2AD5K-CZ3730AWLAN, Bluetooth and Zigbee Module

User Guide CZ3730A WLAN MIMO and Bluetooth and Zigbee Module Evaluation Board for TI Sitara Platform The CZ3730A-COM8 is WLAN dual-band, Bluetooth, BLE and Zigbee module evaluation board (EVB) with the Partron CZ3730A module The CZ3730A offers A 2.4G and 5-GHz module solution with two antennas. Contents 1. Overview ............................................................................................................................................ 2 1.1 General Features ...................................................................................................................... 2 2. Board Pin Assignment ...................................................................................................................... 2 2.1 Pin Description ......................................................................................................................... 3 3. Electrical Characteristics ................................................................................................................. 5 3.1 DC characteristics ................................................................................................................... 5 3.2 External Slow clock Input (RTC Clock) ............................................................................. 5 3.3 1.8V I/O Operation Condition ............................................................................................. 6 3.4 3.3V I/O Operation Condition ............................................................................................. 6 3.5 WLAN 2.4-GHz current consumption (AT BT and ZIGBEE Disable ) .................................. 7 3.6 WLAN 5-GHz current consumption (AT BT and ZIGBEE Disable ) ................................ 7 3.7 Bluetooth 4.0 current consumption (AT WLAN and ZIGBEE Disable ) .............................. 7 3.8 Bluetooth Low Energy Current consumption (AT WLAN and ZIGBEE Disable ) .............. 7 3.9 Bluetooth Low Energy Current consumption (AT WLAN and ZIGBEE Disable ) ......... 8 3.10 2.4GHz WLAN RF specification ............................................................................................ 8 3.11 5GHz WLAN specification ..................................................................................................... 9 3.12 Bluetooth 4.0 RF Specificaiton ........................................................................................... 10 3.15 Bluetooth Low Energy RF Specification ........................................................................... 10 3.16 Zigbee RF Specification ...................................................................................................... 10 4. Antenna Characteristics ................................................................................................................. 11 5. Circuit Design .................................................................................................................................. 12 User Guide 1. Overview Shows the CZ3730A-COM8 EVB Figure 1 CZ3730A-COM8 EVB(Top View) 1.1 General Features The CZ3730A-COM8 EVB includes the following features:  WLAN, Bluetooth, BLE and Zigbee on a single module board  100-pin board card  Dimensions:76mm(L) x 44.02mm(W)  WLAN 2.4- and 5-GHz SISO(20- and 40-MHz channels), 2.4-GHz MIMO(20-MHz channels)  Support for BLE dual mode  Seamless integration with TI Sitara and Other application processors  Design for the TI AM335X General-purpose evaluation module (EVM)  WLAN and Bluetooth single-antenna coexistence  Built-in chip antenna 2. Board Pin Assignment Shows the top view of the EVB Figure 2 EVB Top (Top View) Show the bottom slide of the EVB User Guide Figure 3 EVB Bottom (Top View) 2.1 Pin Description No. Name Type Description 1 RTC_CLK I Slow clock input option (default: NU) 2 Ground G Ground 3 Ground G Ground 4 WLAN_EN_SOC I WLAN enable 5 VBAT_IN P 3.6-V typical voltage input 6 Ground G Ground 7 VBAT_IN P 3.6-V typical voltage input 8 VIO_IN P Vio 1.8-V (I/O voltage) input 9 Ground G Ground 10 N.C No connection 11 WL_RS232_TX O WLAN tool RS232 output 12 N.C No connection 13 WL_RS232_RX I WLAN tool RS232 input 14 N.C No connection 15 WL_UART_DBG O WLAN Logger output 16 N.C No connection 17 N.C No connection 18 Ground G Ground 19 Ground G Ground 20 SDIO_CLK_WL I WLAN SDIO clock 21 N.C No connection 22 Ground Ground 23 N.C No connection 24 SDIO_CMD_WL I/O WLAN SDIO command 25 N.C No connection 26 SDIO_D0_WL I/O WLAN SDIO data bit 0 27 N.C No connection 28 SDIO_D1_WL I/O WLAN SDIO data bit 1 29 N.C No connection User Guide 30 SDIO_D2_WL I/O WLAN SDIO data bit 2 31 N.C No connection 32 SDIO_D3_WL I/O WLAN SDIO data bit 3 33 N.C No connection 34 WLAN_IRQ O WALN SDIO interrupt out 35 N.C No connection 36 N.C No connection 37 Ground G Ground 38 N.C No connection 39 N.C No connection 40 N.C No connection 41 N.C No connection 42 Ground G Ground 43 N.C No connection 44 N.C No connection 45 N.C No connection 46 N.C No connection 47 Ground G 48 N.C No connection 49 N.C No connection 50 N.C No connection 51 N.C No connection 52 BT_AUD_CLK I/O Bluetooth PCM clock input of output 53 N.C No connection 54 BT_AUD_FSYNC I/O Bluetooth PCM frame sync input of output 55 N.C No connection 56 BT_AUD_IN I Bluetooth PCM data input 57 N.C No connection 58 BT_AUD_OUT O Bluetooth PCM data output 59 N.C No connection 60 Ground G Ground 61 N.C No connection 62 N.C No connection 63 Ground G Ground 64 Ground G Ground 65 N.C No connection 66 BT_HCI_TX O Bluetooth HCI UART transmit output 67 N.C No connection 68 BT_HCI_RX I Bluetooth HCI UART receive input 69 N.C No connection 70 BT_HCI_CTS I Bluetooth HCI UART Clear to Send input 71 N.C No connection 72 BT_HCI_RTS O Bluetooth HCI UART Request to Send output 73 N.C No connection 74 N.C No connection 75 N.C No connection 76 BT_UART_DBG O Bluetooth Logger UART output 77 Ground G Ground 78 N.C No connection 79 N.C No connection 80 N.C No connection 81 N.C No connection 82 N.C No connecti…

