2ACQM-APG3-VGE1-BVUSION Gate E1-G1

SES-imagotag I 55 Place Nelson Mandela I CS 60106 | FR-92024 Nanterre Cedex, FRANCE T. +33 1 34 34 61 61 I E. [email protected] I www.ses-imagotag.com VUSION Gate Read all documents and system instructions carefully to minimize the risk of harming people by misuse and to avoid damage to the system or to the environment. Keep all documents and guidance accessible at all times. If necessary, the content of this document will be updated. You can request the latest version of the document via [email protected]. The company SES-imagotag assumes no liability for any damage caused by improper installation or handling. The installation instructions are intended for trained electricians who can exhibit the following qualifications: • Knowledge of the use of tools and work instructions. • Knowledge of the usable conditions of the tool. • Knowledge of the electrical safety instructions. • Knowledge of the electrical building regulations. • Knowledge of the relevant standards. • Knowledge of the assembly schedule. Mounting location The Access Point can be mounted on a: • Concrete wall • Mortar wall • T-Mounting rail Select the installation location for the Access Point carefully. Pay particular attention to the following requirements: • Install the Access Point only in areas where the permissible environmental conditions can be observed. • Don’t install the Access Point in an environment with direct sunlight or heat source. • Mount the metal bracket for the Access Point on dry surfaces only. • Don’t mount the Access Point on any flammable material. • The minimum bearing capacity of the substrate has to be 5 kg. • The LAN cable manufacturer must be compliant to the default specifications (e.g. minimum bend radius of 3cm) Approachability • Mount the metal bracket in a way that the Access Point can easily be attached to it by applying light pressure to it. • Make sure that the LAN socket is easily accessible after the installation. • The LED must be clearly visible after the installation is completed. Page 2 • It is important that the inner surface of the Access Point has sufficient air circulation. The vents must be free to ensure sufficient ventilation to prevent overheating. The mounting material (e.g. screws or pegs) for securing the metal bracket on concrete walls is not part of the scope of delivery. It has to be purchased separately if needed, depending on the actual substrate. Maintenance • The SES-imagotag VUSION Gate does not contain parts that have to be maintained by the user. The SES-imagotag VUSION Gate must NOT be opened. For necessary maintenance or repair works always contact the manufacturer. • The device is provided with a warranty seal. Damaging the warranty seal expires all warranty claims. Problems which require maintenance or replacement of the VUSION Gate Unplug the power supply and contact SES-imagotag if following cases occur: • The VUSION Gate was strewn with liquid. • The VUSION Gate has been dropped or damaged. • The LAN port of the VUSION Gate is damaged. • The LED of the VUSION Gate no longer lights up. Contact the manufacturer if despite intended purpose the device is not working and none of the mentioned cases occurred. Operating and storage of the SES-imagotag VUSION Gate If the mounting of the SES-imagotag VUSION Gate is intended to be done at a later date, please assure proper storage: • Operate the SES-imagotag VUSION Gate at a temperature from 0°C to +40°C. • Store the SES-imagotag VUSION Gate in the delivered original packing at a temperature from -20°C up to +70°C • Store the SES-imagotag VUSION Gate in the delivered original packing at a humidity from 10% up to 85% (non-condensing) • The SES-imagotag VUSION Gate must be switched OFF while stored. • Check the condition of the SES-imagotag VUSION Gate after unpacking. • Do not store other objects on top of the SES-imagotag VUSION Gate. Improper Use The SES-imagotag is not responsible and does not assume liability for damage or injury to persons, property, environment and the VUSION Gate itself caused by improper installation or improper handling. Page 3 The operator assumes liability for any damage that results from improper use. The following usage is not allowed: • Don't drop the VUSION Gate. • Keep the VUSION Gate away from water. • Don’t use the VUSION Gate with defective parts. • Don’t use the VUSION Gate with spare parts and accessories which are not examined and approved by the SES-imagotag. • Unauthorized changes or modifications to the VUSION Gate and their components without the consent of SES-imagotag are not allowed. • Don't throw VUSION Gate into the dustbin. Deposit VUSION Gate at a reprocessing company. • Contact SES-imagotag for more details about the removal process. • Please do not use any liquid or spray cleaners directly on the surface of the VUSION Gate. Environmental protection and removal Please assure that you meet all local law restrictions when removing the VUSION Gate. The SES-imagotag VUSION Gate correlates to the ROHS guideline. Certificates This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION TO USERS Changes or modifications not expressly approved by the party responsible for compliance could void the user`s authority to operate the equipment. FCC rules apply to the following products: APG3-VGE1-A, APG3-VGE1-B This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence- exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le prés…

Text truncated - open the document above for the full version.

