2AC8UA2005Amazfit band 6

Amazfit band User Manual Read this manual carefully before use, and retain it for future reference. Product Overview Product Overview Installation 1. Insert one end of the fifitness tracker into the slot from the front of the wristband. 2. Press down on the other end with your thumb to push the fifitness tracker completely into the slot. Wearing 1. Comfortably tighten the band around your wrist, about 1 fifinger width away from your wrist bone. 2. To achieve the optimal performance of the heart rate sensor, make sure its back to contact with your skin. When wearing your wristband, keep it neither too tight nor too loose but leaving some space for the skin to be able to breathe. Tighten the wristband before you start to exercise and properly loosen it afterward. Connecting 1. The Amazfit band can be connected to the Amazfit app. Scan the QR code below, or search for Amazfit in Google Play or Apple's App Store to download and install the Amazfit app. 2. Log into your Amazfit account in the Amazfit app, and follow the instructions to connect and pair the band with your phone. Once the band vibrates and a pairing request is displayed on its screen, tap the touch button to complete the pairing with your phone. Note: Make sure the Bluetooth on your phone is enabled. Hold the phone and the band close to each other during pairing. Usage After successfully pairing with your device, the band will start tracking and analyzing your daily activities and sleeping habits. Touch the button to light up the screen. Swipe up or down to view various functions such as PAI (Personal Activity Intelligence), exercise data, and heart rate measurements. Swipe right to return to the previous page. Disassembly Remove the band from your wrist, hold on to each end and pull on the wristband until you see a small gap between the fitness tracker and the wristband. Use your finger to pop the fitness tracker out of its slot from the front side of the wristband. Charging Recharge your band immediately when the battery level is low. Precautions When using the band to measure your heart rate, please keep your wrist still. The Amazfit band has a water resistance rating of 5 ATM. It can be worn in the shower, swimming pool, or while swimming near the shore. It cannot be used, however, in a sauna or while scuba diving. The function of the touch button and touchscreen are not accessible during underwater. When your band comes in contact with water, use a soft cloth to wipe away excess water from its surface before using it. During daily use, avoid wearing the band too tightly and try to keep its contact area dry. Please clean the wristband regularly with water. Please stop using the product immediately and seek medical assistance if the contact area on your skin shows signs of redness or swelling. Specifications Name: Amazfit band Model: A2005 Net Weight: 11.9 g Fitness Tracker Dimensions: 46.95 × 18.15 × 12.45 mm Wristband Material: Thermoplastic elastomer (TPE) Clasp Material: AluAmazfitnum alloy Adjustable Length: 155–219 mm Compatible with: Android 5.0 & iOS 10.0 or above Baery Capacity: 125 mAh Baery Type: Lithium polymer baery Input voltage: DC 5.0 V Input Current: 250 mA Max. IP Rating: 5 ATM Bluetooth Frequency: 2402–2480 MHz Operating Temperature: -10°C to 50°C Wireless Connectivity: Bluetooth 5.0 BLE Disposal and Recycling Information All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/EU) which should not be mixed with unsorted household waste. Instead, you should protect human health and the environment by handing over your waste equipment to a designated collection point for the recycling of waste electrical and electronic equipment, appointed by the government or local authorities. Correct disposal and recycling will help prevent potential negative consequences to the environment and human health. Please contact the installer or local authorities for more information about the location as well as terms and conditions of such collection points. Certifications and Safety Approvals Hereby, Shenzhen Yecon Industry Co. Ltd., declares that the radio equipment type A2005 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: hp://www.mi.com/global/service/support/declaration.html For regulatory information, product certification, and compliance logos related to the Amazfit band, please go to More > Settings > Regulatory. Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence- exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1) L’appareil ne doit pas produire de brouillage; 2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection agains…

Text truncated - open the document above for the full version.

