2AD2WIVAGLOWGLOW by Ivation

C&A Marketing Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Feb 10, 2015
Application Purpose: Original Equipment
Date of Application: Feb 10, 2015
Equipment Note: GLOW by Ivation
Frequency Range: 2402.00000000 - 2480.00000000
Company: C&A Marketing Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Glow by Ivation Product Information Guide Welcome to your Glow by Ivation alarm lamp This guide contains helpful information that enables you to enjoy all of the features of your alarm lamp Congratulations Thank you for purchasing this alarm lamp! To fully enjoy this product please read the following instructions carefully. Care and Maintenance 1. Do not attempt to service the product yourself. Opening or removing covers may expose you to dangerous voltages or other hazards, please contact your dealer. 2. Do not use the product in temperatures that exceed the standard. Extreme temperature will lead to damage to product. 3. Keep the product out of the reach of children. 4. Do not use the product close to other wireless devices or radiators. 5. Do not drop the product into fire or water. 6. Use the product in proper volume. Extremely high volume can be harmful to your ears. Contents PG Care and Maintenance 1 Feature List 3 Layout 4 Alarm Hardware Controls 6 Connecting 7 Charging Mobile Devices 7 Operations: how to operate your alarm lamp 8 Troubleshooting 18 Specifications 19 Features List 1. Superior audio quality 2. Stereo audio output 3. Capacitive touch interface with hard switch light and alarm modes 4. Bluetooth connection (Bluetooth V4.0) 5. Multiple audio input options: Bluetooth and auxiliary 6. Dimmable LED clock display 7. Adjustable date and time 8. Dual alarm function with custom audio and light alarm modes 9. Lamp with adjustable light brightness and color 10. USB for charging mobile devices Layout Front View Rear View To p Vi e w Alarm Hardware Controls Function Key Function Alarm Mode Slider Slider allows you to select between four alarm mode types: 1. Light 2. Audio 3. Light and Audio 4. Off Sleep / On Button Turns audio on and off. Turns the alarm off, or sets the alarm to sleep mode. View clock, date and year Set Button Long press to enter Alarm/Clock settings. Sets selection within functions. Single press to show current audio method playing. Light Select Button Single press activates lighting mode, allowing light brightness and color to be changed. Audio Select Button Single press to show current audio method playing and enter Audio settings. Bluetooth Paring Button Press and hold to pair Bluetooth. Single press to reconnect to old device. Control Up/Down Button Increases and decreases values for light and sound, and toggles through modes within their respective functions. Light Switch Toggle the light switch to turn the lamp on/off. Connecting Connect the plug of the power supply to the power jack of the alarm lamp, and then plug the power DC12V, 3A into a standard AC wall outlet. Charging Mobile Devices To charge some mobile devices, plug the connector in the USB port on the base, then plug the other connector in the port of your mobile phone. Operations: how to operate your alarm lamp Pair Bluetooth 1. Press and hold , BT and the arrow animation will turn on in the front display and BT button will light up. 2. The blue backlight on the key will be flashing during pairing. The blue indicator will be off when the Bluetooth has been successfully paired. 3. Repeat steps 1, 2 to connect another device. 4. After paired successfully，the device will back to Clock Screen and time shows steady. Notes: Single Press will connect with previous device. Change FM 1. Press button. Current audio mode will appear on screen. 2. Press to toggle through audio modes between AUX, BT and RADIO. 3. RADIO will appear on screen, single press to confirm. 4. Current tuning will appear on screen. In tuner use to tune up and down with a single touch, or long press to scan ahead or backwards the tuning, and SCN>-SCN>>will flash on screen. 5. Single Press or wait 3 seconds, the device will save current settings and back to Clock Screen and time shows steady. Notes: When you plug in the audio cable, it will be an antenna for FM and enhance the receiving signal. Audio In 1. Press button. Current audio mode will appear on screen. 2. Press to toggle through audio modes between AUX, BT and RADIO. 3. AUX will appear on screen, single press to confirm. Play Music (BT Mode) 1. Pair and connect your Bluetooth device with the speaker. 2. Long Press on the alarm lamp to play, Long press it again to pause. 3. Press ，BT will appear on screen. Press , SONG will flash. Press to play next or previous song, and NEXT or PREV will appear on screen. Press and hold to fast forward or rewind through the song, and FF or REW will appear on screen. 4. Press or wait 3 seconds and the device will bring back to Clock Screen and time shows steady Change and/or Set Volume 1. Single press to increase or decrease the volume. Press and hold to keep increasing or decreasing the volume. 2. Press or wait 3 seconds, the device will save current settings and back to Clock Screen and time shows steady. Set Clock and Date 1. Slide Alarm Mode Slider to position, the OFF will show on screen. 2. Long press . Screen will flash Hour. 3. Single press to change the hour. Press and hold to keep changing the hour. when reaching the PM hours the screen will show PM and Bottom left side should have a dot lit up when in AM hours displays AM and the bottom left side dot is off. 4. Single press . Screen will flash Minute. 5. Single press to change the minute. Press and hold to keep changing the minute. 6. Single press . Screen will flash Month. 7. Single press to change the month. Press and hold to keep changing the month. 8. Single press . Screen will flash Date. 9. Single press to change the date. Press and hold to keep changing the date. 10. Single press . Screen will flash Year. 11. Single press to change the year. Press and hold to keep changing the year. 12. Single press , screen will appear BEEP，then ON flash on screen. Press to select ON or OFF. 13. Single press , screen will show BRI steady. This function allows you adjust screen LCD brightness . Wait 350ms, screen will flash HIGH and lettering very bright. Single press to select from HIGH, M…
