2AD2W-PHOTOBOOTHSprocket Photobooth

C&A Marketing Inc.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jan 04, 2024
Application Purpose: Original Equipment
Date of Application: Jan 03, 2024
Equipment Note: Sprocket Photobooth
Frequency Range: 2412.00000000 - 2462.00000000
Company: C&A Marketing Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s auth ority to operate the equipment. FCC Statement to the User : This equipment has been tested and found to comply with the limits for a Class B digital device, pu rsuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equ ipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interferen ce to radio communications.However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful inter ference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio T 9 technician for help. Do not make any changes or modifications to the equipment unless otherwise specified in the manual. If such changes or modifica tions should be made, you could be required to stop operation of the equipment. Warning :

Attestation Statements

C+A GLOBAL 1 November 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA Applicant: Address: Contact Person: Position: Tel.: Email: FCC ID: C&A Marketing, INC. 114 lived Lane East. Edison, NJ 08837, USA Chaim Piekarski Chief Executive Officer 8482442000-389 legal(&,caglobal.com Shlomo.EngelAcaglobal.com 2AD2W-PHOTOBOOTH Reference 1: Attestation Statements Part 2.911(d)(5)(i) Filing Applicant C&A Marketing, Inc. hereby certifies that the equipment for which authorization is sought does not fall under the definition of "covered equipment" that would have been prohibited from receiving an equipment authorization pursuant to Section 2.903 of the Federal Communications Commission's rules. Reference 2: Attestation Statements Part 2.911(d)(5)(ii) Filing Applicant C&A Marketing, INC. likewise certifies that, as of the date of the filing of the application, Applicant is not identified on the Covered List as an entity producing "covered equipment" as shown on https:/ /www.fcc.gov/supplychain/coveredlist. Done this 1st day of November 2023, in New Jersey, U.S.A. CHAIM PIE SKI Chief Executive Officer 114 lived Lane East I Edison, NJ 08837 I www.caglobal.com • * • O‘ 111111 " SARIS 4l1 Ic Esgi I Jifeprinr Fit,m p(iv(1Ic FEYWAPD RITZCAMERA Mcr . L.W.41 REGT IAR, SOmmy (ow tritt [PEW . ivnbl. 7DrEuifiy• pawrhe j umbi ivation° iltal %Iv scillitug *Authorised Licensee. Apart front the ICenSed trademarks, all are trademarks of COO IP Holdings. LLC, ZINK Holdings, LLC, or Saris Equipment LLC. radiStered in the U.S. and Of hnr en.ntro. al login'

Attestation Statements

C+A GLOBAL 31 October 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA Reference: FCC ID: FRN: Attestation Statements Part 2.911(d)(7) Filing 2AD2W-PHOTOBOOTH 0025643727 Applicant C&A Marketing, Inc. hereby certifies that, as of the date of the filing of the application, C&A Marketing, Inc. is the designated U.S. agent of said applicant for the service of processes for the above referenced equipment (FCC ID: 2AD2W- PHOTOBOOTH). C&A Marketing, Inc. accepts to maintain itself as said U.S. agent for no less than one year after the grantee has terminated all marketing and importation of the equipment or the conclusion of any FCC related proceeding involving the equipment. C&A Marketing, Inc. likewise accepts, as of the date of the filing of the application, the obligations of the designated U.S. agent for the service of processes for the above referenced equipment (FCC ID: 2AD2W-PHOTOBOOTH). The details of said U.S. agent are set forth as follows: U.S. Agent: Address: FRN: Contact Person: Tel.: Email: C&A Marketing, INC. 114 Tived Lane East. Edison, NJ 08837, USA 0025643727 Chairn Piekarski 8482442000-389 legalAcaglobal.corn Shlomo.Engel(i'maglobal.com Done this 31st day of October 2023, in New Jersey, U.S.A. C&A MARKETING, INC. Applicant CHAIM PIE SKI Chief Executive Officer 114 Tived Lane East I Edison, NJ 08837 I www.caglobal.com SARIS ZIflKffsi glifeprint. FINE pilVCIIC FHEYWAPD" RITICAMERA COr C&A MARKETING, INC. U.S. Agent sr..; . .14i! CHAIM PIEKARSKI Chief Executive Offica : - :4'1Z 2012 zE - 01-14A 1, ,ckcos:0 0%. JS .••• • ........ • * 1-"X I ffINCI I sumo, -eoft)W (RIO junbl DeuiFEY PawPle Jumbi ivatiorr Pets /mar Jumbl SCHMtat. CI t°9i6 — WARE 'Authorized Licensee Apart from the licensed trademarks, all are trademarks of GSA IF Hoictings, LLC. ZINC Hoidings, LLC. or Sans Equipment LLC. registered in the US and other countnes.

