2ACWO-HC7-STelpad

TELPAD HC7 USER MANUAL 1 GETTING STARTED 01 1.1 About your Telpad 02 2 TELPAD INTRODUCTION 03 2.1 Getting to know your Telpad 04 2.2 Product Specification 07 2.3 Installation 09 2.3.1Basic Connection 09 2.3.2Installing the dock battery 10 2.3.3Docking and undocking the Tablet 10 3 TABLET FUNCTIONS 11 3.1 Turning the Tablet on or off 12 3.1.1To turn on your Tablet 12 3.1.2 To turn the Tablet off 12 3.2 Charging the battery 13 3.2.1Charging the Tablet battery 13 3.2.2Charging the dock battery 13 3.3 Working with the key 14 3.3.1Working the physical keys 14 3.3.2 Working the touchscreen keys 14 3.4 Using the touchscreen 15 3.5 Home screen 16 3.5.1Getting to know the Home screen 16 3.5.2Extended Home screens 17 3.5.3Customizing the Home screen 17 3.6 Locking and unlocking the screen 18 3.6.1Locking the screen 18 3.6.2Unlocking the screen 18 3.6.3Setting up a screen lock 18 3.6.4Setting a screen timeout period 18 3.7 Inputting text 19 3.7.1Entering text using the onscreen keyboard 19 3.7.2Cutting or copying text 20 3.8 Opening and switching applications 21 3.9 Accessing the Settings 21 3.10 Languages & input method & account setting 22 3.11 Setting the date and time 23 3.11.1 To automatically set date and time 23 3.11.2 To manually set date and time 23 3.12 Installing or removing the microSD card 24 3.13 Connecting or disconnecting from a computer using USB 25 3.14 Connecting the Tablet to a TV 26 3.15 Wireless networks 27 3.15.1 Opening Wi-Fi settings 27 3.15.2 Turning Wi-Fi on or off 27 3.15.3 Connecting to a Wi-Fi network 28 3.15.4 Turning open network notification on or off 28 3.15.5 Adding a Wi-Fi Network 28 3.15.6 Forgetting a Wi-Fi network 29 3.16 Bluetooth 30 3.16.1 Opening Bluetooth settings 30 3.16.2 Turning Bluetooth on or off 30 3.16.3 Changing the Bluetooth name of your Tablet 30 3.16.4 Connecting to Bluetooth devices 31 3.16.5 Disconnecting from or unpairing a Bluetooth device 31 3.17 Google Services 32 3.17.1 Creating a Google Account 32 3.17.2 Using Play Store 33 3.17.3 Searching for Applications 33 3.17.4 Installing an Application 33 3.17.5 Uninstalling an Application 34 3.17.6 Backing up and restoring apps and settings from a Google account 34 3.18 E-mail 34 3.18.1 Opening E-mail 34 3.18.2 Adding and deleting e-mail accounts 3 5 3.19 Using the Camera 37 3.20 Home control 38 3.20.1 IR Universal remote Initial Configuration 38 3.20.2 IR Learning 39 3.20.3 Reservation 40 3.20.4 Reservation Setup 41 3.20.5 Mobile remote control 42 3.20.6 Motion detection 45 3.21 Home care 47 3.22 Wifidisplay 54 3.22.1 Source 54 3.22.2 Sink 56 3.22.3 Attentions 58 3.23 DLNA 60 3.23.1 Wi-Fi connection 60 3.22.2 The brief introduction of interactions between tablet and modile phone 63 4 THE CONNECTION BETWEEN DOCK PHONE AND TABLE 67 4.1 Voice call Services 68 4.1.1 Making a call 68 4.1.2 Answering a call 69 4.1.3 Ending a call 69 4.1.4 Selecting area code 69 4.1.5 Favorites 70 4.1.6 Memo 70 4.1.7 Importing/exporting contacts 70 4.1.8 Changing ringtones 71 4.1.9 Contacts 71 4.2 Dock phone entertainment functions 73 4.2.1The speaker box function 73 4.3 Dock Phone Wifi Function 77 4.3.1 Interface Specification 77 4.3.2 Function and Configuration of WI-FI router 77 4.3.3 Wi-Fi router configuration interface 78 4.3.4 Setting of wired broadband internet parameters 79 4.3.5 WiFi basic setting 82 4.3.6 The restoration of wireless router to factory setting 82 4.3.7 To charge through dock phone USB 5V output 82 5 BASIC TROUBLESHOOTING FOR THE TELPAD 83 5.1 Tablet not powering up 84 5.2 No dial tone 84 5.3 Distorted audio on speaker 84 5.4 Tablet Dialler cannot make a call 84 5.5 No audio response in the Handset 84 6 FAQs 85 7 WARNINGS AND PRECAUTIONS 91 8 PERSONAL INFORMATION AND DATA SECURITY 96 9 LEGAL NOTICE 98 10 DISCLAIMER OF WARRANTIES 100 11 INDEX 102 1 GETTING STARTED 1.1 About your TELPAD The Telpad is the world’s first Tablet and landline in one, a device that that not only gives you access to basic communication services, but also brings to your home a world of productivity and entertainment – powered by Android™, the world’s leader in smartphone technology. With its stunning 7 inch touchscreen display, sleek design, built-in camera & Wi-Fi, and access to hundreds of thousands of free and paid Android™ Apps, the Telpad is definitely a device you will want to become acquainted with to be able to maximize its full set of features! 02 2 TELPAD INTRODUCTION 2.1 Getting to know your TELPAD 14 15 16 17 18 14.15.16.17.18. 04 19 20 21 22 23 24 25 26 27 28 19.20.21.22.23.24.25.26.27.28. 05 Accessories USB Data Cable Coiled Phone Cord Phone Line HDMI Converter USB Charger USB Power Cable DC4.0 Battery 29 30 31 32 33 34 29.30.31.32.33.34. 06 2.2 Product Specificiation GENERAL SPECIFICATIONS AND DISPLAY DIMENSION 114 mm x 193 mm x 10 mm 7 Inch HD IPS (1280X800) DISPLAY AND RESOLUTION Android™ 4.2.2 SYSTEM SOFTWARE Wi-Fi - 802.11b/g/n 24-bit AIR INTERFACE Capacitive 5-Points-Touch MULTI-TOUCH PANEL 3 Standard Soft Keys: Home, Back, Recent Applications PRIMARY KEYPADDISPLAY COLOR DEPTH CONNECTIVITY BLUETOOTH Bluetooth 4.0 + EDR Micro USB OTG USB HDMI V 1.4A / Supports 3D output DIGITAL TV OUT Built-in-speaker SPEAKER Built-in-microphone MICROPHONE 3-Axis Accelerometer for UI Auto Rotate Ambient Light sensor SENSOR Standard 3.5 mm headphone jack AUDIO OUT HANDSET PSTN Support (POTS) RJ9 (4P4C) Built-in SPEAKER Built-in MICROPHONE 07 SMART DIALER PSTN Call HoldSpeed DialSpeakerVolume Adjustment COMMUNICATION AND ORGANIZER EMAIL Protocols: SMTP, POP3 and IMAP4 Supports Exchange Calendar, Contacts synchronous MEDIA PERFORMANCE VIDEO DECODINGAUDIO DECODING 3GPP2, 3GPP, RMV, TS, 3GP, VOB, AVI, MP4, FLV, WMV, MKVAAC, AMR, APE, FLAC, MID, MP3, OGG, WAV, WMA PICTURE FORMATS STREAMING MEDIA JPEG, JPG, BMP, PNGRTSP/HTTP, Support Download play, Progressive play BATTERY AND POWER TABLET BATTERY STD Lithium-Ion Polymer battery, 5500 mAh rechargeable STD Lithium-Ion Polymer battery, 1000 mAh rechargeable DOCK BATTERY Input - …

