2AC8UA2211Smart watch

Product Manual Manual del producto Bedienungsanleitung Manuale del prodotto Ürün Kılavuzu Instrukcja obsługi produktu Návod k použití Manuel du produit Руководство по использованию изделия Посібник користувача Εγχειρίδιο προϊόντος ...................................................... ............................................. ......... ................................................... ............................................. ............................................. ............................................................ .................................... ......................................................... .......................................... ............................................. ................................................ ............................................. ................................................ Manual del producte 12 34 Zepp App Bluetooth output power: 10 dBm Operating temperature: 0°C to 45°C Water resistance rating: 5 ATM Bluetooth frequency: 2402–2480 MHz 2 1. This device is equipped with a built-in battery that cannot be removed or replaced. Do not disassemble or modify the battery by yourself. 2. Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion. 3. Leaving a battery in an extremely high temperature surrounding environment can result in an explosion or the leakage of flammable liquid or gas. 4. A battery subjected to extremely low air pressure may result in an explosion or the leakage of flammable liquid or gas. 5. Do not use unauthorized or incompatible power adapters or data cables, which may damage the watch and accessories, or cause fire, explosion, or other hazards. Battery Safety View product certification information on the watch's Settings > System > Regulatory page. Device requirements: Devices installed with Android 7.0 or iOS 14.0 or above OS versions. Packa ge Contents: Smartwatch with the band, Charging base, Instruction manual. Please refer to the watch user interface to see the software version. 3 War ranty and Return Policy The Amazfit Limited Warranty covers Amazfit products against manufacturing defects beginning on the original purchase date. The warranty period is 12 months or another specified period as the applicable consumer laws in the consumer’s country of purchase require. Our warranty is in addition to rights provided by applicable consumer laws. Official website: en.amazfit.com Please check the FAQ on the website: https://support.amazfit.com/en. Notes: • This product isn't a medical device. None of the data or measurements are intended for medical diagnosis or medical monitoring. • If the product is not in use for a long period of time, it is recommended that you power off the product before storing it. Recharge the battery every 6 months to 100% to prevent battery damage by over-discharge due to long-term storage. • For more information about safety precautions, repair, and maintenance, please refer to the electronic manual. 4 Certifications and Safety Approvals Hereby, Anhui Huami Information Technology Co., Ltd. declares that the radio device type A2211 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://api.huami.com/t/343ca 67 IC: 21806-A2211 CAN ICES-003 (B)/NMB-003(B) Disposal and Recycling Information All products bearing this symbol are waste electrical and electronic equipment which comply with the Reduction of Hazardous Substances in the e-waste (Management) Rules, and should not be mixed with unsorted household waste. Instead, you should protect human health and the environment by handing over your waste equipment to a designated collection point for the recycling of waste electrical and electronic equipment, appointed by the government or local authorities. Correct disposal and recycling will help prevent potential negative consequences to the environment and human health. Please contact the retailer or local authorities for more information about the location as well as terms and conditions of such collection points. 5 FCC ID: 2AC8UA2211 Hereby, Anhui Huami Information Technology Co., Ltd. declares that the radio device type A2211 is in compliance with Radio Equipment Regulations 2017 (S.I. 2017/1206). The full text of the UK declaration of conformity is available at the following internet address: http://en.amazfit.com/support.html 16 As sociation de la montre L'application Zepp est indispensable à cette montre. Elle fournit des conseils scientifiques sur le sommeil et l'entraînement, ainsi que des services personnalisés pour vous aider à adopter un mode de vie sain. 1. À l'aide de votre téléphone portable, scannez le code QR code à droite pour télécharger et installer l'appli, ou recherchez l'appli sur Google Play Store ou sur l'App Store d'Apple, puis téléchargez et installez la dernière version de l'appli. 2. Ouvrez l’application, inscrivez-vous et connectez-vous à un compte. 3. Associez la montre comme vous y invite l'application. Remarque : 1. Pour une meilleure expérience utilisateur, veuillez utiliser la version la plus récente de l'application. 2. Le système d'exploitation doit être Android 7.0, iOS 14.0 ou une version ultérieure. 3. N'associez pas la montre directement en utilisant la fonction Bluetooth de votre téléphone portable. Suivez les étapes fournies par l’application pour associer correctement votre montre. Téléchargez l'application Zepp 17 22 Ba tteriesicherheit 1. Dieses Gerät ist mit einem fest verbauten Akku ausgestattet, de r nicht herausgenommen oder ersetzt werden kann. Zerlegen oder modifizieren Sie den Akku nicht selbst. 2. Entsorgen Sie einen Akku nicht im Feuer oder einem heißen Ofen oder zerstören Sie einen Akku nicht mechanisch durch Quetschen oder Schneiden, was zu einer Explosion führen kann. 3. Setzen Sie einen Akku keiner Umgebung mit extrem hohen Temperaturen aus,…

Text truncated - open the document above for the full version.