Text truncated - open the document above for the full version.

PARTRON CO., LTD 22, Samsung 1-ro 2-gil, Hwaseong-si, Gyeonggi-do, Korea 445-170 Date: October 14 2015 Letter of Authorization We, the undersigned, hereby authorize DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCCID: 2AD5K-CZ3730A including signing of all documents relating to these matters. Any and all acts carried out by DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from PARTRON CO., LTD . “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Park Ji Hong RF Team Leader

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 5.0 Oct. 15, 2015 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, PARTRON CO., LTD hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (WLAN, Bluetooth and Zigbee Module, CZ3730A) FCC ID: 2AD5K-CZ3730A Sincerely, Client’s signature Client’s name / title Park Ji Hong / RF Team Leader Contact information / address PARTRON CO., LTD / 22, Samsung 1-ro 2-gil, Hwaseong-si, Gyeonggi-do, Korea 445-170

SCS-F19: Confidentiality Request Letter Page 1 of 4 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 4 Rev 4.0 Oct. 15, 2015 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AD5K-CZ3730A We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description - e.g. Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title Park Ji Hong / RF Team Leader Contact information / address PARTRON CO., LTD / 22, Samsung 1-ro 2-gil, Hwaseong-si, Gyeonggi-do, Korea 445-170 SCS-F19: Confidentiality Request Letter Page 3 of 4 Rev 4.0 Oct. 15, 2015 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: 2AD5K-CZ3730A To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days (please check one). - e.g. User Manual - e.g. Ext Photo - e.g. Int Photo - e.g. Test Photo The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Client’s signature Client’s name / title Park Ji Hong / RF Team Leader Contact information / address PARTRON CO., LTD / 22, Samsung 1-ro 2-gil, Hwaseong-si, Gyeonggi-do, Korea 445-170

