bit not only, ANSI standards. It is the responsibility of the Manufacturer and the designers of the Machine on which you intends to install and use the Elca Radio Remote Control to make sure that the structure, condition, organisation and the markings of the Machine as well as how it is installed in its place of use are appropriate and allow the Machine to be used and controlled safely and reliably using the interface of the Elca Radio Remote Control. IT IS THE RESPONSIBILITY OF THE USER OF THE SYSTEM AND THEIR DESIGNERS that the installation, maintenance and use of the Elca Radio Remote Control and all its components are carried out only and entirely in accordance with this Manual and in compliance with all applicable Laws, Regulations and Standards, also local. It is also the responsibility of the Owner, the system user and their designers to make sure that the structure, the condition, the organisation and the markings of the Machine and the place where the Elca Radio Remote Control is installed and used are appropriate and allow the Machine to be used and controlled safely and reliably using the interface of the Elca Radio Remote Control. ONLY QUALIFIED AND SUITABLY TRAINED PERSONNEL ARE ALLOWED TO CONTROL AND USE THE ELCA RADIO REMOTE CONTROL AND THE MACHINE CONTROLLED BY THE ELCA RADIO REMOTE CONTROL. ONLY QUALIFIED AND SUITABLY TRAINED PERSONNEL ARE ALLOWED ACCESS TO THE VICINITY OF THE MACHINE CONTROLLED BY THE ELCA RADIO REMOTE CONTROL. INADEQUATE INSTALLATION, OPERATION, MAINTENANCE AND ASSISTANCE OPERATIONS ON THE ELCA RADIO REMOTE CONTROL CAN CAUSE SERIOUS PHYSICAL DAMAGE OR DEATH AND/OR DAMAGE TO PROPERTY. For further assistance refer to this Manual and all its parts, or else contact Elca. Elca is not responsible for and accepts no liability for any installation of the Elca Radio Remote Control carried out by Elca itself, or for any use or maintenance of the Elca Radio Remote Control that do not fully comply with all the instructions and warnings supplied by Elca and with all applicable Laws, Regulations and Standards, also local. Elca is not responsible for and accepts no liability for any alterations or modifications of the Elca Radio Remote Control, or for the use of non-original Elca parts that are used together or incorporated inside the Radio Remote Control itself. IT IS THE RESPONSIBILITY OF THE OWNER, AND USER OF THE SYSTEM AND ITS DESIGNERS to make sure that the Elca Radio Remote Control is always maintained and serviced in compliance with all the instructions and warnings provided by Elca, and in compliance with all applicable Laws, Regulations and Standards, also local. IT IS THE RESPONSIBILITY OF THE OWNER, THE USER OF THE SYSTEM AND THEIR EMPLOYEES MANAGERS AND SUPERVISORS to make sure that all the Users of the Elca Radio Remote Control and all those that work or will work with or near the Machine operated by or through the Elca Radio Remote Control are completely and adequately instructed and trained by qualified persons on the correct and safe use of the Elca Radio Remote Control and the Machine, including without restrictions the complete familiarity with and understanding of the warnings and instructions provided by Elca, and all applicab…

Text truncated - open the document above for the full version.