AnhuiHuamiInformationTechnologyCo.,Ltd. CFR47§2.911(d)(5)(i)AttestationLetter AttestationLetter Date:06/09/2023 FEDERALCOMMUNICATIONSCOMMISSIONS AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Ref:AttestationStatementsCFR47§2.911(d)(5)(i)Filing FCCID:2AC8UA2211 AnhuiHuamiInformationTechnologyCo.,Ltd.(“theapplicant”)certifiesthattheequipmentfor whichauthorizationissoughtisnot“covered”equipmentprohibitedfromreceivingan equipmentauthorizationpursuanttosection2.903oftheFCCrules. Sincerely, Signature Name:LloydWong Title:SeniorCertificationManager Address:7/F,BuildingB2,HuamiGlobalInnovationCenter,No.900,WangjiangWestRoad, High-techZone,HefeiCityAnhuiPilotFreeTradeZone,China Tel:+86-15345601722 Fax:+86-551-5837200-1133 Email:[email protected]

AnhuiHuamiInformationTechnologyCo.,Ltd. CFR47§2.911(d)(5)(ii)AttestationLetter AttestationLetter Date:06/09/2023 FEDERALCOMMUNICATIONSCOMMISSIONS AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Ref:AttestationStatementsCFR47§2.911(d)(5)(ii)Filing FCCID:2AC8UA2211 AnhuiHuamiInformationTechnologyCo.,Ltd.(“theapplicant”)certifiesthatasofthedateof thefilingoftheapplication,theapplicantisnotidentifiedontheCoveredListasanentity producing“covered”equipment. Sincerely, Signature Name:LloydWong Title:SeniorCertificationManager Address:7/F,BuildingB2,HuamiGlobalInnovationCenter,No.900,WangjiangWestRoad, High-techZone,HefeiCityAnhuiPilotFreeTradeZone,China Tel:+86-15345601722 Fax:+86-551-5837200-1133 Email:[email protected]

AnhuiHuamiInformationTechnologyCo.,Ltd. Address:7/F,BuildingB2,HuamiGlobalInnovationCenter,No.900,WangjiangWest Road,High-techZone,HefeiCityAnhuiPilotFreeTradeZone,China Tel.:+86-15345601722 Fax:+86-551-5837200-1133 Email:[email protected] QA-FR-170-B FCCAuthorization Date:2023-06-15 FEDERALCOMMUNICATIONSCOMMISSIONS AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Subject:AgentAuthorization Towhomitmayconcern: We,AnhuiHuamiInformationTechnologyCo.,Ltd.herebyauthorizeShenzhenAccurate TechnologyCo.,Ltd.toactonitsbehalfinallmattersrelatingtoapplicationfor Equipmentauthorization,includingthesigningofalldocumentsrelatingtothesematters. AllactscarriedoutbyShenzhenAccurateTechnologyCo.,Ltd.onourbehalfshallhave thesameeffectasourownaction. We,AnhuiHuamiInformationTechnologyCo.,Ltd.theundersigned,herebycertifythat wearenotsubjecttoadenialoffederalbenefits,thatincludesFCCbenefits,pursuantto Section5301oftheAnti-DrugAbuseActof1988,21U.S.C.862. Thisauthorizationisvaliduntilfurtherwrittennoticefromtheapplicant. SincerelyYours, Signature Name:LloydWong Title:SeniorCertificationManager