SCS-F26 Modular Approval Letter Page 1 of 2 Rev 8.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Modular Approval Declaration Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (Obsolete) 1.0 1.0 Dec-04-2006 Added IC Modular Letter (Obsolete) 1.0 2.0 Feb 16 2009 Add LMA and MA option (Obsolete) 2.0 3.0 April 14 2010 Revised per RSS Gen issue 3.0 (Obsolete) 3.0 4.0 Jan 12 2011 Removed Foot(2) (obsolete) 4.0 5.0 July 19 2011 Adding New note per KDB996369 D01 V01R03 (obsolete) 5.0 6.0 August 29 2011 Updated company template & Added text box (obsolete) 6.0 7.0 Jan-31-2012 Updated modular requirement (current) 7.0 8.0 Sept 05 2014 SCS-F26 Modular Approval Letter Page 2 of 2 Rev 8.0 10 / 01 / 2015 (WLAN, Bluetooth and Zigbee Module) FCC ID : 2AD5K-CZ3730A , is seeking FCC Authorization as a Single Modular transmitter / Single Limited Modular Approval (Please check one). The EUT meets the requirements for Single Modular approval / Single Limited Modular Approval (please check one) as detailed in FCC public Notice DA00-1407. Compliance to each of the requirements is described below: Questions are: * Please provide a detailed explanation if the answer is “No.” Item Modular requirement Yes No 1 The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly; Y 2 The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal; Y 3 The module must contain power supply regulation on the module; Y 4 The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b); N 5 The module must demonstrate compliance in a stand-alone configuration; Y 6 The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labelling requirements); Y 7 The module must comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee; Y 8 The module must comply with RF exposure requirements Y Note: (1) LMA may be granted when one or more of the requirements in the table above cannot be demonstrated. LMA will also be issued in those instances where applicants can demonstrate that they will retain control over the final installation of the device, such that compliance of the end product is assured. In such cases, an operating condition on the LMA for the module must state that the module is only approved for use when installed in devices produced by a specific manufacturer. When LMA is sought, the application for equipment certification must specifically state how control of the end product into which the module will be installed, and will be maintained, such that full compliance of the end product is always ensured. (2) Please provide Clear and specific instructions describing the conditions, limitations and procedures for third-parties to use and/or integrate the module into a host device. (3) For non-Software Defined Radio transmitter modules where software is used to ensure compliance of the device, technical description of how such control is implemented to ensure prevention of third party modification must be provided (see KDB 594280). Note 1: Compliance of a module in its final configuration is the responsibility of the applicant. A host device will not be considered certified if the instructions regarding antenna configuration provided in the original description, of one or more separately certified modules it contains, were not followed. Example: A separately certified low-power transceiver module using Bluetooth technology which is housed in a desktop computer, laptop or peripheral does not require the overall system to be recertified, if the desktop computer, laptop or peripheral, as a stand-alone unit, complies with all applicable technical standards. Client’s signature : Client’s name / title : Park JiHong / RF Team Leader Contact information / address : PARTRON CO., LTD / 22, Samsung 1-ro 2-gil, Hwaseong-si, Gyeonggi-do, Korea 445-170

FCCID: 2AD5K-CZ3730A Copyright Ⓒ 2015 DT&C Co., Ltd. Page 1 / 2 View 1 FCCID: 2AD5K-CZ3730A Copyright Ⓒ 2015 DT&C Co., Ltd. Page 2 / 2 View 2

FCC ID: 2AD5K-CZ3730A Copyright Ⓒ 2015, DT&C Co., Ltd. FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included on this label.

FCC ID: 2AD5K-CZ3730A Copyright Ⓒ 2015, DT&C Co., Ltd. View 1 FCC ID: 2AD5K-CZ3730A Copyright Ⓒ 2015, DT&C Co., Ltd. View 2 <Ant: WLAN> <Ant: BT, WLAN> <Ant: Zigbee>