24 16 General operating instructions The radio remote control system BRAVO has been developed to ensure the best operating performance and has some special features outlined below. The symbols illustrated in this document are indicative and may vary. Refer to the specific documentation attached to the cable control unit. 25 e N 16.1 Mechanical starting keyswitch I The cable control unit has a mechanical switch-on key used to power the electronics, and cannot work if the key is not inserted. To insert the mechanical key: • introduce the key inside the relative seat with the index pointing to position 0. To remove the key: • turn the key anti-clockwise to position 0; • pull the key out of the seat. Remove the mechanical key when the cable control unit is not being used, or when the work is suspended, even for a short period. “Slow” mode Turning the mechanical key to Slow (At symbol) the belt outputs slow in Movement mode. The cable control unit does not come on if the mechanical key is in the Slow position, on Start the Check LED turns red fixed. 16.2 START command The START command enables the cable control unit and the HORN output. START RADIOCOM. The START command enables the machine operating mode with the system active. The cable control unit does not come on if: • the mechanical key is turned to the “Slow” position, the Check LED turns red fixed; • selector S13 is in an operating mode other than Positioning, the Check LED comes on red fixed with the START active; • the STOP button has been pressed, the Check LED goes off when the START command is released; • one of the ON/OFF commands is active, or one of the joysticks is out of zero, the Check LED turns red fixed with the START enabled. Note:Having pressed START, the LEDS flash rapidly and intermittently; the Check LED flashes green, while the JET / PUMP / ENABLE LEDs flash yellow, finally the Check LED flashes green slowly. 16.3 STOP button The STOP button stops the machine and switches off the cable control unit. To restart working after the STOP button was pressed, proceed as follows: • check that the operating conditions are safe; • turn the STOP button in the direction indicated to disengage it; • carry out the cable control unit start-up procedure (see paragraph 16.5 ). If the STOP button has been pressed, during start-up the cable control unit goes off when the START command is released. if a dangerous situation arises press the STOP button to immediately stop the Machine. It is necessary to check that the Manufacturer of the Machine and/or the Installer provide suitable instructions and warnings in relation to any risks that derive from the stoppage of the Machine. These risks could, for example, come from inertial movements or from the swinging of the load. 16.4 Activating the controls The actuators on the cable control unit may be of different types. They can be: • toggle switches; • buttons; • on/off joystick; • proportional joystick; • potentiometer. For the functions of the various keys on the unit, refer to the command layout attached to the unit itself. 16.5 Starting the cable control unit Starting the cable control unit consists of enabling the internal electronic card and the machine activation outputs. To start the cable control unit the key must be in position 1, the cable control unit powered, selector S13 in "Positioning" operating mode and the START command enabled. Also see the safety warnings in paragraph 7.1 . Use this procedure to start the cable control unit: • turn selector S13 to Positioning mode; • turn the mechanical key to position 1; • check that the STOP button is off; • press the START command to enable the functional LED test (horn enabled on the Machine). The cable control unit does not come on if: • the mechanical key is turned to the “Slow” position, the Check LED turns red fixed; • selector S13 is in an operating mode other than Positioning, the Check LED comes on red fixed with the START active; • the STOP button has been pressed, the Check LED goes off when the START command is released; • one of the ON/OFF commands is active, or one of the joysticks is out of zero, the Check LED turns red fixed with the START enabled. Switch off the cable control unit when it is not being used to operate the machine, or when the work is interrupted in another way, even for short periods. 26 16.6 Selecting the operating mode MODE S13 The selector S13 selects the operating mode of the machine. When changing the operating mode, press START to enable it. When activated, this switch must be in Positioning mode. Movement Only the functions shown on an orange background and the GAS+, GAS- and STOP motor functions are active in this operating mode. Slow mode functions only in Movement mode. All others are deactivated. Positioning Only the functions shown on a yellow background and the GAS+, GAS- and START motor functions are active in this operating mode. All others are deactivated. Drilling (Operational) Only the functions shown on a blue background and the GAS+, GAS- and STOP motor functions are active in this operating mode. All others are deactivated. Drilling with Loader Only the functions shown on a blue background, on a grey background as a second function (from J8 to J12) and the GAS+, GAS- and STOP motor functions are active in this operating mode. All others are deactivated. When passing from Drilling operating mode to Loader operating mode, the shared functions (J8 - J12) switch off, press the START button to enable them. 16.6.1 Clamp opening functions with safety enabled B34 S19 J12J11 To enable the clamp open function (purple background), press Enable B34, the Enable LED remains on. The selector S19 and the joysticks J11-J12 open the clamps (actuators pushed upwards) protected by a safety enable command. The clamp close command does not require the enable command. In other radio remote control applications, some drilling functions may require safety enabling. Refer to the layout. 16.7 Special functions…

Text truncated - open the document above for the full version.

