2AC8UA2287Smart watch with Bluetooth and Wi-Fi

Noto Sans / Regular—6 PT Noto Sans / Light—4.5 PT 英 94 mm 46 mm Product Manual .1 產品手冊 .4 Bedienungsanleitung .6 Manuel du produit .9 Manuale del prodotto .12 Manual del producto .15 Руководство по использованию изделия .18 Instrukcja obsługi produktu .21 ユーザーガイド .24 제품 사용 설명서 .27 คู ่ มื อผลิ ตภั ณฑ์ .30 Manual do produto .33 Ürün Kılavuzu .36 Panduan Produk .39 Producthandleiding .42 Produktmanual .45 Produktvejledning .48 Hướng dẫn sử dụng sản phẩm .51 Produkthåndbok .54 Tuotteen käyttöopas .57 Εγχειρίδιο προϊόντος .60 Manualul produsului .63 Termékútmutató .66 Návod k použití .69 Manual del producte .72 Посібник користувача .75 Priručnik za proizvod .78 Manual Produk .81 83. دليل المنتج 86. מדריך למשתמש 2 Bluetooth version: V5.0 BLE output power: <8 dBm View product certification information on the watch's Settings > System > Regulatory page. Device requirements: Devices installed with Android 7.0 or iOS 14.0 or above OS versions Package Contents: Smartwatch with the band, Charging base, Instruction manual Please refer to the watch user interface to see the software version. Battery Safety 1. 2. 3. 4. 5. This device is equipped with a built-in battery that cannot be removed or replaced. Do not disassemble or modify the battery by yourself. Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion. Leaving a battery in an extremely high temperature surrounding environment can result in an explosion or the leakage of flammable liquid or gas. A battery subjected to extremely low air pressure may result in an explosion or the leakage of flammable liquid or gas. Do not use unauthorized or incompatible power adapters or data cables, which may damage the watch and accessories, or cause fire, explosion, or other hazards. Bluetooth output power: <18 dBm Operating temperature: 0°C to 45°C Water resistance rating: 5 ATM Bluetooth frequency: 2402–2480 MHz 1 Pairing the Watch Download Zepp App Basic Parameters Product Name: Smart Watch Product model: A2287 Input: DC 5 V 800 mA MAX WLAN: 2.4 GHz 802.11 b/g/n Wi-Fi frequency: 2402–2480 MHz Wi-Fi output power: <16 dBm Zepp is a must-have app for this watch. It provides scientific sleep and workout guidance and personalized health services to help you start a healthy lifestyle. Use your mobile phone to scan the QR code on the right side to download and install the app, or search for the app in the Google Play Store or Apple App Store and then download and install the the latest version of the app. Open the app, register an account and log in. Pair the watch as prompted by the app. 1. 2. 3. Note: 1. 2. 3. For better user experience, please use the most recent version of the app. The operating system needs to be Android 7.0, iOS 14.0, or above. Do not pair the watch directly using your mobile phone’s Bluetooth. Follow the steps in the app to pair your watch correctly. 3 Warranty and Return Policy The Amazfit Limited Warranty covers Amazfit products against manufacturing defects beginning on the original purchase date. The warranty period is 12 months or another specified period as the applicable consumer laws in the consumer’s country of purchase require. Our warranty is in addition to rights provided by applicable consumer laws. Official website: en.amazfit.com Note: This product isn't a medical device. None of the data or measurements are intended for medical diagnosis or medical monitoring. If the product is not in use for a long period of time, it is recommended that you power off the product before storing it. Recharge the battery every 6 months to 100% to prevent battery damage by over-discharge due to long-term storage. For detailed operating instructions, FAQs, safety precautions, and repair and maintenance information, please visit the website https://support.amazfit.com to download the user manual. 7 BLE-Ausgangsleistung: <8 dBm WLAN-Frequenz: 2402–2480 MHz Angaben zur Zertifizierung finden Sie in der Uhr unter „Einstellungen > System > Regulierung“. Geräteanforderungen: Geräte mit Android 7.0 bzw. iOS 14.0 oder höher Batteriesicherheit 1. 2. 3. 4. 5. Dieses Gerät ist mit einem fest verbauten Akku ausgestattet, der nicht herausgenommen oder ersetzt werden kann. Zerlegen oder modifizieren Sie den Akku nicht selbst. Entsorgen Sie einen Akku nicht im Feuer oder einem heißen Ofen oder zerstören Sie einen Akku nicht mechanisch durch Quetschen oder Schneiden, was zu einer Explosion führen kann. Setzen Sie einen Akku keiner Umgebung mit extrem hohen Temperaturen aus, was zu einer Explosion oder zu Lecks von entflammbaren Flüssigkeiten oder Gasen führen kann. Setzen Sie einen Akku keinem extrem niedrigen Luftdruck aus, was zu einer Explosion oder zu Lecks von entflammbaren Flüssigkeiten oder Gasen führen kann. Verwenden Sie keine nicht autorisierten oder inkompatiblen Netzteile oder Datenkabel, welche die Uhr und ihr Zubehör beschädigen sowie Feuer, Explosionen oder andere Gefahren verursachen können. Eingang: 5 V DC, max. 800 mA WLAN: 2,4 GHz 802.11 b/g/n Bluetooth-Frequenz: 2402–2480 MHz 6 Die Uhr koppeln Zepp-App herunterladen Grundlegende Parameter Produktmodell: A2287 Bluetooth-Version: V5.0 Wasserfestigkeit: 5 ATM Betriebstemperatur: 0-45 °C WLAN-Ausgangsleistung: <16 dBm Bluetooth-Ausgangsleistung: <18 dBm Zepp ist eine unverzichtbare App für diese Uhr. Sie gibt wissenschaftliche Handlungsempfehlungen zu Schlaf und Training sowie angepasste Gesundheitsdienste für einen gesunden Lebensstil. Verwenden Sie Ihr Mobiltelefon zum Scannen des auf der rechten Seite befindlichen QR-Codes, um die App herunterzuladen und zu installieren, oder suchen Sie im Google Play Store oder im Apple App Store nach der App und laden Sie die aktuellste Version der App herunter und installieren Sie sie. Öffnen Sie die App, registrieren Sie sich und melden Sie sich an. Koppeln Sie die Uhr entsprechend den Anweisungen der App. 1. 2. 3. Hinweis: 1. 2. 3. Für ein besseres Nutzererlebnis verwenden Sie bi…

