2ACWISE42UMTLED TV

SE42UMT Read the User Manual carefully before using the TV and keep it for further reference. Avant d’utiliser le téléviseur, lisez attentivement le manuel d’utilisation et conservez-le pour consultation future. Lea el Manual del usuario antes de utilizar el televisor y consérvelo para futuras consultas. USER MANUAL MANUEL D’UTILISATION MANUAL DEL USUARIO 1 En - CONTENTSImportant Safety Instructions Safety Information Preparation What's Included Front View Rear View Installing the Stand Removing the Stand for Wall-Mounting Remote Control Connecting External Devices Customizing TV Settings Initial Setup Navigating the Setup Settings Streaming Media Viewing Photos Listening to Music Source Setup System Channel Support Lock Picture Network Audio Parental Control Troubleshooting Maintaining   Limited Warranty OTT APP Service 2344567 789 10 10 11 1213131414151517171819202223252727 29 30 2 En - IMPORTANT SAFETY INSTRUCTIONS Read these instructions – All the safety and operating instructions should be read before this product is operated. Keep these instructions – The safety and operating instructions should be retained for future reference. Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to. Follow all instructions – All operating and use instructions should be followed. Do not use this apparatus near water – The appliance should not be used near water or moisture – for example, in a wet basement or near a swimming pool, and the like.  Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other        Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for             replacement of the obsolete outlet.  Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.                !    "         #          or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.  Please keep the unit in a well-ventilated environment.WARNING: $  #    # %       $   %      &   with liquids, such as vases should not be placed on apparatus. WARNING: $    % %         the like.WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable.WARNING: $     #      #       #      (    )  *    $   + " "  "   *       to alert the user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the appliance. This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require a safety connection to electrical earth.This product contains electrical or electronic materials. The presence of these materials may,if not disposed of properly, have potential adverse effects on the environment and human health. Presence of this label on the product means it should not be disposed of as unsorted waste and must be collectedseparately. As a consumer, you are responsible for ensuring that this product is disposed of properly.  Unplug this apparatus during lightning storms or when unused for long periods of time. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as the power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 3 En - SAFETY INFORMATIONTo ensure reliable and safe operation of this equipment, please carefully read all the instructions in this user guide, especia lly the safety information below. Electrical Safety  The TV set should only be connected to a main power supply with voltage that matches the label at the rear of the product. To prevent overload, do not share the same power supply socket with too many other electronic components. Do not place any connecting wires where they may be stepped on or tripped over. Do not place heavy items on any connecting wire , which may damage the wire.  Hold the main plug, not the wires, when removing from a socket. During a thunderstorm or when not in using the television for long periods, turn off the power switch on the back of the tele vision.  Do not allow water or moisture to enter the TV or power adapter. Do not use in wet, moist areas, such as bathrooms, steamy ki tchens or near swimming pools.  Pull the plug out immediately, and seek professional help if the main plug or cable is damaged, liquid is spilled onto the se t, if the TV set accidentally exposed to water or moisture, if anything accidentally penetrates the ventilation slots or if the TV set does not work normally.  : …

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Shenyang Tongfang Multimedia Technology Co., Limited (2015-07-13) To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _____Shenyang Tongfang Multimedia Technology Co., Limited _hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product: LED TV M/N: LE-42GY15T, LE-42GY15-M1, SE42UMT, E4SFC421, EW42XXXXXXXXX, DWM42XXXXXXXXX, SEXXXXXXXXX, ELXXXXXXXXX, LE42GXXXXXXXXX, LE-42GXXXXXXXXX (where X would be any Arabic number or English letter or blank) FCC ID: 2ACWISE42UMT Sincerely, Yu Li Engineer Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Shenyang Tongfang Multimedia Technology Co., Limited (2015-07-13) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ACWISE42UMT We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Yu Li Engineer Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China

Shenyang Tongfang Multimedia Technology Co., Limited WIFI Channel 12 & 13 Declaration Letter To whom it may concern : We have declared below featured for FCC equipment authorization in regard to 802.11b/g/n channel 12 & 13 operating capability for FCC ID: 2ACWISE42UMT Please check Product hardware does not have the capability to operate on channel 12 & 13 Product hardware has the capability to operate on channel 12 & 13. However , these 2 channels will be disabled via software and user will not able to enable these 2 channels Product hardware has the capability to operate on channel 12 & 13. And meeting KDB 594280 D01 requirement. Pls explain detail here. Others Pls explain detail here. Yu Li Engineer Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China Telephone: 86-755-33010881 E-mail: [email protected]

Date: 2015-07-13 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2ACWISE42UMT To Whom It May Concern: This letter is to ascertain that Shenyang Tongfang Multimedia Technology Co., Limited Product LED TV has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Yu Li Engineer Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China

