2AC8UA2292Smart watch with Bluetooth and Wi-Fi

Poppins / Regular—6 PT Poppins / Light—4.5 PT 英 94 mm 46 mm Product Manual .1 Bedienungsanleitung .4 Manuel du produit .7 Manuale del prodotto .10 Manual del producto .13 Руководство по использованию изделия .16 Instrukcja obsługi produktu .19 Manual do produto .22 Ürün Kılavuzu .25 Producthandleiding .28 Produktmanual .31 Produktvejledning .34 Produkthåndbok .37 Tuotteen käyttöopas .40 Εγχειρίδιο προϊόντος .43 Manualul produsului .46 Termékútmutató .49 Návod k použití .52 Manual del producte .55  .58 Priručnik za proizvod .61 64. دليل المنتج 67. מדריך למשתמש Product Regulation Information .70 1 23 12 34 Zepp App Pairing the Watch Download Zepp App Basic Parameters Product Name: Smart Watch Product model: A2292 Input: DC 5 V 700 mA MAX Bluetooth version: V5.0 WLAN: 2.4 GHz 802.11 b/g/n Bluetooth output power: <16 dBm BLE output power: <8 dBm Operating temperature: 0°C to 45°C View product certification information on the watch's Settings > System > Regulatory page. Device requirements: Devices installed with Android 7.0 or iOS 12.0 or above OS versions Package Contents: Smartwatch with the band, Charging base, Instruction manual Please refer to the watch user interface to see the software version. Zepp is a must-have app for this watch. It provides scientific sleep and workout guidance and personalized health services to help you start a healthy lifestyle. Use your mobile phone to scan the QR code on the right side to download and install the app, or search for the app in the Google Play Store or Apple App Store and then download and install the the latest version of the app. Open the app, register an account and log in. Pair the watch as prompted by the app. Battery Safety 1. 2. 3. 4. 5. This device is equipped with a built-in battery that cannot be removed or replaced. Do not disassemble or modify the battery by yourself. Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion. Leaving a battery in an extremely high temperature surrounding environment can result in an explosion or the leakage of flammable liquid or gas. A battery subjected to extremely low air pressure may result in an explosion or the leakage of flammable liquid or gas. Do not use unauthorized or incompatible power adapters or data cables, which may damage the watch and accessories, or cause fire, explosion, or other hazards. Warranty and Return Policy The Amazfit Limited Warranty covers Amazfit products against manufacturing defects beginning on the original purchase date. The warranty period is 12 months or another specified period as the applicable consumer laws in the consumer’s country of purchase require. Our warranty is in addition to rights provided by applicable consumer laws. Official website: en.amazfit.com Please check the FAQ on the website: https://support.amazfit.com/en. Note: This product isn't a medical device. None of the data or measurements are intended for medical diagnosis or medical monitoring. If the product is not in use for a long period of time, it is recommended that you power off the product before storing it. Recharge the battery every 6 months to 100% to prevent battery damage by over-discharge due to long-term storage. For more information about safety precautions, repair, and maintenance, please refer to the electronic manual. Water resistance rating: 5 ATM Wi-Fi output power: <16 dBm Bluetooth frequency: 2402–2480 MHz Wi-Fi frequency: 2402–2480 MHz 1. 2. 3. Note: 1. 2. 3. For better user experience, please use the most recent version of the app. The operating system needs to be Android 7.0, iOS 12.0, or above. Do not pair the watch directly using your mobile phone’s Bluetooth. Follow the steps in the app to pair your watch correctly. Poppins / Regular—6 PT Poppins / Light—4.5 PT 法 7 89 Association de la montre Téléchargez l'application Zepp Paramètres de base Modèle du produit : A2292 Entrée : 5 V c.c. 700 mA MAX Version Bluetooth : V5.0 WLAN : 2,4 GHz 802.11 b/g/n Puissance de sortie Bluetooth : <16 dBm Puissance de sortie BLE : <8 dBm Étanchéité à l’eau : 5 ATM Puissance de sortie WIFI : <16 dBm Consultez les informations relatives à la certification du produit sur la page Paramètres > Système > Régulation. Exigences relatives à l'appareil : Appareils pris en charge par les systèmes d'exploitation Android 7.0 ou iOS 12.0 ou une version ultérieure L'application Zepp est indispensable à cette montre. Elle fournit des conseils scientifiques sur le sommeil et l'entraînement, ainsi que des services personnalisés pour vous aider à adopter un mode de vie sain. À l'aide de votre téléphone portable, scannez le code QR code à droite pour télécharger et installer l'appli, ou recherchez l'appli sur Google Play Store ou sur l'App Store d'Apple, puis téléchargez et installez la dernière version de l'appli. Ouvrez l'application, inscrivez-vous et connectez-vous à un compte. Associez la montre comme vous y invite l'application. Sécurité de la batterie 1. 2. 3. 4. 5. L'appareil est équipé d'une batterie intégrée qui ne peut être retirée ou remplacée. Ne démontez pas, ou ne modifiez pas vous-même la batterie. La mise au rebut d'une batterie dans du feu ou dans un four chaud, ou l'écrasement ou le découpage mécanique d'une batterie peut entraîner une explosion. Laisser une batterie dans un environnement à température extrêmement élevée peut entraîner une explosion ou une fuite de liquide ou de gaz inflammable. Une batterie soumise à une pression d'air trop basse peut entraîner une explosion ou une fuite de liquide ou de gaz inflammable. N'utilisez pas d'adaptateurs secteur, de chargeurs ou de câbles de données non autorisés ou incompatibles, cela pourrait endommager la montre et ses accessoires, ou causer un incendie, une explosion ou d'autres dégâts. Garantie et politique de renvoi La Garantie Limitée Amazfit couvre les produits Amazfit contre les défauts de fabrication à compter de la date d'achat d'origine.…