FCC Agent Authorization Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 4/19/2023 To whom it may concern, Sincerely, Philipp Jauck, Head of IP Management & Regulatory Compliance SES-imagotag GmbH Kalsdorfer Strasse 12 8072 Fernitz-Mellach, Austria Mobil: +43 664 88252901 [email protected] www.ses-imagotag.com We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. We, SES-imagotag GmbH, FRN: 0024111486, hereby authorize TÜV AUSTRIA Services GmbH to act on our behalf in all matters relating to applications for equipment authorization of VUSION Gate E1-G1 FCC ID: 2ACQM-APG3-VGE1- B, including the signing of all documents relating to these matters. Any and all acts carried out by TÜV AUSTRIA Services GmbH on our behalf shall have the same effect as acts of our own. All statements we make in our request for equipment authorization are true and correct to the best of our knowledge and belief. SES-imagotag GmbH I Kalsdorfer Straße 12 I A-8072 Fernitz-Mellach - AUSTRIA FB: FN350927w I HG : Graz I UID : ATU65936017 I WEEE : DE 65879240 T. +43 (0) 5 9460-400 I F. +43 (0) 5 9460-900 I E. [email protected] I www.ses-imagotag.com

SES-imagotag GmbH I Kalsdorfer Straße 12 I A-8072 Fernitz-Mellach - AUSTRIA CR: FN350927w I Commercial court: Graz I UID : ATU65936017 T. +43 (0) 5 94604-00 I E. [email protected] I www.ses-imagotag.com Covered List, § 2.911(d)(5) Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 February 1, 2023 To whom it may concern, regarding the FCC 22-84 Report and Order and the Commission’s Covered List https://www.fcc.gov/supplychain/coveredlist. 1 SES-imagotag GmbH (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. SES-imagotag GmbH (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Philipp Jauck Head of IP Management & Regulatory Compliance Phone: +43 664 88252901 [email protected] www.ses-imagotag.com SES-imagotag GmbH Kalsdorfer Strasse 12 8072 Fernitz-Mellach Austria 1 The inclusion of producers or providers of equipment or services identified on this list should be read to include the subsidiaries and affiliates of such entities.

SES-imagotag GmbH I Kalsdorfer Straße 12 I A-8072 Fernitz-Mellach - AUSTRIA CR: FN350927w I Commercial court: Graz I UID : ATU65936017 T. +43 (0) 5 94604-00 I E. [email protected] I www.ses-imagotag.com U.S. Agent for Service of Process, § 2.911(d)(7) Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 February 8, 2023 To whom it may concern, As required by section US Code Title 47 § 2.911(d)(7), the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. We, SES-Imagotag Inc. accept the obligation to act as U.S. agent for service of process on behalf of the applicant. Adress: SES-Imagotag Inc. 625 N. Michigan Ave., Suite 650 Chicago, IL 60611 United States Email: [email protected] We, SES-imagotag GmbH consent to SES-Imagotag Inc. acting as our U.S. agent for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. DocuSign Envelope ID: EE0D6C40-A92A-4B65-B3CB-00B6AA0288EB SES-imagotag GmbH I Kalsdorfer Straße 12 I A-8072 Fernitz-Mellach - AUSTRIA CR: FN350927w I Commercial court: Graz I UID : ATU65936017 T. +43 (0) 5 94604-00 I E. [email protected] I www.ses-imagotag.com Sincerely, The U.S. Agent for Service of Process: Philippe Bottine (CEO) Signature (can be electronically inserted) SES-Imagotag Inc. 625 N. Michigan Ave., Suite 650 Chicago, IL 60611 United States The Applicant for Equipment Authorization: Philipp Jauck Signature (can be electronically inserted) Head of IP Management & Regulatory Compliance SES-imagotag GmbH Kalsdorfer Strasse 12 8072 Fernitz-Mellach Austria DocuSign Envelope ID: EE0D6C40-A92A-4B65-B3CB-00B6AA0288EB

Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 April 17, 2023 TO WHOM IT MAY CONCERN FCC ID Number Product: Title/Model o Product Code: APG3-VGE1-B / FCC: 2ACQM-APG3-VGE1-B For the product stated above, we request that the following information be held Long-Term confidential: 1. Circuit diagrams, BOM, and PCBs submitted as Equipment Authorization Electronic Filing attachment: “folder: Hardware” 2. Block diagram, Operational description submitted as Equipment Authorization For the product stated above, we request that the following information be held Short-Term confidential: 1. External photos 2. Test setup photos 3. Internal photos 4. User's manual If you have any questions, please feel free to contact me at the address shown below. Sincerely, Philipp Jauck, Head of IP Management & Regulatory Compliance SES-imagotag GmbH Kalsdorfer Strasse 12 8072 Fernitz-Mellach, Austria Mobil: +43 664 88252901 [email protected] www.ses-imagotag.com CONFIDENTIALITY REQUEST Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, SES-imagotag GmbH (FRN: 0023782022) requests confidentiality for the following products: The above exhibits contain SES-imagotag GmbH trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our Smart Tagging System. This material is not customarily available to the general public and we request that it be withheld from public inspection. SES-imagotag GmbH I Kalsdorfer Straße 12 I A-8072 Fernitz-Mellach - AUSTRIA FB: FN350927w I HG : Graz I UID : ATU65936017 I WEEE : DE 65879240 T. +43 (0) 5 9460-400 I F. +43 (0) 5 9460-900 I E. [email protected] I www.ses-imagotag.com

Coverletter: SES-Imagotag GmbH wants to get FCC-Certification for the following device: APG3-VGE1-B. The unit will get the following FCC-ID: 2ACQM-APG3-VGE1-B The device is an access point for electronic shelf labelling systems. The access point transmits information to the displays and receives acknowledgements. List of documents: Exhibit Thema File Exhibit 01 Label and placement label_and_placement.pdf Exhibit 02 Applicant Authorization Covered List US Agent for Service of Process FCC Authorization Letter - VUSION Gate E1-G1 - APG3-VGE1-B.pdf TUV_Covered_List_FCC_IC_20230201_signed.pdf TUV_US Agent for Service of Process_20230208_2x_signed.pdf ° Exhibit 03 External Photos photos_external.pdf * Exhibit 04 Block Diagrams AppMini02C VGate Module Blockdiagram.pdf RFACP003J00B_BlockDiagram_v1.0.pdf SeCoMo01B Compute Module Blockdiagram.pdf * Exhibit 05 Schematic Diagrams antbrd001a00b_schematics_v1.1.pdf AppMini02C.pdf RFACP003J00B_Schematics_v1.0.pdf SeCoMo01B.pdf Exhibit 06 Testreport 2023-IN-AT-TICL-E-EX-0-000006-FG-002-Rev- 1_noPhotos.pdf ° Exhibit 07 Test Set-up Photos photos_setup.pdf ° Exhibit 08 User Manual V-Gate Productionsheet-2023-04-19_FCC_IC.pdf ° Exhibit 09 Internal Photos photos_internal.pdf Exhibit 10 Antenna Information see test report see internal photos Exhibit 11 RF exposure see test report * Exhibit 12 Operational Description FCC Protocol Timing Specification.pdf 2023-04-28 Operational Description APG3-VGE1- B.pdf Exhibit 13 Cover letter Request for confidentiality This file Long Term - Short Term Confidentiality Request FCC - VUSION Gate E1-G - APG3-VGE1-B.pdf For the Exhibits marked with ‘*’ SES-imagotag GmbH requested Long-Term Confidentiality and for exhibits marked with ‘°’ SES-imagotag GmbH requested Short-Term Confidentiality according to 47 CFR 0.457 and 0.459 of the FCC rules because these are sensitive parts owned by this company and include much of know-how or sensitive data, it will not be provided to the public. Regarding part 15 antenna information: The device uses an internal sheet metal inverted-F antenna (IFA) that is custom built on the PCB. The antenna is shown in the internal photo exhibit. Measured antenna gain is given in the test report. The labelling on some photos may be not the actual status. The correct labelling is shown on the label photo in Exhibit 1.

