2ABSA7051705101

CC2652R7 SimpleLink™ Multiprotocol 2.4 GHz Wireless MCU 1 Features Wireless microcontroller •Powerful 48-MHz Arm® Cortex®-M4F processor •704KB flash program memory •256KB of ROM for protocols and library functions •8KB of cache SRAM •144KB of ultra-low leakage SRAM with parity for high-reliability operation •Dynamic multiprotocol manager (DMM) driver •Programmable radio includes support for 2- (G)FSK, 4-(G)FSK, MSK, Bluetooth® 5.2 Low Energy, IEEE 802.15.4 PHY and MAC •Supports over-the-air upgrade (OTA) Ultra-low power sensor controller •Autonomous MCU with 4KB of SRAM •Sample, store, and process sensor data •Fast wake-up for low-power operation •Software defined peripherals; capacitive touch, flow meter, LCD Low power consumption •MCU consumption: –3.10 mA active mode, CoreMark –65 μA/MHz running CoreMark –0.9 μA standby mode, RTC, 144KB RAM –0.1 μA shutdown mode, wake-up on pin •Ultra low-power sensor controller consumption: –29.2 μA in 2 MHz mode –799 μA in 24 MHz mode •Radio Consumption: –6.4 mA RX –7.3 mA TX at 0 dBm –9.7 mA TX at +5 dBm Wireless protocol support •Thread, Zigbee®, Matter •Bluetooth® 5.2 Low Energy •SimpleLink™ TI 15.4-stack •6LoWPAN •Proprietary systems High performance radio •-104 dBm for Bluetooth® Low Energy 125-kbps •Output power up to +5 dBm with temperature compensation Regulatory compliance •Suitable for systems targeting compliance with these standards: –ETSI EN 300 328, EN 300 440 Cat. 2 and 3 –FCC CFR47 Part 15 –ARIB STD-T66 MCU peripherals •Digital peripherals can be routed to any GPIO •Four 32-bit or eight 16-bit general-purpose timers •12-bit ADC, 200 kSamples/s, 8 channels •8-bit DAC •Two comparators •Programmable current source •Two UART, two SSI, I 2 C, I 2 S •Real-time clock (RTC) •Integrated temperature and battery monitor Security enablers •AES 128- and 256-bit cryptographic accelerator •ECC and RSA public key hardware accelerator •SHA2 Accelerator (full suite up to SHA-512) •True random number generator (TRNG) Development tools and software •LP-CC2652R7 Development Kit •SimpleLink™ CC13xx and CC26xx Software Development Kit (SDK) •SmartRF™ Studio for simple radio configuration •Sensor Controller Studio for building low-power sensing applications •SysConfig system configuration tool Operating range •On-chip buck DC/DC converter •1.8-V to 3.8-V single supply voltage •-40 to +105°C Package •7-mm × 7-mm RGZ VQFN48 (31 GPIOs) •RoHS-compliant package CC2652R7 SWRS253A – MAY 2021 – REVISED NOVEMBER 2021 An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications, intellectual property matters and other important disclaimers. PRODUCTION DATA. 2 Applications •2400 to 2500 MHz ISM and SRD systems 1 with down to 4 kHz of receive bandwidth •Building automation –Building security systems – motion detector, electronic smart lock, door and window sensor, garage door system, gateway –HVAC – thermostat, wireless environmental sensor, HVAC system controller, gateway –Fire safety system – smoke and heat detector, fire alarm control panel (FACP) –Video surveillance – IP network camera –Elevators and escalators – elevator main control panel for elevators and escalators •Industrial transport – asset tracking •Factory automation and control •Medical •Electronic point of sale (EPOS) – Electronic Shelf Label (ESL) •Communication equipment –Wired networking – wireless LAN or Wi-Fi access points, edge router , small business router •Personal electronics –Home theater & entertainment – smart speakers, smart display, set-top box –Wearables (non-medical) – smart trackers, smart clothing 3 Description The SimpleLink ™ CC2652R7 device is a multiprotocol 2.4-GHz wireless microcontroller (MCU) supporting Thread, Zigbee ® , Matter, Bluetooth ® 5.2 Low Energy, IEEE 802.15.4g, IPv6-enabled smart objects (6LoWPAN), TI 15.4-Stack (2.4 GHz), and concurrent multiprotocol through a Dynamic Multiprotocol Manager (DMM) driver. The CC2652R7 is based on an Arm ® Cortex ® M4F main processor and optimized for low-power wireless communication and advanced sensing in grid infrastructure, building automation, retail automation, personal electronics and medical applications. The CC2652R7 has a software defined radio powered by an Arm® Cortex® M0, which allows support for multiple physical layers and RF standards. The device supports operation in the 2360 to 2500-MHz frequency band. PHY and frequency switching can be done runtime through a dynamic multiprotocol manager (DMM) driver. The CC2652R7 supports +5 dBm TX at 9.7 mA in the 2.4-GHz band. CC2652R7 has a receive sensitivity of -104 dBm for 125-kbps Bluetooth® Low Energy Coded PHY. The CC2652R7 has a low sleep current of 0.9 μA with RTC and 144KB RAM retention. In addition to the main Cortex® M4F processor, the device also has an autonomous ultra-low power Sensor Controller CPU with fast wake-up capability. As an example, the sensor controller is capable of 1-Hz ADC sampling at 1-μA system current. The CC2652R7 has Low SER (Soft Error Rate) FIT (Failure-in-time) for long operational lifetime. Always-on SRAM parity minimizes risk for corruption due to potential radiation events. Consistent with many customers’ 10 to 15 years or longer life cycle requirements, TI has a product life cycle policy with a commitment to product longevity and continuity of supply. The CC2652R7 device is part of the SimpleLink™ MCU platform, which consists of Wi-Fi®, Bluetooth® Low Energy, Thread, Zigbee, Wi-SUN®, Amazon Sidewalk, mioty®, Sub-1 GHz MCUs, and host MCUs. CC2652R7 is part of a scalable portfolio with flash sizes from 32KB to 704KB with pin-to-pin compatible package options. The common SimpleLink™CC13xx and CC26xx Software Development Kit (SDK) and SysConfig system configuration tool supports migration between devices in the portfolio. A comprehensive number of software stacks, application examples and SimpleLink ™ Academy training sessions are included in the SDK. For more information, v…

