2ACEY-TSM-3000TS Electronic Lock & Trim

3000 Series Management System e-Cronus 3000 e-Kestros 3000 User’s manual YW2540 1 Index Introduction ............................................................................................................................................................................................... 2 Lock Features ........................................................................................................................................................................................... 2 Deadbolt and Privacy feature ............................................................................................................................................................... 7 Programming Locks ................................................................................................................................................................................. 8 Low Battery Warning ................................................................................................................................................................................ 9 Reset Lock to Factory Default Settings ................................................................................................................................................. 9 Using a Pin Code ..................................................................................................................................................................................... 6 YW25402 Introduction This manual is intended for individuals who program and manage 3000 Series locks. It covers PIN code assignment, scheduling, lock configuration, and maintenance. The 3000 Series is composed Grade 1 heavy-duty offline electronic locks that uses user- and manager-assigned PIN codes to control access. Codes can be scheduled to work during specific times or holidays, and locks can be set to automatically unlock on defined schedules, offering a flexible, standalone access control solution. Lock Features Change Master Code Allows you to update the master PIN code used for high-level access and programming of the lock. Only authorized users can perform this function. Add or Change User Codes Enables you to assign new PIN codes or update existing ones for users or managers. Each code can be customized with access schedules and permissions. Deleting User Codes Removes existing user or manager PIN codes from the lock, immediately revoking access for that individual. Disabling User Codes Temporarily deactivates a user or manager PIN code without deleting it, allowing access to be restored later without reprogramming. YW25403 Passage mode schedules A lock can be programmed to automatically unlatch or latch at specified times for each day of the week. A credential is not required to perform the unlatching and latching activities. When a lock is unlatched, a key is not required to open the door. The lock may have up to three different unlatch/latch times per week. First-In Prevents scheduled auto-unlock from activating until a valid user PIN code is entered, ensuring the lock only opens when someone is physically present. Single-Use Service Codes Generates a one-time PIN code that grants access only once, ideal for temporary entry by service personnel or vendors. Pass Time (Door Unlock) Temporarily unlocks the door for a set duration after a valid code is entered, allowing extended access without keeping the door unlocked indefinitely. Internal Clock and Calendar The lock contains a clock crystal that maintains actual date and time. The time is updated every minute and the crystal automatically adjusts for changes due to daylight savings and leap year. Check Firmware Version Displays the current firmware version installed on the lock to ensure it is up to date and functioning with the latest features and security enhancements. Lock / Unlocked Status Indicator Shows whether the door is currently locked or unlocked, providing a clear visual confirmation of the lock’s status. YW25404 Holidays Allows you to set special dates when regular access schedules are overridden, enabling or restricting entry according to holiday-specific rules. User Schedule Defines specific time periods when individual user PIN codes are valid, controlling when each user can access the lock. Manager-Code A special PIN code with elevated privileges used to program the lock and manage user codes and settings. Low Battery If the lock’s batteries are low a yellow indicator light will flash when a correct credential is used before displaying the green LED and unlocking. Keystroke Sound Level Adjusts the volume of the keypad tones to provide audible feedback when keys are pressed. Remote Service Codes Generates time-limited PIN codes offsite that can be provided to service personnel or guests for temporary access without needing to be physically present at the lock. Time Zones Configures defined time periods that can be assigned to user codes or lock functions, enabling scheduled access control across different days and times. YW25405 Audit Trail Audit trail determines which credential was used, when an access occurred, who owned the credential at the time of access and what action was performed. Audit trail is stored in the lock’s nonvolatile memory. Displayed in the 3000 software in order of most recent event. Encryption Ensures secure communication between the Door Lock Programmer (DLP3) and the lock by using encrypted data transfer to protect sensitive programming information. PIN Code Length Specifies the number of digits required for user and manager PIN codes, enhancing security by allowing configurable code complexity. Authorized User A designated user with administrative privileges who can manage lock settings, user codes, schedules, and perform system-level programming. Door Lock Programmer (DLP3) A handheld device used to configure, program, and update 3000 Series locks, including transferring user codes, schedules, and firmware. YW25406 Using a PIN Code Wak…

Text truncated - open the document above for the full version.