www.tuv.at | [email protected] | T‹V Æ DN- FM-INE-EMV-ALL-Anl2_en Rev00 Appendix 2 Photodocumentation Description: Top view Division: Industry & Energy Test report reference: 2023-IN-AT-TICL-E-EX-0- 000006-FG-002- Rev-1 Page: 1 of 17 Date: 19.04.2023 www.tuv.at | [email protected] | T‹V Æ DN- FM-INE-EMV-ALL-Anl2_en Rev00 Appendix 2 Photodocumentation Description: Bottom view Division: Industry & Energy Test report reference: 2023-IN-AT-TICL-E-EX-0- 000006-FG-002- Rev-1 Page: 2 of 17 Date: 19.04.2023 www.tuv.at | [email protected] | T‹V Æ DN- FM-INE-EMV-ALL-Anl2_en Rev00 Appendix 2 Photodocumentation Description: Connectors Division: Industry & Energy Test report reference: 2023-IN-AT-TICL-E-EX-0- 000006-FG-002- Rev-1 Page: 3 of 17 Date: 19.04.2023 www.tuv.at | [email protected] | T‹V Æ DN- FM-INE-EMV-ALL-Anl2_en Rev00 Appendix 2 Photodocumentation Description: Product Label Division: Industry & Energy Test report reference: 2023-IN-AT-TICL-E-EX-0- 000006-FG-002- Rev-1 Page: 4 of 17 Date: 19.04.2023

www.tuv.at | [email protected] | T‹V Æ DN- FM-INE-EMV-ALL-Anl2_en Rev00 Appendix 2 Photodocumentation Description: Case opened Division: Industry & Energy Test report reference: 2023-IN-AT-TICL-E-EX-0- 000006-FG-002 -Rev-1 Page: 5 of 17 Date: 19.04.2023 www.tuv.at | [email protected] | T‹V Æ DN- FM-INE-EMV-ALL-Anl2_en Rev00 Appendix 2 Photodocumentation Description: Internal view #1 Division: Industry & Energy Test report reference: 2023-IN-AT-TICL-E-EX-0- 000006-FG-002 -Rev-1 Page: 6 of 17 Date: 19.04.2023 www.tuv.at | [email protected] | T‹V Æ DN- FM-INE-EMV-ALL-Anl2_en Rev00 Appendix 2 Photodocumentation Description: Internal view #2 Division: Industry & Energy Test report reference: 2023-IN-AT-TICL-E-EX-0- 000006-FG-002 -Rev-1 Page: 7 of 17 Date: 19.04.2023 www.tuv.at | [email protected] | T‹V Æ DN- FM-INE-EMV-ALL-Anl2_en Rev00 Appendix 2 Photodocumentation Description: Internal view #3 Division: Industry & Energy Test report reference: 2023-IN-AT-TICL-E-EX-0- 000006-FG-002 -Rev-1 Page: 8 of 17 Date: 19.04.2023 www.tuv.at | [email protected] | T‹V Æ DN- FM-INE-EMV-ALL-Anl2_en Rev00 Appendix 2 Photodocumentation Description: Internal view #4 Division: Industry & Energy Test report reference: 2023-IN-AT-TICL-E-EX-0- 000006-FG-002- Rev-1 Page: 9 of 17 Date: 19.04.2023 www.tuv.at | [email protected] | T‹V Æ DN- FM-INE-EMV-ALL-Anl2_en Rev00 Appendix 2 Photodocumentation Description: Internal view #5 Division: Industry & Energy Test report reference: 2023-IN-AT-TICL-E-EX-0- 000006-FG-002 -Rev-1 Page: 10 of 17 Date: 19.04.2023 www.tuv.at | [email protected] | T‹V Æ DN- FM-INE-EMV-ALL-Anl2_en Rev00 Appendix 2 Photodocumentation Description: Internal view #6 Division: Industry & Energy Test report reference: 2023-IN-AT-TICL-E-EX-0- 000006-FG-002 -Rev-1 Page: 11 of 17 Date: 19.04.2023 www.tuv.at | [email protected] | T‹V Æ DN- FM-INE-EMV-ALL-Anl2_en Rev00 Appendix 2 Photodocumentation Description: Internal view #7 Division: Industry & Energy Test report reference: 2023-IN-AT-TICL-E-EX-0- 000006-FG-002 -Rev-1 Page: 12 of 17 Date: 19.04.2023 www.tuv.at | [email protected] | T‹V Æ DN- FM-INE-EMV-ALL-Anl2_en Rev00 Appendix 2 Photodocumentation Description: Internal view #8 Division: Industry & Energy Test report reference: 2023-IN-AT-TICL-E-EX-0- 000006-FG-002 -Rev-1 Page: 13 of 17 Date: 19.04.2023 www.tuv.at | [email protected] | T‹V Æ DN- FM-INE-EMV-ALL-Anl2_en Rev00 Appendix 2 Photodocumentation Description: Internal view #9 Division: Industry & Energy Test report reference: 2023-IN-AT-TICL-E-EX-0- 000006-FG-002- Rev-1 Page: 14 of 17 Date: 19.04.2023