Text truncated - open the document above for the full version.

CC3235S and CC3235SF SimpleLink™ Wi-Fi ® , Dual-Band, Single-Chip Solution 1 Features •Multiple-core architecture, system-on-chip (SoC) •802.11 a/b/g/n: 2.4 GHz and 5 GHz •FIPS 140-2 Level 1 Certification •Multilayered security features, help developers protect identities, data, and software IP •Low-Power Modes for battery powered application •Coexistence with 2.4 GHz Radios •Industrial temperature: –40°C to +85°C •Wi-Fi CERTIFIED ® by the Wi-Fi Alliance ® •Application microcontroller subsystem: –Arm ® Cortex ® -M4 core at 80 MHz –User-dedicated memory •256KB RAM •Optional 1MB executable Flash –Rich set of peripherals and timers –27 I/O pins with flexible multiplexing options •UART, I2S, I2C, SPI, SD, ADC, 8-bit parallel interface •Timers and PWM •Wi-Fi network processor subsystem: –Wi-Fi ® core: •802.11 a/b/g/n 2.4 GHz and 5 GHz •Modes: –Access Point (AP) –Station (STA) –Wi-Fi Direct ® (only supported on 2.4 GHz) •Security: –WEP –WPA ™ / WPA2 ™ PSK –WPA2 Enterprise –WPA3 ™ Personal –WPA3 ™ Enterprise –Internet and application protocols: •HTTPs server, mDNS, DNS-SD, DHCP •IPv4 and IPv6 TCP/IP stack •16 BSD sockets (fully secured TLS v1.2 and SSL 3.0) –Built-in power management subsystem: •Configurable low-power profiles (always, intermittent, tag) •Advanced low-power modes •Integrated DC/DC regulators •Multilayered security features: –Separate execution environments –Networking security –Device identity and key –Hardware accelerator cryptographic engines (AES, DES, SHA/MD5, CRC) –Application-level security (encryption, authentication, access control) –Initial secure programming –Software tamper detection –Secure boot –Certificate signing request (CSR) –Unique per device key pair •Application throughput: –UDP: 16 Mbps, TCP: 13 Mbps –Peak: 72 Mbps •Power-Management Subsystem: –Integrated DC/DC converters support a wide range of supply voltage: •VBAT wide-voltage mode: 2.1 V to 3.6 V •VIO is always tied with VBAT –Advanced low-power modes: •Shutdown: 1 μA, hibernate: 4.5 μA •Low-power deep sleep (LPDS): 120 μA •Idle connected (MCU in LPDS): 710 μA •RX traffic (MCU active): 59 mA •TX traffic (MCU active): 223 mA •Wi-Fi TX power: –2.4 GHz: 18.0 dBm at 1 DSSS –5 GHz: 18.1 dBm at 6 OFDM •Wi-Fi RX sensitivity: –2.4 GHz: –96 dBm at 1 DSSS –5 GHz: –92 dBm at 6 OFDM •Clock source: –40.0-MHz crystal with internal oscillator –32.768-kHz crystal or external RTC •RGK package –64-Pin, 9-mm × 9-mm very thin quad flat nonleaded (VQFN) package, 0.5-mm pitch •Device supports SimpleLink™ MCU Platform Developer's Ecosystem CC3235S, CC3235SF SWRS215D – APRIL 2019 – REVISED MAY 2021 An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications, intellectual property matters and other important disclaimers. PRODUCTION DATA. 2 Applications •For Internet of Things applications, such as: –Building and Home Automation: •HVAC Systems & Thermostat •Video Surveillance, Video Doorbells, and Low-Power Camera •Building Security Systems & E-locks –Appliances –Asset Tracking –Factory Automation –Medical and Healthcare –Grid Infrastructure 3 Description The dual-band wireless MCU CC3235x device comes in two variants, CC3235S and C3235SF. •The CC3235S includes 256KB of RAM, IoT networking security, device identity/keys, as well as, MCU level security features such as file system encryption, user IP (MCU image) encryption, secure boot and debug security. •The CC3235SF builds on the CC3235S and integrates a user-dedicated 1MB of executable flash in addition to the 256KB of RAM. Simplify your IoT design with a Wi-Fi CERTIFIED™ wireless microcontroller (MCU). The SimpleLink ™ Wi-Fi ® CC3235x device family is a dual-band system-on-chip (SoC) solution that integrates two processors within a single chip, including: •Application processor: Arm ® Cortex ® -M4 MCU with a user-dedicated 256KB of RAM and an optional 1MB of executable flash •Network processor to run all Wi-Fi and internet logical layers. This ROM-based subsystem completely offloads the host MCU and includes an 802.11 a/b/g/n dual-band 2.4 GHz and 5 GHz radio, baseband, and MAC with a powerful hardware cryptography engine These devices introduce new capabilities that further simplify the connectivity of things to the Internet. The main new features include: •802.11a (5 GHz) support •BLE/2.4 GHz radio coexistence •Antenna selection •Enhanced security with FIPS 140-2 Level 1 certification and more 1 •Up to 16 concurrent secure sockets •Certificate sign request (CSR) •Online certificate status protocol (OCSP) •Wi-Fi ® Alliance certified IoT power-saving features (such as DMS, proxy ARP, and so forth) •Hostless mode for offloading template packet transmissions •Improved fast scan The CC3235x device family is part of the SimpleLink™ MCU platform—a common, easy-to-use development environment based on a single-core software development kit (SDK) with a rich tool set and reference designs. The E2E™ community supports Wi-Fi ® , Bluetooth ® low energy, Sub-1 GHz, and host MCUs. For more information, visit www.ti.com/simplelink or www.ti.com/simplelinkwifi. Device Information (1) PART NUMBERPACKAGEBODY SIZE (NOM) CC3235SM2RGKRVQFN (64)9.00 mm × 9.00 mm CC3235SF12RGKRVQFN (64)9.00 mm × 9.00 mm (1)For all available packages, see Section 12. 1 For exact status of FIPS certification for a specific part number, please refer to https://csrc.nist.gov/publications/fips. CC3235S, CC3235SF SWRS215D – APRIL 2019 – REVISED MAY 2021 www.ti.com 2Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated Product Folder Links: CC3235S CC3235SF 4 Functional Block Diagrams Functional Block Diagram shows the functional block diagram of the CC3235x SimpleLink™ Wi-Fi ® solution. CC3235x 32.768 kHz XTAL 40 MHz XTAL SPI Flash SPI Peripheral I2C Peripheral Miscellaneous Peripherals Camera sensor Audio codec Wi-Fi RF Switch 5 GHz BPF Diplexer / SPDT RF Switch V CC Wide voltage (2.1 to 3.6V) SSPI GSPI I2C Output GPIOs GPIO/ PWM P…