FCC ID: 2AC8UA2005 IC: 21806-A2005 Page 1 of 3 External Picture FCC ID: 2AC8UA2005 IC: 21806-A2005 Page 2 of 3 External view of EUT External view of EUT FCC ID: 2AC8UA2005 IC: 21806-A2005 Page 3 of 3 View of accessories

FCC ID: 2AC8UA2005 IC: 21806-A2005 Page 1 of 6 Internal Picture FCC ID: 2AC8UA2005 IC: 21806-A2005 Page 2 of 6 Internal view of EUT Internal view of EUT FCC ID: 2AC8UA2005 IC: 21806-A2005 Page 3 of 6 Internal view of EUT Front view of PCB FCC ID: 2AC8UA2005 IC: 21806-A2005 Page 4 of 6 Internal view of EUT Antenna of EUT FCC ID: 2AC8UA2005 IC: 21806-A2005 Page 5 of 6 Back view of PCB Internal battery pack (EVE PL401223GH) FCC ID: 2AC8UA2005 IC: 21806-A2005 Page 6 of 6 Internal battery pack (Everpower PL401224H) Internal battery pack (ATL PL401323)

Anhui Huami Information Technology Co., Ltd. SAR COMPLIANCE REPORT Report Type: FCC SAR assessment report Model: A2005 REPORT NUMBER: 200401756SHA-002 ISSUE DATE: June 3, 2020 DOCUMENT CONTROL NUMBER: TTRFFCCSAR-01_V1 © 2018 Intertek Intertek Testing Services Shanghai Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRFFCCSAR-01_V1© 2018 Intertek Page 2 of 8 Report no.: 200401756SHA-002 Applicant: Anhui Huami Information Technology Co., Ltd. Room 1201, Building A4, National Animation Industry Base, No. 800 Wangjiang West Road, Gaoxin District, Hefei, Anhui, China Manufacturer: Anhui Huami Information Technology Co., Ltd. Room 1201, Building A4, National Animation Industry Base, No. 800 Wangjiang West Road, Gaoxin District, Hefei, Anhui, China FCC ID: 2AC8UA2005 SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: KDB447498 D01 General RF Exposure Guidance v06 FCC Part2.1091, FCC Part2.1093 FCC Part1.1307(b) PREPARED BY: REVIEWED BY: Project Engineer Erick Liu Reviewer Daniel Zhao Report No.: 200401756SHA-002 TEST REPORT TTRFFCCSAR-01_V1© 2018 Intertek Page 3 of 8 Revision History Report No. Version Description Issued Date 200401756SHA-002 Rev. 01 Initial issue of report June 3, 2020 Report No.: 200401756SHA-002 TEST REPORT TTRFFCCSAR-01_V1© 2018 Intertek Page 4 of 8 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test (EUT) Product name: Amazfit band 6 Type/Model: A2005 Description of EUT: The EUT is a smart band with BLE function, it has only one model. It contains a charging wire, the model is CSH2020. Rating: 5Vdc, 250mA max Category of EUT: Class B EUT type: Table top Floor standing Software Version: / Hardware Version: / Sample received date: April 24, 2020 Date of test: April 27, 2020 – May 15, 2020 1.2 Technical Specification Frequency Range: 2402-2480MHz Support Standards: IEEE 802.15.1 Type of Modulation: GFSK Channel Number: 40 Channel Separation: 2MHz Antenna Information: 0.31dBi, FPC antenna Report No.: 200401756SHA-002 TEST REPORT TTRFFCCSAR-01_V1© 2018 Intertek Page 5 of 8 1.3 Description of Test Facility Name: Intertek Testing Services Shanghai Address: Building 86, No. 1198 Qinzhou Road(North), Shanghai 200233, P.R. China Telephone: 86 21 61278200 Telefax: 86 21 54262353 The test facility is recognized, certified, or accredited by these organizations: CNAS Accreditation Lab Registration No. CNAS L0139 FCC Accredited Lab Designation Number: CN1175 IC Registration Lab CAB identifier.: CN0051 VCCI Registration Lab Registration No.: R-14243, G-10845, C-14723, T-12252 A2LA Accreditation Lab Certificate Number: 3309.02 Report No.: 200401756SHA-002 TEST REPORT TTRFFCCSAR-01_V1© 2018 Intertek Page 6 of 8 2 SAR Assessment Test result: Pass 2.1 SAR Test Exclusion Limit 100 MHz – 6 GHz and ≤ 50 mm Report No.: 200401756SHA-002 TEST REPORT TTRFFCCSAR-01_V1© 2018 Intertek Page 7 of 8 100 MHz – 6 GHz and > 50 mm < 100 MHz and < 200 mm Report No.: 200401756SHA-002 TEST REPORT TTRFFCCSAR-01_V1© 2018 Intertek Page 8 of 8 2.2 Assessment Results The highest EIRP adjusted with tune-up tolerance is -0.22dBm = 0.95mW < 10mW (Test Exclusion Thresholds of 2450MHz at 5mm). Therefore, the SAR requirement is deemed to be satisfied without test. ******************************************* END ************************************

