2AD4M-VTZ0119Digital Voice Recorder

User manual DVT4110, DVT6110, DVT7110, DVT8110 Table of Contents 1. Important ................................................................................................................................................... 3 Safety instructions ................................................................................................................................. 3 Cleaning and disinfection ....................................................................................................................... 4 Disposal of your old product ................................................................................................................... 4 About this user manual ........................................................................................................................... 5 2. Your VoiceTracer audio recorder ................................................................................................................... 6 Product highlights .................................................................................................................................. 6 What's in the box ................................................................................................................................... 6 Overview of your audio recorder .............................................................................................................. 7 3. Get started ................................................................................................................................................. 8 Charging the battery .............................................................................................................................. 8 Turn the device on and off ...................................................................................................................... 8 Key lock ................................................................................................................................................ 8 Connect to a computer ........................................................................................................................... 9 Set the date and time ............................................................................................................................. 9 Set the device language ......................................................................................................................... 9 4. Recording ................................................................................................................................................. 10 Record a file ......................................................................................................................................... 10 Edit a file ............................................................................................................................................. 10 5. Playback .................................................................................................................................................. 11 Play back files ...................................................................................................................................... 11 Delete files ........................................................................................................................................... 11 6. Settings .................................................................................................................................................... 12 7. Connect to VoiceTracer App ........................................................................................................................ 14 To connect your VoiceTracer to the app: .................................................................................................. 14 8. How to use the meeting microphone (DVT8110 only) ..................................................................................... 15 9. Connect to video camera (DVT7110 only) ...................................................................................................... 16 10. Device and data management ................................................................................................................... 17 Transfer data to the computer ................................................................................................................ 17 Reset your device and data .................................................................................................................... 17 Updating your device ............................................................................................................................ 18 11. Troubleshooting ........................................................................................................................................ 19 12. Technical data ......................................................................................................................................... 20 13. Certifications ........................................................................................................................................... 22 FCC Warning Statement ........................................................................................................................ 22 Open source software .......................................................................................................................... 22 2 1. Important Do not make any adjustments and modifications that are not described in this manual. Follow all safety instructions to ensure proper operation of the device. The manufacturer assumes no liability for damages resulting from non-com- pliance with the safety instructions. View this user manual online: help.voicetracer.com/ dvt8110 Safety instructions • Protect the device from rain and liquids to prevent dam- age to the device or a sh…

Text truncated - open the document above for the full version.

Speech Processing Solutions GmbH May 14 th , 2021 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370a Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Hong gyu Lee of ICR Co.,Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: 2AD4M-VTZ0119 including signing of all documents relating to these matters. Any and all acts carried out by Hong gyu Lee of ICR Co.,Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Speech Processing Solutions GmbH “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Wolfgang Spannlang / Manager

Speech Processing Solutions GmbH Rev 11/20/07 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AD4M-VTZ0119 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram DVT4110_Blk.pdf Part list DVT4110_Plist.pdf Schematics DVT4110_Schem.pdf Operational Description DVT4110_OpDesc.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); Exhibit Type File Name Internal Photo DVT4110_Int Photos.pdf External Photo DVT4110_Ext Photos.pdf Manual DVT4110_Manual_Rev.2.pdf Test Set-up Photo DVT4110_Tsup Photos_Rev.1.pdf For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. Sincerely, Wolfgang Spannlang/ Manager