Text truncated - open the document above for the full version.

2023-02-08

Date: 07-14-2023 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Ref: Attestation Statements Part 2.911(d)(5)(i) and Part 2.911(d)(5)(ii) Filing Re. KDB 986446 D01 FCC ID: 2AC8UA2287 Dear Sir or Madam, Anhui Huami Information Technology Co., Ltd. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, Anhui Huami Information Technology Co., Ltd. certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List ( as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment . If you have any questions, please contact us. Sincerely, Contact name: Lloyd Wong Company name: Anhui Huami Information Technology Co., Ltd. Address: 7/F,Building B2,Huami Global Innovation Center, No. 900, Wang jiang West Road, High-tech Zone Hefei City China (Anhui) Pilot Free Trade Zone E-mail: [email protected] Tel: +86-15345601722

Date (06/30/2023) TUV SUD BABT UNLIMITED TCB Octagon House, Segensworth North, Fareham, Hampshire, PO15 5RL, United Kingdom Confidentiality Request FCC ID: 2AC8UA2287 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Anhui Huami Information Technology Co., Ltd. hereby requests permanent confidential treatment of information accompanying this application as outlined below: PCB layout, Schematics Block Diagrams Parts List Operational Description Anhui Huami Information Technology Co., Ltd. also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of (can list up to 180) days: Internal Photos External Photos User Manual Set-up Photo The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Name: Lloyd Wong Title: Senior Certification Manager

Data: 2023-07-31 Subject: Statement of disable 5G wifi by software FCC ID: 2AC8UA2287 IC:21806-A2287 PMN:A2287 HVIN:A2287 To Whom It May Concern: We Anhui Huami Information Technology Co., Ltd. hereby declare that 5G wifi are disabled by software in the factory, this setting is not accessible and can’t active by the user or any other third-party. Best Regards Contact name: Lloyd Wong Company name: Anhui Huami Information Technology Co., Ltd. Address: 7/F, Building B2, Huami Global Innovation Center, No. 900, Wangjiang West Road, High-tech Zone, Hefei City, China (Anhui) Pilot Free Trade Zone E-mail: [email protected] Tel: +86-15345601722

View product certification information on the watch's Settings > System > Regulatory page.

