2ABY6-RP170CMobile Payment Terminal

RP170c NFC Mobile Card Reader Powering secure mobile- to-mobile transactions • Accept magstripe transactions and NFC/ contactless payments, including Apple Pay, MasterCard contactless, and Visa payWave in a single device • Certifications include EMV Level 1 Contactless, Visa Ready & mPOS MasterCard approved • Support for 100+ iOS and Android™ mobile devices • White labeling options enabling custombranding of device security magstripe contactless audio jack The RP170c enables the acceptance of both card-based transactions and NFC/contactless payments, allowing merchants to offer their customers a fast, simple and secure way to pay – anywhere, anytime. Innovative • NFC/contactless reader and dual track magstripe reader (MSR) in one unit • Accept new and existing forms of NFC/contactless payment like Apple Pay, MasterCard contactless and Visa payWave• Integrated extended life rechargeable battery • Audible buzzer and color LEDs to signal completed contactless transactions Flexible • Compatible with virtually any iOS or Android device and connects via a 3.5mm standard audio jack • Secure APIs compatible with hundreds of iOS and Android™ mobile devices • White labeling options enabling custom-branding of device • Universal SDK across RP- and G-series mobile card readers with automatic device identification Secure • EMV L1 Contactless certified, and compliant with the latest Visa Ready and MasterCard guidelines • End-to-end encryption of cardholder data upon swipe or NFC/contactless tap • Developed by the world’s first and most experienced provider of secure mobile card readers Feature Description Card Readers Magnetic card reader: Standard (ISO 7810, 7813, Track 1 & 2) Contactless reader: Standard (ISO 1443 A&B) with 4 LEDs Display 1x LED for device & battery status, 4x LEDs for contactless Buzzer Yes Connectivity Audio jack: for communication with mobile device Battery Li-ion - 260 mAh Battery Life Minimum 200 magstripe or 50 contactless transactions, over 1 week Dimensions 66 x 49 x 16mm / 2.60 x 1.93 x .63in (l x w x h) Certifications EMV L1 contactless PayPass Paywave Power Supply via μUSB AB cable • TR-39 & PCI PIN 2.0 certified facility for in-factory DATA key injection

We, Roam Data, Inc. Roam Data Inc. QA-FR-170-B ADD: 280 Summer St Boston, Massachusetts, Boston,US TEL: 857-254-2365 FAX: 617-904-0151 FCC Authorization Date: 2015-08-03 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: , the undersigned, Hereby authorizes Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratories Corp. on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Client’s signature Sriram Seetharam Devices Product Manager

Roam Data Inc. QA-FR-171-A ADD: 280 Summer St Boston, Massachusetts, Boston,US TEL: 857-254-2365 FAX: 617-904-0151 FCC Confidential Authorization Date:2015-08-03 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2ABY6-RP170C In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Inc. hereby requests long-term confidential treatment of information accompanying this application as outlined below: • Block Diagram • Detailed Circuit Schematics of EUT • Circuit Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Client’s signature Sriram Seetharam Devices Product Manager Roam Data

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT—All View EUT— Top View EUT- Bottom View EUT- Side View EUT- Side View EUT- Side View EUT- Side View

EXHIBIT A - FCC ID LABELING AND LOCATION FCC ID Label Proposed FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925) Label Here

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS EUT- Uncover View EUT- Main Board Top View EUT- Main Board Bottom View EUT- Battary View EUT- Antenna View NFC Antenna

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Dongguan). This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. FCC PART 15C TEST REPORT For ROAM Data Inc. 280 Summer St, Boston MA, USA FCC ID: 2ABY6-RP170C Report Type: Original Report Product Type: Mobile Payment Terminal Test Engineer: Dean Liu Report Number: RXM150610050-00A Report Date: 2015-06-24 Reviewed By: Sula Huang RF Leader Test Laboratory: Bay Area Compliance Laboratories Corp. (Dongguan) No.69 Pulongcun, Puxinhu Industrial Zone, Tangxia, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RXM150610050-00A FCC Part 15.225 Page 2 of 19 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) .................................................................................... 3 OBJECTIVE ................................................................................................................................................................... 3 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................. 3 TEST METHODOLOGY .................................................................................................................................................. 3 TEST FACILITY ............................................................................................................................................................. 3 SYSTEM TEST CONFIGURATION .......................................................................................................................... 4 JUSTIFICATION ............................................................................................................................................................. 4 EUT EXERCISE SOFTWARE .......................................................................................................................................... 4 LOCAL SUPPORT EQUIPMENT LIST AND DETAILS ........................................................................................................ 4 SUPPORT CABLE LIST AND DETAILS ............................................................................................................................ 4 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 4 SUMMARY OF TEST RESULTS ............................................................................................................................... 5 FCC§15.203 - ANTENNA REQUIREMENT .............................................................................................................. 6 APPLICABLE STANDARD .............................................................................................................................................. 6 ANTENNA CONNECTED CONSTRUCTION ...................................................................................................................... 6 FCC §15.207 – AC LINE CONDUCTED EMISSION ............................................................................................... 7 MEASUREMENT UNCERTAINTY .................................................................................................................................... 7 EUT SETUP .................................................................................................................................................................. 7 EMI TEST RECEIVER SETUP ......................................................................................................................................... 8 TEST EQUIPMENT LIST AND DETAILS ........................................................................................................................... 8 TEST PROCEDURE ........................................................................................................................................................ 8 CORRECTED AMPLITUDE & MARGIN CALCULATION ................................................................................................... 9 TEST RESULTS SUMMARY ............................................................................................................................................ 9 TEST DATA .................................................................................................................................................................. 9 FCC§15.225, §15.205 & §15.209 - RADIATED EMISSIONS TEST ...................................................................... 12 APPLICABLE STANDARD ............................................................................................................................................ 12 MEASUREMENT UNCERTAINTY .................................................................................................................................. 12 EUT SETUP ................................................................................................................................................................ 13 EMI TEST RECEIVER SETUP ....................................................................................................................................... 13 CORRECTED AMPLITUDE & MARGIN CALCULATION ................................................................................................. 13 TEST EQUIPMENT LIST AND DETAILS .................................................................…

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Conducted Emissions - Front View Conducted Emissions – Side View Radiated Emission -Front View (9kHz~30MHz) Radiated Emission - Rear View (9kHz~30MHz) Radiated Emission -Front View (30MHz-1GHz) Radiated Emission - Rear View (30MHz-1GHz)
