2ACWISE58GY27TLED TV

Printed in China www.SEIKI.com Service Hotlin e: 1-855-MY-SEIKI (1-855-697-3454) Ligne d’assistance téléphonique: Línea de servicio: Imprimé en Chine Impreso en China USER MANUAL Read the User Manual carefully before using the TV and keep it for further reference. MANUEL D’UTILISATION MANUAL DEL USUARIO Avant d’utiliser le téléviseur, lisez attentivement le manuel d’utilisation et conservez-le pour consultation future Lea el Manual del usuario antes de utilizar el televisor y consérvelo para futuras consultas SE58GY27T © 2014 Seiki LLCAll r ights reserved. 1 En - CONTENTS Important Safety Instructions 2 Safety Information 3 Preparation 4 What's Included 4 Front View 5 Rear View 6 Installing the Stand 7 Removing the Stand for Wall-Mounting 7 Remote Control 8 Connecting External Devices 9 Customizing TV Settings 10 Initial Setup 10 Navigating the Setup Settings 11 Streaming 12 Media 13 Viewing Photos 13 Listening to Music 14 Source 14 Setup 15 Settings 15 Audio 16 Picture 17 Channel 18 Time 18 Network 19 Lock 21 Parental Control 22 Troubleshooting 24 Maintaining 25 Specification 26 Limited Warranty 27 OTT APP Service 28 CONTENTS 2 En - IMPORTANT SAFETY INSTRUCTIONS • Read these instructions – All the safety and operating instructions should be read before this product is operated. • Keep these instructions – The safety and operating instructions should be retained for future reference. • Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to. • Follow all instructions – All operating and use instructions should be followed. • Do not use this apparatus near water – The appliance should not be used near water or moisture – for example, in a wet basement or near a swimming pool, and the like. • Clean only with dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. • Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. • Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding- type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. • Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. • Only use attachments/accessories specified by the manufacturer. • Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. • Unplug this apparatus during lightning storms or when unused for long periods of time. IMPORTANT SAFETY INSTRUCTIONS • Unplug this apparatus during lightning storms or when unused for long periods of time. • Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as the power - supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. • Please keep the unit in a well-ventilated environment. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus should not be exposed to dripping or splashing. Objects filled with liquids, such as vases should not be placed on apparatus. WARNING: The batteries shall not be exposed to excessive heat such as sunshine, fire or the like. WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable. WARNING: To reduce the risk of electric shock, do not remove cover (or back) as there are no user-serviceable parts inside. Refer servicing to qualified personnel. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the appliance. This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require a safety connection to electrical earth. This product contains electrical or electronic materials. The presence of these materials may,if not disposed of properly, have potential adverse effects on the environment and human health. Presence of this label on the product means it should not be disposed of as unsorted waste and must be collectedseparately. As a consumer, you are responsible for ensuring that this product is disposed of properly. 3 En - SAFETY INFORMATION To ensure reliable and safe operation of this equipment, please carefully read all the instructions in this user guide, especially the safety information below. Electrical Safety • The TV set should only be connected to a main power supply with voltage that matches the label at the rear of the product. • To prevent overload, do not share the same power supply socket with too many other electronic components. • Do not place any connecting wires where they may be stepped on or tripped over. • Do not place heavy items on any connecting wire, which may damage the wire. • Hold the main plug, not the wires, when removing from a socket. • During a thunderstorm or when not in using the television for long periods, turn off the power switch on the back of the television. • Do not allow water or moisture to enter the TV or power adapter. Do…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 4.0 Shenyang Tongfang Multimedia Technology Co., Limited (2014-09-02) To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ____ Shenyang Tongfang Multimedia Technology Co., Limited _____hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product Name: LED TV Model Number: SE58GY27T FCC ID: 2ACWISE58GY27T Sincerely, Yu Li Engineer Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Shenyang Tongfang Multimedia Technology Co., Limited (2014-09-02) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ACWISE58GY27T We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Yu Li Engineer Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China

LE-58GCL-B SE58GY27T SY14425 Model No.:SE58GY27T INPUT POWER: AC 100-240V ~ 50/60Hz, 150W CONFORMS TO/CONFORME À ANSI/UL STD.60065 CERTIFIED TO/CERTIFIÉ AU CAN/CSA STD. C22.2 No.60065 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. FCC ID : 2ACWISE58GY27T