Text truncated - open the document above for the full version.

Irrigreen Controller 705101 Frequency Block Diagram CC3235SF 40 MHz Osc 32768 Hz Osc 2.4 GHz Wi-Fi A Texas Instruments CC3235SF combines a microprocessor and radio in the Irrigreen Controller 705101. The specification sheet is listed separately. A 40 MHz oscillator provides source frequencies of operation using a clock divider for lower frequencies or a Digital PLL for higher clock frequencies needed for the 2.4 GHz and 5 GHz radios. A Wi-Fi software stack from Texas Instruments is used where the 2.4GHz radio ranges from 2.412 GHz to 2.462 GHz and the 5GHz radio ranges from 5.180 GHz to 5.825 GHz. A 32768 Hz oscillator operates a real time clock. 5 GHz Wi-Fi TX 5 GHz Wi-Fi RX Irrigreen Controller 705101 Frequency Block Diagram CC2652R7 48 MHz Osc 32768 Hz Osc 2.4 GHz Bluetooth A Texas Instruments CC2652R7 combines a microprocessor and radio in the Irrigreen Controller 705101. The specification sheet is listed separately. A 48 MHz oscillator provides source frequencies of operation using a clock divider for lower frequencies or a Digital PLL for higher clock frequencies needed for the 2.4 GHz radio. A Bluetooth Low Energy software stack from Texas Instruments is used where the BLE 2.4 GHz ranges from 2.402 GHz to 2.480 GHz. A 32768 Hz oscillator operates a real time clock.

Controller 705101 Photos External Enclosure right side Enclosure back Enclosure bottom Enclosure closed left side Enclosure top Enclosure closed right side Enclosure open back Enclosure with sprinkler cable Enclosure top view Enclosure left side

Controller 75101 FCC label The label will be weatherproof vinyl with permanent pressure sensitive adhesive. FCC Label on bottom of controller Controller Model 705101 FCC ID: 2ABSA7051 100-240 VAC 50 W FCC Label on Controller box

Controller 705101 Photos Internal Wi-Fi RF section of circuit board 40 MHz osc. 32768 Hz osc. CC3235SF Antenna Diversity RF Switch 5 Ghz RX/TX RF switch 2.4 Ghz Matching Network and filter 5 Ghz Matching Network and filter 2.4/5 GHz Diplexor Bluetooth RF section of circuit board F-type Ant. CC2652R7 Balun Matching Network 48 MHz osc. 32768 Hz osc. Distance to outside of enclosure 10 mm Inside PCB antenna connnections Inside display connection Internal back of PCB Internal mask part with PCB attached front Internal mask part with PCB attached back Internal mask part with PCB attached side Internal mask part with PCB attached removed to show interface Internal mask part back no PCB attached Wi-Fi Antenna Placement

