2AC2O-SCR200MONear Field Contactless Secure Card Reader

SCR200MO Hardware Guide Version 0.5 Procedure: Number 56 – SCR200MO Hardware Guide Date: June 2020 Approved by: Implementation Manager Copyright © Copyright 2020, Windcave Inc. www.windcave.com All rights are reserved. No part of this work may be reproduced or copied in any form or by any means, electronic or mechanical, including photocopying, without the express written permission of Windcave Inc. Proprietary Notice The information described in this document is proprietary and confidential to Windcave Inc. Any unauthorised use of this material is expressly prohibited except as authorised by Windcave Inc. in writing. This document is uncontrolled when printed Procedure: Number 56 – SCR200MO Hardware Guide Date: June 2020 Approved by: Implementation Manager Document Revision Information and Amendments All amendments are to be identified and the manual updated, noting the amendment on this amendment page. Version Date Section Revision Information Amended by 0.1 2020/05/25 All Initial Draft KH 0.2 2020/06/08 1 2 Updated introduction and description of device Updated hardware overview, power requirements, temperature ratings and compliance & standards KH 0.3 2020/06/10 3 Added note about using non-metallic mounting plate KH 0.4 2020/06/10 1 Updated introduction KH 0.5 2020/06/12 2 Formatting update KH Related Documents Document Title Link/Location Procedure: Number 56 – SCR200MO Hardware Guide Date: June 2020 Approved by: Implementation Manager SCR200MO Hardware Guide Version: 0.5 Page | 3 of 12 Contents 1 Overview ................................................................................................................................................................ 4 1.1 Introduction ................................................................................................................................................ 4 1.2 Hardware Models ...................................................................................................................................... 4 1.3 Connectivity ................................................................................................................................................ 4 2 SCR200MO ........................................................................................................................................................... 5 2.1 Hardware Overview ................................................................................................................................... 5 2.1.1 Physical Link Interface ......................................................................................................................... 5 2.1.2 Power Requirements............................................................................................................................ 5 2.1.3 Operating & Storage Temperature Ratings ..................................................................................... 5 2.1.4 Standards & Compliance ..................................................................................................................... 6 2.1.5 Additional Comments .......................................................................................................................... 6 2.1.5.1 FCC Part 15 User Information ................................................................................................... 6 2.2 SCR200MO Dimensions .......................................................................................................................... 7 3 Machine Face & Cut-out Dimensions .............................................................................................................. 9 3.1 SCR200MO ................................................................................................................................................. 9 4 Installation .......................................................................................................................................................... 10 5 Maintenance....................................................................................................................................................... 11 5.1 Tradeouts & Deactivation Process ...................................................................................................... 11 5.2 Cleaning Instructions .............................................................................................................................. 11 6 Document Control Procedure ......................................................................................................................... 12 Procedure: Number 56 – SCR200MO Hardware Guide Date: June 2020 Approved by: Implementation Manager SCR200MO Hardware Guide Version: 0.5 Page | 4 of 12 1 Overview 1.1 Introduction The Windcave SCR200MO solution is a contactless secure card reader. It can act as an accessory to the SCR200F for the handling of contactless reads, or act as a standalone contactless payment solution. The standalone option provides a simple solution for accepting contactless payments in an unattended card present environment; where only contactless payments are required. Integration of the SCR200MO standalone mode utilizes the same global Serial API specification accepted by the SCR solutions. Windcave develops and owns the hardware design, intellectual property and processor platform to ensure end to end accountability from card read to bank card provider. 1.2 Hardware Models Model Description SCR200MO Contactless Secure Card Reader 1.3 Connectivity The connector for the device is on the rear of the unit, this connector is used to connect the SCR200MO to other Windcave secure card readers. Procedure: Number 56 – SCR200MO Hardware Guide Date: June 2020 Approved by: Implementation Manager SCR200MO Hardware Guide Version: 0.5 Page | 5 of 12 2 SCR200MO 2.1 Hardware Overview 2.1.1 Physical Link Interface Refer to connectivity 1.3 2.1.2 Power Requirements The devic…

Text truncated - open the document above for the full version.