AnhuiHuamiInformationTechnologyCo.,Ltd. Address:7/F,BuildingB2,HuamiGlobalInnovationCenter,No.900,WangjiangWest Road,High-techZone,HefeiCityAnhuiPilotFreeTradeZone,China Tel.:+86-15345601722 Fax:+86-551-5837200-1133 Email:[email protected] FCCConfidentialAuthorization Date:2023-06-15 FEDERALCOMMUNICATIONSCOMMISSIONS AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Subject:ConfidentialityRequestregardingapplicationforcertificationof FCCID:2AC8UA2211 InaccordancewithSections0.457and0.459oftheCommission’sRules,AnhuiHuami InformationTechnologyCo.,Ltd.herebyrequestslong-termconfidentialtreatmentof informationaccompanyingthisapplicationasoutlinedbelow: BlockDiagram Schematics OperationDescription Theabovematerialscontainproprietaryandconfidentialinformationnotcustomarily releasedtothepublic.Thepublicdisclosureofthesematerialsprovidesunjustified benefitstoitscompetitorsinthemarket. SincerelyYours, Signature Name:LloydWong Title:SeniorCertificationManager

Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-RF EXHIBITA-FCC ID LABEL AND LOCATION FCC ID Label The label shown on display screen shall be readily accessible, and the user manual must describe how to access the electronic display. (Labeling requirements per 2.935)

Shenzhen Accurate Technology Co., Ltd. Project No.: RA23052-30064E- RF Internal Photos Page 1 of 9 Internal Photos Shenzhen Accurate Technology Co., Ltd. Project No.: RA23052-30064E- RF Internal Photos Page 2 of 9 Shenzhen Accurate Technology Co., Ltd. Project No.: RA23052-30064E- RF Internal Photos Page 3 of 9 Shenzhen Accurate Technology Co., Ltd. Project No.: RA23052-30064E- RF Internal Photos Page 4 of 9 ANT Shenzhen Accurate Technology Co., Ltd. Project No.: RA23052-30064E- RF Internal Photos Page 5 of 9 Shenzhen Accurate Technology Co., Ltd. Project No.: RA23052-30064E- RF Internal Photos Page 6 of 9 Shenzhen Accurate Technology Co., Ltd. Project No.: RA23052-30064E- RF Internal Photos Page 7 of 9 ANT Port Shenzhen Accurate Technology Co., Ltd. Project No.: RA23052-30064E- RF Internal Photos Page 8 of 9 Shenzhen Accurate Technology Co., Ltd. Project No.: RA23052-30064E- RF Internal Photos Page 9 of 9

Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 1 of 2 APPENDIX B EUT TEST POSITION PHOTOS Liquid depth ≥ 15cm Phantom Type: Twin SAM Phantom ; Type: QD000 P40 CD; Serial: TP:1744 Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 2 of 2 Face up(25mm) Limbs-worn(0mm) 25 mm

Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 1 of 15 APPENDIX C PROBE CALIBRATION CERTIFICATES Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 2 of 15 Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 3 of 15 Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 4 of 15 Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 5 of 15 Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 6 of 15 Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 7 of 15 Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 8 of 15 Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 9 of 15 Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 10 of 15 APPENDIX D DIPOLE CALIBRATION CERTIFICATES Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 11 of 15 Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 12 of 15 Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 13 of 15 Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 14 of 15 Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-20A Page 15 of 15