Anhui Huami Information Technology Co., Ltd. RF TEST REPORT Report Type: FCC Part 15.247 & ISED RSS-247 RF report Model: A2005 REPORT NUMBER: 200401756SHA-001 ISSUE DATE: July 14, 2020 DOCUMENT CONTROL NUMBER: TTRF15.247-02_V1 © 2018 Intertek Intertek Testing Services Shanghai Building No.86, 1198 Qinzhou Road (North) Caohejing Development Zone Shanghai 200233, China Telephone: 86 21 6127 8200 www.intertek.com TEST REPORT This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. TTRF15.247-02_V1 © 2018 Intertek Page 2 of 41 Report no.: 200401756SHA-001 Applicant: Anhui Huami Information Technology Co., Ltd. Room 1201, Building A4, National Animation Industry Base, No. 800 Wangjiang West Road, Gaoxin District, Hefei, Anhui, China Manufacturer: Anhui Huami Information Technology Co., Ltd. Room 1201, Building A4, National Animation Industry Base, No. 800 Wangjiang West Road, Gaoxin District, Hefei, Anhui, China FCC ID: 2AC8UA2005 IC: 21806-A2005 SUMMARY: The equipment complies with the requirements according to the following standard(s) or Specification: 47CFR Part 15 (2019): Radio Frequency Devices (Subpart C) ANSI C63.10 (2013): American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices RSS-247 Issue 2 (February 2017): Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSs) and Licence-Exempt Local Area Network (LE-LAN) Devices RSS-Gen Issue 5 Amendment 1 (March 2019): General Requirements for Compliance of Radio Apparatus PREPARED BY: REVIEWED BY: Project Engineer Erick Liu Reviewer Daniel Zhao Report No.: 200401756SHA-001 TEST REPORT TTRF15.247-02_V1 © 2018 Intertek Page 3 of 41 Content REVISION HISTORY................................................................................................................................................ 5 MEASUREMENT RESULT SUMMARY ..................................................................................................................... 6 1 GENERAL INFORMATION ............................................................................................................................. 7 1.1 DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ..................................................................................................... 7 1.2 TECHNICAL SPECIFICATION .................................................................................................................................... 7 1.3 DESCRIPTION OF TEST FACILITY .............................................................................................................................. 9 2 TEST SPECIFICATIONS ................................................................................................................................. 10 2.1 STANDARDS OR SPECIFICATION ............................................................................................................................. 10 2.2 MODE OF OPERATION DURING THE TEST ................................................................................................................. 10 2.3 TEST SOFTWARE LIST .......................................................................................................................................... 11 2.4 TEST PERIPHERALS LIST ....................................................................................................................................... 11 2.5 TEST ENVIRONMENT CONDITION: .......................................................................................................................... 11 2.6 INSTRUMENT LIST .............................................................................................................................................. 12 2.7 MEASUREMENT UNCERTAINTY ............................................................................................................................. 14 3 MINIMUM 6DB BANDWIDTH ..................................................................................................................... 15 3.1 LIMIT .............................................................................................................................................................. 15 3.2 MEASUREMENT PROCEDURE ............................................................................................................................... 15 3.3 TEST CONFIGURATION ........................................................................................................................................ 15 3.4 TEST RESULTS OF MINIMUM 6DB BANDWIDTH ....................................................................................................... 15 4 MAXIMUM CONDUCTED OUTPUT POWER AND E.I.R.P. ............................................................................. 16 4.1 LIMIT .............................................................................................................................................................. 16 4.2 MEASUREMENT PROCEDURE ............................................................................................................................... 16 4.3 TEST CONFIGURATION ...…

Text truncated - open the document above for the full version.

FCC ID: 2AC8UA2005 IC: 21806-A2005 Page 1 of 4 Test Setup FCC ID: 2AC8UA2005 IC: 21806-A2005 Page 2 of 4 Conducted Emission FCC ID: 2AC8UA2005 IC: 21806-A2005 Page 3 of 4 Radiated Emission Below 1000MHz FCC ID: 2AC8UA2005 IC: 21806-A2005 Page 4 of 4 Above 1000MHz