FCC ID: RF function or Mode Max Target Power (dBm) ANT Gain (dBi) Maximum EIRP (dBm) Maximum EIRP (mW) Max i mum powe r density (mW/cm 2 ) Requriment (mW/cm 2 ) 802.11b 2412.00 ~ 2462.00 16.00 1.63 17.63 57.943 0.012 1.000 802.11g 2412.00 ~ 2462.00 16.00 1.63 17.63 57.943 0.012 1.000 802.11n(HT20) / Single transmit 2412.00 ~ 2462.00 16.00 1.63 17.63 57.943 0.012 1.000 802.11n(HT40) 2422.00 ~ 2452.00 14.50 1.63 16.13 41.021 0.009 1.000 802.11n(HT20) / Multiple transmit 2412.00 ~ 2462.00 16.50 1.63 18.13 65.013 0.013 1.000 ~~~~ ▪ S = - Note = / ( 4 X 20 2 X π ) = mW/cm 2 Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm 2 ) Averageing time (minutes) 0.3 ~ 1.34 614 1.63 *100 30 1.34 ~ 30 824/f 2.19 / f *180 / f 2 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1,500 f / 1500 30 1,500 ~ 100,000 1.0 30 Conclusion : The exposure condition of this device is compliant with FCC 2AD5K-CZ3730A 57.943 S= Maximum power density(mW/cm 2 ) 0.012 EIRP= Equivalent Isotropic Radiated Power(mW)R= Distance to the center of the radiation of the antenn f = frequency in MHz * = Plane-wave equivalent power density MPE Calculation : Frequency range (MHz) WLAN(2.4GHz) Frequency range (MHz) The EUT will only be used with a separation of 20 centimeters o r greater between the antenna and the body of the user. The MPE sample calculation for this exposure is shown below. EIRP / ( 4 R 2 π ) ▪ Limits for General Population/Uncontrolled Exposure FCC ID: RF function or Mode Max Target Power (dBm) ANT Gain (dBi) Maximum EIRP (dBm) Maximum EIRP (mW) Max i mum powe r density (mW/cm 2 ) Requriment (mW/cm 2 ) 802.11a 5180.00 ~ 5240.00 13.50 1.16 14.66 29.242 0.006 1.000 802.11n(HT20) 5180.00 ~ 5240.00 13.50 1.16 14.66 29.242 0.006 1.000 802.11n(HT40) 5190.00 ~ 5230.00 14.00 1.16 15.16 32.810 0.007 1.000 802.11a 5745.00 ~ 5825.00 15.50 -0.08 15.42 34.834 0.007 1.000 802.11n(HT20) 5745.00 ~ 5825.00 15.50 -0.08 15.42 34.834 0.007 1.000 802.11n(HT40) 5755.00 ~ 5795.00 14.00 -0.08 13.92 24.661 0.005 1.000 ~~~ ▪ S = - Note = / ( 4 X 20 2 X π ) = mW/cm 2 Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm 2 ) Averageing time (minutes) 0.3 ~ 1.34 614 1.63 *100 30 1.34 ~ 30 824/f 2.19 / f *180 / f 2 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1,500 f / 1500 30 1,500 ~ 100,000 1.0 30 Conclusion : The exposure condition of this device is compliant with FCC EIRP / ( 4 R 2 π ) 29.242 S= Maximum power density(mW/cm 2 ) 0.006 EIRP= Equivalent Isotropic Radiated Power(mW)R= Distance to the center of the radiation of the antenn f = frequency in MHz * = Plane-wave equivalent power density ▪ Limits for General Population/Uncontrolled Exposure Frequency range (MHz) 2AD5K-CZ3730A MPE Calculation : WLAN(5GHz) Frequency