Exterior Photographs Front Top Rear Bottom Side 1 Side 2 Side 3 Side 4

Label & Location

Internal of sample Main Board(Front) Main Board (rear) Module Antenna

페이지(page) : ( 2 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.0 Report No. ICRT-TR-E211125-0A Contents 1. Applicant & Manufacturer & Test Laboratory Information .......................................................................................... 3 1.1 Applicant information ............................................................................................................................................ 3 1.2 Manufacturer Information .................................................................................................................................... 3 1.3 Test Laboratory Information ................................................................................................................................ 3 2. Equipment under Test(EUT) Information ..................................................................................................................... 4 2.1 General Information .............................................................................................................................................. 4 2.2 Additional Information .......................................................................................................................................... 4 2.3 Mode of operation during the test ...................................................................................................................... 4 2.4 Modifications of EUT ............................................................................................................................................ 4 2.5 Reason of Additional Model Name..................................................................................................................... 4 3. Maximum Permissible Exposure ................................................................................................................................... 5 3.1 RF Exposure calculation ...................................................................................................................................... 5 3.2 EUT Descrption ..................................................................................................................................................... 5 3.3 Result ..................................................................................................................................................................... 6 Revision History Issued Report No. Issued Date Revisions Effect Section ICRT-TR-E211125-0A 17-May-2021 Initial Issue All 페이지(page) : ( 3 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.0 Report No. ICRT-TR-E211125-0A 1. Applicant & Manufacturer & Test Laboratory Information 1.1 Applicant information Applicant Speech Processing Solutions GmbH Address Gutheil Schoder Gasse 8-12, 1100 Vienna, Austria Contact Person Wolfgang Spannlang Telephone No. +43-1-60529-4691 Fax No. - E-mail [email protected] 1.2 Manufacturer Information Manufacturer 1 Zaram Technology Inc. Address 2 Fl, FineVenture Building, 41, Seongnam-daero 925 Beon-gil, Seongnam-si, Gyeonggi-do, 13496, Republic of Korea 1.3 Test Laboratory Information Conducted tests were performed at Laboratory ICR Co., Ltd. Address 112, Hwanggeum 3-ro 7beon-gil, Hagun-ri, Yangchon-eup, Gimpo-si, Gyeonggi- do, Korea Telephone No. +82-2-6351-9002 Fax No. +82-2-6351-9007 RRA No. KR0165 KOLAS No. KT652 Test Firm Registration Number 490614 페이지(page) : ( 4 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.0 Report No. ICRT-TR-E211125-0A 2. Equipment under Test(EUT) Information 2.1 General Information Product Name Digital Voice Recorder (Voice Tracer) Brand Name - Model Name DVT4110 Additional Model Name DVT6110, DVT7110, DVT8110 FCC ID 2AD4M-VTZ0119 Power Supply DC 5.0 V 2.2 Additional Information Equipment Class DTS-Digital Transmission System Device Type Stand-alone Operating Frequency 2 412 ㎒ ~ 2 462 ㎒ RF Output Power 5.63 ㏈m Number of Channel 11 Modulation Type 802.11b: DSSS Modulation 802.11g/n(HT20): OFDM Modulation Antenna Type FPCB Antenna Antenna Gain -0.82 ㏈i Antenna Operating Mode Single Antenna Equipment with only one antenna 2.3 Mode of operation during the test - The EUT is continuous transmission mode during the test with set to each of the Low Channel, Middle Channel, and High Channel at the worst case data rate. The worst case data rate for each modulation is determined 1 Mbps for IEEE 802.11b, 6 Mbps for IEEE 802.11g, 6.5 Mbps for HT20. 2.4 Modifications of EUT - None 2.5 Reason of Additional Model Name NO Family model name Differential point 1 DVT6110 Basic model and electric performance, structure and circuit are the same, but simple derivative model name is added according to buyer request 2 DVT7110 3 DVT8110 페이지(page) : ( 5 )/( 총(Total) 6 ) ICRT-QPA-17-03 Rev.0 Report No. ICRT-TR-E211125-0A 3. Maximum Permissible Exposure 3.1 RF Exposure calculation According to the FCC rule 1.1310 table 1B, the limit for the maximum permissible RF exposure for an uncontrolled environment are f/1500 ㎽/㎝² for the frequency range between 300 ㎒ and 1 500 ㎒ and 1.0 ㎽/㎝² for the frequency range between 1 500 ㎒ and 100 000 ㎒. The electric field generated for a 1 ㎽/㎝² exposure is calculated as follows: E = √ (30 * P * G) / d, and S = E² / Z = E² / 377, because 1 ㎽/㎝² = 10 W/m² Where S = Power density in ㎽/㎝², Z = Impedance of free space, 377 Ω E = Electric filed strength in V/m, G = Numeric antenna gain, and d = distance in meter Combing equations and rearranging the terms to express the distance as a function of the remaining variable d = √ (30 * P * G) / (377 *10 S) Changing to units of ㎽ and cm, using P (㎽) = P (W) / 1 000, d (㎝) = 0.01 * d (m) d = 0.282 * √ (P * G) / S Where d = distance in ㎝, P = Power in ㎽, G = Numeric antenna gain, and S = Power density in ㎽/㎝² 3.2 EUT Descrption Kind of EUT Wireless Home Camera Operating Frequency Band ■ WLAN(802.11b/g/n(HT20)): 2 412 ㎒ ~ 2 462 ㎒ □ WLAN(802.11n(HT40)): 2 422 ㎒ ~ 2 452 ㎒ □ WLAN: 5 180 ㎒ ~ 5 320 ㎒ / 5 500 ㎒ ~ 5 700 ㎒ □ WLAN: 5 745 ㎒ ~ 5 825 ㎒ □ Bluetooth: …

Text truncated - open the document above for the full version.

