2ABWOCMP765TOUCH SCREEN TABLET_7 inch touch screen display

Please setup Gmail account during initial device setup. If you are going to use a password or a pattern unlock you must have a valid Gmail account setup in the event you forget either. Forgot lock pattern? Here's a way to reset it.  Enter wrong pattern 5 times and wait for 30 seconds.  Select “Forgot pattern” and enter your Gmail account username and password.  Make sure you use the same account that was used to activate the device and double check the password by logging in to that Google account in a browser on laptop or PC.  If you don't have access to the original Gmail account, you will need to do a hard reset and lose your settings and apps on the device. Data on the memory card will not be erased. 1 2 3 4 This manual contains important safety precautions and information for correct usage. Please be sure to read this manual carefully before use to avoid any damage to the device.  Do not place the product in hot, wet or dusty environments.  Do not place the product in hot environments. Especially in summer, do not place it in a car with all the windows closed or in the sun.  Avoid dropping or smashing the product and do not shake the TFT screen excessively as it may cause damage or abnormal display screen.  Select a suitable volume and avoid loud sound while using headphone/earphones. Turn down the volume or stop using the product if your ears start hurting or ringing.  In the following situations, please charge the product: A. The device shows on the top of the screen. B. System automatically shuts down, and it turns off soon after restart. C. Operation buttons do not work properly. D. The unit will not turn on. Note: Chargers of other models cannot be used for this device because they may cause damage to the device that will void the warranty. Please contact our customer service department if you need a replacement charger.  Do not disconnect the device while formatting, downloading and/or uploading; otherwise, application errors may occur.  We are not responsible for any memory erasure or loss caused by damage or product maintenance, or other personal reasons.  Do not disassemble the product, and avoid cleaning the product with ethyl alcohol, thinner, or benzene.  Do not use this product in areas which prohibit the use of electronic devices, for example, in an airplane.  Do not use this product while driving or walking in the street, as it may cause a car accident. Notes:  This device is not waterproof.  All images in this manual are for reference only. Specifications and appearance of the product and the screens are subject to change without prior notice. 5 UPOWER SOURCE:U Battery Recharge The device has Recharging the Battery a built-in DC 3.7V, 2800 mAh rechargeable Lithium-ion Polymer batteries. Recharge as follows:  Insert the small plug from the supplied AC/USB Adaptor to the Micro USB jack on the device. Plug the AC/USB Adaptor to wall outlet having AC 100-240V~, 50/60 Hz.  During charging, the on screen charging icon will turn on. When finished, it will show fully charged icon. This power unit is intended to be in a vertical or floor mount position. Notes: Your battery will last longer if you follow these simple guidelines for caring for and storing it. 1. Using the supplied AC/DC Adaptor for charging only. Other models charger may damage the device. 2. For charging first time, charge it approximately 10 hours. For normal charging, it needs approximately 4 hours. 3. Recharge and store the device within the temperature range of 5°C~35°C (40°F~95°F). 4. Do not overcharge (longer than 24 hours). Excessive charging or running the unit until battery goes empty will damage battery. Battery life will be extended if you keep the battery fully charged. 5. Battery life naturally shortens slowly over time. 6. The rechargeable battery incorporated in this product is not user replaceable. Using the touch screen − Touch the corresponding button on the touch screen with your finger. − Touch the screen and swipe from Right to Left; Left to Right to scroll the pages. Notes:  Do not use force when touching the touch screen, as it may damage to the screen.  To avoid damaging the touch screen, do not use any object other than your fingers.  Do not touch on the touch screen if your fingers are not clean.  Do not touch on the touch screen with gloves on.  The touch screen may not function if you use a fingernail or other instruments Micro SD card This device supports a Micro SD Memory Card (Card not included). To increase memory size, insert an Micro SD card into the card slot on the side of unit as the figure below: 6 Notes: A. Insert the card (Up to 32GB, not included) into the card slot on left side of unit with metal chip face up. B. To take out the card, press the card until a “Touch” is heard then pulls out the card. C. Before replacing the storage card, make sure the unit has been powered off. D. When inserting the storage card, make sure the direction you select is correct. Never insert violently to avoid damaging the card or the unit. If the storage card doesn’t work, please check if the direction is correct. E. When the card is used for the first time, or it has been used in another device, please format it first through the Computer. You also need to download the desired music, photos and/or movie onto the card before installing into the unit Important: Formatting the Micro SD Card will delete all the data on the card. Download the data to your computer before formatting the card. Micro USB Port (USB OTG) This device supports USB device for extending the memory size, or USB Thumb Drive, inserts the supplied USB cable (micro USB plug to Full size USB female jack) into the micro USB port on the side of unit. Insert USB device into Full size USB female jack, like in the PC. Notes:  Before replacing a USB drive, make sure the unit has been powered off.  When inserting the USB driver, make sure the direction you selected is correct. Never insert violently to avoi…

Text truncated - open the document above for the full version.