range (MHz) The EUT will only be used with a separation of 20 centimeters o r greater between the antenna and the body of the user. The MPE sample calculation for this exposure is shown below. FCC ID: RF function or Mode Max Target Power (dBm) ANT Gain (dBi) Maximum EIRP (dBm) Maximum EIRP (mW) Max i mum powe r density (mW/cm 2 ) Requriment (mW/cm 2 ) BT 2402.00 ~ 2480.00 13.00 -1.07 11.93 15.596 0.004 1.000 LE 2402.00 ~ 2480.00 10.00 -1.07 8.93 7.817 0.002 1.000 Zigbee 2405.00 ~ 2480.00 3.00 2.75 5.75 3.759 0.001 1.000 ~~~~~~ ▪ S = - Note = / ( 4 X 20 2 X π ) = mW/cm 2 Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm 2 ) Averageing time (minutes) 0.3 ~ 1.34 614 1.63 *100 30 1.34 ~ 30 824/f 2.19 / f *180 / f 2 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1,500 f / 1500 30 1,500 ~ 100,000 1.0 30 Conclusion : The exposure condition of this device is compliant with FCC EIRP / ( 4 R 2 π ) 15.596 S= Maximum power density(mW/cm 2 ) 0.004 EIRP= Equivalent Isotropic Radiated Power(mW)R= Distance to the center of the radiation of the antenn f = frequency in MHz * = Plane-wave equivalent power density ▪ Limits for General Population/Uncontrolled Exposure Frequency range (MHz) 2AD5K-CZ3730A MPE Calculation : BT, LE, Zigbee Frequency range (MHz) The EUT will only be used with a separation of 20 centimeters o r greater between the antenna and the body of the user. The MPE sample calculation for this exposure is shown below. ▪ ▪ Zigbee WLAN (Single transmit ) Σ of MPE ratios 2405~2480 0.001 1.000 0.001 2402~2480 1.0001.000 0.012 0.012 5180~5240 5190~5230 0.013 0.002 1.000 Configurations for simultaneous operations 2412~2462 2422~2452 0.012 1.000 5745~5825 5755~5795 0.006 1.000 0.002 Power Density (mW/cm2) - Configuration 1: - Configuration 2: - Configuration 3: 2402~24802412~2462 0.013 RF function or mode Frequency range (MHz) MPE ratio (Power Density/Requirement) 0.0060.0070.004 Configuration 2 (MPE ratio) 0.001 Conclusion : Σ of MPE ratios ≤ 1▪ Requirment = Configuration 1 (MPE ratio) 0.0070.004 Note: The maximum power density in each RF function was used for above table. 0.013 Requirement (mW/cm2) 0.004 The exposure condition of this device is compliant with FCC rules. 2AD5K-CZ3730AFCC ID: RF Exposure Compliance for simultaneous operations 0.007 Configuration 3 (MPE ratio) Note: Above configuration was declared from applicant. Configurations for simultaneous operations 0.003 0.005 0.0010.002 Configuration 4 (MPE ratio) 0.001 0.006 Zigbee + WLAN 2.4GHz(Ant 1) Zigbee + WLAN 2.4GHz(Ant 1+2) Zigbee + WLAN 5GHz Zigbee + BT or LE- Configuration 4: WLAN (Multiple transmit ) WLAN (Single transmit ) WLAN (Single transmit ) BTLE 1.000 0.008 0.001 0.0010.007 0.0010.0140.013

