2ACWO-MA7Telpad

TELPAD MA7 Android 4.4 Jellybean | 1.6GHz Quad Core Processor | Infrared Function 1 GETTING STARTED 01 1.1 About your TELPAD 02 2 TELPAD INTRODUCTION 03 2.1 Getting to know your TELPAD 04 2.2 Product Specication 07 2.3 Installation 09 2.3.1Basic Connection 09 2.3.2Installing the dock battery 10 2.3.3Docking and undocking the Tablet 10 3 TABLET FUNCTIONS 11 3.1 Turning the Tablet ON or OFF 12 3.1.1Turning the Tablet ON 13 3.1.2Turning the Tablet OFF 13 3.2 Charging the battery 14 3.2.1Charging the Tablet battery 14 3.2.2Charging the dock battery 14 3.3 Working with the keys 15 3.3.1 Using the physical keys 15 3.3.2 Working the touchscreen keys 15 3.4 Using the touch screen 16 3.5 Home screen 17 3.5.1Getting to know the Home screen 17 3.5.2Extended Home screens 18 3.5.3Customizing the Home screen 18 3.6 Locking and unlocking the screen 19 3.6.1Locking the screen 19 3.6.2Unlocking the screen 19 3.6.3Setting up a screen lock 19 3.6.4Setting a screen timeout period 19 3.7 Inputting text 20 3.7.1Entering text using the onscreen keyboard 20 3.7.2Cutting or copying text 21 3.8 Opening and switching applications 22 3.9 Accessing the Settings 22 3.10 Languages & input method & account setting 23 3.11 Setting the date and time 24 3.11.1To automatically set date and time 24 3.11.2 To manually set date and time 24 3.12 Installing or removing the microSD card 25 3.13 Connecting or disconnecting from a computer using USB 26 3.14 Connecting the Tablet to a TV 27 3.15 Wireless networks 28 3.15.1 Opening Wi-Fi settings 28 3.15.2 Turning Wi-Fi on or o 28 3.15.3 Connecting to a Wi-Fi network 29 3.15.4 Turning open network notication on or o 29 3.15.5 Adding a Wi-Fi Network 29 3.15.6 Forgetting a Wi-Fi network 29 3.16 Bluetooth 30 3.16.1 Opening Bluetooth settings 30 3.16.2 Turning Bluetooth on or o 30 3.16.3 Changing the Bluetooth name of your Tablet 30 3.16.4 Connecting to Bluetooth devices 31 3.16.5 Disconnecting from or unpairing a Bluetooth device 31 3.17 Google Services 32 3.17.1 Creating a Google Account 32 3.17.2 Using Play Store 33 3.17.3 Searching for Applications 33 3.17.4 Installing an Application 33 3.17.5 Uninstalling an Application 34 3.17.6 Backing up and restoring apps and settings from a Google account 34 3.18 E-mail 34 3.18.1 Opening E-mail 34 3.18.2 Adding and deleting e-mail accounts 35 3.19 Camera Instructions 37 3.20 Home control 40 3.20.1 IR Universal remote Initial Conguration 40 3.20.2 IR Learning 42 3.20.3 Reservation 43 3.20.4 Reservation Setup 44 3.20.5 Outside Home control 45 3.20.6 Motion detection 47 3.21 Home care 50 3.21.1 Bluetooth body scale User Guide 50 3.21.2 iFever Manage User Guide 54 3.22 Cast Screen Function Operation Guide 63 3.23 DLNA 68 3.23.1 DLNA introduction 68 3.23.2 DLNA functions 68 3.23.3 Control device discovery and connection 69 3.23.4 The brief introduction of interactions 72 4 THE CONNECTION BETWEEN DOCK PHONE AND TABLE 82 4.1 Voice call Services 83 4.1.1 Making a call 83 4.1.2 Answering a call 84 4.1.3 Ending a call 84 4.1.4 Selecting area code 84 4.1.5 Favorites 85 4.1.6 Memo 85 4.1.7 Importing/exporting contacts 85 4.1.8 Changing ringtones 86 4.1.9 Contacts 86 5 BASIC TROUBLESHOOTING FOR THE TELPAD 88 5.1 Tablet not powering up 89 5.2 No dial tone 89 5.3 Distorted audio on speaker 89 5.4 Tablet Dialler cannot make a call 89 5.5 No audio response in the Handset 89 6 FAQs 90 7 WARNINGS AND PRECAUTIONS 96 8 PERSONAL INFORMATION AND DATA SECURITY 101 9 LEGAL NOTICE 103 10 DISCLAIMER OF WARRANTIES 105 11 INDEX 107 1 GETTING STARTED 01 1.1 About your TELPAD 02 2 TELPAD INTRODUCTION 03 2.1 Getting to know your TELPAD 04 2.2 Product Specication 07 2.3 Installation 09 2.3.1Basic Connection 09 2.3.2Installing the dock battery 10 2.3.3Docking and undocking the Tablet 10 3 TABLET FUNCTIONS 11 3.1 Turning the Tablet ON or OFF 12 3.1.1Turning the Tablet ON 13 3.1.2Turning the Tablet OFF 13 3.2 Charging the battery 14 3.2.1Charging the Tablet battery 14 3.2.2Charging the dock battery 14 3.3 Working with the keys 15 3.3.1 