LCD LIGHT SENSOR RESET KEY_TACT MICRO SD (DVT4110~8110) LED POWER /HOLD USB POWER MIC & AUDIO IN/OUT X_TAL SPEAKER RTC SERIAL FLASH BATTERY NAND FLASH(TSOP) WIFI SWITCH WIFI DECODER PULL UP/DOWN BATTERY CHARGER CENTER MIC DP/DM differential 임피던스 : 90 ohm. 패턴 길이 같게DP/DM 패턴 길이 같게CONTOL, DATA 간(U701-BAT1) BAT_PL 패턴 굵게 패턴 길이 같게CONTOL, DATA 간 패턴 굵게(J901-U701) V_BUS SD(boot) eMMC uSD CARDTSOPeMMC MEMORY OPTION TABLE O O O O LOC. O O O O O O O O O O O O O O O O CON6 R309,R310,R311 U303 R319,R320,R321 CON6A C316 R317,R318 C302 C308,C309,C314 C315 U302 O C310,C312 R312,R313,R314 C301,C311 R315 C313,C304,C307 U301 CODEC O O O O O DVT8110 O O O O O O O O LOC. MODEL OPTION TABLE DVT4110 C521C519 C509 C518 C527C526 C516 C512C511C515 C517 C523 R536 R516 R534 R535 R522R513 C205 C207 C204C202C201 C208 U501 U201 R201 R202 R203 C522 R538 C528 C529 C507 C520 C508 C510 R529 R531 R515R528 R511 R512R502 R527 R527,C522 : DVT4110 R538,C528,C529 : DVT6110/8110 O O O O O O R903 R907 R942 R943 O O O OO O R504 R953O O O r322추가 보강용 PATTERN 보강용 PATTERN 보강용 PATTERN 보강용 PATTERN X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X 및 전원 분리 GND 분리 GND U701 에 BODY GND 연결 최대한굵게 () C203 C206O X 추가 MIC ON/OFF VCC_D30 VCC_D30 VCC_D30 VCC_D30 VCC_D30VCC_D30 VCC_D30 VCC_D30VCC_M VCC_D30 VCC_D30 VCC_D30VCC_D30VCC_M V_BUS V_BUS VCC_D30VCC_12VCC_A30 VCC_M VCC_M BAT_PL VCC_M VCC_D30 V_BUS VCC_D30 VCC_18 VCC_D30 VCC_W30 VCC_W30 BAT_PL VCC_D30 VCC_D30 VCC_M V_BUS VCC_MVCC_18VCC_W30VCC_MVCC_12 VCC_FVVCC_D30VCC_FVQ VCC_D30 V_USB VCC_A30 VCC_D30 VCC_D30 VCC_A30 VCC_D30 VCC_D30 VCC_MVCC_D30VCC_D30 VCC_FVVCC_FVQ VCC_FVQ VCC_18 VCC_M VCC_A30 VCC_A30 B C VCC_MW VCC_MW C CCC CCCC C B Title Size Document NumberRev Date:Sheetof SF-DVT8110_17A EPP DVT4110/6110/8110(2019) A2 11Wednesday, May 08, 2019 Title Size Document NumberRev Date:Sheetof SF-DVT8110_17A EPP DVT4110/6110/8110(2019) A2 11Wednesday, May 08, 2019 Title Size Document NumberRev Date:Sheetof SF-DVT8110_17A EPP DVT4110/6110/8110(2019) A2 11Wednesday, May 08, 2019 R907 4.7KJ R801 47KJ U801 RT8035GQW EN1 1 FB1 2 VIN2 3 GND 4 LX2 5 EN2 6 FB2 7 VIN1 8 9 GND LX1 10 PAD 11 R320 10KJ,NM C512 105 R535 100RJ R704 2.2KJ C102 105 R608 10KJ C817 22pF D802 KDS121E + C505 100/6.3V "B" C520 105 C311 104 C802 104 R603 100RJ C309 104,NM C801 22/6.3V R314 4.7KJ R934 330RJ R529 0RJ R502 10KJ C813 104 R321 10KJ,NM R931 5.1KF R522 100RJ TP2 1 Q901 KRC403E R203 33KJ R909 4.7KJ R807 4.7KJ uSD_CARD CON3A uSD,NM R921 3.3KJ R910 1.5KJ C807 22/6.3V U501 NAU88C22YG LMICP 1 LMICN 2 LLIN 3 RMICP 4 RMICN 5 RLIN 6 FS 7 BCLK 8 ADCOUT 9 DACIN 10 MCLK 11 VSSD 12 VDDC 13 VDDB 14 CSB 15 SCLK 16 SDIO 17 MODE 18 LAUXIN 19 RAUXIN 20 AUXOUT1 21 AUXOUT2 22 RSPOUT 23 VSSSP 24 VDDSP 26 VDDA 31 VREF 27 LSPOUT 25 MICBIAS 32 VSSA 28 LHP 30 RHP 29 PAD 33 R322 10KJ,NM TP7 1 C804 105 S2 ST-1198S REC 3 1 4 2 U802 RT8035GQW EN1 1 FB1 2 VIN2 3 GND 4 LX2 5 EN2 6 FB2 7 VIN1 8 9 GND LX1 10 PAD 11 C927 103 R905 4.7KJ FB91 CIC10P121N D801 KDS121E R506 470RJ R932 5.1KF CON7 