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 <2014-11-26> TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2ACWO-HC7-S Telpad For the product stated above, we request permanent confidentiality for exhibits which contain Operational Description, Block Diagram, Schematics, Parts Lists or Tune Up Information. The above exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact me at the address shown below. Sincerely, (signed) Name: Lisa He Company: AURA TECHNOLOGY LIMTED Address: FLAT/RM810, Star House, 3 Salisbury Road, Tsimshatsui, Hong Kong Phone: +86-0755-86706282-810 Fax: +86-0755-86706280 Email: [email protected]

AURA TECHNOLOGY LIMTED AURA TECHNOLOGY LIMTED FCC ID: 2ACWO-HC7-S DATE: Nov 26, 2014 We, AURA TECHNOLOGY LIMTED don’t provide any controls or software to allow the operation outside of the USA frequency band when we sell this product in USA. The product only use frequency band from 2412-2462MHz in USA. Sincerely yours, AURA TECHNOLOGY LIMTED Lisa He / Quality Engineer Fax: +86-0755-86706280 Tel: +86-0755-86706282-810 E-mail: [email protected]

External photos of The EUT

FCC ID Label and Label Location FCC ID Label: AURA TECHNOLOGY LIMTED Model: HC7 FCC ID:2ACWO-HC7-S This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location:

Internal Photos of The EUT WLAN Antenna BT Antenna

Report No.: A1411096077-MPE MPE TEST REPORT FCC Per 47 CFR 2.1091(b) Report Reference No. ..................... : FCC ID. ........................................... : A1411096077-MPE 2ACWO-HC7-S Compiled by ( position+printed name+signature) .. : File administrators Tony Li Supervised by ( position+printed name+signature) .. : Technique principal Robin Fang Approved by ( position+printed name+signature) .. : Manager James Wu Date of issue ..................................... : Nov,28 2014 Representative Laboratory Name .... : Shenzhen CTL Electron Technology Co., Ltd. Address ............................................. : A0402, Block 1, Kefa Industrial District, Huanguan Nan Rd, Xintian community, Guanlan, Baoan, Shenzhen, China Testing Laboratory Name ................. : Dongguan Dongdian Testing Service Co.,Ltd Address ............................................. : No.17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China Applicant’s name ............................ : AURA TECHNOLOGY LIMTED Address ............................................. : FLAT/RM810, Star House, 3 Salisbury Road, Tsimshatsui, Hong Kong Test specification: Standard ........................................... : FCC Per 47 CFR 2.1091(b) KDB447498 v05r02 TRF Originator .................................. : Shenzhen CTL Electron Technology Co., Ltd. Master TRF ....................................... : Dated 2012-06 Shenzhen CTL Electron Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Electron Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Electron Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Telpad Trade Mark ....................................... : / Model/Type reference ....................... : HC7 Listed Models .................................. : / Manufacturer .................................... : SHENZHEN KWANG SUNG ELECTRONICS CO.,LTD Operation Frequency ........................ : WLAN (2412MHz to 2462MHz)/BT(2402MHz to 2480MHz) Rating ............................................... : DC3.70V/DC 5.6V Adapter from AC 120V/60Hz Exposure category ............................ : General population/uncontrolled environment EUT Type.......................................... : Production Unit Result ................................................ : PASS Page 2 of 9 Report No.: A1411096077-MPE MPE T E S T R E P O R T Test Report No. : A1411096077-MPE Nov,28 2014 ______________________________________________________________________________________________ Date of issue Equipment under Test : Telpad Model /Type : HC7 Listed Models : / Applicant : AURA TECHNOLOGY LIMTED Address : FLAT/RM810, Star House, 3 Salisbury Road, Tsimshatsui, Hong Kong Manufacturer SHENZHEN KWANG SUNG ELECTRONICS CO.,LTD Address : Shitoushan Industrial Zone, Shi Yan Town, Baoan District, Shenzhen, PRC Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Page 3 of 9 Report No.: A1411096077-MPE Contents 1. SUMMARY ............................................................................. 4 1.1. EUT configuration 4 1.2. NOTE 4 2. TEST ENVIRONMENT ............................................................... 5 2.1. Address of the test laboratory 5 2.2. Test Facility 5 2.3. Environmental conditions 5 2.4. Statement of the measurement uncertainty 5 3. METHOD OF MEASUREMENT .................................................... 6 3.1. Applicable Standard 6 3.2. Limit 6 3.3. Conducted Power Results 6 3.4. MPE Calculation Method 7 3.4.1 Standalone MPE 8 3.4.2 Simultaneous transmission MPE Considerations 9 4. CONCLUSION ........................................................................ 9 Page 4 of 9 Report No.: A1411096077-MPE 1. SUMMARY 1.1. EUT configuration The following peripheral devices and interface cables were connected during the measurement: ● - supplied by the manufacturer ○ - supplied by the lab ○ Power Cable Length (m) : / Shield : / Detachable : / ○ Multimeter Manufacturer : / Model No. : / 1.2. NOTE 1. The EUT is a Telpad with WLAN and Bluetooth function,The functions of the EUT listed as below: Test Standards Reference Report WLAN FCC Part 15 Subpart C A1411096077-WLAN Bluetooth-EDR FCC Part 15 Subpart C A1411096077-EDR MPE FCC Per 47 CFR 2.1091(d) A1411096077-MPE 2. The frequency bands used in this EUT are listed as follows: Frequency Band(MHz) 2400-2483.5 5150-5350 5470-5725 5725-5850 802.11b √ － － － 802.11g √ － － － 802.11n(20MHz) √ － － － 802.11n(40MHz) √ － － － BT 2.1+EDR √ 3. The EUT incorporates a SISO function, Physically, the EUT provides one completed transmitter and one completed receiver. Modulation Mode TX Function 802.11b 1TX 802.11g 1TX 802.11n (20MHz) 1TX 802.11n (40MHz) 1TX BT 2.1+EDR 1TX . Page 5 of 9 Report No.: A1411096077-MPE 2. TEST ENVIRONMENT 2.1. Address of the test laboratory Dongguan Dongdian Testing Service Co.,Ltd No.17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 (2003) and CISPR Publication 22. 2.2. Test Facility The test facility is recognized, certified, or accredited by the following organizations: IC Registration No.: 10288A-1 The 3m alternate test site of Dongguan Dongdian Testing Service Co.,Ltd EMC Laboratory has been registered by Certification and Engineer Bureau of Industry Canada for the performance of with Registration No.: 10288A-1 on Mar, 2012. FCC-Registration No.: 270092 Dongguan Dongdian Testing Service Co.,Ltd EMC Laborator…