Cover Letter(s)

SCS-F019: Confidentiality Request Letter Page 1 of 2 Rev 8 One Distribution Center Circle, Suite 1 Littleton, MA 01460 Tel: +1 978 486 8880 Email: [email protected] Website: https://www.cps.bureauveritas.com/ Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 Updated References and Contact Info 6.0 7.0 Aug-30-2020 Updated BV Company Address 7.0 8 Nov-28-2023 SCS-F019: Confidentiality Request Letter Page 2 of 2 Rev 8 Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagram Short Term External Photos Short Term Permanent i Internal Photos Short Term Permanent Operational Description/ Theory of Operation Short Term Permanent Parts List Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent i User’s Manual Short Term Permanent SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES

Cover Letter(s)

WIFI Channel 12 and 13 Declaration Letter Reason for Amendment Revision History Approved Date From To Initial Release (obsolete) - Initial 1.0 December 22, 2015 Modify the select options (current) 1.0 2.0 September 23, 2016 SCS-F190 WiFi Channel 12&13 Declaration Letter I Page 1 of 2 Rev.2.0 Created by William Graff Approved by Bao-Thuong Nguyen C&A Marketing, Inc. WIFI Channel 12 and 13 Declaration Letter We declare the equipment identified below with regards to Channel 12 and 13 capabilities for FCC ID: 2AD2W-PHOTOBOOTH Declaration El Product hardware does not have the capability to operate on Channel 12 and 13. Product hardware has the capability to operate on Channel 12 and 13. However, these two channels will be disabled via software and will not be accessible to user. a El Product hardware has the capability to operate on Channel 12 and 13. However, all the operated channels can't be changed in the RF parameter via software. All channels have complied with all of the requirements sets out in FCC Part 15.247. El Product hardware has the capability to operate on WiFi Channel 12 and 13, and meets the requirements of KDB 594280 DO1 v02r01. Please note: 1.) By default, this device operates in a mode that is compliant with the U.S. requirements. 2.) This device will also use supplemental information such as geo-location data to determine that it is operating outside the U.S., if necessary, to change its power. Such supplemental data will be derived from the following: El Global Navigation Satellite System (GNSS)7 sensors in the device El Mobile Country Code (MCC),8 or MCC with a Mobile Network code (MNC), received from a CMRS9 carrier and received directly by a receiver on the device Country information derived from multiple adjacent access points (for example using IEEE Std 802.11d provisions) may be permitted on case-by-case basis El Other suitable geo-location data based on IP addresses or other reliable source. Name / Title: Chaim Piekarski / Chief Executiseficer Signature: Date: 4 December 2023 Phone: 848 244 2000-389 Email: legal caglobal.com; Shlomo.Enciel cacilobal.com SCS-F190 WiFi Channel 12&13 Declaration Letter Page 2 of 2 Rev.2.0 Created by William Graff Approved by Bao-Thuong Nguyen

External Photos

ID Label/Location Info

CAN ICES-3(B)/NMB-3(B) IC:4613B-PHOTOBOOTH Model:HPISPPB 12V4A FCC ID:2AD2W-PHOTOBOOTH 21.2MM 92.7MM CODE 128 Month A=Jan, B=Feb, C=Mar, D=Apr, E=May, F=Jun, G=Jul, H=Aug, J=Sep, K=Oct, M=Nov, P=Dec Day 1~31 Year Factory code fixed code color code WHITE=WH, BK=Black serial NO. B 2 3 2 2 0 1 5 WH 0 0 0 0 1 White Device SKU:HPISPPBW B2323015WH00001 SKU:HPISPPBW SN encoding rule CAN ICES-3(B)/NMB-3(B) IC:4613B-PHOTOBOOTH Model:HPISPPB 12V4A FCC ID:2AD2W-PHOTOBOOTH B2323015WH00001 SKU:HPISPPBW