Note: This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “★”. Shenzhen Accurate Technology Co., Ltd. is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. Shenzhen Accurate Technology Co., Ltd. 1/F., Building A, Changyuan New Material Port, Science & Industry Park, Nanshan District, Shenzhen, Guangdong, P.R. China Tel: +86 755-26503290 Fax: +86 755-26503290 Web: www.atc-lab.com Version 39: 2023-01-30 Page 1 of 32 FCC SAR TEST REPORT Applicant Name : Anhui Huami Information Technology Co., Ltd. Address : 7/F,Building B2,Huami Global Innovation Center,No. 900, Wang jiang West Road, High-tech Zone,Hefei City Anhui Pilot Free Trade Zone, China Factory1 Name Cosonic Electroacoustic Technology Co., Ltd. Factory1 Address: No.151, Shipai Section, Dongyuan Avenue, Shipai Town Dongguan, Guangdong, China Factory2 Name COSONIC VIETNAM COMPANY LIMITED Factory2 Address: Lot C5-1, Ba Thien ll Industrial Park,Thien Ke Ward,Binh Xuyen District,Vinh Phuc Province,Vietnam Report Number : SZNS2230529-30064E-20A FCC ID: 2AC8UA2211 Test Standard (s) FCC Part 2.1093 Sample Description Product Type: Smart watch Model No.: A2211 Multiple Models: N/A Trade Mark: AMAZFIT Date Received: 2023/05/29 Date of Test: 2023/06/06 Report Date: 2023/06/12 Test Result: Pass* * In the configuration tested, the EUT complied with the standards above. Prepared and Checked By: Approved By: Lance Li Candy Li EMC Engineer EMC Engineer Shenzhen Accurate Technology Co., Ltd. Report No.: SZNS2230529-30064E-20A Version 39: 2023-01-30 Page 2 of 32 FCC SAR Attestation of Test Results MODE Max. SAR Level(s) Reported(W/kg) Limit (W/kg) Bluetooth 1g Head SAR 0.01 1.6 10g Limbs SAR 0.01 4.0 Applicable Standards FCC 47 CFR part 2.1093 Radiofrequency radiation exposure evaluation: portable devices RF Exposure Procedures: TCB Workshop October 2016(Bluetooth Duty Factor) IEEE1528:2013 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques KDB procedures KDB 447498 D01 General RF Exposure Guidance v06 KDB 865664 D01 SAR Measurement 100 MHz to 6 GHz v01r04 KDB 865664 D02 RF Exposure Reporting v01r02 Note: This wireless device has been shown to be capable of compliance for localized specific absorption rate (SAR) for General Population/Uncontrolled Exposure limits specified in FCC 47 CFR part 2.1093 and has been tested in Accordance with the measurement procedures specified in IEEE 1528-2013 and RF exposure KDB procedures. The results and statements contained in this report pertain only to the device(s) evaluated. Shenzhen Accurate Technology Co., Ltd. Report No.: SZNS2230529-30064E-20A Version 39: 2023-01-30 Page 3 of 32 FCC SAR TABLE OF CONTENTS DOCUMENT REVISION HISTORY ......................................................................................................................... 4 EUT DESCRIPTION ................................................................................................................................................... 5 TECHNICAL SPECIFICATION ............................................................................................................................................. 5 REFERENCE, STANDARDS, AND GUIDELINES ................................................................................................. 6 SAR LIMITS ..................................................................................................................................................................... 7 FACILITIES ................................................................................................................................................................. 8 DESCRIPTION OF TEST SYSTEM .......................................................................................................................... 9 EQUIPMENT LIST AND CALIBRATION ............................................................................................................. 15 EQUIPMENTS LIST & CALIBRATION INFORMATION ........................................................................................................ 15 SAR MEASUREMENT SYSTEM VERIFICATION ............................................................................................. 16 LIQUID VERIFICATION ................................................................................................................................................... 16 SYSTEM ACCURACY VERIFICATION ............................................................................................................................... 17 SAR SYSTEM VALIDATION DATA ......................................................................................................................... 18 EUT TEST STRATEGY AND METHODOLOGY ................................................................................................. 19 FRONT-OF-FACE DEVICE ................................................................................................................................................ 19 LIMB-WORN DEVICE ...................................................................................................................................................... 19 TEST DISTANCE FOR SAR EVALUATION ..................................................................................................…

Text truncated - open the document above for the full version.

ShenZhen Accurate Technology CO., Ltd Report No.: RA230529-30064E-20A Page 1 of 2 Test Plot 1#: DUT: A2211; Type: Smart watch; Serial: 26CG-1; Communication System: UID 0, Bluetooth(GFSK) (0); Frequency: 2441 MHz;Duty Cycle: 1:1.3031 Medium parameters used: f = 2441 MHz; σ = 1.862 S/m; ε r = 38.154; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: • Probe: EX3DV4 - SN3701; ConvF(7.25, 7.25, 7.25) @ 2441 MHz; Calibrated: 2023/03/15 • Sensor-Surface: 1.4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1325; Calibrated: 2022/08/29 • Phantom: Twin SAM; Type: QD000P40CD; Serial: 1744 • Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) Face up/Bluetooth BDR(GFSK) Mid/Area Scan (9x9x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 0.00233 W/kg Face up/Bluetooth BDR(GFSK) Mid/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 1.295 V/m; Power Drift = -0.10 dB Peak SAR (extrapolated) = 0.00480 W/kg SAR(1 g) = 0.00153 W/kg; SAR(10 g) = 0.00121 W/kg Maximum value of SAR (measured) = 0.00389 W/kg 0 dB = 0.00389 W/kg = -24.10 dBW/kg ShenZhen Accurate Technology CO., Ltd Report No.: RA230529-30064E-20A Page 2 of 2 Test Plot 2#: DUT: A2211; Type: Smart watch; Serial: 26CG-1; Communication System: UID 0, Bluetooth(GFSK) (0); Frequency: 2441 MHz;Duty Cycle: 1:1.3031 Medium parameters used: f = 2441 MHz; σ = 1.862 S/m; ε r = 38.154; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY5 Configuration: • Probe: EX3DV4 - SN3701; ConvF(7.25, 7.25, 7.25) @ 2441 MHz; Calibrated: 2023/03/15 • Sensor-Surface: 1.4mm (Mechanical Surface Detection) • Electronics: DAE4 Sn1325; Calibrated: 2022/08/29 • Phantom: Twin SAM; Type: QD000P40CD; Serial: 1744 • Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) Limbs-Worn/Bluetooth BDR(GFSK) Mid/Area Scan (9x9x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 0.00848 W/kg Limbs-Worn/Bluetooth BDR(GFSK) Mid/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 0 V/m; Power Drift = 0.11 dB Peak SAR (extrapolated) = 0.0670 W/kg SAR(1 g) = 0.00632 W/kg; SAR(10 g) = 0.00285 W/kg Maximum value of SAR (measured) = 0.0408 W/kg 0 dB = 0.0408 W/kg = -13.89 dBW/kg

