Rugged Android Tablet PA-301 User’s Guide PA-301 User Guide 2 PA-301 User’s Guide 1 Safety Information 1. Please read these safety instructions carefully. 2. Please keep this User’s Guide for later reference. 3. Please disconnect this device from the power source before cleaning. Do not use liquid or detergent for cleaning. Use a moist sheet or cloth for cleaning. 4. Make sure the device is connected to a power source with the correct voltage, frequency, and ampere. 5. All cautions and warnings on the equipment should be noted. 6. Never pour any liquid into opening to prevent fire or electrical shock. 7. Never open the device. Only qualified service personnel should open the device to prevent damage or personal injury. 8. Get the equipment checked by a service personnel in any of these cases: a. Liquid has penetrated the device. b. The device has been exposed to moisture. c. The equipment has not worked well or you cannot get it to work according to User’s Guide. d. The device was dropped and damaged, and there are obvious signs of breakage. PA-301 User’s Guide 2 9. Caution on the use of the battery: Use only the battery recommended by the manufacturer or the same type of battery installed by the manufacturer. Incorrect battery may cause explosion or fire hazard. Recycle or discard used batteries according to the manufacturer’s instruction or your local authorities. 10. The device uses nonvolatile memory that requires a battery to retain system information when power is removed. The 3V lithium battery is onboard the system. Battery life depends on the amount of time the computer is powered on. If the computer does not display the correct time and date, replace the battery. WARNING: A risk of fire and chemical burn exists if the battery is not handled properly. Do not disassemble, crush, puncture, or short external contacts, or expose the battery to temperatures higher than 60 °C (140 °F). Do not dispose of a used battery in water or fire. CAUTION: There is a danger of explosion if the battery is incorrectly replaced. Replace only with same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. PA-301 User’s Guide 3 FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/ TV technician for help. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. This device is operation in 5.15 – 5.25GHz frequency range, then restricted in indoor use only, Outdoor operations in the 5.15 – 5.25GHz is prohibit. This device is slave equipment; the device is not radar detection and not ad-hoc operation in the DFS band. PA-301 User’s Guide 4 Labeling requirements This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RF exposure warning This equipment must be installed and operated in accordance with provided instructions and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be providing with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. SAR Value: 802.11b/g(2.4GHz): 1.362 W/kg 802.11a(5 GHz): 1.406 W/kg PA-301 User’s Guide 5 Europe – EU Declaration of Conformity This device complies with the essential requirements of the R&TTE Directive 1999/5/EC and EMC directive 2004/108/EC. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the R&TTE Directive 1999/5/EC and EMC directive 2004/108/EC:  EN 55022: 2010 +AC: 2011  EN 61000-3-2: 2006 +A2: 2009  EN 61000-3-3: 2008  EN 55024: 2010  IEC 61000-4-2 ED 2.0 : 2008;  IEC 61000-4-3 ED 3.2 : 2010  IEC 61000-4-4 ED 3.0 : 2012  IEC 61000-4-5 ED 2.0: 2005;  IEC 61000-4-6 ED 3.0 : 2008;  IEC 61000-4-8 ED 2.0 : 2009;  IEC 61000-4-11 ED 2.0 : 2004  IEC 60950-1: 2005 + A1 PA-301 User’s Guide 6 Safety of information technology equipment  EN 302 291-1/-2  EN 300 440-1/-2  EN 300 328  EN 301 893  EN 301 489-1/-3/-17  EN 62311 This device is a 2.4GHz wideband transmission system (transceiver), intended for use in all EU member states and EFTA countries under the following conditions and/or with the following restrictions:  In Italy, the end-user should apply for a license at the national spectrum authorities in order to obtain authorization to use the device for setting up outdoor radio links and/or for supplying public access to telecommunications and/or network services.  This device may not be used for setting up outdoor radio links in France and in some areas the RF output power may be limited to 10mW EIRP in the frequency range of 2454 – 2483.5MHz. For…