This report must not be used to claim product certification, approval, or endorsement by A2LA, NIST, or any agency of the U.S. Government. This Report shall not be reproduced, except in full without written approval of the laboratory. IrriGreen, Inc. Controller 3, Model 705101 FCC 1.1307:2024 FCC 2.1091:2024 802.11a/b/g/n Bluetooth Low Energy Report: IRRI0024.5, Issue Date: September 19, 2024 TABLE OF CONTENTS 2023.04.17 Section Page Number Certificate of Evaluation .................................................................................. 3 Revision History .............................................................................................. 4 Accreditations .................................................................................................. 5 Facilities .......................................................................................................... 6 Product Description ......................................................................................... 7 Exposure Condition ......................................................................................... 8 Exemption from RF Exposure Evaluation ....................................................... 9 End of Report .................................................................................................. 12 Report No. IRRI0024.52/12 CERTIFICATE OF EVALUATION 2018-09-14 Product compliance is the responsibility of the client; therefore, the tests and equipment modes of operation represented in this report were agreed upon by the client, prior to testing. The results of this test pertain only to the sample(s) tested. The specific description is noted in each of the individual sections of the test report supporting this certificate of test. This report reflects only those tests from the referenced standards shown in the certificate of test. It does not include inspection or verification of labels, identification, marking or user information. As indicated in the Statement of Work sent with the quotation, Element’s standard process is to always use the latest published version of the test methods even when earlier versions are cited in the test specification. Issuance of a purchase order was de facto acceptance of this approach. Otherwise, the client would have advised Element in writing of the specific version of the test methods they wanted applied to the subject testing Last Date of Evaluation: September 19, 2024 IrriGreen, Inc. EUT: Controller 3, Model 705101 RF Exposure Evaluation Standards Specification Method FCC 1.1307:2024 FCC 2.1091:2024 FCC 1.1307:2024 Results Method Clause Description Applied Results Comments (b)(3)(ii)(B) Exemption From RF Exposure Evaluation Yes Pass None Deviations From Evaluation Standards None Approved By: Donald Facteau, Process Architect Report No. IRRI0024.53/12 REVISION HISTORY 2018.07.17 Revision Number Description Date (yyyy-mm-dd) Page Number 00 None Report No. IRRI0024.54/12 ACCREDITATIONS AND AUTHORIZATIONS 2021.09.01 United States FCC - Designated by the FCC as a Telecommunications Certification Body (TCB). Certification chambers, Open Area Test Sites, and conducted measurement facilities are listed with the FCC. A2LA - Each laboratory is accredited by A2LA to ISO / IEC 17025, and as a product certifier to ISO / IEC 17065 which allows Element to certify transmitters to FCC and IC specifications. Canada ISED - Recognized by Innovation, Science and Economic Development Canada as a Certification Body (CB) and as a CAB for the acceptance of test data. European Union European Commission – Recognized as an EU Notified Body validated for the EMCD and RED Directives. United Kingdom BEIS – Recognized by the UK as an Approved Body under the UK Radio Equipment and UK EMC Regulations. Australia/New Zealand ACMA - Recognized by ACMA as a CAB for the acceptance of test data. Korea MSIT / RRA - Recognized by KCC’s RRA as a CAB for the acceptance of test data. Japan VCCI - Associate Member of the VCCI. Conducted and radiated measurement facilities are registered. Taiwan BSMI – Recognized by BSMI as a CAB for the acceptance of test data. NCC - Recognized by NCC as a CAB for the acceptance of test data. Singapore IDA – Recognized by IDA as a CAB for the acceptance of test data. Israel MOC – Recognized by MOC as a CAB for the acceptance of test data. Hong Kong OFCA – Recognized by OFCA as a CAB for the acceptance of test data. Vietnam MIC – Recognized by MIC as a CAB for the acceptance of test data. SCOPE For details on the Scopes of our Accreditations, please visit: California Minnesota Oregon Texas Washington Report No. IRRI0024.55/12 FACILITIES 2024.08.21 Testing was performed at the following location(s) Location Labs (1) Address A2LA (2) ISED (3) BSMI (4) VCCI (5) CAB (6) FDA (7) ☐ California OC01-17 41 Tesla Irvine, CA 92618 (949) 861-8918 3310.04 2834B SL2-IN-E-1154R A-0029 US0158 TL-55 ☐ Minnesota MN01-11 9349 W Broadway Ave. Brooklyn Park, MN 55445 (612) 638-5136 3310.05 2834E SL2-IN-E-1152R A-0109 US0175 TL-57 ☐ Oregon EV01-12 6775 NE Evergreen Pkwy #400 Hillsboro, OR 97124 (503) 844-4066 3310.02 2834D SL2-IN-E-1017 A-0108 US0017 TL-56 ☐ Plano Texas PT01-15 1701 E Plano Pkwy, Ste 150 Plano, TX 75074 (972) 509-2566 214.19 32637 SL2-IN-E-057R A-0426 US0054 N/A ☐ Texas TX01-09 3801 E Plano Pkwy Plano, TX 75074 (469) 304-5255 3310.03 2834G SL2-IN-E-1158R N/A US0191 TL-54 ☐ Washington NC01-05 19201 120th Ave NE Bothell, WA 98011 (425) 984-6600 3310.06 2834F SL2-IN-E-1153R A-0110 US0157 TL-67 ☐ Offsite N/A See Product Description N/A N/A N/A N/A N/A N/A See data sheets for specific labs (1) The lab designations denote individual rooms within each location. (OC01, OC02, OC03, etc.) (2) A2LA Certificate No. (3) ISED Company No. (4) BSMI No. (5) VCCI Site Filing No. (6) CAB Identifier. Recognized Phase I CAB for ISED, ACMA, BSMI, IDA, KCC/RRA, MIC, MOC, NCC, OFCA (7) FDA ASCA No. Report No. IRRI0024.56/12 PRODUCT DESCRIPTION 2018-07-17 Client and Equipment…

