2AD5YBTHS3352Bluetooth headset

FCC NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: R eorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC WARNING This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. Modifications not authorized by the manufacturer may void user’s authority to operate this device. 1 December 31, 2019_V1 This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. LOCATION OF CONTROLS 1. LED Display 2. Button 3. Button 4. Volume Control/ Knob 5. USB Type-C Port 6. USB QC3.0 Port 7. Headset 8. Headset Base 9. FM Transmitter 10. Button 11. Indicator 12. Car Cigarette Plug 2 December 31, 2019_V1 9 7 8 11 10 2 6 3 4 5 12 1 OPERATION For listening to music from your BT Device through the unit and your Car Radio, follow the steps below: PAIRING: Step1: Pairing the unit to your Car Radio: 1. Connect the unit to the car cigarette lighter socket as illustrated below: 2. The unit will automatically power on and the LED Display on the Unit will illuminate & blink. The voltage of the car battery will appear on the LED Display at first. 3 December 31, 2019_V1 3. Then a default FM Channel will appear on the unit as illustrated below (For example: 88.1MHz).. 4. The Headset on the Unit will start to charging and the Red Indicator on it will illuminate (When charging is complete, the Red Indicator will turn off). 5. Turn on your Car Radio and enter the radio FM mode as usual. Search for a blank FM channel without any radio signal received (For example: 107.0 MHz). 6. Press and hold the Volume Control/ Knob on the unit until the LED Display on the unit start to blink. Then, press the / Button on the unit repeatedly (or turn around the Volume Control/ Knob on the unit) until the same channel frequency appear on the LED Display as illustrated below (For example: 107.0 MHz): 4 December 31, 2019_V1 Step 2: Pair your BT (Bluetooth) Device to the FM Transmitter on the unit: In first time use or re-pairing the FM Transmitter on the unit to a new BT Device, pairing it as below: 1. Power on and pair the unit to Car Radio as step 1 above. 2. Power on the external BT Device and enter to BT mode. Start pairing the FM Transmitter on the unit following the screen instruction from the external BT Device. Note:  When the external BT Device searches for the FM Transmitter on the unit, the BT Device name “Onn BT/FM” will appear on the BT Device Name List on your external BT Device. Pair your BT Device with it. 3. After the FM Transmitter on the unit paired, you will hear an audible prompt from Car Radio to say “Paired” Step 3: Pair your BT (Bluetooth) Device to the Headset on the unit: In first time use or re-pairing the Headset on the unit to a new BT Device, pairing it as below: 1. Power on and pair the unit to Car Radio as step 1 above. 2. Pair your BT (Bluetooth) Device to the FM Transmitter on the unit as step 2 above. 3. Pick up the Headset from the unit, the Blue & Red LED indicator on the Headset will illuminate and blink. 4. Power on the external BT Device and enter to BT mode. Start pairing the Headset on unit following the screen instruction from the external BT Device. Note:  When the external BT Device searches for the Headset, the BT Device name “Onn BT/Headset” will appear on the BT Device Name List on your external BT Device. Pair your BT Device with it. 5. After the Headset paired, you will hear an audible prompt from headset to say “Connected”, then the Red LED indicator will turn off, and the Blue LED indicator will turn to slow blink. * Above step 2 and 3 can be reversed. 5 December 31, 2019_V1 LISTENING TO MUSIC THROUGH PAIRED BT DEVICE 1. After step 1 & 2 & 3, now you can play the music or answer the incoming call with the paired BT Device as usual. 2. During playback:  Turn the Volume Control/ Knob on the unit to adjust volume level as desire. (Or, use the Volume Controls on the Car Radio or paired BT Device to adjust volume level).  Press the Volume Control / Knob to pause; press again to resume normal playback.  Press the or Buttons repeatedly to skip tracks. 3. If the unit is paired to a Cell Phone and a call is incoming during an active music session:  Pick up the Headset from unit and hang to your ear, then you can answer the call as normal. When your call is complete, press the Button on Headset or put the Headset back to Headset Base directly to disconnect or end the call. Then Press the Volume Control / Knob to resume to music playback.  Or, pick up the Headset from the unit and put it back to the Headset base after 2-3 seconds to decline the incoming call, then resume to music playback.  Quick press the Button twice to redial the last telephone number your cell phone called. 4. To shut off the unit, unplug the unit from car cigarette lighter socket. Notes:  When the external BT Device searches the FM Transm…

Text truncated - open the document above for the full version.

Shenzhen Orderly Electronics Co., Ltd. Agent Authorization Company: Shenzhen Orderly Electronics Co., Ltd. Address: 4F, Building 7, Asian Industry Park, Bantian Street, Longgang District, Shenzhen, China, 518129 Product Name: WIRELESS FM Transmitter with Headset With Bluetooth® Wireless Technology Model Number(s ): 100014268, CBT3353, MBT3353, G52 Product Description: Bluetooth headset We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020/01/13 Name: Flora Huang Title: Manager Company: Shenzhen Orderly Electronics Co., Ltd.