Using the physical keys 15 3.3.2 Working the touchscreen keys 15 3.4 Using the touch screen 16 3.5 Home screen 17 3.5.1Getting to know the Home screen 17 3.5.2Extended Home screens 18 3.5.3Customizing the Home screen 18 3.6 Locking and unlocking the screen 19 3.6.1Locking the screen 19 3.6.2Unlocking the screen 19 3.6.3Setting up a screen lock 19 3.6.4Setting a screen timeout period 19 3.7 Inputting text 20 3.7.1Entering text using the onscreen keyboard 20 3.7.2Cutting or copying text 21 3.8 Opening and switching applications 22 3.9 Accessing the Settings 22 3.10 Languages & input method & account setting 23 3.11 Setting the date and time 24 3.11.1To automatically set date and time 24 3.11.2 To manually set date and time 24 3.12 Installing or removing the microSD card 25 3.13 Connecting or disconnecting from a computer using USB 26 3.14 Connecting the Tablet to a TV 27 3.15 Wireless networks 28 3.15.1 Opening Wi-Fi settings 28 3.15.2 Turning Wi-Fi on or o 28 3.15.3 Connecting to a Wi-Fi network 29 3.15.4 Turning open network notication on or o 29 3.15.5 Adding a Wi-Fi Network 29 3.15.6 Forgetting a Wi-Fi network 29 3.16 Bluetooth 30 3.16.1 Opening Bluetooth settings 30 3.16.2 Turning Bluetooth on or o 30 3.16.3 Changing the Bluetooth name of your Tablet 30 3.16.4 Connecting to Bluetooth devices 31 3.16.5 Disconnecting from or unpairing a Bluetooth device 31 3.17 Google Services 32 3.17.1 Creating a Google Account 32 3.17.2 Using Play Store 33 3.17.3 Searching for Applications 33 3.17.4 Installing an Application 33 3.17.5 Uninstalling an Application 34 3.17.6 Backing up and restoring apps and settings from a Google account 34 3.18 E-mail 34 3.18.1 Opening E-mail 34 3.18.2 Adding and deleting e-mail accounts 35 3.19 Camera Instructions 37 3.20 Home control 40 3.20.1 IR Universal remote Initial Conguration 40 3.20.2 IR Learning 42 3.20.3 Reservation 43 3.20.4 Reservation Setup 44 3.20.5 Outside Home control 45 3.20.6 Motion detection 47 3…

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 <201 5-04-26> T O WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2ACWO- MA7 Telpad For the product stated above, we request permanent confidentiality for exhibits which contain Operational Description, Block Diagram, Schematics, Parts Lists or Tune Up Information. The above exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact me at the address shown below. Sincerely, (signed) Name: Lisa He Company: AURA TECHNOLOGY LIMTED Address: FLAT/RM810, Star House, 3 Salisbury Road, Tsimshatsui, Hong Kong Phone: +86-0755-86706282-810 Fax: +86-0755-86706280 Email: [email protected]

External photos of The EUT

Internal Photos of The EUT WLAN/BT Antenna

Shenzhen CTL Electron Technology Co., Ltd. Report No.: A150A166219-SAR TEST REPORT Report Reference No. ..................... : FCC ID. ........................................... : A150A166219-SAR 2ACWO-MA7 Compiled by ( position+printed name+signature) .. : File administrators Tony Li Supervised by ( position+printed name+signature) .. : Technique principal Robin Fang Approved by ( position+printed name+signature) .. : Manager James Wu Date of issue ..................................... : Apr,24, 2015 Representative Laboratory Name .... : Shenzhen CTL Electron Technology Co., Ltd. Address............................................. : A0402, Block 1, Kefa Industrial District, Huanguan Nan Rd, Xintian community, Guanlan, Baoan, Shenzhen, China Testing Laboratory Name ................. : The Testing and Technology Center for Industrial Products of Shenzhen Entry-Exit Inspection and Quarantine Bureau Address............................................. : No.289, 8th Industry Road, NanshanDistrict,Shenzhen,Guangdong Applicant’s name ............................ : AURA TECHNOLOGY LIMTED Address............................................. : FLAT/RM810, Star House, 3 Salisbury Road, Tsimshatsui, Hong Kong Test specification .......................... : Standard ........................................... : ANSI C95.1–1999 47CFR §2.1093 TRF Originator .................................. : Shenzhen CTL Electron Technology Co., Ltd. Master TRF ....................................... : Dated 2012-06 Shenzhen CTL Electron Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Electron Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Electron Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Telpad Trade Mark ....................................... : / Manufacturer .................................... : SHENZHEN KWANG SUNG ELECTRONICS CO.,LTD Model/Type reference ....................... : MA7 Listed Models .................................. : / Rating ............................................... : DC 3.70V/DC 5.0V adapter from AC120V/60Hz Android Version ................................ : Android 4.2.2 Result ................................................ : PASS Page 2 of 60 Report No.: A150A166219-SAR T E S T R E P O R T Test Report No. : A150A166219-SAR Apr,24 2015 ______________________________________________________________________________________________ Date of issue Equipment under Test : Telpad Model /Type : MA7 Listed Models : / Applicant : AURA TECHNOLOGY LIMTED Address : FLAT/RM810, Star House, 3 Salisbury Road, Tsimshatsui, Hong Kong Manufacturer : SHENZHEN KWANG SUNG ELECTRONICS CO.,LTD Address : Shitoushan Industrial Zone, Shi Yan Town, Baoan District, Shenzhen, PRC Test Result PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Page 3 of 60 Report No.: A150A166219-SAR ** Modifited History ** Revison Description Issued Data Remark Revsion 1.0 Initial Test Report Release 2015-04-24 James Wu Page 4 of 60 Report No.: A150A166219-SAR Contents 1. TEST STANDARDS 5 2. SUMMARY 6 2.1. General Remarks 6 2.2. Product Description 6 2.3. Statement of Compliance 6 2.4. Equipment under Test 7 2.5. Short description of the Equipment under Test (EUT) 7 2.6. EUT configuration 7 2.7. TEST Configuration 7 2.8. Note 8 3. TEST ENVIRONMENT 9 3.1. Address of the test laboratory 9 3.2. Test Facility 9 3.3. Environmental conditions 9 3.4. SAR Limits 9 3.5. Equipments Used during the Test 10 4. SAR Measurements System configuration 11 4.1. SAR Measurement Set-up 11 4.2. DASY5 E-field Probe System 12 4.3. Phantoms 13 4.4. Device Holder 13 4.5. Scanning Procedure 13 4.6. Data Storage and Evaluation 14 4.7. Tissue Dielectric Parameters for Head and Body Phantoms 16 4.8. Tissue equivalent liquid properties 16 4.9. System Check 16 4.10. SAR measurement procedure 18 4.11. Power Reduction 21 5. TEST CONDITIONS AND RESULTS 22 5.1. Conducted Power Results 22 5.2. Simultaneous TX SAR Considerations 23 5.3. SAR Measurement Results 25 5.4. SAR Measurement Variability 26 5.5. Measurement Uncertainty (300MHz-3GHz) 27 5.6. System Check Results 31 5.7. SAR Test Graph Results 33 6. Calibration Certificate 35 6.1. Probe Calibration Ceriticate 35 6.2. D2450V2 Dipole Calibration Ceriticate 46 6.3. DAE4 Calibration Ceriticate 54 7. Test Setup Photos 57 8. External Photos of the EUT 60 Page 5 of 60 Report No.: A150A166219-SAR 1. TEST STANDARDS The tests were performed according to following standards: IEEE Std C95.1, 1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 KHz to 300 GHz. It specifies the maximum exposure limit of 1.6 W/kg as averaged over any 1 gram of tissue for portable devices being used within 20 cm of the user in the uncontrolled environment. IEEE Std 1528™-2013: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. KDB 447498 D01 Mobile Portable RF Exposure v05r01: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies KDB865664 D01 SAR measurement 100 MHz to 6 GHz v01r02: SAR Measurement Requirements for 100 MHz to 6 GHz KDB865664 D02 SAR Reporting v01: RF Exposure Compliance Reporting and Documentation Considerations KDB248227: SAR measurement procedures for 802.112abg transmitters FCC Part 2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices KDB 616217 D04 SAR for laptop and Internet Tablets v01: SAR Evaluation Considerations …

Text truncated - open the document above for the full version.