Antenna specifications Electrical Characteristics Description Model: Hannover BLE antenna Transmitter Frequency: 2402MHz-2480MHz Receiver Frequency: 2402MHz-2480MHz Antenna information: Antenna Name Model(s)/Type(s) RF Antenna Assembly Model/Part Number: Hannover BLE Manufacturer: Anhui Huami Information Technology Co., Ltd. 7/F,Building B2,Huami Global Innovation Center, No. 900, Wang jiang West Road, High-tech Zone, Hefei City Anhui Pilot Free Trade Zone, China Frequency Range: 2402MHz-2480MHz Connector Type/ Maximum Gain -3.46dBi Antenna Type/ Pattern: metalantenna Antenna Size L=21.69mm Measurement: See below Dimensions Dimensions See Fig.1. Fig. 1 Antenna Dimensions Electrical Performance S11 parameter test result as Fig.2. Fig. 2 S11 Parameter test result Table 1 shows the emission efficiency and the maximum gain of the antenna at different frequencies changes. Theantenna radiation pattern diagram show in Fig.3. Frequency(MHz) Efficiency（%） Max. Gain dBi 2400 26.36 -3.54 2410 26.07 -3.46 2420 25.96 -3.46 2430 25.73 -3.65 2440 25.27 -3.57 2450 24.44 -3.62 2460 24.18 -3.5 2470 24.05 -3.65 2480 23.82 -3.59 2490 23.24 -3.67 2500 21.88 -3.99 Table 1Max. Gain and Efficiency Vs. Frequency(Free space) Fig. 3 Operating diagram Fig. 4 antenna radiation pattern diagram

