2AD8Y-15693RRemote Controller

REMOTE LAYOUT & INSTRUCTIONS Installing/Replacing the Battery 1. Remove the plastic tab located on the bottom of the remote to activate the battery. 2. To replace the battery - remove the cover from the back of the remote by pushing the tab (A) in and pulling the cover out to release the battery pack (B). 3. Install the new (CR2025) battery. 4. Close the cover – the remote is now be ready for use. FCC Certification This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. Color Changing LED Accent Light Owner’s Manual INSTALLATION INSTRUCTIONS The Aqueon ® Color Changing LED Accent Light is fully submersible. It can be installed in the aquarium using the included suction clips and can also be clipped into Aqueon ® LED Strip Lights and Modular LED Light fixtures. Installation Using the Suction Cups 1. Attach the suction cups to each end of the Accent Light. (Fig. 1) 2. Place the Accent Light in the aquarium, using the suction cups to attach it securely. Adjust the light to the desired angle by rotating the light tube in the suction cups. a. The Accent Light can be placed anywhere in the aquarium – just be sure that the control box is not submersed in the water. (Fig. 1). 3. Connect the transformer to the connector on the Accent Light. 4. Plug the transformer into an acceptable outlet. Be sure to incorporate a “drip loop” to prevent water droplets from running down the cord and into the outlet should any water get onto the cord. 5. Turn the Accent Light on using the remote control. Installation into an Aqueon ® LED Fixture 1. Turn the light fixture off and unplug the transformer from the outlet prior to installing or uninstalling the LED Accent Light. Flip the fixture over onto a clean/non abrasive surface so the underside is accessible. 2. Install the Accent light (without the suction cups) on the fixture by snapping both plastic ends of the LED lamp into the lamp clips inside the fixture housing making sure it is completely installed and held securely by the clips. (Fig. 2) a. To uninstall, unclip the plastic ends of the lamp from the lamp clips inside the fixture and remove. 3. For the Aqueon ® Modular LED Light: Be sure to route the light cord under the cover plates so they can slide back into their original position, covering the ends of the LED lamps. 4. Connect the transformer to the connector on the Accent Light. 5. Plug the transformer into an acceptable outlet. Be sure to incorporate a “drip loop” to prevent water droplets from running down the cord and into the outlet should any water get onto the cord. 6. Turn the Accent Light on using the remote control. Color Changing LED Accent Light Fits >> Aqueon ® Modular LED Fixture Aqueon ® LED Strip Light Size 30 LED Accent Light 15612 21102 Size 36 LED Accent Light 15613 21103 Size 48 LED Accent Light 15614 -

FCC ID Label The FCC ID is marked on the back of Remote controller by Laser etchin g.

Technical description 1. Key: User interface. 2. MCU: Receiving data from key unit and output signal to RF transmitting unit. 3. RF：Receiving signal from MCU and output signal via antenna. 4. The whole unit is powered by 3 AA battery. An integral antenna has been used. 1. Key 2. MCU 3. RF

5 5 4 4 3 3 2 2 1 1 DD CC BB AA 433.92MHZ <Doc><RevCode> <Title> A 11Tuesday, March 17, 2015 Title SizeDocument NumberRev Date:Sheetof VCC C7 0.1UF SW9 SW7 SW12 Q2 8050 C10 0.1UF SW8 Q1 8550 SW11 D1 LED SW16 U2 SDFRF/SOT23-6 CLK SW VDD A2 A0 A1 R1 220R SW15 L1 82NH SW13 SW18 C3 8.2PF SW14 C6 10UF SW17 L2 82NH SW22 R41K SW21 SW19 SW24 C1 100PF SW20 C9 NC C2 4.7PF C8 10UF SW23 R6 4.7R U1 SDFMCU/SOP14 VDD IOB5 IOB4 IOB3IOB2 IOB1 IOB0 VSS IOA3 IOA2 IOA1 IOB6 IOA0 IOB7 SW1 Y213.56MHZ SW2 R2 100K SW3 R3 10K SW4 SW5 C4 33PF SW6 C5 33PF SW10