Internal Photo Antenna Battery

Page: 1 of 30 TEST REPORT For SAR Report No. ...................................... : CHTEW23070045 Report verificaiton: Project No. ...................................... : SHT2306090502EW FCC ID ............................................. : 2AC8UA2287 IC ..................................................... : 21806-A2287 Applicant’s name ........................... : Anhui Huami Information Technology Co.,Ltd Address ............................................. : 7/F, Building B2, Huami Global Innovation Center, No. 900, Wangjiang West Road, High-tech Zone, Hefei City, China (Anhui) Pilot Free Trade Zone Test item description .................... : Smart watch Trade Mark ....................................... : AMAZFIT Model/Type reference ....................... : A2287 Listed Model(s) ................................. : - Standard ......................................... : Part 2.1093; IEEE Std C95.1: 1999 Edition; IEEE Std 1528: 2013; RSS-102,Issue 5; IEC/IEEE 62209-1528:2020 Date of receipt of test sample..........: Jun. 30, 2023 Date of testing..............................: Jul. 03, 2023- Jul. 10, 2023 Date of issue...............................: Jul. 13, 2023 Result .................. ........................: PASS Compiled by ( position+printedname+signature) ... : File administrators:Xiaodong Zhao Supervised by ( position+printedname+signature) ... : Test Engineer: Xiaodong Zhao Approved by ( position+printedname+signature) ... : Manager: Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW23070045 Page: 2 of 30 Issued: 2023-07-13 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) Contents 1. Statement of Compliance 3 2. Test Standards and Report version 4 2.1. Test Standards 4 2.2. Report version 4 3. Summary 5 3.1. Client Information 5 3.2. Product Description 5 3.3. RF Specification Description 5 3.4. Testing Laboratory Information 6 3.5. Environmental conditions 6 4. Equipments Used during the Test 7 5. Measurement Uncertainty 8 6. SAR Measurements System Configuration 11 6.1. SAR Measurement Set-up 11 6.2. DASY5 E-field Probe System 12 6.3. Phantoms 13 6.4. Device Holder 13 7. SAR Test Procedure 14 7.1. Scanning Procedure 14 7.2. Data Storage and Evaluation 16 8. Position of the wireless device in relation to the phantom 18 8.1. Front-of-face and Limbs 18 9. Dielectric Property Measurements & System Check 19 9.1. Tissue Dielectric Parameters 19 9.2. System Check 21 10. SAR Exposure Limits 24 11. Conducted Power Measurement Results and Tune up 25 11.1. Wi-Fi 25 11.2. Bluetooth 26 12. Antenna Location 27 12.1. Antenna Location 27 12.2. Standalone SAR test exclusion considerations 28 13. Measured and Reported SAR Results 29 13.1. Next to mouth SAR 30 13.2. Limbs SAR 30 Report No.: CHTEW23070045 Page: 3 of 30 Issued: 2023-07-13 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) 1. Statement of Compliance Maximum Reported SAR (W/kg) RF Exposure Conditions WIFI BT 1g Next to mouth(Dist.= 10mm) 0.057 0.010 10g Limbs(Dist.= 0mm) 0.056 0.009 This device is in compliance with Specific Absorption Rate (SAR) for general population/uncontrolled exposure limits (1.6 W/kg) specified in FCC 47 CFR Part 2.1093 and RSS-102, and had been tested in accordance with the measurement methods and procedures specified in IEC/IEEE 62209- 1528:2020 and FCC KDB publications. Report No.: CHTEW23070045 Page: 4 of 30 Issued: 2023-07-13 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V05 (2023-03) 2. Test Standards and Report version 2.1. Test Standards The tests were performed according to following standards: FCC 47 Part 2.1093: Radiofrequency radiation exposure evaluation: portable devices. IEEE Std C95.1, 1999 Edition: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz IEEE Std 1528™-2013: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. RSS-102,Iusse 5:Radio Standards Specification 102, Radio Frequency (RF) Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands), sets out the requirements and measurement techniques used to evaluate radio frequency (RF) exposure compliance of radiocommunication apparatus designed to be used within the vicinity of the human body. IEC/IEEE 62209-1528:2020: Measurement procedure for the assessment of specific absorption rate of human exposure to radio frequency fields from hand-held and body-worn wireless communication devices - Human models, instrumentation and procedures (Frequency range of 4 MHz to 10 GHz) FCC published RF exposure KDB procedures: 865664 D01 SAR Measurement 100 MHz to 6 GHz v01r04: SAR Measurement Requirements for 100 MHz to 6 GHz 865664 D02 RF Exposure Reporting v01r02: RF Exposure Compliance Reporting and Documentation Considerations 447498 D04 Interim General RF Exposure Guidance v01: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 248227 D01 802 11 Wi-Fi SAR v02r02: SAR Measurement Proceduresfor802…

Text truncated - open the document above for the full version.