Shenzhen CTL Electron Technology Co., Ltd. Report No.: A150A166219-BLE FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ........................................... : A150A166219-BLE 2ACWO-MA7 Compiled by ( position+printed name+signature) .. : File administrators Tony Li Supervised by ( position+printed name+signature) .. : Technique principal Robin Fang Approved by ( position+printed name+signature) .. : Manager James Wu Date of issue ..................................... : Apr 25, 2015 Representative Laboratory Name .... : Shenzhen CTL Electron Technology Co., Ltd. Address ............................................ : A0402, Block 1, Kefa Industrial District, Huanguan Nan Rd, Xintian community, Guanlan, Baoan, Shenzhen, China Testing Laboratory Name ................. : Dongguan Dongdian Testing Service Co.,Ltd Address ............................................ : No.17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China Applicant’s name ............................ : AURA TECHNOLOGY LIMTED Address ............................................ : FLAT/RM810, Star House, 3 Salisbury Road, Tsimshatsui, Hong Kong Test specification ...........................: Standard ........................................... : FCC Part 15.247: Operation within the bands 902-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz TRF Originator .................................. : Shenzhen CTL Electron Technology Co., Ltd. Master TRF ....................................... : Dated 2012-06 Shenzhen CTL Electron Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Electron Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Electron Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Telpad Trade Mark ....................................... : / Model/Type reference....................... : MA7 Listed Models .................................. : / Manufacturer .................................... : SHENZHEN KWANG SUNG ELECTRONICS CO.,LTD Modulation Type ............................... : GFSK Operation Frequency ........................ : From 2402MHz to 2480MHz Rating ............................................... : DC 3.70V Result................................................ : PASS Page 2 of 45 Report No.: A150A166219-BLE T E S T R E P O R T Test Report No. : A150A166219-BLE Apr 25, 2015 ______________________________________________________________________________________________ Date of issue Equipment under Test : Telpad Model /Type : MA7 Listed Models : / Applicant : AURA TECHNOLOGY LIMTED Address : FLAT/RM810, Star House, 3 Salisbury Road, Tsimshatsui, Hong Kong Manufacturer : SHENZHEN KWANG SUNG ELECTRONICS CO.,LTD Address : Shitoushan Industrial Zone, Shi Yan Town, Baoan District, Shenzhen, PRC Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Page 3 of 45 Report No.: A150A166219-BLE Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY ............................................................................. 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment Under Test 5 2.4. Short description of the Equipment under Test (EUT) 5 2.5. EUT operation mode 5 2.6. Block Diagram of Test Setup 6 2.7. Related Submittal(s) / Grant (s) 6 2.8. Modifications 6 2.9. NOTE 6 3. TEST ENVIRONMENT ............................................................... 8 3.1. Address of the test laboratory 8 3.2. Test Facility 8 3.3. Environmental conditions 8 3.4. Test Description 8 3.5. Statement of the measurement uncertainty 9 3.6. Equipments Used during the Test 10 4. TEST CONDITIONS AND RESULTS ............................................ 11 4.1. AC Power Conducted Emission ................................................................................... 11 4.2. Radiated Emission ........................................................................................................ 14 4.3. Maximum Peak Output Power ...................................................................................... 18 4.4. Power Spectral Density ................................................................................................ 19 4.5. 6dB Bandwidth ............................................................................................................. 22 4.6. Band Edge Compliance of RF Emission ...................................................................... 25 4.7. Spurious RF Conducted Emission ............................................................................... 27 4.8. Antenna Requirement ................................................................................................... 38 5. TEST SETUP PHOTOS OF THE EUT .......................................... 39 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 40 Page 4 of 45 Report No.: A150A166219-BLE 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.247 : Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2009 : American National Standard for Testing Unlicensed Wireless Devices Page 5 of 45 Report No.: A150A166219-BLE 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Apr 07, 2015 Testing commenced on : Apr 07, 2015 Testing concluded on : Apr 24, 2015 2.2. Product Description The AURA TECHNOLOGY LIMTED’s Model: MA7 or the “EUT” a…

Text truncated - open the document above for the full version.