Text truncated - open the document above for the full version.

2023-02-08

Date: 03-30-2023 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Ref: Attestation Statements Part 2.911(d)(5)(i) and Part 2.911(d)(5)(ii) Filing Re. KDB 986446 D01 FCC ID: 2AC8UA2292 Dear Sir or Madam, Anhui Huami Information Technology Co., Ltd. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered List as an entity producing “covered” equipment. If you have any questions, please contact us. Sincerely, Contact name: Lloyd Wong Company name: Anhui Huami Information Technology Co., Ltd. Address: 7/F,Building B2,Huami Global Innovation Center, No. 900, Wang jiang West Road, High-tech Zone Hefei City China (Anhui) Pilot Free Trade Zone Tel.: +86-15345601722 Email: [email protected]

Date (03/30/2023) TUV SUD BABT UNLIMITED TCB Octagon House, Segensworth North, Fareham, Hampshire, PO15 5RL, United Kingdom Confidentiality Request FCC ID: 2AC8UA2292 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Anhui Huami Information Technology Co., Ltd. hereby requests permanent confidential treatment of information accompanying this application as outlined below: PCB SCH Block Diagrams BOM Operational Description Anhui Huami Information Technology Co., Ltd. also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of 180 days: Internal Photos External Photos User Manual Set-up Photo The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Name: Lloyd Wong Title: Senior Certification Manager

Date: 2023-04-06 To: Federal Communications Commission 7435 Oakland Mills Road Columbia MD FCC ID: 2AC8UA2292 To Whom It May Concern: This letter is to ascertain that Anhui Huami Information Technology Co., Ltd. Product name: Smart watch, Model: A2292has been the units used for conducting FCC compliance testing, the SDoC part will be tested by FCC recognized test lab. If you have any question or concerns, please contact us. Sincerely, Company name: Anhui Huami Information Technology Co., Ltd. Address: 7/F,Building B2,Huami Global Innovation Center, No. 900, Wang jiang West Road, High-tech Zone Hefei City China (Anhui) Pilot Free Trade Zone E-mail: [email protected] Tel: +86-15345601722

External Photos:

View product certification information on the watch's Settings > System > Regulatory page.