Everex Electronics Ltd Date: 2014/08/17 FCC ID: 2ABWOCMP765 Subject: Ad Hoc Mode Function Declaration To Whom it may concern, This device is acting as slave and operating in the 2.4 GHz (2412 – 2462 MHz) band. Ad Hoc function is supported but not able to operate on non-US frequencies. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, Yours sincerely, Signatory Signature Date: 2014/08/17 Name: Fanhua woo Title: Manager Tel: 18675257587 Company: Everex Electronics Ltd

Everex Electronics Ltd Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: SUBJECT: FCC Application for ( FCC ID: 2ABWOCMP765 ) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to -government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Signature Date: 2014/08/17 Name: Fanhua woo Title: Manager Tel: 18675257587 Company: Everex Electronics Ltd Address: Unit 03,16F .,Block A,Kailey Industrial Centre,12 Fung Yip Street, Chai Wan ,HONGKONG

Everex Electronics Ltd 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 Everex Electronics Ltd 2014/08/17 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ABWOCMP765 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Date: 2014/08/17 Name: Fanhua woo Title: Manager Tel: 18675257587 Company: Everex Electronics Ltd SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0

Full View Top View Bottom View Rear View Left View Right View Front View

Label: Label Location FCC ID: 2ABWOCMP765 Everex Electronics Ltd Model No.: CMP765 Model name: TOUCH SCREEN TABLET_7 inch touch screen display This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Label: FCC ID: 2ABWOCMP765 Everex Electronics Ltd Model No.: CMP765 Model name: TOUCH SCREEN TABLET_7 inch touch screen display This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

To p Vi e w To p Vi e w Antenna To p Vi e w Bottom View

Differences Description We Everex Electronics Ltd state: FCC ID: 2ABWOCMP765 Product name: TOUCH SCREEN TABLET_7 inch touch screen display Model: CMP765, CMP761, CMP762, CMP763, CMP764, CMP766, CMP767, CMP768, CMP769, CMP765_BUN, EX761, EX762, EX763, EX764, EX765, EX766, EX767, EX768, EX769, EX765_BUN All model’s the function, software and electric circuit are the same , only with a product color and model named different. Signatory Signature Date: 2014/08/17 Name: Fanhua woo Title: Manager Tel: 18675257587 Company: Everex Electronics Ltd

FCC ID: 2ABWOCMP765 RF EXPOSURE TEST FCC ID: 2ABWOCMP765 SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,16 where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation 17  The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID: 2ABWOCMP765 Maximum measured transmitter power. 802.11B frequency range (MHz) Maximum Peak Conducted Output Power (dBm) Maximum Conducted Output Power (mW) Exclusion Thresholds Results Limit 2412 9.61 9.14 2.839 3.0 2437 9.47 8.85 2.763 3.0 2462 9.49 8.89 2.790 3.0 Conclusion: No SAR is required. Note: Exclusion Thresholds Results=[(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] f(GHz) is the RF channel transmit frequency in GHz  Distance=5mm 802.11G frequency range (MHz) Maximum Peak Conducted Output Power (dBm) Maximum Conducted Output Power (mW) Exclusion Thresholds Results Limit 2412 9.02 7.98 2.479 3.0 2437 8.91 7.78 2.429 3.0 2462 8.96 7.87 2.470 3.0 Conclusion: No SAR is required. Note: Exclusion Thresholds Results=[(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] f(GHz) is the RF channel transmit frequency in GHz  Distance=5mm FCC ID: 2ABWOCMP765 802.11N20 frequency range (MHz) Maximum Peak Conducted Output Power (dBm) Maximum Conducted Output Power (mW) Exclusion Thresholds Results Limit 2412 8.63 7.29 2.264 3.0 2437 8.57 7.19 2.245 3.0 2462 8.39 6.90 2.165 3.0 Conclusion: No SAR is required. Note: Exclusion Thresholds Results=[(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] f(GHz) is the RF channel transmit frequency in GHz  Distance=5mm 802.11N 40M frequency range (MHz) Maximum Peak Conducted Output Power (dBm) Maximum Conducted Output Power (mW) Exclusion Thresholds Results Limit 2422 7.79 6.01 1.870 3.0 2437 7.63 5.79 1.808 3.0 2452 7.68 5.86 1.835 3.0 Conclusion: No SAR is required. Note: Exclusion Thresholds Results=[(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] f(GHz) is the RF channel transmit frequency in GHz  Distance=5mm

