2ABWHPCPP380REAS System

RF TRX 8,2MHz v0.9 RF TRX 8,2MHz DIGITAL SECURITY SYSTEM (RF_TRX_8,2MHz_FW_v0.9) TYPE: INSTALLATION AND SERVICE GUIDE Version 1.3 July 2022 CALLIDUS TRADING spol. s r.o. Page - 2 - This document was created to provide intended recipient documentation of requested device for technician purposes only. Any other usage of this document is an illegal and unlawful act. This document is a confidential and proprietary document and consist of information what can be protected by copyrights or the others intellectual property protection instruments of the others subjects. All other information, what are not generally known ones, is an intellectual property. This document including any and all attachments hereto is intended solely to be used by individual or entity to which it is addressed. If the reader of this document is not the intended recipient, or an employee or agent responsible for delivering this document to its intended recipient, you are herewith notified that any dissemination, distribution, copying or retention of this document or the information contained herein is strictly prohibited. If you have received this document in error, please immediately and permanently delete and destroy the original and any copy or printout thereof. INSTALLATION AND SERVICE This setup and service guide describes how to tune service and troubleshoot RF TRX security system that works on frequency 8.2MHz. DIGITAL SECURITY SYSTEM FEATURES • Remote maintenance and diagnostics • ShopMonitor Lite, RestAPI, MQTT connectivity • Optional Detacher detection • Advertisement space CONTENT 1. OPERATION GUIDELINES ........................................................................................................................................................................................................................................... 3 2. BASIC INFORMATION ................................................................................................................................................................................................................................................ 3 3. PRE-INSTALL TASKS ................................................................................................................................................................................................................................................... 3 4. SPECIFICATIONS ........................................................................................................................................................................................................................................................ 4 4.1 ELECTRICAL ...................................................................................................................................................................................................................................................... 4 5. MOUNTING SECURITY SYSTEM - SINGLE ENTRANCE ................................................................................................................................................................................................. 4 6. ELECTRONIC BOARD RF TRX 8,2MHz ......................................................................................................................................................................................................................... 6 7. EL. BOARD SETTING CONNECTION – SMARTEAS APPLICATION ................................................................................................................................................................................. 7 7.1 CONNECTING TO SMARTEAS APPLICATION ..................................................................................................................................................................................................... 7 7.1.2 REMOTE CONNECTING – INTERNET (ECOMM) .............................................................................................................................................................................................. 9 7.2 SCOPE ............................................................................................................................................................................................................................................................ 10 7.2.1 FREQUENCY RESPONSE ............................................................................................................................................................................................................................... 11 7.2.2 SNR EVALUATION HISTORY ......................................................................................................................................................................................................................... 11 7.3 RF ................................................................................................................................................................................................................................................................... 12 7.4 DD .................................................................................................................................................................................................................................................................. 14 7.5 ALARMS ......................................................................................................................................................................................................................................................... 15 7.6 PEOPLE COUNTERS ........................................................................................................................................................................................................................................ 16 7.7 NETWORKING ........................................…

Text truncated - open the document above for the full version.

CPP+ 380 RF TRX, ISO, white CPP+ 380 RF TRX, FRONT CPP+ 380 RF TRX, REAR Top View of the EUT Bottom View of the EUT Side View of the EUT Location of People Counter

FCC ID: 2ABWHPCPP380R This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation. IC: 29314-PCPP380R Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

RF TRX board RF TRX board, TOP RF TRX board, BOTTOM People counter, TOP People counter, BOTTOM LED Piezo

Apply a duty cycle? no SAR type Head/Body This device FCC ID: is excluded from SAR testing by the following justification The maximum power that the transmitter is capable of is 0.00006 mW* Using formula G.1 from ANSI C63.10: 2013 Using the following formula from section 4.3.1 (c)(2)of KDB 447498{[(Power limit for <50mm) + (separation distance - 50mm) * (100/150)] * [1 + log(100/f(MHz))]} *1/2 Duty Cycle 100.00% Power Threshold 10-g (mW) 494.426 ###### "Value" is  3 , the SAR test exclusion threshold The maximum EUT power is less than the Power Threshold“source-based” time-averaging based on an inherent property or duty-cycle of a device is allowed. An example of this is the determination of exposure from a device that uses digital technology such as a time-division multiple-access (TDMA) scheme for transmission 2ABWHPCPP380R When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. Max Peak Power (dBm) Min Separation distance (mm) Frequency (MHz) -42.09 <50 8.2