Note: This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “★”. Shenzhen Accurate Technology Co., Ltd. is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. Shenzhen Accurate Technology Co., Ltd. 1/F., Building A, Changyuan New Material Port, Science & Industry Park, Nanshan District, Shenzhen, Guangdong, P.R. China Tel: +86 755-26503290 Fax: +86 755-26503290 Web: www.atc-lab.com Version 139: 2023-01-30 Page 1 of 67 FCC&RSS-RF TEST REPORT Applicant Name : Anhui Huami Information Technology Co.,Ltd. Address(FCC) : 7/F,Building B2,Huami Global Innovation Center,No. 900, Wang jiang West Road, High-tech Zone,Hefei City Anhui Pilot Free Trade Zone, China Address(IC) : 7/F,Building B2,Huami Global Innovation Center, No. 900, Wang jiang West Road, High-tech Zone, Pilot Free Trade Zone, Hefei Anhui China (Peoples Republic Of) Factory1 Name Cosonic Electroacoustic Technology Co., Ltd. Factory1 Address: No.151, Shipai Section, Dongyuan Avenue, Shipai Town Dongguan, Guangdong, China Factory2 Name COSONIC VIETNAM COMPANY LIMITED Factory2 Address: Lot C5-1, Ba Thien ll Industrial Park,Thien Ke Ward,Binh Xuyen District,Vinh Phuc Province,Vietnam Report Number : RA230529-30064E-RFB FCC ID: 2AC8UA2211 IC: 21806-A2211 Test Standard (s) FCC PART 15.247, RSS-GEN ISSUE 5, FEBRUARY 2021 AMENDMENT 2; RSS-247, ISSUE 2, FEBRUARY 2017 Sample Description Product Type: Smart watch Model No.: A2211 Trade Mark: AMAZFIT Date Received: 2023-05-29 Date of Test: 2023-06-01 to 2023-06-05 Report Date: 2023-06-09 Test Result: Pass* * In the configuration tested, the EUT complied with the standards above. Prepared and Checked By: Approved By: Dave Liang Candy Li EMC Engineer EMC Engineer Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-RFB Version 139: 2023-01-30 Page 2 of 67 FCC&RSS-RF TABLE OF CONTENTS DOCUMENT REVISION HISTORY ......................................................................................................................... 4 GENERAL INFORMATION ....................................................................................................................................... 5 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 5 OBJECTIVE ................................................................................................................................................................... 5 TEST METHODOLOGY .................................................................................................................................................. 5 MEASUREMENT UNCERTAINTY .................................................................................................................................... 6 SYSTEM TEST CONFIGURATION .......................................................................................................................... 7 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 7 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 7 EUT EXERCISE SOFTWARE .......................................................................................................................................... 7 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 7 EXTERNAL I/O CABLE .................................................................................................................................................. 7 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 8 SUMMARY OF TEST RESULTS ............................................................................................................................... 9 TEST EQUIPMENT LIST ......................................................................................................................................... 10 FCC §1.1307(B)&§2.1093-RF EXPOSURE .............................................................................................................. 11 RSS-102 §4-RF EXPOSURE ...................................................................................................................................... 12 APPLICABLE STANDARD ............................................................................................................................................ 12 FCC §15.203 & RSS-GEN §6.8 – ANTENNA REQUIREMENT............................................................................ 13 APPLICABLE STANDARD ............................................................................................................................................ 13 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 13 §15.207 (A) & RSS-GEN §8.8 AC LINE CONDUCTED EMISSIONS .................................................................. 14 APPLICABLE STANDARD ............................................................................................................................................ 14 EU…

Text truncated - open the document above for the full version.

Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-RFB Version 139: 2023-01-30 Page 42 of 67 FCC&RSS-RF FCC §15.247(a) (1) (iii) & RSS-247 § 5.1 (d) - TIME OF OCCUPANCY (DWELL TIME) Applicable Standard According to FCC §15.247(a) (1) (iii): Frequency hopping systems in the 2400-2483.5 MHz shall use at least 15 channels. The average time of occupancy on any channel shall not be greater than 0.4 seconds within a period of 0.4 seconds multiplied by the number of hopping channels employed. Frequency hopping systems may avoid or suppress transmissions on a particular hopping frequency provided that a minimum of 15 channels are used. According to RSS-2 47 § 5.1 (d ): Frequency hopping systems (FHSs) operating in the band 2400-2483.5 MHz shall use at least 15 hopping channels. The average time of occupancy on any channel shall not be greater than 0.4 seconds within a period of 0.4 seconds, multiplied by the number of hopping channels employed. Transmissions on particular hopping frequencies may be avoided or suppressed provided that at least 15 hopping channels are used. Test Procedure According to ANSI C63.10-2013, section 7.8.4 1. The EUT was worked in channel hopping. 2. Set the RBW to: 1MHz. 3. Set the VBW ≥ 3×RBW. 4. Set the span to 0Hz. 5. Detector = peak. 6. Sweep time = auto couple. 7. Trace mode = max hold. 8. Allow trace to fully stabilize. 9. Recorded the time of single pulses Spectrum Analyzer EUT Open Switch and Control Unit Attenuator Shenzhen Accurate Technology Co., Ltd. Report No.: RA230529-30064E-RFB Version 139: 2023-01-30 Page 43 of 67 FCC&RSS-RF Test Data Environmental Conditions Temperature: 25 °C Relative Humidity: 44-45 % ATM Pressure: 101.0 kPa The testing was performed by Matt Liang on 2023-06-03 and 2023-06-05. EUT operation mode: Transmitting Test Result: Compliant. Please refer to the below table and plots: Test Mode Antenna Channel Burst Width [ms] Total Hops [Num] Res…