Declaration on model difference Page 1 of 1 We the undersigned hereby confirm that these models are identical, and all models have the same RF module and antenna, except for decorative parts in front panels, color of enclosures, the only differences are the trade mark and model no. for trading purpose. „ Productio n name Trade name FCC ID INPUT Model no. LED TV THTF, Fluid, Westinghouse, Seiki, Element 2ACWISE42UMT AC 100V- 240V, 50/60Hz, 140W LE-42GY15T, LE-42GY15-M1, SE42UMT, E4SFC421, EW42XXXXXXXXX, DWM42XXXXXXXXX, SEXXXXXXXXX, ELXXXXXXXXX, LE42GXXXXXXXXX, LE-42GXXXXXXXXX (where X would be any Arabic number or English letter or blank) Confirmed by: Yu Li Engineer 2015-07-13 Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China

Model No.:SE42UMT 65mm INPUT POWER: AC 100-240V~ 50/60Hz, 140W S/N: CONFORMS TO/CONFORME À ANSI/UL STD.60065 CERTIFIED TO/CERTIFIÉ AU CAN/CSA STD. C22.2 No.60065 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. FCC ID:2ACWISE42UMT

Label Location on EUT

Antenna 1 Antenna 2

1 RF EXPOSURE EVALUATION EUT Specification EUT LED TV FCC ID 2ACWISE42UMT Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Exposure classification Occupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 14.27dBm for 802.11b; 13.62dBm for 802.11g; 11.53dBm for 802.11n(HT20); 11.04dBm for 802.11n(HT40); Antenna gain (Max) 2.0dBi ( for per antenna port Max) 5.01dBi for MIMO(Ant1+Ant2 Directional Gain) Evaluation applied MPE Evaluation SAR Evaluation 2 Applicable Standard: Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J. Section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m Normally can be maintained between the user and the device. Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f)* 6 30-300 61.4 0.163 1.0 6 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- F/1500 30 1500-100000 -- -- 1 30 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where Pd= Power density in mW/cm 2 , Pout=output power to antenna in Mw G= gain of antenna in linear scale, Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. 3 Measurement Result Max power Result: Operation Mode Channel Number Channel Frequency (MHz) Measurement Level (dBm) Limit (dBm) Verdict Ant1 Ant2 Sum 802.11b 1 2412 12.05 11.25-- 30 PASS 6 2437 13.42 12.43-- 30 PASS 11 2462 14.27 13.67-- 30 PASS 802.11g 1 2412 11.62 10.25-- 30 PASS 6 2437 12.47 11.74-- 30 PASS 11 2462 13.62 12.92-- 30 PASS 802.11n (HT20) 1 2412 6.59 7.46 10.06 28 PASS 6 2437 7 8.13 10.61 28 PASS 11 2462 8.41 8.63 11.53 28 PASS 802.11n (HT40) 3 2422 6.24 7.41 9.87 28 PASS 6 2437 7.13 7.92 10.55 28 PASS 9 2452 8.04 8.01 11.04 28 PASS Antenna 1: Operating Mode Test Channel Tune up tolerance (dBm) Max tune up conducted power(dBm) Output Peak power (mW) Ant. Gain (dBi) Ant. Gain (numeric) Power density at 20cm (mW/ cm2 ) Power density Limits (mW/cm2 ) 802.11b 1 121 13 19.95 2 1.585 0.006292 1 6 131 14 25.12 2 1.585 0.007921 1 11 141 15 31.62 2 1.585 0.009971 1 802.11g 1 111 12 15.85 2 1.585 0.004998 1 6 121 13 19.95 2 1.585 0.006292 1 11 141 15 31.62 2 1.585 0.009971 1 802.11n (HT20) 1 71 8 6.31 2 1.585 0.001990 1 6 71 8 6.31 2 1.585 0.001990 1 11 81 9 7.94 2 1.585 0.002505 1 802.11n (HT40) 3 61 7 5.01 2 1.585 0.001580 1 6 71 8 6.31 2 1.585 0.001990 1 9 81 9 7.94 2 1.585 0.002505 1 4 Antenna 2: Operating Mode Test Channel Tune up tolerance (dBm) Max tune up conducted power(dBm) Output Peak power (mW) Ant. Gain (dBi) Ant. Gain (numeric) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 802.11b 1 111 12 15.85 2 1.585 0.004998 1 6 121 13 19.95 2 1.585 0.006292 1 11 141 15 31.62 2 1.585 0.009971 1 802.11g 1 101 11 12.59 2 1.585 0.003970 1 6 121 13 19.95 2 1.585 0.006292 1 11 131 14 25.12 2 1.585 0.007921 1 802.11n (HT20) 1 71 8 6.31 2 1.585 0.001990 1 6 81 9 7.94 2 1.585 0.002505 1 11 91 10 10.00 2 1.585 0.003153 1 802.11n (HT40) 3 71 8 6.31 2 1.585 0.001990 1 6 81 9 7.94 2 1.585 0.002505 1 9 81 9 7.94 2 1.585 0.002505 1 MPE Result: Operation Mode Channel Number Channel Frequency (MHz) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) Verdict Ant1 Ant2 Sum 802.11b 1 2412 0.006292 0.004998 -- 1 PASS 6 2437 0.007921 0.006292 -- 1 PASS 11 2462 0.009971 0.009971 -- 1 PASS 802.11g 1 2412 0.004998 0.003970 -- 1 PASS 6 2437 0.006292 0.006292 -- 1 PASS 11 2462 0.009971 0.007921 -- 1 PASS 802.11n (HT20) 1 2412 0.001990 0.001990 0.003980 1 PASS 6 2437 0.001990 0.002505 0.004495 1 PASS 11 2462 0.002505 0.003153 0.005658 1 PASS 802.11n (HT40) 3 2422 0.001580 0.001990 0.003570 1 PASS 6 2437 0.001990 0.002505 0.004495 1 PASS 9 2452 0.002505 0.002505 0.005010 1 PASS