FCC RADIO TEST REPORT FCC ID: 2ABWOCMP765 Product： TOUCH SCREEN TABLET_7 inch touch screen display Trade Name： ICRAIG; EVEREX Model Name： CMP765 Serial Model： CMP761, CMP762, CMP763, CMP764, CMP766, CMP767, CMP768, CMP769, CMP765_BUN, EX761, EX762, EX763, EX764, EX765, EX766, EX767, EX768, EX769, EX765_BUN Report No.： BZT-2014NT0811144F Prepared for Everex Electronics Ltd Unit 03, 16F., Block A, Kailey Industrial Centre, 12 Fung Yip Street, Chai Wan, HONGKONG Prepared by BZT Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. Page 2 of 74 Report No.: BZT-2014NT0811144F TEST RESULT CERTIFICATION Applicant’s name .............. Everex Electronics Ltd Address .............................. Unit 03, 16F., Block A, Kailey Industrial Centre, 12 Fung Yip Street, Chai Wan, HONGKONG Manufacture's Name ......... Everex Electronics Ltd Address .............................. Unit 03,16F .,Block A,Kailey Industrial Centre,12 Fung Yip Street,Chai Wan ,HONGKONG Product description Product name ....................... TOUCH SCREEN TABLET_7 inch touch screen display Model and/or type reference ........................... CMP765 Serial Model .......................... CMP761, CMP762, CMP763, CMP764, CMP766, CMP767, CMP768, CMP769, CMP765_BUN, EX761, EX762, EX763, EX764, EX765, EX766, EX767, EX768, EX769, EX765_BUN DIFF ....................................... All model’s the function, software and electric circuit are the same , only with a product color and model named different. The test mode is CMP765. Standards .......................... FCC Part15.247 Test procedure ...................... ANSI C63.4-2 003 This device described above has been tested by BZT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BZT, this document may be altered or revised by BZT , personal only, and shall be noted in the revision of the document. Date of Test .......................................... Date (s) of performance of tests ........... 11 August. 2014 ~13 August. 2014 Date of Issue ......................................... 14 August. 2014 Te s t Result ............................................. Pass Testing Engineer : (Lynn Chen) Technical Manager : (Carlen Liu) Authorized Signatory : (Tommy zhang) Page 3 of 74 Report No.: BZT-2014NT0811144F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 3.2.9 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 36 4 . POWER SPECTRAL DENSITY TEST 52 4.1 APPLIED PROCEDURES / LIMIT 52 4.1.1 TEST PROCEDURE 52 4.1.2 DEVIATION FROM STANDARD 52 4.1.3 TEST SETUP 52 4.1.4 EUT OPERATION CONDITIONS 52 4.1.5 TEST RESULTS 53 5 . BANDWIDTH TEST 61 5.1 APPLIED PROCEDURES / LIMIT 61 Page 4 of 74 Report No.: BZT-2014NT0811144F Table of Contents Page 5.1.1 TEST PROCEDURE 61 5.1.2 DEVIATION FROM STANDARD 61 5.1.3 TEST SETUP 61 5.1.4 EUT OPERATION CONDITIONS 61 5.1.5 TEST RESULTS 62 6 . PEAK OUTPUT POWER TEST 70 6.1 APPLIED PROCEDURES / LIMIT 70 6.1.1 TEST PROCEDURE 70 6.1.2 DEVIATION FROM STANDARD 70 6.1.3 TEST SETUP 70 6.1.4 EUT OPERATION CONDITIONS 70 6.1.5 TEST RESULTS 71 7 . ANTENNA REQUIREMENT 72 7.1 STANDARD REQUIREMENT 72 7.2 EUT ANTENNA 72 8 . EUT TEST PHOTO 73 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 74 Report No.: BZT-2014NT0811144F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 74 Report No.: BZT-2014NT0811144F 1.1 TEST FACILITY BZT Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.: 701733 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 74 Report No.: BZT-2014NT0811144F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment TOUCH SCREEN TABLET_7 inch touch screen display Trade Name ICRAIG; EVEREX Model Name CMP765 Serial Model CMP761, CMP762, CMP763, CMP764, CMP766, CMP767, CMP768, CMP769, CMP765_BUN, EX761, EX762, EX763, EX764, EX765, EX766, EX767, EX768, EX769, EX765_BUN Model Difference All model’s the function, software and electric circuit are the same , on…

Text truncated - open the document above for the full version.

Radiated Emission Test Setup in Chamber Conducted Emission Test Setup in Chamber
