2ACWISE32HYTLED TV

ELEFJ322S INSTRUCTION MANUAL Please read all the instructions carefully before using this TV, and keep the manual for future reference. 32" HD Digital LED TV 1 CONTENTS CONTENTS Important Safety Instructions 2 Additional Safety Information 3 Preparations 4 What's Included Front View Rear View Wall Mounting Remote Control Connecting External Devices 8 Customizing TV Settings 9 Turning On/Off Your TV Setup Wizard Navigating The On-screen Display Streaming Media Viewing Photos Listening To Music Selecting The Input Source Channel Selection Volume Adjustment Setup Settings Audio Settings Picture Settings Channel Settings Time Settings Network Settings Lock Settings Parental Control Troubleshooting 25 FCC Notes 28 Specifications 28 OTT APP Service 29 2 IMPORTANT SAFETY INSTRUCTIONS • Read these instructions – All the safety and operating instructions should be read before this product is operated. • Keep these instructions – The safety and operating instructions should be retained for future reference. • Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to. • Follow all instructions – All operating and use instructions should be followed. • Do not use this apparatus near water – The appliance should not be used near water or moisture – for example, in a wet basement or near a swimming pool, and the like. • Clean only with dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. • Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. • Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. • Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. • Only use attachments/accessories specified by the manufacturer. • Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. • Unplug this apparatus during lightning storms or when unused for long periods of time. • Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. • Please keep the unit in a well-ventilated environment. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus should not be exposed to dripping or splashing. Objects filled with liquids, such as vases should not be placed on apparatus. WARNING: The batteries shall not be exposed to excessive heat such as sunshine, fire or the like. WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable. WARNING: To reduce the risk of electric shock, do not remove cover (or back) as there are no user-serviceable parts inside. Refer servicing to qualified personnel. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the appliance. This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require a safety connection to electrical earth. This product meets ENERGY STAR ® guidelines for energy efficiency. ENERGY STAR ® and the ENERGY STAR ® mark are registered U.S. marks. ENERGY STAR ® is a registered mark owned by the U.S. government. RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR 3 ADDITIONAL SAFETY INFORMATION To ensure reliable and safe operation of this equipment, please read carefully all the instructions in this user guide, especially the safety information below. Electrical Safety • The TV set should only be connected to a main power supply with voltage that matches the label at the rear of the product. • To prevent overload, do not share the same power supply socket with too many other electronic components. • Do not place any connecting wires where they may be stepped on or tripped over. • Do not place heavy items on them, which may damage the leads. • Hold the main plug, not the wires, when removing from a socket. • During a thunderstorm, or when not using the television for extended period of time, turn off the power switch on the back of the television. • Do not allow water or moisture to enter the TV or power adapter. Do NOT use in wet, moist areas, such as bathrooms, steamy kitchens or near swimming pools. • Pull the plug out immediately, and seek professional help if the main plug or cable is damaged, liquid is spilt onto the set, if accidentally exposed to water or moisture, if anything accidentally penetrates the ventilation slots or if the set does not work normally. • Do not remove the safety covers. There are no user serviceable parts inside. Trying to service the unit yourself is dangerous and may invalidate the product’s warranty. Qualified personnel must only service this apparatus. • To avoid battery leakage, remove exhausted batteries from the remote control, or when not using…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Shenyang Tongfang Multimedia Technology Co., Limited (2015-07-30) To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _____Shenyang Tongfang Multimedia Technology Co., Limited _hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product: LED TV M/N: SE32HYT, LE-32GY15T, LE-32GY15T1, LE-32GY15-T3, SE32FYT, ELSFWC321, ELEFJ322S, EW32XXXXXXXXX, DWM32XXXXXXXXX, SEXXXXXXXXX, ELXXXXXXXXX, LE32GXXXXXXXXX, LE-32GXXXXXXXXX (where X would be any Arabic number or English letter or blank) FCC ID: 2ACWISE32HYT Sincerely, Yu Li Engineer Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Shenyang Tongfang Multimedia Technology Co., Limited (2015-07-30) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ACWISE32HYT We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Yu Li Engineer Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China