13 FR 4 L’Utilisateur doit utiliser la sangle avec l’Unité de transmission et/ou la Commande filaire attachée pour éviter des chutes ou des activations accidentelles des actionneurs. La sangle doit être remplacée si elle présente des signes d’usure ou de dommage. Toute autre utilisation de la sangle constitue une utilisation incorrecte des systèmes de commande. 10 Description de l'Unité de transmission AActionneurs (sélecteurs, boutons, potentiomètres, joysticks) BVoyant Check CCoup-de-poing de STOP DClé de démarrage ETouche START FVoyant Enable étau GVoyant Pompe HVoyant Jet JBatterie KPlaque signalétique LÉcran de 4,3 pouces MTouches d’écran NConnecteur pour programmateur d’écran L’écran est personnalisé par le fabricant de la machine. 14 10.1 Caractéristiques techniques Module radio de réception et de transmission RTB-EA3 Antenneincorporée Distance entre l'antenne et le corps humain > 10 mm Alimentation batterie LI-ion 7,4 V Consommation<130 mA Puissance absorbée<1 W Puissance d'émission R.F< 25 mW ERP Autonomie avec la batterie chargée à 20°C (puissance de l'émission 10 mW) jusqu'à 10 heures (peut varier en fonction de l'utilisation de l'écran) Autonomie après l’avertissement de batterie déchargée 10 min Degré de protectionIP65 Dimensions408x202x271 mm Poids3500 g Écran Taille et couleurs TFT LCD, 4,3 pouces - 480x272 pixels - WQVGA 16M couleurs Luminosité500 (cd/m²) Touchesn°6 programmables La radiocommande a été évaluée pour la fréquence d'exposition (RF) des appareils portables. 10.2 Disposition des commandes et schéma de branchement La documentation fournie avec la Radiocommande se compose de : • « Disposition des Commandes » qui présente la configuration de l'Unité de transmission et les noms des commandes envoyées à l'Unité de réception ; • « Schéma de branchement » qui indique la correspondance entre les commandes envoyées par l'Unité de transmission et celles disponibles dans l'Unité de réception. La Disposition des commandes et le Schéma de branchement doivent rester toujours joints à ce Manuel. s'il faut utiliser un ou plusieurs de ces documents pour des démarches administratives (vérifications, essais, etc.), il est nécessaire d'en faire une copie. 10.3 Plaque signalétique de l'Unité de transmission La plaque signalétique apposée sur l’Unité de transmission AT BRAVO-FUNK+ 915 contient des informations sur : le numéro de série (Serial Num.), l’année de fabrication, les principales données techniques de l'Unité de transmission, le marquage et les éventuelles marques de la Radiocommande. TS84A RADIOCONTROLS Radio remote system type: BRAVO Power supply: 7.4 V Protection degree: IP65 TX module: RTB-EU2 Pot. RF max: 25 mW Freq. range: 863.000-870.000 MHz TRANSMITTING UNIT Transmitting unit model: AT BRAVO FUNK+ Via del Commercio 7/b 36065 Mussolente (VI) - ITALY - www.elcaradio.com 10.4 Signalisations lumineuses 10.4.1 Voyant Check Le voyant Check peut devenir de deux couleurs : verte ou rouge. La couleur verte ou rouge fournit des informations sur la Radiocommande. La signification de l’allumage du voyant est décrite dans les tableaux suivants. Pour les actions à prendre lorsque les signalisations lumineuses verte et/ou rouge sont présentes, voir les tableaux suivants ou le paragraphe 20.1 . Il n’est pas possible de modifier la signification des signalisations verte et rouge du voyant. SIGNALISATIONSIGNIFICATION Le voyant Check est éteint.La Radiocommande est éteinte. Le voyant Check clignote lentement en vert. La Radiocommande fonctionne correctement et la batterie est chargée. Le voyant Check clignote rapidement en vert. La Radiocommande est active, en attente de START. Le voyant Check clignote rapidement en vert et lentement en rouge. La batterie est faible et la liaison radio n'est pas active. Le voyant Check clignote lentement en vert et en rouge. La batterie est faible mais la liaison radio est active. Le voyant Check clignote lentement en rouge. La Radiocommande fonctionne correctement, mais la batterie est déchargée (autonomie restante inférieure à 10 min). Le voyant Check clignote une fois en rouge puis s'éteint. La Radiocommande détecte l’activation du bouton-poussoir de Stop. Le voyant Check clignote deux fois en rouge puis s'éteint. La Radiocommande détecte une commande ON/OFF active. Le voyant Check clignote trois fois en rouge puis s'éteint. La Radiocommande détecte la batterie faible. Le voyant Check clignote quatre fois en rouge puis s'éteint. La Radiocommande détecte un joystick hors zéro. Le voyant Check reste allumé pendant deux secondes puis s'éteint. Unité de transmission défaillante. Lorsque le voyant rouge d'erreur ou de batterie faible de l'unité de transmission s'allume, un signal sonore retentit. 10.4.2 Voyant Enable étau Le voyant Enable étau est allumé fixe lorsque le bouton Enable (B34) est enfoncé alors que le sélecteur S13 est en position Forage avec chargeur. 10.4.3 Voyant Jet En mode Forage ou Forage avec chargeur, le voyant Jet est allumé fixe lorsque la sortie Jet est active. 10.4.4 Voyant Pompe En mode Forage ou Forage avec chargeur, le voyant Pompe est allumé fixe lorsque la sortie Pompe est active. 10.4.5 Test voyant L’Unité de transmission effectue un test fonctionnel des voyants lorsque, la batterie étant insérée, la clé de démarrage est tournée en position 1. Les voyants clignotent rapidement par intermittence ; le voyant Check clignote en vert, tandis que les voyants JET / POMPE / ENABLE clignotent en jaune. Dès que le bouton START est enfoncé, ils s'éteignent et le voyant Check clignote en vert pour indiquer le bon fonctionnement du système. 15 FR 11 Instructions générales de fonctionnement Le système de radiocommande BRAVO a été développé pour assurer les meilleures performances de travail et dispose de certaines fonctions spéciales illustrées ci-dessous. Les symboles figurant dans ce document sont indicatifs et sujets à modification. Se reporter à la documentation fournie avec la radiocommande. 16 11.1 Clé de démarrage mécanique I L’…

Text truncated - open the document above for the full version.