Label Location On EUT

Antenna

RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) FCC ID：2ACWISE58GY27T EUT Specification EUT LED TV Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Exposure classification Occupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 20.66dBm for 802.11b 21.56dBm for 802.11g 20.15dBm for 802.11n(H20) 19.61dBm for 802.11n(H40) Antenna gain (Max) 2dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in Mw G= gain of antenna in linear scale Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Operating Mode Test Channel Output Peak power (dBm) Output Peak power (mW) Antenna Gain (dBi) Antenna Gain (numeric) Power density at 20cm (mW/ cm2 ) Power density Limits (mW/cm 2 ) 802.11b 1 18.75 74.989 2 1.585 0.0236459 1 6 19.99 99.770 2 1.585 0.0314600 1 11 20.66 116.413 2 1.585 0.0367079 1 802.11g 1 20.12 102.802 2 1.585 0.0324160 1 6 20.73 118.304 2 1.585 0.0373042 1 11 21.56 143.219 2 1.585 0.0451605 1 802.11n (H20) 1 18.69 73.961 2 1.585 0.0233218 1 6 19.27 84.528 2 1.585 0.0266538 1 11 20.15 103.514 2 1.585 0.0326406 1 802.11n (H40) 3 18.48 70.469 2 1.585 0.0222206 1 6 18.96 78.705 2 1.585 0.0248177 1 9 19.61 91.411 2 1.585 0.0288242 1 Signature: Yu Li No.10 Nanping East Road, HunNan New Dist., Shenyang, LiaoNing Province, China 86-755-33010881 86-755-33010881 [email protected]

TRF No：FCC 15.247/A Page 1 of 72 Report No.: KAD140806037E Ver.1.0 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF LED TV Model No. SE58GY27T FCC ID: 2ACWISE58GY27T Trademark: THTF, Fluid, Westinghouse, Seiki, Element, SANYO, SHARP Report No.: KAD140806037E Issue Date: September 01, 2014 Prepared for Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road HunNan New District Shenyang, LiaoNing Province P.R .China Prepared by DONGGUAN EMTEK CO., LTD. No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China TEL: 86-769-22807078 FAX: 86-769-22807079 TRF No：FCC 15.247/A Page 2 of 72 Report No.: KAD140806037E Ver.1.0 VERIFICATION OF COMPLIANCE Applicant: Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China Manufacturer: Shenyang Tongfang Multimedia Technology Co., Limited No.10 Nanping East Road Hunnan New District Shenyang, Liaoning Province P.R .China Product Description: LED TV Model Number: SE58GY27T File Number: KAD140806037E Date of Test: August 06, 2014 to August 21, 2014 We hereby certify that: The above equipment was tested by DONGGUAN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247(2013). The test results of this report relate only to the tested sample identified in this report. Approved By Sam Lv / Q.A. Manager DONGGUAN EMTEK CO., LTD. TRF No：FCC 15.247/A Page 3 of 72 Report No.: KAD140806037E Ver.1.0 Modified Information Version Summary Revision Date Report No. Ver.1.0 Original Report / KAD140806037E TRF No：FCC 15.247/A Page 4 of 72 Report No.: KAD140806037E Ver.1.0 Table of Contents 1. GENERAL INFORMATION ......................................................................................... 6 1.1 P RODUCT DESCRIPTION ........................................................................................... 6 1.2 R ELATED SUBMITTAL(S) / GRANT(S) .......................................................................... 6 1.3 T EST METHODOLOGY ............................................................................................... 7 1.4 S PECIAL ACCESSORIES ............................................................................................ 7 1.5 E QUIPMENT MODIFICATIONS ..................................................................................... 7 1.6 T EST FACILITY ......................................................................................................... 7 2. SYSTEM TEST CONFIGURATION ............................................................................ 8 2.1 EUT CONFIGURATION .............................................................................................. 8 2.2 EUT EXERCISE ....................................................................................................... 8 2.3 T EST PROCEDURE ................................................................................................... 8 2.4 C ONFIGURATION OF TESTED SYSTEM ........................................................................ 8 3. DESCRIPTION OF TEST MODES .............................................................................. 9 4. SUMMARY OF TEST RESULTS .............................................................................. 10 5. CONDUCTED EMISSIONS TEST ............................................................................. 11 5.1 M EASUREMENT PROCEDURE ................................................................................... 11 5.2 T EST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .............................................. 11 5.3 M EASUREMENT EQUIPMENT USED ........................................................................... 11 5.4 C ONDUCTED EMISSION LIMIT ................................................................................... 11 5.5 M EASUREMENT RESULT ......................................................................................... 12 6. RADIATED EMISSION TEST ................................................................................... 14 6.1 M EASUREMENT PROCEDURE .................................................................................. 14 6.2 T EST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................. 15 6.3 M EASUREMENT EQUIPMENT USED .......................................................................... 16 6.4 R ADIATED EMISSION LIMIT ...................................................................................... 16 6.5 M EASUREMENT RESULT ......................................................................................... 18 7. 6DB BANDWIDTH TEST .......................................................................................... 27 7.1 M EASUREMENT PROCEDURE .................................................................................. 27 7.2 T EST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................. 27 7.3 M EASUREMENT EQUIPMENT USED .......................................................................... 27 7.4 M EASUREMENT RESULTS ....................................................................................... 27 8. MAXIMUM PEAK OUTPUT POWER TEST ............................................................. 35 8.1 M EASUREMENT PROCEDURE .................................................................................. 35 8.2 T EST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................. 35 8.3 M EASUREMENT EQUIPMENT USED .......................................................................... 35 8.4 P EAK POWER OUTPUT LIMIT .....................…