Text truncated - open the document above for the full version.

This report must not be used to claim product certification, approval, or endorsement by A2LA or any agency of the U.S. Government. This Report shall not be reproduced, except in full without written approval of the laboratory. IrriGreen, Inc. Controller 3, Model 705101 Antenna Pattern Measurements Report: IRRI0024.0 Rev. 0, Issue Date: August 5, 2024 Approved by: Trevor Buls, Principal EMC Test Engineer Signed for and on behalf of Element TABLE OF CONTENTS 2023.04.17 Section Page Number Revision History .............................................................................................. 3 Accreditations .................................................................................................. 4 Facilities .......................................................................................................... 5 Product Description ......................................................................................... 6 Configurations ................................................................................................ 7 Modifications ................................................................................................... 8 Passive 3D Antenna Pattern Measurements................................................... 9 End of Report .................................................................................................. 12 Report No. IRRI00242/12 REVISION HISTORY 2018.07.17 Revision Number Description Date (yyyy-mm-dd) Page Number 00 None Report No. IRRI00243/12 ACCREDITATIONS AND AUTHORIZATIONS 2021.09.01 United States FCC - Designated by the FCC as a Telecommunications Certification Body (TCB). Certification chambers, Open Area Test Sites, and conducted measurement facilities are listed with the FCC. A2LA - Each laboratory is accredited by A2LA to ISO / IEC 17025, and as a product certifier to ISO / IEC 17065 which allows Element to certify transmitters to FCC and IC specifications. Canada ISED - Recognized by Innovation, Science and Economic Development Canada as a Certification Body (CB) and as a CAB for the acceptance of test data. European Union European Commission – Recognized as an EU Notified Body validated for the EMCD and RED Directives. United Kingdom BEIS – Recognized by the UK as an Approved Body under the UK Radio Equipment and UK EMC Regulations. Australia/New Zealand ACMA - Recognized by ACMA as a CAB for the acceptance of test data. Korea MSIT / RRA - Recognized by KCC’s RRA as a CAB for the acceptance of test data. Japan VCCI - Associate Member of the VCCI. Conducted and radiated measurement facilities are registered. Taiwan BSMI – Recognized by BSMI as a CAB for the acceptance of test data. NCC - Recognized by NCC as a CAB for the acceptance of test data. Singapore IDA – Recognized by IDA as a CAB for the acceptance of test data. Israel MOC – Recognized by MOC as a CAB for the acceptance of test data. Hong Kong OFCA – Recognized by OFCA as a CAB for the acceptance of test data. Vietnam