Internal Photos Battery Antenna Antenna

Page: 1 of 25 TEST REPORT For SAR Report No. ...................................... : CHTEW23030002 Report vertification: Project No. ...................................... : SHT2302064403EW FCC ID ............................................. : IC ..................................................... : 2AC8UA2292 21806-A2292 Applicant’s name ........................... : Anhui Huami Information Technology Co.,Ltd Address ............................................. : 7/F, Building B2, Huami Global Innovation Center, No. 900, Wangjiang West Road, High-tech Zone, Hefei City, China (Anhui) Pilot Free Trade Zone Test item description .................... : Smart watch Trade Mark ....................................... : AMAZFIT Model/Type reference ....................... : A2292 Listed Model(s) ................................. : - Standard ......................................... : FCC 47 CFR Part2.1093 , IEEE Std C95.1: 1999 Edition IEEE Std 1528: 2013 RSS-102,Issue 5 , IEC/IEEE 62209-1528:2020 Date of receipt of test sample..........: Feb. 17, 2023 Date of testing..............................: Feb. 18, 2023- Feb. 28, 2023 Date of issue...............................: Mar. 01, 2023 Result .................. ........................: PASS Compiled by ( position+printedname+signature) ... : File administrators: Silvia Li Supervised by ( position+printedname+signature) ... : Test Engineer: Weiyang Xiang Approved by ( position+printedname+signature) ... : Manager: Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW23030002 Page: 2 of 25 Issued: 2023-03-01 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2021-12) Contents 1. Statement of Compliance 3 2. Test Standards and Report version 4 2.1. Test Standards 4 2.2. Report version 4 3. Summary 5 3.1. Client Information 5 3.2. Product Description 5 3.3. RF Specification Description 6 3.4. Testing Laboratory Information 6 3.5. Environmental conditions 6 4. Equipments Used during the Test 7 5. Measurement Uncertainty 8 6. SAR Measurement System Configuration 9 6.1. SAR Measurement Set-up 9 6.2. DASY5 E-field Probe System 10 6.3. Phantoms 11 6.4. Device Holder 11 7. SAR Test Procedure 12 7.1. Scanning Procedure 12 7.2. Data Storage and Evaluation 14 8. Position of the wireless device in relation to the phantom 16 9. Dielectric Property Measurements & System Check 17 9.1. Tissue Dielectric Parameters 17 9.2. System Check 18 10. SAR Exposure Limits 21 11. Conducted Power Measurement Results and Tune-up 22 12. Antenna Location 23 13. Measured and Reported SAR Results 24 14. Test Setup Photos 25 15. External and Internal Photos of the EUT 25 Report No.: CHTEW23030002 Page: 3 of 25 Issued: 2023-03-01 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2021-12) 1. Statement of Compliance Maximum Reported SAR (W/kg @1g) Type Test setting WIFI BT Head (next to mouth) Dist.= 10mm 0.235 0.010 Maximum Reported SAR (W/kg @10g) Type Test setting WIFI BT Limbs Dist.= 0mm 0.407 0.011 Note: 1. This device is in compliance with Specific Absorption Rate (SAR) for general population/uncontrolled exposure limits (1.6 W/kg@1g) and (4 W/kg@10g) specified in FCC 47 CFR part 2 (2.1093) and IEEE Std C95.1, 2. This device had been tested in accordance with the measurement methods and procedures specified in IEEE 1528 and FCC KDB publications. Report No.: CHTEW23030002 Page: 4 of 25 Issued: 2023-03-01 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2021-12) 2. Test Standards and Report version 2.1. Test Standards The tests were performed according to following standards: FCC 47 Part 2.1093: Radiofrequency radiation exposure evaluation: portable devices. IEEE Std C95.1, 1999 Edition: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz IEEE Std 1528™-2013: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. RSS-102,Iusse 5:Radio Standards Specification 102, Radio Frequency (RF) Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands), sets out the requirements and measurement techniques used to evaluate radio frequency (RF) exposure compliance of radiocommunication apparatus designed to be used within the vicinity of the human body. IEC/IEEE 62209-1528:2020: Measurement procedure for the assessment of specific absorption rate of human exposure to radio frequency fields from hand-held and body-worn wireless communication devices - Human models, instrumentation and procedures (Frequency range of 4 MHz to 10 GHz) FCC published RF exposure KDB procedures: 865664 D01 SAR Measurement 100 MHz to 6 GHz v01r04: SAR Measurement Requirements for 100 MHz to 6 GHz 865664 D02 RF Exposure Reporting v01r02: RF Exposure Compliance Reporting and Documentation Considerations 447498 D04 Interim General RF Exposure Guidance v01: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 248227 D01 802 11 Wi-Fi SAR v02r02: SAR Measurement Proceduresfor802.11 a/b/g Transmitters T…

Text truncated - open the document above for the full version.