Text truncated - open the document above for the full version.

Report No.: A1411096077-WLAN FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ........................................... : A1411096077-WLAN 2ACWO-HC7-S Compiled by ( position+printed name+signature) .. : File administrators Tony Li Supervised by ( position+printed name+signature) .. : Technique principal Robin Fang Approved by ( position+printed name+signature) .. : Manager James Wu Date of issue ..................................... : Nov,28 2014 Representative Laboratory Name .... : Shenzhen CTL Electron Technology Co., Ltd. Address ............................................ : A0402, Block 1, Kefa Industrial District, Huanguan Nan Rd, Xintian community, Guanlan, Baoan, Shenzhen, China Testing Laboratory Name ................. : Dongguan Dongdian Testing Service Co.,Ltd Address ............................................ : No.17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China Applicant’s name ............................ : AURA TECHNOLOGY LIMTED Address ............................................ : FLAT/RM810, Star House, 3 Salisbury Road, Tsimshatsui, Hong Kong Test specification ...........................: Standard ........................................... : FCC Part 15.247: Operation within the bands 902-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz TRF Originator .................................. : Shenzhen CTL Electron Technology Co., Ltd. Master TRF ....................................... : Dated 2012-06 Shenzhen CTL Electron Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Electron Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Electron Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Telpad Trade Mark ....................................... : / Model/Type reference....................... : HC7 Listed Models .................................. : / Manufacturer .................................... : SHENZHEN KWANG SUNG ELECTRONICS CO.,LTD Operation Frequency ........................ : From 2412MHz to 2462MHz Rating ............................................... : DC3.70V/DC 5.6V Adapter from AC 120V/60Hz Result................................................ : PASS Page 2 of 84 Report No.: A1411096077-WLAN T E S T R E P O R T Test Report No. : A1411096077-WLAN Nov,28 2014 ____________________________________________________________________________________ Date of issue Equipment under Test : Telpad Model /Type : HC7 Listed Models : / Applicant : AURA TECHNOLOGY LIMTED Address : FLAT/RM810, Star House, 3 Salisbury Road, Tsimshatsui, Hong Kong Manufacturer : SHENZHEN KWANG SUNG ELECTRONICS CO.,LTD Address : Shitoushan Industrial Zone, Shi Yan Town, Baoan District, Shenzhen, PRC Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Page 3 of 84 Report No.: A1411096077-WLAN Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY ............................................................................. 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment Under Test 5 2.4. Short description of the Equipment under Test (EUT) 5 2.5. EUT operation mode 5 2.6. Block Diagram of Test Setup 6 2.7. Related Submittal(s) / Grant (s) 6 2.8. Modifications 6 2.9. NOTE 6 3. TEST ENVIRONMENT ............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 7 3.4. Test Description 7 3.5. Statement of the measurement uncertainty 8 3.6. Equipments Used during the Test 8 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. AC Power Conducted Emission ................................................................................... 10 4.2. Radiated Emission ........................................................................................................ 13 4.3. Maximum Peak Output Power ...................................................................................... 22 4.4. Power Spectral Density ................................................................................................ 23 4.5. 6dB Bandwidth ............................................................................................................. 32 4.6. Band Edge Compliance of RF Emission ...................................................................... 41 4.7. Spurious RF Conducted Emission ............................................................................... 52 4.8. Antenna Requirement ................................................................................................... 77 5. TEST SETUP PHOTOS OF THE EUT .......................................... 78 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 79 Page 4 of 84 Report No.: A1411096077-WLAN 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.247 : Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2009 : American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V03r02: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Page 5 of 84 Report No.: A1411096077-WLAN 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Nov 14, 2014 Testing commenced on : Nov 14, 2014 Testing concluded on : Nov 26, 2014 2.2. Product Des…

Text truncated - open the document above for the full version.

Test setup photos of the EUT_DSS