WPTF-5010-PP CD/DAT3 2 CMD 3 VDD 4 CLK 5 GND 6 DAT0 7 DAT1 8 DAT2 1 GND 10 SD_DET 9 C_GND 11 C_GND 12 C_GND 13 C307 104 L804 NLCV25T4R7M C814 22pF C915 104 R604 100RJ C905 105 R404 220KJ U403 ALS-PDIC17-77B/TR8,NM Vcc 1 NC 2 NC 3 GND 4 NC 5 OUT 6 Q801 KRA307E 2 13 C402 10pF,NM R915 10KJ R524 12KJ R805 100KJ C908 104 R804 100KJ R937 10KJ R706 4.7KJ C303 22/6.3V R101 1RJ R520 10KJ R9424.7KJ,NM C519 104 S4 ST-1198S NEXT 3 1 4 2 C907 105 + MICR COB627L-2032 2 1 C313 104 C314105,NM R929 4.7KJ R307 1RJ C904 105 C822 10/10V R519 10KJ C909 104 TP14 1 C517 105 C910 104 R813 100KJ R531 0RJ Q701 KRC403E R521 47KJ C316 22/6.3V,NM R536 100RJ R316 10KJ,NM C912 104 LED1 19-223/R6G6C-A01/2T 1 32 4 U301 TC58TEG6DDKTA00 Vcc 1 Vss 2 NC 3 NC 4 NC 5 R/B2 6 R/B1 7 /RE 8 /CE1 9 /CE2 10 NC 11 Vcc 12 Vss 13 NC 14 NC 15 CLE 16 ALE 17 /WE 18 /WP 19 NC 20 NC 21 VPP 22 Vss 23 Vcc 24 Vss 48 NC 47 VssQ 46 VccQ 45 I/O7 44 I/O6 43 I/O5 42 I/O4 41 VssQ 40 VccQ 39 PRE/VccQ 38 Vcc 37 Vss 36 DQS 35 VccQ 34 VssQ 33 I/O3 32 I/O2 31 I/O1 30 I/O0 29 VccQ 28 VssQ 27 NC 26 Vss 25 R913 10KJ R938 12KJ R9434.7KJ,NM R530 2.2KJ C301 104 C304 22/6.3V C315 104,NM R901 4.7KJ R505 100KJ Q503 KRC403E C207 22pF C511 104 L803 VLS201610ET-4R7M C508 105 C913 103 J901 014101010-37 GND A1 VBUS A4 CC1 A5 DP1 A6 DN1 A7 SBU1 A8 VBUS A9 GND A12 GND B1 SBU2 B8 VBUS B4 DN2 B7 VBUS B9 CC2 B5 DP2 B6 GND B12 GND 3 GND 4 GND 1 GND 2 C302 104,NM R526 4.7KJ R512 10KJ S10 ST-1198S FILES 3 1 4 2 S1 ST-1198S F1 3 1 4 2 C527 105 S5 ST-1198S BACK 3 1 4 2 R948 220RJ R313 4.7KJ S7 ST-1198S DOWN 3 1 4 2 LED2 19-223/R6G6C-A01/2T 1 32 4 R820 120KJ R510 12KJ C521 105 R95310KJ,NM U803 VRH2901NLX O 1 G 2 E 3 I 4 P 5 C308 104,NM ANT U601 ESP-M2 ADC 1 EN 2 HSCK 3 HMISO 4 U0CTS 5 U0RTS 6 VCC 7 GND 8 TXD1 9 FLASH 10 IO4 11 IO5 12 RXD0 13 TXD0 14 RST 15 IO16 16 R509 12KJ + MICC CUB9745L-2037 2 1 R9364.7KJ CON3 1060806AR001,NM DAT2 1 CD/DAT3 2 CMD 3 VDD 4 CLK 5 GND 6 DAT0 7 DAT1 8 SD_DET 9 C 10 C 11 C 12 C 13 C 14 C 15 C 16 C 17 C 18 R511 10KJ R707 100KJ U502 NJM2107F + 1 G 2 - 3 O 4 V 5 C532 105 R301 220RJ R809 120KF S6 ST-1198S UP 3 1 4 2 C501 221 S9 ST-1198S F3 3 1 4 2 R916 1.5KJ C805 10/10V R919 1.5KJ C704 22/6.3V C305 22/6.3VC408 22pF R518 100KJ C403 105C603 104 C306 103 R401 10KJ,NM R902 4.7KJ R703 1.5KJ R927 220RJ C103 105 R513 1RJ C815 22pF R309 10KJ,NM S11 ST-1198S PLAY 3 1 4 2 S8 ST-1198S F2 3 1 4 2 R918 3.3KJ R914 220KJ C208 104 R538 10KJ R315 1RJ C404 104,NM C526 104 L802 NLCV25T4R7M C310 104 C502 221 R810 115KF R806 470KF R9354.7KJ R803 100KJ C525 221 C903 104 R708 22KJ R912 10KJ C407 22pF C816 22pF S902 ST-1290 1 2 3 76 45 C602 104 C405 103,NM R928 100KJ R310 10KJ,NMC533 105 C914 105C901 104C917 105 C922 104 FB92 CIC10P121N R515 0RJ R816 115KF R811 47KJ R517 100KJ TP4 1 R818 100KJ X401 SSP-T7 12 34 R503 2.2KJ C705 10/10V U903 RT9300 EN 1 GND 2 LED4 3 LED3 4 LED2 5 LED1 6 C809 22/6.3V R501 2.2KJ R508 100KJ R514 4.7KJ C524 105 J501 AJ390-SMT 1 2 3 4 5 6 R817 10KJ R312 1RJ C806 10/10VC810 104 Q902…