Shenzhen CTL Electron Technology Co., Ltd. Report No.: A150A166219-WLAN FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ........................................... : A150A166219-WLAN 2ACWO-MA7 Compiled by ( position+printed name+signature) .. : File administrators Tony Li Supervised by ( position+printed name+signature) .. : Technique principal Robin Fang Approved by ( position+printed name+signature) .. : Manager James Wu Date of issue ..................................... : Apr,28 2015 Representative Laboratory Name .... : Shenzhen CTL Electron Technology Co., Ltd. Address ............................................ : A0402, Block 1, Kefa Industrial District, Huanguan Nan Rd, Xintian community, Guanlan, Baoan, Shenzhen, China Testing Laboratory Name ................. : Dongguan Dongdian Testing Service Co.,Ltd Address ............................................ : No.17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China Applicant’s name ............................ : AURA TECHNOLOGY LIMTED Address ............................................ : FLAT/RM810, Star House, 3 Salisbury Road, Tsimshatsui, Hong Kong Test specification ...........................: Standard ........................................... : FCC Part 15.247: Operation within the bands 902-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz TRF Originator .................................. : Shenzhen CTL Electron Technology Co., Ltd. Master TRF ....................................... : Dated 2012-06 Shenzhen CTL Electron Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Electron Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Electron Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Telpad Trade Mark ....................................... : / Model/Type reference....................... : MA7 Listed Models .................................. : / Manufacturer .................................... : SHENZHEN KWANG SUNG ELECTRONICS CO.,LTD Operation Frequency ........................ : From 2402MHz to 2480MHz Rating ............................................... : DC 3.70V Result................................................ : PASS Page 2 of 97 Report No.: A150A166219-WLAN T E S T R E P O R T Test Report No. : A150A166219-WLAN Apr,28 2015 ____________________________________________________________________________________ Date of issue Equipment under Test : Telpad Model /Type : MA7 Listed Models : / Applicant : AURA TECHNOLOGY LIMTED Address : FLAT/RM810, Star House, 3 Salisbury Road, Tsimshatsui, Hong Kong Manufacturer : SHENZHEN KWANG SUNG ELECTRONICS CO.,LTD Address : Shitoushan Industrial Zone, Shi Yan Town, Baoan District, Shenzhen, PRC Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Page 3 of 97 Report No.: A150A166219-WLAN Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY ............................................................................. 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment Under Test 5 2.4. Short description of the Equipment under Test (EUT) 5 2.5. EUT operation mode 5 2.6. Block Diagram of Test Setup 6 2.7. Related Submittal(s) / Grant (s) 6 2.8. Modifications 6 2.9. NOTE 6 3. TEST ENVIRONMENT ............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 7 3.4. Test Description 7 3.5. Statement of the measurement uncertainty 8 3.6. Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. AC Power Conducted Emission ................................................................................... 10 4.2. Radiated Emission ........................................................................................................ 13 4.3. Maximum Peak Output Power ...................................................................................... 17 4.4. Power Spectral Density ................................................................................................ 18 4.5. 6dB Bandwidth ............................................................................................................. 27 4.6. Band Edge Compliance of RF Emission ...................................................................... 36 4.7. Spurious RF Conducted Emission ............................................................................... 47 4.8. Antenna Requirement ................................................................................................... 91 5. TEST SETUP PHOTOS OF THE EUT .......................................... 92 Page 4 of 97 Report No.: A150A166219-WLAN 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.247 : Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2009 : American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V03r02: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Page 5 of 97 Report No.: A150A166219-WLAN 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Apr 05, 2015 Testing commenced on : Apr 15, 2015 Testing concluded on : Apr 28, 2015 2.2. Product Description The AURA TECHNOLOGY LIMTED’s Model: MA7 or the “EUT” …

Text truncated - open the document above for the full version.