MIC – Recognized by MIC as a CAB for the acceptance of test data. SCOPE For details on the Scopes of our Accreditations, please visit: California Minnesota Oregon Texas Washington Report No. IRRI00244/12 FACILITIES 2024.07.18 Testing was performed at the following location(s) Location Labs (1) Address A2LA (2) ISED (3) BSMI (4) VCCI (5) CAB (6) FDA (7) ☐ California OC01-17 41 Tesla Irvine, CA 92618 (949) 861-8918 3310.04 2834B SL2-IN-E-1154R A-0029 US0158 TL-55 ☒ Minnesota MN01-11 9349 W Broadway Ave. Brooklyn Park, MN 55445 (612) 638-5136 3310.05 2834E SL2-IN-E-1152R A-0109 US0175 TL-57 ☐ Oregon EV01-12 6775 NE Evergreen Pkwy #400 Hillsboro, OR 97124 (503) 844-4066 3310.02 2834D SL2-IN-E-1017 A-0108 US0017 TL-56 ☐ Plano Texas PT01-15 1701 E Plano Pkwy, Ste 150 Plano, TX 75074 (972) 509-2566 214.19 32637 SL2-IN-E-057R N/A US0054 N/A ☐ Texas TX01-09 3801 E Plano Pkwy Plano, TX 75074 (469) 304-5255 3310.03 2834G SL2-IN-E-1158R N/A US0191 TL-54 ☐ Washington NC01-05 19201 120th Ave NE Bothell, WA 98011 (425) 984-6600 3310.06 2834F SL2-IN-E-1153R A-0110 US0157 TL-67 ☐ Offsite N/A See Product Description N/A N/A N/A N/A N/A N/A See data sheets for specific labs (1) The lab designations denote individual rooms within each location. (OC01, OC02, OC03, etc.) (2) A2LA Certificate No. (3) ISED Company No. (4) BSMI No. (5) VCCI Site Filing No. (6) CAB Identifier. Recognized Phase I CAB for ISED, ACMA, BSMI, IDA, KCC/RRA, MIC, MOC, NCC, OFCA (7) FDA ASCA No. Report No. IRRI00245/12 PRODUCT DESCRIPTION 2018-07-17 Client and Equipment under Test (EUT) Information Company Name: IrriGreen, Inc. Address: 5250 West 73rd Street City, State, Zip: Edina, MN 55439 Test Requested By: Gary Klinefelter EUT: Controller 3 First Date of Test: July 16, 2024 Last Date of Test: July 16, 2024 Receipt Date of Samples: July 16, 2024 Equipment Design Stage: Prototype Equipment Condition: No Damage Purchase Authorization: Verified Information Provided by the Party Requesting the Test Functional Description of the EUT: The controller is labeled as a "Controller 3" with an Irrigreen sprinkler model 400104. Testing Objective: To obtain 3D antenna pattern measurements and calculated antenna performance values (gain, efficiency, TRP, etc) Report No. IRRI00246/12 CONFIGURATIONS 2018-07-17 Configuration IRRI0024-7 EUT Description Manufacturer Model/Part Number Serial Number Sprinkler Controller Irrigreen Inc Controller 3, Model 705101 900636 Rev A1 Unit B Report No. IRRI00247/12 MODIFICATIONS 2018-07-17 Equipment Modifications Item Date Test Modification Note Disposition of EUT 1 2024-07-16 Passive 3D Antenna Pattern Measurements Tested as delivered to Test Station. No EMI suppression devices were added or modified during this test. Scheduled testing was completed. Report No. IRRI00248/12 description OTA 2018.01.04 TEST EQUIPMENT IDInterval OTF236 mo OTA36 mo NAM36 mo TEST DESCRIPTION PASSIVE 3D ANTENNA PATTERN MEASUREMENTS Antenna - DipoleETS Lindgren3126-24504/18/2024 Manufacture…

Text truncated - open the document above for the full version.