Antenna specifications Electrical Characteristics Description Model: Monaco antenna Transmitter Frequency: 2400MHz-2483.5MHz Receiver Frequency: 1170 MHz -1180 MHz、 1570MHz-1580MHz、2400MHz-2483.5MHz Antenna information: Antenna Name Model(s)/Type(s) RF Antenna Assembly Model/Part Number: Monaco Manufacturer: Anhui Huami Information Technology Co., Ltd. 7/F, Building B2, Huami Global Innovation Center, No. 900, Wangjiang West Road, High-tech Zone, Hefei City, Anhui Pilot Free Trade Zone China Frequency Range: 1170 MHz -1180 MHz, 1570MHz-1580MHz, 2400MHz-2483.5MHz Connector Type/ Maximum Gain -8.09dBi Antenna Type/ Pattern: Metal Case Antenna Size NA Measurement: NA Dimensions Dimensions Fig: Fig. 1 Antenna Dimensions Electrical Performance S11 parameter-GPS L1 test result as Fig.2. Fig. 2 S11 Parameter-GPS L1/L5 and BT test result Table 1 shows the emission efficiency and the maximum gain of the antenna at different frequencies changes. The antenna radiation pattern diagram show in Fig.4. Table 1Max. Gain and Efficiency Vs. Frequency Fig. 3 Operating diagram Fig. 4 antenna radiation pattern diagram

Report Number: 68.950.23.0606.01 EMC_SZ_FR_23.03 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Guankou Erlu, Nantou, Nanshan District, Shenzhen, Guangdong, China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 1 of 60 FCC/ISED - TEST REPORT Report Number : 68.950.23.0606.01 Date of Issue: 2023-07-14 Model/HVIN : A2287 Product Type : Smart watch Applicant : Anhui Huami Information Technology Co., Ltd. Address : 7/F, Building B2, Huami Global Innovation Center, No. 900, Wangjiang West Road, High-tech Zone, Hefei City, Anhui Pilot Free Trade Zone China Manufacturer : Anhui Huami Information Technology Co., Ltd. Address : 7/F, Building B2, Huami Global Innovation Center, No. 900, Wangjiang West Road, High-tech Zone, Hefei City, Anhui Pilot Free Trade Zone China Test Result : ◼ Positive  Negative Total pages including Appendices : 60 Any use for advertising purposes must be granted in writing. This technical report may only be quoted in full. This report is the result of a single examination of the object in question and is not generally applicable evaluation of the quality of other products in regular production. For further details, please see testing and certification regulation, chapter A-3.4. Report Number: 68.950.23.0606.01 EMC_SZ_FR_23.03 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Guankou Erlu, Nantou, Nanshan District, Shenzhen, Guangdong, China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 2 of 60 1 Table of Contents 1 Table of Contents ..................................................................................................................................................2 2 Details about the Test Laboratory .........................................................................................................................3 3 Description of the Equipment Under Test .............................................................................................................4 4 Summary of Test Standards .................................................................................................................................5 5 Summary of Test Results ......................................................................................................................................6 6 General Remarks ..................................................................................................................................................7 7 Test Setups ...........................................................................................................................................................8 8 Systems Test Configuration ............................................................................................................................... 10 9 Technical Requirement ...................................................................................................................................... 11 9.1 Conducted Emission .................................................................................................................................. 11 9.2 Conducted Peak Output Power & EIRP ..................................................................................................... 14 9.3 6dB Bandwidth and 99% Occupied Bandwidth .......................................................................................... 16 9.4 Power Spectral Density .............................................................................................................................. 23 9.5 Spurious RF Conducted Emissions ........................................................................................................... 27 9.6 Band Edge Testing ..................................................................................................................................... 38 9.7 Spurious Radiated Emissions for Transmitter ............................................................................................ 42 10 Test Equipment List ........................................................................................................................................ 58 11 System Measurement Uncertainty ................................................................................................................. 60 Report Number: 68.950.23.0606.01 EMC_SZ_FR_23.03 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Guankou Erlu, Nantou, Nanshan District, Shenzhen, Guangdong, China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 3 of 60 2 Details about the Test Laboratory Details about the Test Laboratory Test Site 1 Company name: TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Guankou Erlu, Nantou, Nanshan District, Shenzhen, Guangdong, China Telephone: 86 755 8828 6998 Fax: 86 755 8828 5299 FCC Registration No.: 514049 FCC Designation Number: CN5009 IC Registration No.: 10320A Report Number: 68.950.23.0606.01 EMC_SZ_FR_23.03 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Guankou Erlu, Nantou, Nanshan District, Shenzhen, Guangdong, China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 4 of 60 3 Description of the Equipment Under Test Product: Smart watch Model no.: A2287 Hardware Version Identification No. (HVIN) A2287 Product Marketing Name (PMN) A2287 Brand name: AMAZFIT FCC ID: 2AC8UA2287 IC: 21806-A2287 Options and accessories: N/A Rating: 5VDC 800mA Battery information: Rechargeable Li-ion Battery Model:PL412631FPC Rated:3.87VDC 475mAh/1.84Wh RF Transmission Frequency: 2412MHz-2462MHz for 802.11b/g/n20 (Wi-Fi) No. of Operated Channel: 11 for 802.…

Text truncated - open the document above for the full version.