Page 51 of 97 Report No.: A150A166219-WLAN (Plot 4.7.1 B1: Channel 6: 2437MHz @ 802.11b) Page 52 of 97 Report No.: A150A166219-WLAN (Plot 4.7.1 B2: Channel 6: 2437MHz @ 802.11b) (Plot 4.7.1 B3: Channel 6: 2437MHz @ 802.11b) Page 53 of 97 Report No.: A150A166219-WLAN (Plot 4.7.1 B4: Channel 6: 2437MHz @ 802.11b) (Plot 4.7.1 B5: Channel 6: 2437MHz @ 802.11b) Page 54 of 97 Report No.: A150A166219-WLAN (Plot 4.7.1 B6: Channel 6: 2437MHz @ 802.11b) (Plot 4.7.1 C1: Channel 11: 2462MHz @ 802.11b) Page 55 of 97 Report No.: A150A166219-WLAN (Plot 4.7.1 C2: Channel 11: 2462MHz @ 802.11b) (Plot 4.7.1 C3: Channel 11: 2462MHz @ 802.11b) Page 56 of 97 Report No.: A150A166219-WLAN (Plot 4.7.1 C4: Channel 11: 2462MHz @ 802.11b) (Plot 4.7.1 C5: Channel 11: 2462MHz @ 802.11b) Page 57 of 97 Report No.: A150A166219-WLAN (Plot 4.7.1 C6: Channel 11: 2462MHz @ 802.11b) (Plot 4.7.1 D: Channel 1: 2412MHz @ 802.11b) Page 58 of 97 Report No.: A150A166219-WLAN (Plot 4.7.1 E: Channel 11: 2462MHz @ 802.11b) 4.7.2 802.11g Test Mode A. Test Verdict Channel Frequency (MHz) Frequency Range Refer to Plot Limit (dBc) Verdict 1 2412 2412MHz Plot 4.7.2 A1 N/A PASS 9KHz-30MHz Plot 4.7.2 A2 -20 PASS 30MHz-1GHz Plot 4.7.2 A3 -20 PASS 1GHz-8GHz Plot 4.7.2 A4 -20 PASS 8GHz-16GHz Plot 4.7.2 A5 -20 PASS 16GHz-25GHzPlot 4.7.2 A6 -20 PASS 6 2437 2437MHz Plot 4.7.2 B1 N/A PASS 9KHz-30MHz Plot 4.7.2 B2 -20 PASS 30MHz-1GHz Plot 4.7.2 B3 -20 PASS 1GHz-8GHz Plot 4.7.2 B4 -20 PASS 8GHz-16GHz Plot 4.7.2 B5 -20 PASS 16GHz-25GHzPlot 4.7.2 B6 -20 PASS 11 2462 2462MHz Plot 4.7.2 C1 N/A PASS 9KHz-30MHz Plot 4.7.2 C2 -20 PASS 30MHz-1GHz Plot 4.7.2 C3 -20 PASS 1GHz-8GHz Plot 4.7.2 C4 -20 PASS 8GHz-16GHz Plot 4.7.2 C5 -20 PASS 16GHz-25GHzPlot 4.7.2 C6 -20 PASS Frequency (MHz) Delta Peak to Band emission (dBc) Detector Limit (dBc) Refer to Plot Verdict 2400.00 -29.251 Peak -20 Plot 4.7.2 D PASS 2483.50 -41.093 Peak -20 Plot 4.7.2 E PASS Note: 1. For 802.11g mode at finial test to get the worst-case emission at 6Mbps. 2. The test results including the cable lose. B. Test Plots Page 59 of 97 Report No.: A150A166219-WLAN (Plot 4.7.2 A1: Channel 1: 2412MHz @ 802.11g) (Plot 4.7.2 A2: Channel 1: 2412MHz @ 802.11g) Page 60 of 97 Report No.: A150A166219-WLAN (Plot 4.7.2 A3: Channel 1: 2412MHz @ 802.11g) (Plot 4.7.2 A4: Channel 1: 2412MHz @ 802.11g) Page 61 of 97 Report No.: A150A166219-WLAN (Plot 4.7.2 A5: Channel 1: 2412MHz @ 802.11g) (Plot 4.7.2 A6: Channel 