18 May 2020 EMC Technologies NZ Ltd PO Box 68307 Newton Auckland New Zealand To Whom It May Concern I hereby authorize Andrew Cutler, General Manager of EMC Technologies NZ Ltd to act on Windcave Ltd behalf with regard to FCC Certification of the SCR200MO transmitter. Yours Sincerely Cameron Collard Global Head of Compliance, Risk and PMO Windcave Limited FCC ID: 2AC2O-SCR200MO

Windcave Limited 33 Wilkinson Road, Ellerslie Auckland 1060 New Zealand 30 June 2020 Federal Communications Commission Equipment Authorisation Branch 7435 Oakland Mills Road Columbia, MD21046 United States of America Subject: Third Party Confidentiality Request for Exhibits under FCC ID: 2AC2O-SCR200MO To Whom It May Concern: Pursuant of Section 0.457 and 0.459 of the Commission’s Rules and KDB 726920 D01 Confidentiality Request Procedures, we hereby request that the exhibits listed below, submitted in support of the certification application for FCC ID: 2AC2O-SCR200MO, be withheld permanently from public disclosure:  Schematics  Block Diagram  Operational Description  Internal Photographs The above exhibits, owned solely by Windcave Limited, contain trade secrets and proprietary information which is not routinely available to the public or to our competitors. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Confidentiality of the internal photographs is specifically sought because the device could be re- engineered from the photographs. Windcave controls information about and access to the device as follows: Windcave Limited 33 Wilkinson Road, Ellerslie Auckland 1060 New Zealand  The schematics, internal photographs and the like are only used internally by Windcavee or by those 3 rd parties as are required to complete product testing.  User manuals do not include schematics, internal photographs, detailed descriptions of device operation or detailed block diagrams.  To meet strict Payment Card Industry (www.pcisecuritystandards.org) security requirements, the devices include security mechanisms which disable the device if it is opened and prevent the modification of the firmware by the user.  The PCI Security Standards require that all devices are returned to Windcave Ltd. at their end of life. Therefore Section 7.6 of the Windcave Customer Contract states: “Consequences of termination: On the termination of this Agreement, you must immediately: a) return all Windcave Limited Products to Windcave Limited...” The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Yours sincerely Cameron Collard Global Head of Compliance, Risk and PMO Windcave Limited

FCC ID: 2AC2O-SCR200MO Left hand side and bottom face of the product Top face Right side face FCC ID: 2AC2O-SCR200MO Front face of the product under power on condition Rear face: Has a connector through which the product is connected to a computer via RS‐232 to Serial Convertor. FCC ID: 2AC2O-SCR200MO

FCC ID: 2AC2O‐SCR200MO Label submitted by client: Label on tested sample:

____________________________________________________________________________________________________________________________________________________________________________ Page 1 of 23 Test Report No 200103.1 28 th February 2020 This report may not be reproduced except in full. EMC Technologies (NZ) Ltd 47 Mackelvie St, Grey Lynn Auckland 1021 New Zealand Phone 09 360 0862 Fax 09 360 0861 E-Mail Address: [email protected] Web Site: www.emctech.co.nz TEST REPORT Windcave SCR200MO Near Field Contactless Secure Card Reader tested to the specification 47 Code of Federal Regulations Part 15 - Radio Frequency Devices Subpart C – Intentional Radiators Section 15.225 Operation within the band 13.110 -14.010 MHz for Windcave Ltd This test report is issued with the authority of: ______________________________ Andrew Cutler - General Manager ____________________________________________________________________________________________________________________________________________________________________________ Page 2 of 23 Test Report No 200103.1 28 th February 2020 This report may not be reproduced except in full. Table of Contents 1. STATEMENT OF COMPLIANCE 3 2. RESULTS SUMMARY 3 3. INTRODUCTION 4 4. CLIENT INFORMATION 4 5. DESCRIPTION OF TEST SAMPLE 5 6. SETUPS AND PROCEDURES 6 7. TEST EQUIPMENT USED 15 8. ACCREDITATIONS 15 9. PHOTOGRAPHS 16 ____________________________________________________________________________________________________________________________________________________________________________ Page 3 of 23 Test Report No 200103.1 28 th February 2020 This report may not be reproduced except in full. 1. STATEMENT OF COMPLIANCE The Windcave SCR200MO Near Field Contactless Secure Card Reader complies with FCC Part 15 Subpart C Section 15.225 as an Intentional Radiator when the methods as described in ANSI C63.10 - 2013 are applied. 2. RESULTS SUMMARY The results from testing carried out in between February 4 th to 20 th , 2020 are detailed in the following table: Clause Parameter Result 15.201 Equipment authorisation requirement Certification required. 15.203 Antenna requirement Complies. Antenna internal to the device. 15.204 External PA and antenna modifications Not applicable. No external devices. 15.205 Restricted bands of operation Complies. Device transmits on a nominal frequency of 13.560 MHz. 15.207 Conducted limits Complies. 15.209 Radiated emission limits - Emissions < 30 MHz Complies. 15.209 Radiated emission limits – Emissions > 30 MHz Complies. 15.225 Radiated emission limits - Fundamental Complies. 15.225 Frequency stability Complies. ____________________________________________________________________________________________________________________________________________________________________________ Page 4 of 23 Test Report No 200103.1 28 th February 2020 This report may not be reproduced except in full. 3. INTRODUCTION This report describes the tests and measurements performed for the purpose of determining compliance with the specification. The client selected the test sample. This report relates only to the sample tested. This report contains no corrections or erasures. Measurement uncertainties with statistical confidence intervals of 95% are shown below test results. Both Class A and Class B uncertainties have been accounted for, as well as influence uncertainties where appropriate. All compliance statements have been made with respect of the specification limit with no reference to the measurement uncertainty. All testing was carried out as per the standard in the worst-case configuration with no deviations being applied. 4. CLIENT INFORMATION Company Name Windcave Ltd Address 33 Wilkinson Rd, Ellerslie State Auckland 1060 Country New Zealand Contact Mr Mark England ____________________________________________________________________________________________________________________________________________________________________________ Page 5 of 23 Test Report No 200103.1 28 th February 2020 This report may not be reproduced except in full. 5. DESCRIPTION OF TEST SAMPLE Brand Name Windcave Product Near Field Contactless Secure Card Reader Model Number SCR200MO Manufacturer Windcave Limited Country of Origin New Zealand Serial Number 2419090004 FCC ID 2AC2O-SCR200MO The device tested is a Near Field Contactless Secure Card Reader (NFC Card Reader) that operates on 13.560 MHz. When operating this device would normally be installed with in a host device that would supply power and data processing capabilities. Testing was carried out using ancillary items that consisted of a laptop computer and a USB to serial conversion device which supplied 5 Vdc which powered the device. The client has not supplied a highest frequency in use in the device but based upon the results obtained this has been assumed to be less than 108 MHz. ____________________________________________________________________________________________________________________________________________________________________________ Page 6 of 23 Test Report No 200103.1 28 th February 2020 This report may not be reproduced except in full. 6. SETUPS AND PROCEDURES Standard The sample was tested in accordance with 47 CFR Part 15 Subpart C. Methods and Procedures The measurement methods and procedures as described in ANSI C63.10 - 2013 were used. Section 15.201: Equipment authorisation requirement Certification as detailed in Subpart J of Part 2 is required for this device. Section 15.203: Antenna requirement The device has a permanently attached internal 13.560 MHz antenna. Result: Complies. Section 15.204: External radio frequency power amplifiers and antenna modifications It is NOT possible to attach an external power amplifier to this transmitter. Result: Complies. Section 15.205: Restricted bands of operation The device transmits on a nominal frequency of 13.560 MHz. 13.560 MHz transmissions would fall into the 13.110 – 14.010 MHz band that is covered by Section 15.225. Result: Complies. _____…

Text truncated - open the document above for the full version.

Conducted emissions test set up FCC ID: 2AC2O-SCR200MO FCC ID: 2AC2O-SCR200MO Radiated emissions test set up FCC ID: 2AC2O-SCR200MO FCC ID: 2AC2O-SCR200MO FCC ID: 2AC2O-SCR200MO Test Shed showing the use of a Biconical Antenna FCC ID: 2AC2O-SCR200MO ____________________________________________________________________________________________________________________________________________________________________________ Test shed showing the use of a log periodic antenna FCC ID: 2AC2O-SCR200MO ____________________________________________________________________________________________________________________________________________________________________________ Test shed showing a loop antenna in use. FCC ID: 2AC2O-SCR200MO