Report Number: 68.950.23.0605.01 EMC_SZ_FR_23.03 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Guankou Erlu, Nantou, Nanshan District, Shenzhen, Guangdong, China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 1 of 53 FCC/ISED - TEST REPORT Report Number : 68.950.23.0605.01 Date of Issue: 2023-07-14 Model/HVIN : A2287 Product Type : Smart watch Applicant : Anhui Huami Information Technology Co., Ltd. Address : 7/F, Building B2, Huami Global Innovation Center, No. 900, Wangjiang West Road, High-tech Zone, Hefei City, Anhui Pilot Free Trade Zone China Manufacturer : Anhui Huami Information Technology Co., Ltd. Address : 7/F, Building B2, Huami Global Innovation Center, No. 900, Wangjiang West Road, High-tech Zone, Hefei City, Anhui Pilot Free Trade Zone China Test Result : ◼ Positive  Negative Total pages including Appendices : 53 Any use for advertising purposes must be granted in writing. This technical report may only be quoted in full. This report is the result of a single examination of the object in question and is not generally applicable evaluation of the quality of other products in regular production. For further details, please see testing and certification regulation, chapter A-3.4. Report Number: 68.950.23.0605.01 EMC_SZ_FR_23.03 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Guankou Erlu, Nantou, Nanshan District, Shenzhen, Guangdong, China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 2 of 53 1 Table of Contents 1 Table of Contents ................................................................................................................................................................ 2 2 Details about the Test Laboratory ..................................................................................................................................... 3 3 Description of the Equipment Under Test........................................................................................................................ 4 4 Summary of Test Standards .............................................................................................................................................. 5 5 Summary of Test Results ................................................................................................................................................... 6 6 General Remarks ................................................................................................................................................................ 7 7 Test Setups .......................................................................................................................................................................... 8 8 Systems Test Configuration............................................................................................................................................. 10 9 Technical Requirement .................................................................................................................................................... 11 9.1 Conducted Emission.................................................................................................................................................... 11 9.2 Conducted Peak Output Power & EIRP ................................................................................................................ 14 9.3 Power Spectral Density ........................................................................................................................................... 18 9.4 6 dB Bandwidth and 99% Occupied Bandwidth .................................................................................................. 21 9.5 Spurious RF Conducted Emissions ....................................................................................................................... 26 9.6 Band Edge ................................................................................................................................................................. 34 9.7 Spurious Radiated Emissions for Transmitter ...................................................................................................... 37 10 Test Equipment List ...................................................................................................................................................... 51 11 System Measurement Uncertainty ............................................................................................................................. 53 Report Number: 68.950.23.0605.01 EMC_SZ_FR_23.03 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Guankou Erlu, Nantou, Nanshan District, Shenzhen, Guangdong, China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 3 of 53 2 Details about the Test Laboratory Details about the Test Laboratory Test Site 1 Company name: TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Guankou Erlu, Nantou, Nanshan District, Shenzhen, Guangdong, China Telephone: 86 755 8828 6998 Fax: 86 755 8828 5299 FCC Registration No.: 514049 FCC Designation Number: CN5009 IC Registration No.: 10320A Report Number: 68.950.23.0605.01 EMC_SZ_FR_23.03 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Guankou Erlu, Nantou, Nanshan District, Shenzhen, Guangdong, China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 4 of 53 3 Description of the Equipment Under Test Product: Smart watch Model no.: A2287 Hardware Version Identification No. (HVIN) A2287 Product Marketing Name (PMN) A2287 Brand name: AMAZFIT FCC ID: 2AC8UA2287 IC: 21806-A2287 Optio…

Text truncated - open the document above for the full version.

Page: 1 of 1 SAR Test Setup Photos Liquid depth in the Phantom Front (10mm) Rear (0mm)

30M-1000MHz RSE Setup 1G-18GHz RSE Setup 18G-40GHz RSE Setup Conducted Emission