1: 2412MHz @ 802.11g) Page 62 of 97 Report No.: A150A166219-WLAN (Plot 4.7.2 B1: Channel 6: 2437MHz @ 802.11g) (Plot 4.7.2 B2: Channel 6: 2437MHz @ 802.11g) Page 63 of 97 Report No.: A150A166219-WLAN (Plot 4.7.2 B3: Channel 6: 2437MHz @ 802.11g) (Plot 4.7.2 B4: Channel 6: 2437MHz @ 802.11g) Page 64 of 97 Report No.: A150A166219-WLAN (Plot 4.7.2 B5: Channel 6: 2437MHz @ 802.11g) (Plot 4.7.2 B6: Channel 6: 2437MHz @ 802.11g) Page 65 of 97 Report No.: A150A166219-WLAN (Plot 4.7.2 C1: Channel 11: 2462MHz @ 802.11g) (Plot 4.7.2 C2: Channel 11: 2462MHz @ 802.11g) Page 66 of 97 Report No.: A150A166219-WLAN (Plot 4.7.2 C3: Channel 11: 2462MHz @ 802.11g) (Plot 4.7.2 C4: Channel 11: 2462MHz @ 802.11g) Page 67 of 97 Report No.: A150A166219-WLAN (Plot 4.7.2 C5: Channel 11: 2462MHz @ 802.11g) (Plot 4.7.2 C6: Channel 11: 2462MHz @ 802.11g) Page 68 of 97 Report No.: A150A166219-WLAN (Plot 4.7.2 D: Channel 1: 2412MHz @ 802.11g) (Plot 4.7.2 E: Channel 11: 2462MHz @ 802.11g) Page 69 of 97 Report No.: A150A166219-WLAN 4.7.3 802.11n HT20 Test Mode A. Test Verdict Channel Frequency (MHz) Frequency Range Refer to Plot Limit (dBc) Verdict 1 2412 2412MHz Plot 4.7.3 A1 N/A PASS 9KHz-30MHz Plot 4.7.3 A2 -20 PASS 30MHz-1GHz Plot 4.7.3 A3 -20 PASS 1GHz-8GHz Plot 4.7.3 A4 -20 PASS 8GHz-16GHz Plot 4.7.3 A5 -20 PASS 16GHz-25GHzPlot 4.7.3 A6 -20 PASS 6 2437 2437MHz Plot 4.7.3 B1 N/A PASS 9KHz-30MHz Plot 4.7.3 B2 -20 PASS 30MHz-1GHz Plot 4.7.3 B3 -20 PASS 1GHz-8GHz Plot 4.7.3 B4 -20 PASS 8GHz-16GHz Plot 4.7.3 B5 -20 PASS 16GHz-25GHzPlot 4.7.3 B6 -20 PASS 11 2462 2462MHz Plot 4.7.3 C1 N/A PASS 9KHz-30MHz Plot 4.7.3 C2 -20 PASS 30MHz-1GHz Plot 4.7.3 C3 -20 PASS 1GHz-8GHz Plot 4.7.3 C4 -20 PASS 8GHz-16GHz Plot 4.7.3 C5 -20 PASS 16GHz-25GHzPlot 4.7.3 C6 -20 PASS Frequency (MHz) Delta Peak to Band emission (dBc) Detector Limit (dBc) Refer to Plot Verdict 2396.50 -31.682 Peak -20 Plot 4.7.3 D PASS 2485.70 -39.057 Peak -20 Plot 4.7.3 E PASS Note: 1. For 802.11n HT20 mode at finial test to get the worst-case emission at 6.5Mbps. 2. The test results including the cable lose. B. Test Plots Page 70 of 97 Report No.: A150A166219-WLAN (Plot 4.7.3 A1: Channel 1: 2412MHz @ 802.11n HT20) (Plot 4.7.3 A2: Channel 1: 2412MHz @ 802.11n HT20) Page 71 of 97 Report No.: A150A166219-WLAN (Plot 4.7.3 A3: Channel 1: 2412MHz @ 802.11 n HT20) (Plot 4.7.3 A4: Channel 1: 2412MHz @ 802.11n HT20) Page 72 of 97 Report No.: A150A166219-WLAN (Plot 4.7.3 A5:…