Shenzhen Orderly Electronics Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020/01/13 Subject; Request for Confidentiality FCC ID: 2AD5YBTHS3352 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Flora Huang Title: Manager

Shenzhen Orderly Electronics Co., Ltd. Model Difference 2020-01-13 EUT NAME: WIRELESS FM Transmitter with Headset With Bluetooth® Wireless Technology Product Description: Bluetooth headset FCC ID: 2AD5YBTHS3352 MODEL : 100014268, CBT3353, MBT3353, G52 All the model are the same circuit and RF module, except model names Regards Sincerely Client’s signature Client’s name / title : Flora Huang (Manager) Contact information / address: 4F, Building 7, Asian Industry Park, Bantian Street, Longgang District, Shenzhen, China, 518129

External Photos

Size:10*5mm FCCID:2AD5YBTHS3352 Label location

Internal Photos Antenna

RF EXPOSURE EVALUATION METHOD FCC ID: 2AD5YBTHS3352 SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. BT-EDR max possible output power (PK,conducted)：-3±1dbm 0dBi logarithmic terms convert to numeric result is nearly -2dbm=0.63mW 2402MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]=0.63/5*√2.402=0.20≤3.0 Threshold at which no SAR required is 10mw and ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Modulation Frequency ( MHz ) Output Power (dBm) Max Antenna Gain (dBi) GFSK 2402 -4.18 0 GFSK 2441 -4.17 0 GFSK 2480 -4.38 0 Pi/4 DQPSK 2402 -3.42 0 Pi/4 DQPSK 2441 -3.42 0 Pi/4 DQPSK 2480 -3.60 0 2441MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 0.63/5*√2.441=0.20≤3.0 Threshold at which no SAR required is 10mw and ≤ 3.0 for 1-g SAR, Separation distance is 5mm. 2480MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]=0.63/5*√2.48=0.20≤3.0 Threshold at which no SAR required is 10mw and ≤ 3.0 for 1-g SAR, Separation distance is 5mm. Conclusion: No SAR is required.

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2001000014E FCC Part 15C Test Report FCC ID: 2AD5YBTHS3352 Product Name: WIRELESS FM Transmitter with Headset With Bluetooth® Wireless Technology Trademark: Model Name : 100014268 CBT3353, MBT3353, G52 Prepared For : Shenzhen Orderly Electronics Co., Ltd. Address : 4F, Building 7, Asian Industry Park, Bantian Street, Longgang District, Shenzhen, China, 518129 Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Dec. 31, 2019 – Jan. 08, 2020 Date of Report : Jan. 08, 2020 Report No.: BCTC2001000014E Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 1 of 58 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2001000014E TEST RESULT CERTIFICATION Applicant’s name ............. : Shenzhen Orderly Electronics Co., Ltd. Address .............................. : 4F, Building 7, Asian Industry Park, Bantian Street, Longgang District, Shenzhen, China, 518129 Manufacture's Name ........ : Shenzhen Orderly Electronics Co., Ltd. Address .............................. : 4F, Building 7, Asian Industry Park, Bantian Street, Longgang District, Shenzhen, China, 518129 Product description Product name..................... : WIRELESS FM Transmitter with Headset With Bluetooth® Wireless Technology Trademark ......................... : Model and/or type reference 100014268 CBT3353, MBT3353, G52 Standards ......................... : FCC Part15.247 ANSI C63.10:2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Prepared by(Engineer): Willem Wang Reviewer(Supervisor): Eric Yang Approved(Manager): Zero Zhou Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 2 of 58 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2001000014E Table of Contents Test Report Declaration Page 1. TEST SUMMARY ...................................................... 5 2. TEST FACILITY ....................................................... 6 3. MEASUREMENT UNCERTAINTY........................................ 6 4. GENERAL INFORMATION .............................................. 7 4.1 GENERAL DESCRIPTION OF EUT ...................................... 7 4.2 Test Setup Configuration ................................................ 8 4.3 Support Equipment ..................................................... 8 4.4 Channel List ........................................................... 9 4.5 Test Mode ............................................................ 10 5. TEST FACILITY AND TEST INSTRUMENT USED ........................ 11 5.1 Test Facility ........................................................... 11 5.2 Test Instrument Used .................................................. 11 6. CONDUCTED EMISSIONS ............................................. 13 6.1 Block Diagram Of Test Setup ........................................... 13 6.2 Limit ................................................................. 13 6.3 Test procedure ........................................................ 13 6.4 Test Result ........................................................... 14 7. RADIATED EMISSIONS ............................................... 15 7.1 Block Diagram Of Test Setup ........................................... 15 7.2 Limit ................................................................. 16 7.3 Test procedure ........................................................ 16 7.4 Test Result ........................................................... 18 7.5 RADIATED BAND EMISSION MEASUREMENT AND RESTRICTED BANDS OF OPERATION ........................................................... 22 8. CONDUCTED EMISSION .............................................. 25 8.1 Block Diagram Of Test Setup ........................................... 25 8.2 Limit ................................................................. 25 8.3 Test procedure ........................................................ 25 8.4 Test Result ........................................................... 26 9. 20 DB BANDWIDTH .................................................. 32 9.1 Block Diagram Of Test Setup ........................................... 32 9.2 Limit ................................................................. 32 9.3 Test procedure ........................................................ 32 9.4 Test Result ........................................................... 33 10. MAXIMUM PEAK OUTPUT POWER .................................... 37 10.1 Block Diagram Of Test Setup .......................................... 37 10.2 Limit ................................................................ 37 10.3 Test procedure ....................................................... 37 10.4 Test Result .......................................................... 38 11. HOPPING CHANNEL SEPARATION .................................... 42 11.1 Block Diagram Of Test Setup .......................................... 42 Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 3 of 58 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2001000014E 11.2 Limit ................................................................ 42 11.3 Test procedure ....................................................... 42 11.4 Test Result .......................................................... 43 12. NUMBER OF HOPPING FREQUENCY .................................. 47 12.1 Block Diagram Of Test Setup .............…

Text truncated - open the document above for the full version.

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2001000014E 16. EUT TEST SETUP PHOTOGRAPHS Radiated Measurement Photos Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 57 of 58 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2001000014E ※※※※※ END OF REPORT ※※※※※ Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 58 of 58