Text truncated - open the document above for the full version.

페이지(page) : ( 2 )/( 총(Total) 56 ) ICRT-QPA-17-03 Rev.0 Report No. ICRT-TR-E211124-0A Contents 1. Applicant & Manufacturer & Test Laboratory Information .......................................................................................... 4 1.1 Applicant information ............................................................................................................................................ 4 1.2 Manufacturer Information .................................................................................................................................... 4 1.3 Test Laboratory Information ................................................................................................................................ 4 2. Equipment under Test(EUT) Information ..................................................................................................................... 5 2.1 General Information .............................................................................................................................................. 5 2.2 Additional Information .......................................................................................................................................... 5 2.3 Mode of operation during the test ...................................................................................................................... 5 2.4 Modifications of EUT ............................................................................................................................................ 5 2.5 Reason of Additional Model Name..................................................................................................................... 5 3. Test Summary .................................................................................................................................................................. 6 3.1 Test standards and results .................................................................................................................................. 6 3.2 Purpose of the test ............................................................................................................................................... 6 3.3 Test Methodology ................................................................................................................................................. 6 3.4 Configuration of Test System .............................................................................................................................. 6 3.5 Antenna requirement ............................................................................................................................................ 7 4. Used equipment on test .................................................................................................................................................. 8 5. 6 ㏈ Bandwidth ............................................................................................................................................................... 9 5.1 Operating environment ........................................................................................................................................ 9 5.2 Measurement method .......................................................................................................................................... 9 5.3 Test setup .............................................................................................................................................................. 9 5.4 Test data .............................................................................................................................................................. 10 6. Maximum Conducted (Average) Output Power ......................................................................................................... 15 6.1 Operating environment ...................................................................................................................................... 15 6.2 Measurement method ........................................................................................................................................ 15 6.3 Test setup ............................................................................................................................................................ 15 6.4 Test data .............................................................................................................................................................. 16 7. Power Spectral Density ................................................................................................................................................. 17 7.1 Operating environment ...................................................................................................................................... 17 7.2 Measurement method ........................................................................................................................................ 17 7.3 Test setup ............................................................................................................................................................ 17 7.4 Test data .............................................................................................................................................................. 18 8. Conducted Spurious Emission ..................................................................................................................................... 23 8.1 Operating environment ...................................................................................................................................... 23 8.2 Measurement method ........................................................................................................................................ 23 8.3 Test setup .....................................…

Text truncated - open the document above for the full version.

페이지(page) : ( 1 )/( 총 2 ) Test Setup Photo Test Setup Radiated measurement for below 1 ㎓ Test Setup Radiated measurement for Above 1 ㎓ 페이지(page) : ( 2 )/( 총 2 ) Test Setup Conducted Emission Test Setup Conducted Emission