Report Number: B20802D1 FCC Part 15 Subpart B and FCC Section 15.223; ICES-003, RSS-210 & RSS-GEN Test Report EAS system Model: CPP+380 RF TRX Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 22 FCC PART 15, SUBPART B and C; ICES-003, RSS-210 & RSS-GEN TEST REPORT for EAS system Model: CPP+380 RF TRX Prepared for Callidus trading, spol. s r.o. Pašerových 1270/1 709 00 Ostrava - Mariánské Hory, Česká republika Prepared by:_____________________ JAMES ROSS Approved by:____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: DECEMBER 6, 2022 REPORT APPENDICES TOTAL BODY A B C D E PAGES 22 2 2 2 18 43 89 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B20802D1 FCC Part 15 Subpart B and FCC Section 15.223; ICES-003, RSS-210 & RSS-GEN Test Report EAS system Model: CPP+380 RF TRX Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 22 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 1.1 Decision Rule & Risk 7 2. ADMINISTRATIVE DATA 8 2.1 Location of Testing 8 2.2 Traceability Statement 8 2.3 Cognizant Personnel 8 2.4 Date Test Sample was Received 8 2.5 Disposition of the Test Sample 8 2.6 Abbreviations and Acronyms 8 3. APPLICABLE DOCUMENTS 9 4. DESCRIPTION OF TEST CONFIGURATION 10 4.1 Description of Test Configuration - Emissions 10 4.1.1 Cable Construction and Termination 10 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 12 5.1 EUT and Accessory List 12 5.2 Emissions Test Equipment 13 6. TEST SITE DESCRIPTION 14 6.1 Test Facility Description 14 6.2 EUT Mounting, Bonding and Grounding 14 6.3 Measurement Uncertainty 15 7. TEST PROCEDURES 16 7.1 RF Emissions 16 7.1.1 Radiated Emissions (Spurious and Harmonics) Test – Lab A 16 7.1.2 Radiated Emissions (Spurious and Harmonics) Test – Lab D 17 7.1.3 Conducted Emissions Test 18 7.1.4 RF Emissions Test Results 19 7.1.5 Sample Calculations 20 7.1.6 Variation of the Input Power 21 8. CONCLUSIONS 22 Report Number: B20802D1 FCC Part 15 Subpart B and FCC Section 15.223; ICES-003, RSS-210 & RSS-GEN Test Report EAS system Model: CPP+380 RF TRX Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 22 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Models Covered Under This Report D Diagrams and Charts  Test Setup Diagrams  Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of Radiated Site 2 Layout of the Semi-Anechoic Test Chamber 3 Conducted Emissions Test Setup LIST OF TABLES TABLE TITLE 1 Radiated Emission Results 2 Conducted Emission Results Report Number: B20802D1 FCC Part 15 Subpart B and FCC Section 15.223; ICES-003, RSS-210 & RSS-GEN Test Report EAS system Model: CPP+380 RF TRX Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 22 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the federal government. Device Tested: EAS system Model: CPP+380 RF TRX P/N: 18-512.CP, 18.512.CBP; 18-513.CS S/N: P0098144 Product Description: The EUT is a system to read RF tags and triggers a visual an acoustic alarm if the RF tag is activated. Used to prevent theft in retail environments. The EUT was tested respectively with two different power supplies, one was rated at 25 watts, while the other was rated at 65 watts. ○ EUT operating frequency: 8.2 MHz ○Oscillators utilized: 32.768 kHz and 25 MHz ○EUT dimensions: 38 cm (W) x 5 cm (D) x 168 cm (H) Modifications: The EUT was not modified during the testing. Customer: Callidus trading, spol. s r.o. Pašerových 1270/1 709 00 Ostrava - Mariánské Hory, Česká republika Test Date: July 29, 2022; and August 1, 2022 Test Specifications : Emissions requirements CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.207, 15.209, and 15.223; ICES-003, RSS-210 and RSS-Gen Test Procedure: ANSI C63.4 and ANSI C63.10 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B20802D1 FCC Part 15 Subpart B and FCC Section 15.223; ICES-003, RSS-210 & RSS-GEN Test Report EAS system Model: CPP+380 RF TRX Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 22 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Spurious Radiated RF Emissions, 9 kHz – 1,000 MHz (Transmitter and Digital portion) Complies with the Class B limits of ICES-003 and CFR Title 47, Part 15 Subpart B; and the limits of …

Text truncated - open the document above for the full version.

Antenna Information for CPP+380 RF TRX 1.General description Antenna loop dimensions are 1450x330mm. There are three different loops every with one turn inside the aluminum profile. Impedance of loops are about 500 Ω There are 2 loops that are connected directly to the electronic board (visualized as blue and green on the picture), and a simple 0 loop (visualized as orange) that is not connected anywhere (it is just short circuit). The picture below will clarify better, notice on the bottom those 2 loops are connected to the board, while the 0 loop is not.

Report Number: B20802D1 FCC Part 15 Subpart B and FCC Section 15.223; ICES-003, RSS-210 & RSS-GEN Test Report EAS system Model: CPP+380 RF TRX Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page D8 WITH 25 WATT POWER SUPPLY LAB A Callidus trading, spol. s r.o. EAS system Model: CPP+380 RF TRX FCC SUBPART B AND C, RSS-GEN, and RSS-210 – RADIATED EMISSIONS – BELOW 30 MHz PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS Radiated - Lab A - 8.2 MHz System - 25 Watt RF - Lab D - 8.2 MHz System - 25 Watt RR - Lab D - 8.2 MHz System - 25 Watt CF -Lab D - 8.2 MHz System - 25 Watt CR -Lab D - 8.2 MHz System - 25 Watt Report Number: B20802D1 FCC Part 15 Subpart B and FCC Section 15.223; ICES-003, RSS-210 & RSS-GEN Test Report EAS system Model: CPP+380 RF TRX Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page D14 WITH 65 WATT POWER SUPPLY Radiated - Lab A - 8.2 MHz System - 65 Watt RF - Lab D - 8.2 MHz System - 65 Watt RR - Lab D - 8.2 MHz System - 65 Watt CF - Lab D - 8.2 MHz System - 65 Watt CR - Lab D - 8.2 MHz System - 65 Watt