1. 2. 3. 4. 5. 6. 7.7 P/N:EM60 版本: X1 时间:2023.12.5 Product specification ● Electrical Performance: Frequency Range: 2.4&5.8GHz 1.Lmpedance: 50 Ohms nominal 2.VSWR: ≦1.92 3.Gain：3~4dBi 4.Admitted power radlation: 1W 5.Radation of Radlation: To roidal 6 .Radiation: Omni 7.Polarization: Vertical 8.Connctor Ty pe: i-pex ●Mechanical properties: 1.Cable: 1.13 Black Cable 2 .Operation temperature range: -20°C~+70°C 3.Storage temperature range: -30°C~+80°C 4.Color: ● The product structure pictures P/N:EM60 版本: X1 时间:2023.12.5 Shenzhen Keesun Technology co;ltd Network analyzertestdiagram Part NO: EM60 Spec:2.4&5.8 GPCBAntenna Test:: Return Loss/VSWR P/N:EM60 版本: X1 时间:2023.12.5 Antenna 2D Report-2.4&5.8GHz Antenna Efficiency2.4&5.8GHz P/N:EM60 版本: X1 时间:2023.12.5 Peak Gain2.4&5.8GHz P/N:EM60 版本: X1 时间:2023.12.5 Antenna 3D Report2.4&5.8GHz 2.4G 2.5G 2.5G P/N:EM60 版本: X1 时间:2023.12.5 5.15G 5.45G 5.85G 一、Technical specifications 二、Reliability test High and low temperature test Normal electrical and mechanical properties 1m high altitude drop Frequency range 10-55HZ, displacement amplitude: 0.35MM, acceleration amplitude: 50.0M/S, sweep frequency cycle times: 30 times Normal electrical and mechanical properties The dimensions shall meet the requirements and shall meet the requirements of the mechanical and electrical properties. The dimensions shall meet the requirements and shall meet the requirements of the mechanical and electrical properties. Relative humidity 95 + 3%, the test temperature: 40 degrees C, after continuing the 2H effect, the test sample after taking out the electrical performance of 5min, test product under normal conditions 1-2H, check the appearance quality Antenna gain 3~4dBi 2.0(nominal) 1.0GHz 2.9(nominal) 2.0GHz 3.2(nominal) 2.4GHz 3.7(nominal) 3.0GHz 4.3(nominal) 4.0GHz 4.8(nominal) 5.0GHz 5.3(nominal) 6.0GHz Attenuation value 3.3dB/m (at20°C) Voltage resistance Normal electrical and mechanical properties 1 insulation spark voltage 1.5KV 2 sheath spark voltage 1.5KV 3 insulation resistance to sheath voltage 0.5KV Normal electrical and mechanical properties 1 temperature is -30 degrees C to +80 2 relative humidity is 45%-85% 3 air pressure is 86kpa-106kpa Drop test Drawing force test Storage environment To test the bearing strength with push pull test instrument: 10N Vibration test Resistance to constant damp heat test Between 70 and 40 degrees C for 5 cycles, and then under normal conditions 1-2H, check the appearance quality. Impedance50 Ohm ProjectTest conditionSpecifications Temperature, humidity, and air pressure are tested in the absence of specified conditions: Normal electrical and mechanical properties Antenna standard parameters Operating frequency range 2.4GHz~2.5GHz /5.15~5.85 GHz S.W.R≤1.92 Switching modeI-pex

This report must not be used to claim product certification, approval, or endorsement by A2LA or any agency of the U.S. Government. This Report shall not be reproduced, except in full without written approval of the laboratory. IrriGreen, Inc. Controller 3, Model 705101 FCC 15.247:2024 Bluetooth Radio Report: IRRI0024.1 Rev. 1, Issue Date: September 17, 2024 TABLE OF CONTENTS 2023.04.17 Section Page Number Certificate of Test ............................................................................................ 3 Revision History .............................................................................................. 4 Accreditations ............................................................................…

Text truncated - open the document above for the full version.