Internal Photos

RF Exposure Info

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 6 Report Version A Test Report No.: FM2309WDG0108 RF EXPOSURE REPORT Applicant C&A Marketing, INC. Address 114 Tived Lane East. Edison, NJ 08837, USA Manufacturer or Supplier C&A Marketing, INC. Address 114 Tived Lane East. Edison, NJ 08837, USA Product Sprocket Photobooth Brand Name Model HPISPPB Additional Model & Model Difference NA Date of tests Sep. 18, 2023 ~ Oct. 26, 2023 FCC Part 2 (Section 2.1091) FCC Part 1 (Section 1.1310) KDB 447498 D01 V06 IEEE C95.1 CONCLUSION: The submitted sample was found to COMPLY with the test requirement Tested by Lucas Chen Project Engineer / EMC Department Approved by Glyn He Assistant Manager / EMC Department Date: Dec. 26, 2023 This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 6 Report Version A Test Report No.: FM2309WDG0108 TABLE OF CONTENTS RELEASE CONTROL RECORD ................................................................................ 3 1. CERTIFICATION .............................................................................................. 4 2. RF EXPOSURE LIMIT ..................................................................................... 5 3. MPE CALCULATION FORMULA ..................................................................... 5 4. CLASSIFICATION ........................................................................................... 5 5. ANTENNA GAIN .............................................................................................. 6 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ................... 6 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 6 Report Version A Test Report No.: FM2309WDG0108 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED FM2309WDG0108 Original release Dec. 26, 2023 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 4 of 6 Report Version A Test Report No.: FM2309WDG0108 1. CERTIFICATION PRODUCT: Sprocket Photobooth BRAND NAME: MODEL NO.: HPISPPB ADDITIONAL MODEL: NA FCC ID: 2AD2W-PHOTOBOOTH TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: C&A Marketing, INC. STANDARDS: FCC Part 2 (Section 2.1091) KDB 447498 D01 V06 IEEE C95.1 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 5 of 6 Report Version A Test Report No.: FM2309WDG0108 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 6 of 6 Report Version A Test Rep…

Text truncated - open the document above for the full version.

Test Report

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 25 Report Version B Test Report No.: AN2311WDG0039 ANTENNA TEST REPORT Applicant Shenzhen Joyhong Technology CO., Ltd Address 5th Floor, Building1, Zhongtai Road, 18, Loucun Second Industrial Park, Xinhu Street, Guangming, Shenzhen, China Manufacturer or Supplier Shenzhen Joyhong Technology CO., Ltd Address 5th Floor, Building1, Zhongtai Road, 18, Loucun Second Industrial Park, Xinhu Street, Guangming, Shenzhen, China Product WIFI dual-band antenna Brand Name N/A Model XBLP4914-T113420BG Max. Peak Gain 3.38 dBi for 2.4GHz, 2.27 dBi for 5180~5240MHz, 3.26 dBi for 5745~5825MHz Date of tests Nov. 13, 2023 Tested by Andy Zhu Supervisor / EMC Department Approved by Glyn He Assistant Manager / EMC Department Date: Dec. 05, 2023 This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 25 Report Version B Test Report No.: AN2311WDG0039 TABLE OF CONTENTS 1. MEASUREMENTS SETUP ..................................................................................................................3 2. SIZE OF THE ANTENNA .....................................................................................................................4 3. TEST INSTRUMENTS .........................................................................................................................5 4. TEST RESULTS ...................................................................................................................................6 5. PHOTOGRAPHS OF THE TEST CONFIGURATION....................................................................... 25 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 25 Report Version B Test Report No.: AN2311WDG0039 1. MEASUREMENTS SETUP During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating interconnecting cables, Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 4 of 25 Report Version B Test Report No.: AN2311WDG0039 2. SIZE OF THE ANTENNA Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 5 of 25 Report Version B Test Report No.: AN2311WDG0039 3. TEST INSTRUMENTS Equipment Manufacturer Model No. Serial No. Next Cal. Signal Generator Agilent N5183A MY50140980 Jul. 11, 24 Spectrum Analyzer Rohde&Schwarz FSV40 101003 Jan. 11, 24 Broad-Band Horn Antenna SCHWARZBECK BBHA 9120 D 9120D-1247 Apr. 01, 24 Broad-Band Horn Antenna SCHWARZBECK BBHA 9120 B 00740 Jul. 20, 24 Turn Table MF MF-7802 MF780208191 N/A Controller MF MF-7802 MF780208243 N/A Test Software BV ADT BV ADT Antenna Pattern V6.2 N/A NOTE: 1. The test was performed in Fully Anechoic Room. 2. The calibration interval of the above test instruments is 12 months and the calibrations are traceable to CEPREI/CHINA, GRGT/CHINA and NIM/CHINA. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 6 of 25 Report Version B Test Report No.: AN2311WDG0039 4. TEST RESULTS 2.4GHz ANTENNA FREQUENCY (MHz) ANTENNA POLARITY MAX. PEAK GAIN (dBi) PCB 2412 Horizo…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Chaim Piekarski(Chief Executive Officer)

[email protected]8482442000Fax: 8482442361

Test Firm

Bureau Veritas Shenzhen Co., Ltd. Dongguan BranchEdwin Ye

[email protected]86-20-8714 8549

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	441.57 mW

Confidentiality

Long Term

Grant Notes

Power listed is the maximum conducted output power. Device contains 20 and 40 MHz signal bandwidth. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance?