FCC ID: 2AD5K-CZ3730A Report No.: DRTFCC1511-0246 TRF-RF-234(01)151127 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 2 / 55 Test Report Version Test Report No. Date Description DRTFCC1511-0246 Nov. 27, 2015 Initial issue FCC ID: 2AD5K-CZ3730A Report No.: DRTFCC1511-0246 TRF-RF-234(01)151127 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 3 / 55 CONTENTS 1. EUT Description ........................................................................ 4 2. Information about test items .................................................... 5 2.1 Test mode / Channel Information ............................................ 5 2.2 Tested Channel Information .................................................... 5 2.3 Auxiliary equipment ................................................................ 5 2.4 Tested environment ................................................................ 5 2.5 EMI Suppression Device(s) / Modifications ............................ 5 3. Summary of Tests ..................................................................... 6 4. Test Methodology ..................................................................... 7 4.1 EUT configuration .................................................................. 7 4.2 EUT exercise .......................................................................... 7 4.3 General test procedures ......................................................... 7 4.4 Description of test modes ....................................................... 7 5. Instrument Calibration .............................................................. 8 6. Facilities and Accreditations ................................................... 8 6.1 Facilities ................................................................................. 8 6.2 Equipment .............................................................................. 8 7. Antenna Requirements ............................................................. 8 8. TEST RESULT ........................................................................... 9 8.1 Emission Bandwidth (26 dB Bandwidth) ................................. 9 8.2 Minimum Emission Bandwidth (6 dB Bandwidth) .................. 15 8.3 Maximum Conducted Output Power ..................................... 21 8.4 Maximum Power Spectral Density ........................................ 24 8.5 Frequency Stability ............................................................... 37 8.6 Radiated Spurious Emission Measurements ........................ 41 8.7 AC Conducted Emissions ..................................................... 47 9. List of Test Equipment ........................................................... 52 APPENDIX I ................................................................................. 53 APPENDIX II ................................................................................ 53 FCC ID: 2AD5K-CZ3730A Report No.: DRTFCC1511-0246 TRF-RF-234(01)151127 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 4 / 55 1. EUT Description FCC Equipment Class Unlicensed National Information Infrastructure (UNII) Product WLAN, Bluetooth and Zigbee Module Model Name CZ3730A Hardware version Rev_0.2 Software version r8.a8.04_32 Power Supply DC 3.3 V Frequency Range U-NII 1 (5150 ~ 5250MHz) ▪ 802.11a / n(HT20): 5180 ~ 5240 MHz ▪ 802.11n(HT40): 5190 ~ 5230 MHz U-NII 3 (5725 ~ 5850MHz) ▪ 802.11a / n(HT20): 5745 ~ 5825 MHz ▪ 802.11n(HT40): 5755 ~ 5795 MHz Max. RF Output Power U-NII 1 ▪ 802.11a: 12.93 dBm ▪ 802.11n(HT20): 12.75 dBm ▪ 802.11n(HT40): 13.05 dBm U-NII 3 ▪ 802.11a: 15.10 dBm ▪ 802.11n(HT20): 14.99 dBm ▪ 802.11n(HT40): 13.70 dBm Modulation type OFDM Antenna Specification Antenna type : Internal Antenna Antenna gain ▪ U-NII 1 : 1.16 dBi ▪ U-NII 3 : -0.08 dBi FCC ID: 2AD5K-CZ3730A Report No.: DRTFCC1511-0246 TRF-RF-234(01)151127 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 5 / 55 2. Information about test items 2.1 Test mode / Channel Information 5GHz Band Mode Data Rate U-NII 1 802.11a 6Mbps 802.11n(HT20) MCS 0 802.11n(HT40) MCS 0 U-NII 3 802.11a 6Mbps 802.11n(HT20) MCS 0 802.11n(HT40) MCS 0 Note 1: The worst case data rate is determined as above test mode according to the power measurements. And all test items were performed at the worst case data rate. 2.2 Tested Channel Information 5GHz Band 802.11a/n(HT20) 802.11n(HT40) Channel Frequency [MHz] Channel Frequency [MHz] U-NII 1 36 5180 38 5190 40 5200 - - 48 5240 46 5230 U-NII 3 149 5745 151 5755 157 5785 - - 165 5825 159 5795 2.3 Auxiliary equipment Equipment Model No. Serial No. Manufacturer Note - - - - - - - - - - 2.4 Tested environment Temperature : 21 o C ~ 22 o C Relative humidity content : 40 % ~ 45 % R.H. Details of power supply : DC 3.3 V 2.5 EMI Suppression Device(s) / Modifications EMI suppression device(s) added and/or modifications made during testing → None FCC ID: 2AD5K-CZ3730A Report No.: DRTFCC1511-0246 TRF-RF-234(01)151127 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 6 / 55 3. Summary of Tests FCC Part Section(s) Parameter Limit Test Condition Status Note 1 I. Transmitter Mode (TX) 15.407(a) Emission Bandwidth (26 dB Bandwidth) N/A Conducted C 15.407(e) Minimum Emission Bandwidth (6 dB Bandwidth) > 500 kHz in 5725 ~ 5850 MHz C 15.407(a) Maximum Conducted Output Power 5150 ~ 5250 MHz : < 30 dBm or < 23.97 dBm 5250 ~ 5350 MHz & 5470 ~ 5725 MHz : 250 mW or < 11 + 10 log 10 (B) dBm, whichever power is less. 5725 ~ 5850 MHz : < 30 dBm C Note 3 15.407(a) Peak Power Spectral Density 5150 ~ 5250 MHz : 11 dBm/MHz or 17 dBm/MHz 5250 ~ 5350 MHz & 5470 ~ 5725 MHz: 11 dBm/MHz 5725 ~ 5850 MHz: 30 dBm/500kHz C Note 4 15.407(g) Frequency Stability N/A C 15.407(b) Undesirable Emissions 5150 ~ 5725 MHz: < -27 dBm/MHz EIRP 5725 ~ 5850 MHz: < -17 dBm/MHz EIRP or < -27 dBm/MHz EIRP Radiated C Note 5 15.205 15.209 15.407(b) Genera…

Text truncated - open the document above for the full version.

FCC ID: 2AD5K-CZ3730A Copyright Ⓒ 2015, DT&C Co., Ltd. Test Setup photographs EUT Position: X-axis EUT Position: Y-axis EUT Position: Z-axis FCC ID: 2AD5K-CZ3730A Copyright Ⓒ 2015, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (0.009 ~ 30MHz) FCC ID: 2AD5K-CZ3730A Copyright Ⓒ 2015, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (below 1000MHz) FCC ID: 2AD5K-CZ3730A Copyright Ⓒ 2015, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (Above 1GHz) FCC ID: 2AD5K-CZ3730A Copyright Ⓒ 2015, DT&C Co., Ltd. Test Setup Photo of AC Conducted Emissions