www.tuv.at | [email protected] | T‹V Æ DN: FM-INE-EMV-EMC-0100a_en Page 1 of 20 2023-IN-AT-TICL-E-EX-0-000006-FG-002-Rev-1.docx Rev04 TEST REPORT of the accredited test laboratory T‹V Nr.: 2023-IN-AT-TICL-E-EX-0-000006-FG-002- Rev-1 Applicant: SES-imagotag GmbH Kalsdorfer Strasse 12 A 3 8072 Fernitz-Mellach Tested Product: Electronic shelf labelling system 3 Access Point Product Name: VUSION Gate E1-G1 Model: APG3-VGE1-B FCC-ID: 2ACQM-APG3-VGE1-B IC-ID: 12154A-APG3VGE1B Manufacturer: SES-imagotag GmbH Kalsdorfer Strasse 12 A 3 8072 Fernitz-Mellach Output power / field strength: 40,74 mV/m average @ 3m distance power supply: 5V DC via external power supply Frequency range: 2404,053 - 2479,285 MHz Channel separation: 0,35 MHz Standard: FCC: 47 CFR Part 15 (eCFR 20.12.2022) RSS-102 Issue 5, March 2015 RSS-210 Issue 10, December 2019 T‹V AUSTRIA SERVICES GMBH Test laboratory for EMC Ing. Andreas Malek examined by / Testing Laboratory T‹V AUSTRIA SERVICES GMBH Official seal 19.04.2023 Ing. Michael Emminger approved by / Testing Laboratory T‹V AUSTRIA SERVICES GMBH A publication of this test report is only permitted literally. Copying or reproduction of partial sections needs a written permission of T‹V AUSTRIA SERVICES GMBH. The results of this test report only refer to the provided equipment. T‹V AUSTRIA SERVICES GMBH Office: Deutschstrasse 10 1230 Vienna/Austria T: +43 5 0454-0 F: +43 5 0454-6505 E: [email protected] W: www.tuv.at Business Area Industry & Energy Austria Technik T‹V Æ Testing Laboratory, Inspection Body, Certification Body, Calibration Laboratory, Verifizierungsstelle Notified Body 0408 IC 2932K-1 Non-executive Board of Directors: KR DI Johann Marihart Management: DI Dr. Stefan Haas Mag. Christoph Wenninger Registered Office: Deutschstrasse 10 1230 Vienna/Austria Branch Offices: www.tuv.at/standorte Company Register Court / - Number: Vienna / FN 288476 f Bank Details: IBAN AT131200052949001066 BIC BKAUATWW VAT ATU63240488 DVR 3002476 www.tuv.at | [email protected] | T‹V Æ Test Report Reference: 2023-IN-AT-TICL-E-EX-0-000006-FG-002 -Rev-1 Date: 19.04.2023 Ambient temperature: 23∞C Relative humidity: 20% DN: FM-INE-EMV-EMC-0100a_en Page 2 of 20 2023-IN-AT-TICL-E-EX-0-000006-FG-002-Rev-1.docx Rev04 Contents Designation PAGE 1. Applicant 3 2. Description of EUT 4 3. Standards / Final result 5 4. Test results List of measurements according to 47 CFR 15 and RSS-210 4.1 Test object data 6 4.2 Number of channels and channel spacing 7 4.3 Duty Cycle for averaging 8 4.4 Field strength at 2400 3 2483,5 MHz 9-11 4.5 Emissions outside 2400 3 2483,5 MHz (15.209) 12-16 4.6 AC conducted emissions (15.207) 17 4.7 RF Exposure 18-20 Appendix Designation PAGES 1 Test equipment used 5 2 Photodocumentation 17 www.tuv.at | [email protected] | T‹V Æ Test Report Reference: 