Report Number: 68.950.23.0229.01 EMC_SZ_FR_23.01 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Guankou Erlu, Nantou, Nanshan District, Shenzhen, Guangdong, China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 1 of 71 FCC/ISED - TEST REPORT Report Number : 68.950.23.0229.01 Date of Issue: 2023-03-03 Model/HVIN : A2292 Product Type : Smart watch Applicant : Anhui Huami Information Technology Co., Ltd. Address : 7/F, Building B2, Huami Global Innovation Center, No. 900, Wangjiang West Road, High-tech Zone, Hefei City, Anhui Pilot Free Trade Zone China Manufacturer : Anhui Huami Information Technology Co., Ltd. Address : 7/F, Building B2, Huami Global Innovation Center, No. 900, Wangjiang West Road, High-tech Zone, Hefei City, Anhui Pilot Free Trade Zone China Factory : Shenzhen Yecon Industry Co., Ltd. Address : Section A of Floor 6 and Floor 1 to Floor 5, No. 101, No. 2 Building, District 6th, Cuigang Industrial Zone, Huaide, Fuyong, Bao’an District, Shenzhen City, Guangdong Province, P.R. China Test Result : ◼ Positive  Negative Total pages including Appendices : 71 Any use for advertising purposes must be granted in writing. This technical report may only be quoted in full. This report is the result of a single examination of the object in question and is not generally applicable evaluation of the quality of other products in regular production. For further details, please see testing and certification regulation, chapter A-3.4. Report Number: 68.950.23.0229.01 EMC_SZ_FR_23.01 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Guankou Erlu, Nantou, Nanshan District, Shenzhen, Guangdong, China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 2 of 71 1 Table of Contents 1 Table of Contents ..................................................................................................................................................2 2 Details about the Test Laboratory .........................................................................................................................3 3 Description of the Equipment Under Test .............................................................................................................4 4 Summary of Test Standards .................................................................................................................................5 5 Summary of Test Results ......................................................................................................................................6 6 General Remarks ..................................................................................................................................................7 7 Test Setups ...........................................................................................................................................................8 8 Systems Test Configuration ............................................................................................................................... 10 9 Technical Requirement ...................................................................................................................................... 11 9.1 Conducted Emission .................................................................................................................................. 11 9.2 Conducted Peak Output Power & EIRP ..................................................................................................... 14 9.3 20 dB Bandwidth and 99% Occupied Bandwidth ....................................................................................... 19 9.4 Carrier Frequency Separation .................................................................................................................... 27 9.5 Number of Hopping Frequencies ............................................................................................................... 30 9.6 Dwell Time .................................................................................................................................................. 33 9.7 Spurious RF Conducted Emissions ........................................................................................................... 37 9.8 Band Edge Testing ..................................................................................................................................... 48 9.9 Spurious Radiated Emissions for Transmitter ............................................................................................ 54 10 Test Equipment List ............................................................................................................................................ 70 11 System Measurement Uncertainty ..................................................................................................................... 71 Report Number: 68.950.23.0229.01 EMC_SZ_FR_23.01 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Guankou Erlu, Nantou, Nanshan District, Shenzhen, Guangdong, China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 3 of 71 2 Details about the Test Laboratory Details about the Test Laboratory Test Site 1 Company name: TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District Shenzhen 518052 P.R. China Telephone: 86 755 8828 6998 Fax: 86 755 828 5299 FCC Registration No.: 514049 FCC Designation Number: CN5009 IC Registration No.: 10320A Report Number: 68.950.23.0229.01 EMC_SZ_FR_23.01 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Guankou Erlu, Nantou, Nanshan Dis…

Text truncated - open the document above for the full version.

Antenna specifications Electrical Characteristics Description Model: Cheetah antenna Transmitter Frequency: 2400MHz-2483.5MHz Receiver Frequency: 1170 MHz -1180 MHz、 1570MHz-1580MHz、2400MHz-2483.5MHz Antenna information: Antenna Name Model(s)/Type(s) RF Antenna Assembly Model/Part Number: Cheetah Manufacturer: Anhui Huami Information Technology Co., Ltd. 7/F, Building B2, Huami Global Innovation Center, No. 900, Wangjiang West Road, High-tech Zone, Hefei City, China (Anhui) Pilot Free Trade Zone Frequency Range: 1170MHz-1180MHz 1570MHz-1580MHz 2400MHz-2483.5MHz Connector Type/ Maximum Gain -2.99dBi Antenna Type/ Pattern: Metal Case Antenna Size NA Measurement: NA Dimensions Dimensions Fig: Fig. 1 Antenna Dimensions Electrical Performance S11 parameter-GPS L1 test result as Fig.2. Fig. 2 S11 Parameter-GPS L1/L5 and BT test result Table 1 shows the emission efficiency and the maximum gain of the antenna at different frequencies changes. The antenna radiation pattern diagram show in Fig.4. Freq（MHz）Eff_dBEff（%）Gain 1155-13.434.54%-7.76 1165-13.454.51%-7.49 1175-13.524.44%-7.57 1185-13.524.45%-7.47 1195-13.534.43%-7.49 1205-13.414.56%-7.35 1535-11.936.41%-5.26 1545-11.936.42%-5.02 1555-12.016.29%-5.22 1565-12.116.15%-5.32 1575-12.196.04%-5.33 1585-12.235.99%-5.55 1595-12.16.16%-5.5 1605-11.756.68%-5.25 1615-11.636.88%-5.42 1625-11.387.28%-5.34 2400-8.2315.03%-3.11 2410-8.3414.65%-3.15 2420-8.4214.37%-3.24 2430-8.4714.21%-3.22 2440-8.5513.98%-3.2 2450-8.6713.57%-3.21 2460-8.6713.57%-3.2 2470-8.6213.73%-3.09 2480-8.5314.02%-2.99 2490-8.5214.06%-3.05 2500-8.6713.58%-3.11 L5 L1 BT Table 1Max. Gain and Efficiency Vs. Frequency Fig. 3 Operating diagram Fig. 4 antenna radiation pattern diagram

30M-1000MHz Radiated spurious emission 1G-18GHz Radiated spurious emission Test Setup Photos ! 18G-40GhzHz Radiated spurious emission Conducted Emission

Page：1 Appendix G: Test Setup Photos Liquid depth in the Body phantom Front (10mm) Rear (0mm)