Declaration on model difference Page 1 of 1 We the undersigned hereby confirm that these models are identical, and all models have the same RF module and antenna, except for decorative parts in front panels, color of enclosures, the only differences are the trade mark and model no. for trading purpose. „ Productio n name Trade name FCC ID INPUT Model no. LED TV THTF, Fluid, Westinghouse, Seiki, Element 2ACWISE32HYT AC 100V- 240V, 50/60Hz, 60W SE32HYT, LE-32GY15T, LE- 32GY15T1, LE-32GY15-T3, SE32FYT, ELSFWC321, ELEFJ322S, EW32XXXXXXXXX, DWM32XXXXXXXXX, SEXXXXXXXXX, ELXXXXXXXXX, LE32GXXXXXXXXX, LE- 32GXXXXXXXXX (where X would be any Arabic number or English letter or blank) Confirmed by: Yu Li Engineer 2015-07-31 Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China

Shenyang Tongfang Multimedia Technology Co., Limited WIFI Channel 12 & 13 Declaration Letter To whom it may concern : We have declared below featured for FCC equipment authorization in regard to 802.11b/g/n channel 12 & 13 operating capability for FCC ID: 2ACWISE32HYT Please check Product hardware does not have the capability to operate on channel 12 & 13 Product hardware has the capability to operate on channel 12 & 13. However , these 2 channels will be disabled via software and user will not able to enable these 2 channels Product hardware has the capability to operate on channel 12 & 13. And meeting KDB 594280 D01 requirement. Pls explain detail here. Others Pls explain detail here. Yu Li Engineer Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China Telephone: 86-755-33010881 E-mail: [email protected]

Label Location on EUT

Antenna

RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) FCC ID：2ACWISE32HYT EUT Specification EUT LED TV Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Exposure classification Occupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 802.11b: 14.72dBm 802.11g: 13.42dBm 802.11n(HT20): 12.69dBm 802.11n(HT40): 11.56dBm Antenna gain (Max) 2dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where Pd= Power density in mW/cm 2 , Pout=output power to antenna in Mw G= gain of antenna in linear scale, Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Test Channel Measurement Peak Output Power(dBm) 802.11b 802.11g 802.11n(HT20) 802.11n(HT40) Lowest 12.05 11.10 10.28 9.14 Middle 13.69 12.62 11.44 10.03 Highest 14.72 13.42 12.69 11.56 Operating Mode Test Channel Tune up tolerance (dBm) Max tune up conducted power(dBm) Output Peak power (mW) Ant. Gain (dBi) Ant. Gain (nume ric) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 802.11b 1 12±1 13 19.95 2 1.585 0.006292 1 6 14±1 15 31.62 2 1.585 0.009971 1 11 15±1 16 39.81 2 1.585 0.012553 1 802.11g 1 11±1 12 15.85 2 1.585 0.004998 1 6 13±1 14 25.12 2 1.585 0.007921 1 11 13±1 14 25.12 2 1.585 0.007921 1 802.11n (H20) 1 10±1 11 12.59 2 1.585 0.003970 1 6 11±1 12 15.85 2 1.585 0.004998 1 11 13±1 14 25.12 2 1.585 0.007921 1 802.11n (H40) 3 9±1 10 10.00 2 1.585 0.003153 1 6 10±1 11 12.59 2 1.585 0.003970 1 9 12±1 13 19.95 2 1.585 0.006292 1 Signature: Print: Sam Lv Title: Manager Date: 2015-07-30