17901 Railroad Street, City of Industry, CA 91748 Tel: (626) 965-8917 Fax (626) 965-8919 Covered list Attestation Statement Date: January 15, 2026 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2ACEY-TSM-3000 TownSteel Inc. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature Contact Name: Steven Cima Job Title: Quality Director Email: [email protected]

17901 Railroad Street, City of Industry, CA 91748 Tel: (626) 965-8917 Fax (626) 965-8919 Covered list Attestation Statement Date: January 15, 2026 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2ACEY-TSM-3000 TownSteel Inc. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Signature Contact Name: Steven Cima Job Title: Quality Director Email: [email protected]

17901 Railroad Street, City of Industry, CA 91748 Tel: (626) 965-8917 Fax (626) 965-8919 U.S. Agent Authorized Letter Date: January 15, 2026 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Attestation Statements Part 2.911(d)(7) Filing FCC ID: 2ACEY-TSM-3000 To Whom It May Concern: This letter is to confirm that the Applicant will also serve as the U.S. Agent for Service of Process as required by 47 CFR 2.911(d)(7). The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The Applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information changes. Sincerely, Company: TownSteel Inc. FRN: 0023632110 Address: 17901 Railroad Street, City of Industry, California, 91748, United States Contact Name: Steven Cima Title: Quality Director Tel.: 626-965-8917 Email: [email protected]

17901 Railroad Street, City of Industry, CA 91748 Tel: (626) 965-8917 Fax (626) 965-8919 Authorization Letter Date: January 15, 2026 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ACEY-TSM-3000 To Whom It May Concern: We, the undersigned, hereby authorize the following person on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by DEKRA Testing and Certification Co., Ltd. on our behalf shall have the same effect as acts of our own. Agent Company name : DEKRA Testing and Certification Co., Ltd. Address : No. 26, Hwaya 1st Road., Guishan District, Taoyuan City, 33341, Taiwan Contact Name : Phoenix Chen Email : [email protected] We are therefore responsible for the contents of the application. Product description : TS Electronic Lock & Trim Model No. : e-Cronus 3000, e-Kestros 3000 Brand : TownSteel Sincerely, Signature Contact Name: Steven Cima Job Title: Quality Director Email: [email protected]

17901 Railroad Street, City of Industry, CA 91748 Tel: (626) 965-8917 Fax (626) 965-8919 Confidential Request Letter Date: January 15, 2026 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for confidentiality FCC ID: 2ACEY-TSM-3000 Long-Term Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics Bill of Materials/Parts List Block Diagrams Tune-up procedure Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Short-Term Confidentiality (STC) Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Internal Photos User’s Manual External Photos Test Set-up Photos Justification: Planned Release Date STC: If no date is given, __ days from grant date will be used. Sincerely, Signature Contact Name: Steven Cima Job Title: Quality Director Email: [email protected]

17901 Railroad Street, City of Industry, CA 91748 Tel: (626) 965-8917 Fax (626) 965-8919 Declaration of Identity Date: January 15, 2026 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ACEY-TSM-3000 To Whom It May Concern: Due to the business consideration, we, TownSteel Inc., hereby declare that our product of TS Electronic Lock & Trim (Model: e-Cronus 3000, e-Kestros 3000 / Brand: TownSteel) have as following difference: Model No Password Panel keyhole Internal handle e-Cronus 3000 Independent panel Independent Different designs e-Kestros 3000 Connected to the handle Connected to the handle In addition to the above information, these devices are identical in RF hardware design and circuit. Any questions regarding this declaration, please don’t hesitate to contact us. Sincerely, Signature Contact Name: Steven Cima Job Title: Quality Director Email: [email protected]

Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 1 of 28 FAX : +886-3-582-8958  EUT External Photograph (1) EUT Photo (Model No.: e-Cronus 3000) (2) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 2 of 28 FAX : +886-3-582-8958 (3) EUT Photo (4) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 3 of 28 FAX : +886-3-582-8958 (5) EUT Photo (6) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 4 of 28 FAX : +886-3-582-8958 (7) EUT Photo (Key* 1) Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 5 of 28 FAX : +886-3-582-8958 (1) EUT Photo (Model No.: e-Kestros 3000) (2) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 6 of 28 FAX : +886-3-582-8958 (3) EUT Photo (4) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 7 of 28 FAX : +886-3-582-8958 (5) EUT Photo (6) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 8 of 28 FAX : +886-3-582-8958 (7) EUT Photo (Key* 1)

LABEL LOCATION Model: e-Kestros 3000 FCC ID: 2ACEY-TSM-3000 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label Size: L30mm x W15mm Model: e-Cronus 3000 FCC ID: 2ACEY-TSM-3000 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label Size: L30mm x W15mm Blank label in the photo shows FCC label location

Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 9 of 28 FAX : +886-3-582-8958  EUT Internal Photograph (1) EUT Photo (Model No.: e-Cronus 3000) (2) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 10 of 28 FAX : +886-3-582-8958 (3) EUT Photo (4) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 11 of 28 FAX : +886-3-582-8958 (5) EUT Photo (6) EUT Photo (Antenna) Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 12 of 28 FAX : +886-3-582-8958 (7) EUT Photo (8) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 13 of 28 FAX : +886-3-582-8958 (9) EUT Photo (10) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 14 of 28 FAX : +886-3-582-8958 (11) EUT Photo (12) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 15 of 28 FAX : +886-3-582-8958 (13) EUT Photo (14) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 16 of 28 FAX : +886-3-582-8958 (15) EUT Photo (16) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 17 of 28 FAX : +886-3-582-8958 (17) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 18 of 28 FAX : +886-3-582-8958 (1) EUT Photo (Model No.: e-Kestros 3000) (2) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 19 of 28 FAX : +886-3-582-8958 (3) EUT Photo (4) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 20 of 28 FAX : +886-3-582-8958 (5) EUT Photo (6) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 21 of 28 FAX : +886-3-582-8958 (7) EUT Photo (8) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 22 of 28 FAX : +886-3-582-8958 (9) EUT Photo (10) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 23 of 28 FAX : +886-3-582-8958 (11) EUT Photo (12) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 24 of 28 FAX : +886-3-582-8958 (13) EUT Photo (14) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 25 of 28 FAX : +886-3-582-8958 (15) EUT Photo (16) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 26 of 28 FAX : +886-3-582-8958 (17) EUT Photo (18) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 27 of 28 FAX : +886-3-582-8958 (19) EUT Photo (20) EUT Photo Report No.: 2590298R TEL : +886-3-582-8001 Page Number : 28 of 28 FAX : +886-3-582-8958 (21) EUT Photo (Antenna)

