2AC2O-CHU200TPRCDesktop Payment Terminal

Radiation Hazard Assessment Date 26 th November 2025 FCC ID 2AC2O-CHU200TPRC Brand Name Windcave Product Desktop Payment Terminal Model Number CHU200TP Release C Manufacturer Windcave Limited Country of Origin New Zealand Serial Number(s) 3425230068 Firmware version v3.0.0.6-E Antenna type and gain The NFC antenna is a 2-turn loop antenna around the perimeter of the LCD with gain of zero. The device tested is Desk Payment Terminal with a number of features that would typically be used for the payment in a retail situation. The device contains a NFC Card Reader that operates on 13.560 MHz The product is powered at 12 Vdc using a power supply that is connected to the 120 Vac 60 Hz Public AC mains supply. FCC part 15 testing as detailed in EMC Technologies NZ Ltd test report number 250507.1 dated 17 th A ugust 2025 shows the following: When transmitting on 13.560 MHz a field strength of 40.8 dBuV/m was measured at 10 metres which gives a calculated transmitter power of 0.00004 mW. Calculations were made using the formula: Power (watts) = ((field strength (V/m) x distance (metres)) 2 )/30 As per FCC KDB 447498 D04 and Section 2.1091 radio frequency transmitters are required to be operated in a manner that ensures the public is not exposed to high levels of RF energy. In normal use the transmitter in this device may come in close contact with the human body, the hand, when cards are placed in or near the device when a transaction is carried out. As the radiated power is below 1 mW this transmitter will be below the SAR testing threshold and therefore no further action will be required. Result: Complies

Windcave Limited 33 Wilkinson Road, Ellerslie Auckland 1060 New Zealand United States of America Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 16/11/2025 SUBJECT: FCC Application for 2AC2O-CHU200TPRC To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Regards, Cameron Collard Global Head of Compliance Risk & PMO Windcave Limited

Windcave Limited 33 Wilkinson Road, Ellerslie Auckland 1060 New Zealand Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 12-02-2025 Ref: Attestation Statements Part 2.911(d)(5)(i) and Part 2.911(d)(5)(ii) Filing FCC ID: 2AC2O-CHU200TPRC Windcave Limited (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Windcave Limited (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, Cameron Collard Windcave Limited 33 Wilkinson Road, Ellerslie Auckland 1060 New Zealand Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 12-02-2025 Ref: Attestation Statements Part 2.911(d)(5)(i) and Part 2.911(d)(5)(ii) Filing FCC ID: 2AC2O-CHU200TPRC Windcave Limited (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Cameron Collard

Windcave 33 Wilkinson Road, Ellerslie Auckland 1060 New Zealand United States of America Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 20 January 2026 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: 2AC2O-CHU200TPRC FCC FRN: 0026591925 Windcave (“the applicant”) certifies that, as of the date of the filing of the application, the Windcave Inc. office located in Phoenix, Arizona is our designated U.S. agent for service of process for the above referenced FCC ID. Windcave accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The Windcave Inc. office located in Phoenix, Arizona accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Windcave Inc. FRN: 0026591925 Address: 1601 N 7th Street, Suite 420, Phoenix, AZ 85006 Contact Person: Cameron Collard Tel.: +1 213 378 1190 Email: [email protected] Sincerely, Cameron Collard Global Head of Compliance Risk & PMO Windcave Cameron Collard Global Head of Compliance Risk & PMO Windcave Inc., as Designated U.S. Agent

Windcave 33 Wilkinson Road, Ellerslie Auckland 1060 New Zealand 20 January 2026 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD21046 United States of America Subject: Third Party Confidentiality Request for Exhibits under FCC ID: 2AC2O-CHU200TPRC To Whom It May Concern: Pursuant of Section 0.457 and 0.459 of the Commission’s Rules and KDB 726920 D01 Confidentiality Request Procedures, we hereby request that the exhibits listed below, submitted in support of the certification application for FCC ID: 2AC2O- CHU200TPRC, be withheld permanently from public disclosure: •S chematics •Block Diagram •Operational Description •Internal Photographs •Hardware Guide T he above exhibits, owned solely by Windcave Limited, contain trade secrets and proprietary information which is not routinely available to the public or to our competitors. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Confidentiality of the internal photographs is specifically sought because the device could be re- engineered from the photographs. Windcave 33 Wilkinson Road, Ellerslie Auckland 1060 New Zealand Windcave controls information about and access to the device as follows: • The schematics, internal photographs and the like are only used internally by Windcave or by those 3 rd parties as are required to complete product testing. Windcave staff are subject to confidentiality obligations under their employment agreements. Third parties completing product testing are subject to NDAs or equivalent confidentiality obligations in their terms of service. • Internal photographs are not made available to customers or end users. Sales of these devices to customers or resellers are subject to customer and reseller agreements which contain confidentiality obligations prohibiting reverse engineering and restricting the disclosure of proprietary information. • User manuals do not include schematics, internal photographs, detailed descriptions of device operation or detailed block diagrams. User manuals are provided to customers and resellers, and are not confidential in nature. • To meet strict Payment Card Industry (www.pcisecuritystandards.org) security requirements, the devices include security mechanisms which disable the device if it is opened and prevent the modification of the firmware by the user. • The PCI Security Standards require that all devices are returned to Windcave Ltd. at their end of life. Therefore Section 7.6 of the Windcave Customer Contract states: “Consequences of termination: On the termination of this Agreement, you must immediately: a) return all Windcave Limited Products to Windcave Limited...” The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Yours sincerely Cameron Collard Global Head of Compliance Risk & PMO Windcave

Windcave Limited 33 Wilkinson Road, Ellerslie Auckland 1060 New Zealand 16 November 2025 EMC Technologies NZ LTD 47 Mackelvie Street Grey Lynn Auckland 1021 To Whom It May Concern I hereby authorize Andrew Cutler, General Manager of EMC Technologies NZ Ltd to act on Windcave Ltd behalf with regard to FCC and ISED Certification of the CHU200TP Release C device. FCC-ID: 2AC2O-CHU200TPRC ISED Number: 26550-CHU200TPRC Contains: 4G Modem: FCC ID: XPYNINAW15, IC:8595A-NINAW15 WIFI Modem: FCC ID: N7NHL78A Yours Sincerely Cameron Collard Global Head of Compliance Risk & PMO Windcave Limited

The client advises that to fit this label on the product the letter will need to be set to 4 This means the label would be the following size: CHU200TP-REL C HW: CHU200T-C-P2-00 AB273-C11 FCC ID: 2AC2O-CHU200TPRC IC ID 26550-CHU200TPRC Contains FCC ID: XPYNINAW15 Contains IC:8595-NINAAW15 Contains FCC ID: N7NHL78A Contains IC: 2417C-HL78A www.windcave.com Made in New Zealand
