2ACFF-UC3101USB-C HUB WITH WIRELESS DISPLAY(TRANSMITTER+RECEIVER)

Receiver (UC3101R) connection: 1. Make sure the display is switched to the corresponding HDMI/VGA mode before use 2. Insert the HDMI and VGA M/M cable into the display HDMI input port and connect one end to the product 3. Plug the charger or USB power supply through the usb-c interface 4. At this point, there will be a user interface display on the monitor, and the screen can be automatically cast after waiting for the transmitter to work Transmitter (UC3101T) connection: 1. Plug usb-c /M into the usb-c output port of the phone/tablet/laptop (the phone/computer should support video output) 2. Insert the usb drive into usb3.0a /F to connect the usb drive data 3. Insert SD/TF into the card holder to realize data connection 4. Make sure that the PIN PIN in the product does not sag or bend during use, so as not to affect the insertion 5. Please pay attention not to splash liquid into the connector, so as not to affect its performance 6. The product should be placed in a dry place, not in a wet environment a. Why is there no video output? 1. Pls check the connection is good. 2. Pls use standard HDMI or VGA cable. 3. The automatic screen casting link will take about 10 seconds, please wait patiently. 4. Mobile phone/computer supports video output 5. The default of the factory is that it is matched. If there is no problem with the above four points, Please re-pair and reuse b. Why is there no audio output from HDMI port? 1. Pls make sure that there is audio output function on the monitor. 2. Pls set the external monitor as default audio output device. C. How to use the products in pairs? 1. After the receiver is powered, press 5 seconds to enter the matching mode. At this point, the screen display switches to waiting for pairing... 2. After the emitter is inserted into the device for 20 seconds, long press 5 seconds to enter the matching mode 3. When the receiver and transmitter enter the matching mode at the same time, it will automatically match. The matching time is about 5-15 seconds 4. After the pairing is successful, the screen will automatically switch to the normal projection mode Transmitter: 1. USB 3.0 5Gb/s data transfer, downward compatible with USB2.0; power supply up to 4.5W Max. 2. SD/TF Card Reader Read: 50 - 104MB/s; Write: 30 - 40MB/s； affected by card’s quality. 3. WiFi supports wireless dual frequency Protocol standard 802.11a/b/g/n/ac Receiver: 1. HDMI 1920X1080P/60HZ, downward compatible with 1080P, 1080I, 720P. HDMI and VGA can work together. 2. USB-C USB charger or USB port power supply. 3. VGA: 1920X1080P/60HZ, downward compatible with 1080P, 1080I, 720P. 4. 3.5mm Audio Support max transmission distance 10 meters USB-C multi-function wireless display screen projector is composed of transmitter and receiver, which must be used together with the adapted receiver. The built-in conversion chip of the transmitter converts the DP signal in type-c into MIPI signal and I2S, and encodes the MIPI signal and I2S together into audio and video stream, which is then sent to the adaptive receiver via WiFi using a private protocol. Input devices include mobile phones, tablet computers and laptops that support usb-c interface for video output. Usb-c interface is small in size and supports forward and backward interpolation and data transmission. HDMI/VGA output terminal supports up to 1080P/60HZ video resolution. UC3101 USB-C Hub wi th Wirelss Display Transmi tt er + Receiver Audio USB-C VGA USB-A x 2 Mobile Notebook Tablet PC Monitor Project or 1 2 3 4 5 Receiver ： 1. Function key 2. USB-C （Power supply port） 3. 3.5mm Audio 4. VGA 5. 1 4 3 2 Transmitter ： 1. Power indicator light 2. USB3.0-A 3. SD&TF Card Reader 4. Function key Short press: change the screen state(screen/disconnect); Long press for 5 seconds: enter matching mode; Long press for 10 seconds: restore factory Settings. 5V2A Main chip Par ame ter Wi Working Frequency Oper ating System DDR Flash Memory Resolution Transmission Speed Pr ot oc ol Standard Int erf ac e Power Supply 1080P 1 Mbps 802.11a/b/g/n/ ac HDMI/VGA 5V /2A USB-C interf ac e TX unit: RV1108 RX unit: RK3036 2.4G or 5G Linux 128MB 16MB FCC Warning Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐‐ Reorient or relocate the receiving antenna. ‐‐ Increase the separation between the equipment and receiver. ‐‐ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐‐ Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Specific Absorption Rate (SAR) information: This smart phone meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin des…