TRF No.: FCC 15.247/A Page 1 of 82 Report No.: KAD150603010E Ver.1.0 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF LED TV Model No.: SE32HYT, LE-32GY15T, LE-32GY15T1, LE-32GY15-T3, SE32FYT, ELSFWC321, ELEFJ322S, EW32XXXXXXXXX, DWM32XXXXXXXXX, SEXXXXXXXXX, ELXXXXXXXXX, LE32GXXXXXXXXX, LE-32GXXXXXXXXX (where X would be any Arabic number or English letter or blank) FCC ID: 2ACWISE32HYT Trademark: THTF, Fluid, Westinghouse, Seiki, Element Report No.: KAD150603010E Issue Date: July 29, 2015 Prepared for Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road HunNan New District Shenyang, LiaoNing Province P.R .China Prepared by DONGGUAN EMTEK CO., LTD. No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China TEL: 86-769-22807078 FAX: 86-769-22807079 This report shall not be reproduced, except in full, without the written approval of DONGGUAN EMTEK CO., LTD. TRF No.: FCC 15.247/A Page 2 of 82 Report No.: KAD150603010E Ver.1.0 VERIFICATION OF COMPLIANCE Applicant: Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China Manufacturer: Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China Product Description: LED TV Model Number: SE32HYT, LE-32GY15T, LE-32GY15T1, LE-32GY15-T3, SE32FYT, ELSFWC321, ELEFJ322S, EW32XXXXXXXXX, DWM32XXXXXXXXX, SEXXXXXXXXX, ELXXXXXXXXX, LE32GXXXXXXXXX, LE-32GXXXXXXXXX (where X would be any Arabic number or English letter or blank) We hereby certify that: The above equipment was tested by DONGGUAN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10-2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247(2014). Date of Test : June 03, 2015 to July 29, 2015 Prepared by : Ivy Huang/Editor Reviewer : Hong Yang/Supervisor Approved & Authorized Signer : Sam Lv/Manager TRF No.: FCC 15.247/A Page 3 of 82 Report No.: KAD150603010E Ver.1.0 Modified Information Version Summary Revision Date Report No. Ver.1.0 Original Report / KAD150603010E TRF No.: FCC 15.247/A Page 4 of 82 Report No.: KAD150603010E Ver.1.0 Table of Contents 1. GENERAL INFORMATION ...................................................................................................................... 6 1.1 PRODUCT DESCRIPTION ...................................................................................................................... 6 2. SYSTEM TEST CONFIGURATION ......................................................................................................... 7 2.1 EUT CONFIGURATION .......................................................................................................................... 7 2.2 EUT EXERCISE ................................................................................................................................... 7 2.3 TEST PROCEDURE ............................................................................................................................... 7 2.4 CONFIGURATION OF TESTED SYSTEM ................................................................................................... 7 3. DESCRIPTION OF TEST MODES ........................................................................................................... 8 4. SUMMARY OF TEST RESULTS .............................................................................................................. 9 5. TEST FACILITY ...................................................................................................................................... 10 6. CONDUCTED EMISSIONS TEST ......................................................................................................... 11 6.1 MEASUREMENT PROCEDURE ............................................................................................................. 11 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ........................................................................ 11 6.3 MEASUREMENT EQUIPMENT USED ..................................................................................................... 11 6.4 CONDUCTED EMISSION LIMIT ............................................................................................................. 11 6.5 MEASUREMENT RESULT ..................................................................................................................... 11 7. RADIATED EMISSION TEST ................................................................................................................. 16 7.1 MEASUREMENT PROCEDURE ............................................................................................................. 16 7.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ........................................................................ 17 7.3 MEASUREMENT EQUIPMENT USED ..................................................................................................... 18 7.4 RADIATED EMISSION LIMIT ................................................................................................................. 19 7.5 MEASUREMENT RESULT ..................................................................................................................... 20 8. 6DB BANDWIDTH TEST ....................................................................................................................... 37 8.1 MEASUREMENT PROCEDURE ............................................................................................................. 37 8.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ........................................................................ 37 8.3 MEASUREMENT EQUIP…