2023-IN-AT-TICL-E-EX-0-000006-FG-002 -Rev-1 Date: 19.04.2023 Ambient temperature: 23∞C Relative humidity: 20% DN: FM-INE-EMV-EMC-0100a_en Page 3 of 20 2023-IN-AT-TICL-E-EX-0-000006-FG-002-Rev-1.docx Rev04 1. Applicant Company: SES-imagotag GmbH Department: Product & Project Manager Address: A 3 8072 Fernitz-Mellach; Kalsdorfer Strasse 12 Contact person: Mr. Philipp Jauck EUT received on: 20.12.2022 Tests were performed on: 20. till 23.12.2022 and 13.02.2023 www.tuv.at | [email protected] | T‹V Æ Test Report Reference: 2023-IN-AT-TICL-E-EX-0-000006-FG-002 -Rev-1 Date: 19.04.2023 Ambient temperature: 23∞C Relative humidity: 20% DN: FM-INE-EMV-EMC-0100a_en Page 4 of 20 2023-IN-AT-TICL-E-EX-0-000006-FG-002-Rev-1.docx Rev04 2. Description of EUT EUT: Electronic shelf labelling system 3 Access Point Product Name: VUSION Gate E1-G1 Model: APG3-VGE1-B Serial Number: Prototype Manufacturer: SES-imagotag GmbH A 3 8072 Fernitz-Mellach; Kalsdorfer Strasse 12 Description: SES-imagotag GmbH provided the following configuration for the measurements: Prototype with special test-firmware for continuous transmission Operating mode: The measurements were carried out at the following running states: test-firmware running, transmitting continuously Technical data EUT: Rated voltage: 5VDC Rated current: <3A Rated frequency: DC Mains voltage during the tests: 5VDC via external power supply Climatic conditions in the emc laboratory: Relative humidity: 20% Temperature: 23∞C www.tuv.at | [email protected] | T‹V Æ Test Report Reference: 2023-IN-AT-TICL-E-EX-0-000006-FG-002 -Rev-1 Date: 19.04.2023 Ambient temperature: 23∞C Relative humidity: 20% DN: FM-INE-EMV-EMC-0100a_en Page 5 of 20 2023-IN-AT-TICL-E-EX-0-000006-FG-002-Rev-1.docx Rev04 3. Standards / Final result Name Title Deviation Result Title 47 CFR Part 15 eCFR 20.12.2022 RADIO FREQUENCY DEVICES none OK RSS-210 Issue 10, December 2019 Licence-Exempt Radio Apparatus: Category I Equipment none OK Result: Opinions and interpretation of testing laboratory OK: EUT passed NOK: EUT failed www.tuv.at | [email protected] | T‹V Æ Test Report Reference: 2023-IN-AT-TICL-E-EX-0-000006-FG-002 -Rev-1 Date: 19.04.2023 Ambient temperature: 23∞C Relative humidity: 20% DN: FM-INE-EMV-EMC-0100a_en Page 6 of 20 2023-IN-AT-TICL-E-EX-0-000006-FG-002-Rev-1.docx Rev04 4.1 TEST OBJECT DATA General EUT Description This transceiver is working in a network consisting of a controller station, so called Accesspoint, and various displays. The Accesspoint transmits information to the displays and receives acknowledgements. This device is an Accesspoint operating in the network system. 2.1033 (c) Technical description 2.1033 (4) Type of emission: Minimum shift keying 3 declared channel bandwidth 250 kHz 3 8virtual9 channel spacing about 0,35 MHz. Only 11 channels from the channel plan are used, therefore the channel spacing in reality is much higher and varies from 2,45 MHz minimum up to 17,15 MHz. 2.1033 (5) Frequency range: 2404,053 3 2479,285 MHz (channel center frequencies of channel 0 up to ch. 10) 2.1033 (6) Power range and Controls: The maximum field strength measured is 40,74 mV/m average @ 3m distance. There is no power control or regulation. 2.1033 (7) Maximum o…