TRF No: FCC 15.247/A Page 1 of 110 Report No.: KAD150408030E Ver.1.0 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF LED TV Model No.: LE-42GY15T, LE-42GY15-M1, SE42UMT, E4SFC421, EW42XXXXXXXXX,DWM42XXXXXXXXX, SEXXXXXXXXX, ELXXXXXXXXX, LE42GXXXXXXXXX, LE-42GXXXXXXXXX (where X would be any Arabic number or English letter or blank) FCC ID: 2ACWISE42UMT Trademark: THTF, Fluid, Westinghouse, Seiki, Element Report No.: KAD150408030E Issue Date: July 13, 2015 Prepared for Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road HunNan New District Shenyang, LiaoNing Province P.R .China Prepared by DONGGUAN EMTEK CO., LTD. No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China TEL: 86-769-22807078 FAX: 86-769-22807079 This report shall not be reproduced, except in full, without the written approval of DONGGUAN EMTEK CO., LTD. TRF No: FCC 15.247/A Page 2 of 110 Report No.: KAD150408030E Ver.1.0 VERIFICATION OF COMPLIANCE Applicant: Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China Manufacturer: Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China Product Description: LED TV Model Number: LE-42GY15T, LE-42GY15-M1, SE42UMT, E4SFC421, EW42XXXXXXXXX,DWM42XXXXXXXXX, SEXXXXXXXXX, ELXXXXXXXXX, LE42GXXXXXXXXX, LE-42GXXXXXXXXX (where X would be any Arabic number or English letter or blank) Input Rating: AC 100-240V, 50/60Hz, 140W We hereby certify that: The above equipment was tested by DONGGUAN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10-2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247(2014). Date of Test : April 08, 2015 to July 07, 2015 Prepared by : Ivy Huang/Editor Reviewer : Hong Yang/Supervisor Approved & Authorized Signer : Sam Lv/Manager TRF No: FCC 15.247/A Page 3 of 110 Report No.: KAD150408030E Ver.1.0 Modified Information Version Summary Revision Date Report No. Ver.1.0 Original Report / KAD150408030E TRF No: FCC 15.247/A Page 4 of 110 Report No.: KAD150408030E Ver.1.0 Table of Contents 1. GENERAL INFORMATION .......................................................................................................................... 6 1.1 PRODUCT DESCRIPTION ............................................................................................................................ 6 2. SYSTEM TEST CONFIGURATION ............................................................................................................. 7 2.1 EUT CONFIGURATION ............................................................................................................................... 7 2.2 EUT EXERCISE ......................................................................................................................................... 7 2.3 TEST PROCEDURE .................................................................................................................................... 7 2.4 CONFIGURATION OF TESTED SYSTEM ......................................................................................................... 7 3. DESCRIPTION OF TEST MODES .............................................................................................................. 8 4. SUMMARY OF TEST RESULTS ................................................................................................................. 9 5. TEST METHODOLOGY ............................................................................................................................... 9 6. TEST FACILITY ........................................................................................................................................... 9 7. TEST SYSTEM UNCERTAINTY ................................................................................................................ 10 8. CONDUCTED EMISSIONS TEST ............................................................................................................. 11 8.1 MEASUREMENT PROCEDURE ................................................................................................................... 11 8.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .............................................................................. 11 8.3 MEASUREMENT EQUIPMENT USED ........................................................................................................... 11 8.4 CONDUCTED EMISSION LIMIT ................................................................................................................... 11 8.5 MEASUREMENT RESULT .......................................................................................................................... 11 9. RADIATED EMISSION TEST .................................................................................................................... 16 9.1 MEASUREMENT PROCEDURE ................................................................................................................... 16 9.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .............................................................................. 17 9.3 MEASUREMENT EQUIPMENT USED ........................................................................................................... 18 9.4 RADIATED EMISSION LIMIT ....................................................................................................................... 19 9.5 MEASUREMENT RESULT .......................................................................................................................... 20 10. 6DB BANDWIDTH TEST ...............................…