Report No.：2590298R-RFUSV17S-A TEL : +886-3-582-8001 Page Number : 1 of 8 FAX : +886-3-582-8958 Issued Date : Jan. 15, 2026 Report Version : V1.0 Test Report No: 2590298R-RFUSV17S-A RF EXPOSURE EVALUATION DECLARATION Product Name TS Electronic Lock & Trim Brand Name TownSteel Model No. e-Cronus 3000, e-Kestros 3000 FCC ID 2ACEY-TSM-3000 Applicant ́s Name / Address TownSteel Inc. 17901 Railroad Street, City of Industry, CA, 91748, United States Manufacturer’s Name / Address TownSteel Inc. 17901 Railroad Street, City of Industry, CA, 91748, United States Te s t Method Requested, Standard FCC CFR Title 47 Part 2.1091 Radiofrequency radiation exposure evaluation: mobile devices. Verdict Summary IN COMPLIANCE Documented By Jennie She Approved By Rueyyan Lin Date of Receipt Sep. 10, 2025 Date of Issue Jan. 15, 2026 Report Version V1.0 Report No.：2590298R-RFUSV17S-A TEL : +886-3-582-8001 Page Number : 2 of 8 FAX : +886-3-582-8958 Issued Date : Jan. 15, 2026 Report Version : V1.0 INDEX page Competences and Guarantees ................................................................................................................................ 3 General Conditions .................................................................................................................................................. 3 Revision History ....................................................................................................................................................... 4 1. General Information ............................................................................................................................... 5 1.1. EUT Description .................................................................................................................................... 5 1.2. Testing Location Information ................................................................................................................. 6 2. RF Exposure Evaluation ........................................................................................................................ 7 2.1. Test Limit ............................................................................................................................................... 7 2.2. Test Result of RF Exposure Evaluation ................................................................................................. 8 Report No.：2590298R-RFUSV17S-A TEL : +886-3-582-8001 Page Number : 3 of 8 FAX : +886-3-582-8958 Issued Date : Jan. 15, 2026 Report Version : V1.0 Competences and Guarantees DEKRA is a testing laboratory competent to carry out the tests described in this report. In order to assure the traceability to other national and international laboratories, DEKRA has a calibration and maintenance program for its measurement equipment. DEKRA guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated in the report and it is based on the knowledge and technical facilities available at DEKRA at the time of performance of the test. DEKRA is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Test Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA. General Conditions 1. The test results relate only to the samples tested. 2. The test results shown in the test report are traceable to the national/international standard through the calibration report of the equipment and evaluated measurement uncertainty herein. 3. This report must not be used to claim product endorsement by TAF or any agency of the government. 4. The test report shall not be reproduced without the written approval of DEKRA Testing and Certification Co., Ltd. 5. Measurement uncertainties evaluated for each testing system and associated connections are given here to provide the system information for reference. Compliance determinations do not take into account measurement uncertainties for each testing system, but are based on the results of the compliance measurement. Report No.：2590298R-RFUSV17S-A TEL : +886-3-582-8001 Page Number : 4 of 8 FAX : +886-3-582-8958 Issued Date : Jan. 15, 2026 Report Version : V1.0 Revision History Version Description Issued Date V1.0 Initial issue of report Jan. 15, 2026 Report No.：2590298R-RFUSV17S-A TEL : +886-3-582-8001 Page Number : 5 of 8 FAX : +886-3-582-8958 Issued Date : Jan. 15, 2026 Report Version : V1.0 1. General Information 1.1. EUT Description RF General Information Evaluation Mode Frequency Range (MHz) Operating Frequency (MHz) Modulation Type Bluetooth 2400 ~ 2483.5 2402 ~ 2480 LE: GFSK The difference for each model is shown as below: Model No Password Panel keyhole Internal handle e-Cronus 3000 Independent panel Independent Different designs e-Kestros 3000 Connected to the handle Connected to the handle Note: 1. In addition to the above information, these devices are identical in RF hardware design and circuit. 2. From the above models, model: e-Cronus 3000 was selected as representative model for the test and its data was recorded in this report. Note: The above EUT information is declared by the manufacturer. Report No.：2590298R-RFUSV17S-A TEL : +886-3-582-8001 Page Number : 6 of 8 FAX : +886-3-582-8958 Issued Date : Jan. 15, 2026 Report Version : V1.0 1.2. Testing Location Information Testing Location Information Test Laboratory：DEKRA Testing and Certification Co., Ltd. 1 ADD: No.372-2, Sec. 4, Zhongxing Rd., Zhudong Township, Hsinchu County 31061, Taiwan, R.O.C. (TAF: 3024) TEL: +886-3-582-8001 FAX: +886-3-582-8958 Test site Designation No. TW3024 with FCC. Conformity Assessm…