Report No.: 150129061GZU-001 Issued: 2015-5-11 FCC ID: 2AD8Y-15693R Page 2 of 22 CONTENT TEST REPORT ........................................................................................................................................................... 1 CONTENT ................................................................................................................................................................... 2 1.0 Summary of Test ............................................................................................................................................ 3 2.0 General Description ....................................................................................................................................... 4 2.1 Product Description ........................................................................................................................ 4 2.3 Test Methodology ........................................................................................................................... 5 2.4 Test Facility .................................................................................................................................... 5 3.0 System Test Configuration ............................................................................................................................. 6 3.1 Justification .................................................................................................................................... 6 3.2 EUT Exercising Software ............................................................................................................... 7 3.3 Special Accessories ......................................................................................................................... 7 3.4 Measurement Uncertainty ............................................................................................................... 7 3.5 Equipment Modification ................................................................................................................. 7 3.6 Support Equipment List and Description ........................................................................................ 7 4.0 Measurement Results ..................................................................................................................................... 8 4.1 Antenna Requirement: .................................................................................................................... 8 4.2 Radiated Emissions......................................................................................................................... 9 4.3 Occupied Bandwidth .................................................................................................................... 17 4.4 Dwell Time: .................................................................................................................................. 19 4.5 Conducted Emission Test ............................................................................................................. 21 5.0 Test Equipment List ..................................................................................................................................... 22 Report No.: 150129061GZU-001 Issued: 2015-5-11 FCC ID: 2AD8Y-15693R Page 3 of 22 1.0 Summary of Test TEST TEST REQUIREMENT TEST METHOD RESULT Radiated Emission FCC PART 15 section 15.231(b) ANSI C 63.10: Clause 6.4, 6.5 and 6.6 PASS Occupied Bandwidth FCC PART 15 section 15.231(c) ANSI C 63.10: Clause 6.9 PASS Dwell Time FCC PART 15 section 15.231(a) FCC PART 15: Section 15.231(a) PASS Remark: N/A: not applicable. Refer to the relative section for the details. EUT: In this whole report EUT means Equipment Under Test. Tx: In this whole report Tx (or tx) means Transmitter. Rx: In this whole report Rx (or rx) means Receiver. RF: In this whole report RF means Radio Frequency. ANSI C63.10: the detail version is ANSI C63.10:2009 in the whole report. Report No.: 150129061GZU-001 Issued: 2015-5-11 FCC ID: 2AD8Y-15693R Page 4 of 22 2.0 General Description 2.1 Product Description Operating Frequency 433.92 MHz Type of Modulation: ASK modulated by internal signal Antenna Type Integral Antenna gain: 0 dBi Function: Wireless control with 433.92 MHz as carrier. Power Supply: DC 3 V for remote controller Power cord: Power by battery Report No.: 150129061GZU-001 Issued: 2015-5-11 FCC ID: 2AD8Y-15693R Page 5 of 22 2.3 Test Methodology For radiated emission measurement, preliminary scans and final tests were performed in the semi-anechoic chamber to determine the worst case modes. All radiated tests were performed at an antenna to EUT distance of 3 meters, unless stated otherwise. 2.4 Test Facility All of the tests are performed at: Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Block E, No.7-2 Guang Dong Software Science Park, Caipin Road, Guangzhou Science City, GETDD Guangzhou, China. This test facility and site measurement data have been fully placed on file with the FCC, test firm registration number is 549654. Report No.: 150129061GZU-001 Issued: 2015-5-11 FCC ID: 2AD8Y-15693R Page 6 of 22 3.0 System Test Configuration 3.1 Justification For emissions testing, the equipment under test (EUT) setup to transmit continuously to simplify the measurement methodology. Care was taken to ensure proper power supply voltages during testing. During testing, it was powered by DC 3V supply. The signal is maximized through rotation and placement in the three orthogonal axes. The antenna height and polarization are varied during the search for maximum signal level. The antenna height is varied from 1 to 4 meters. Radiated emissions are taken at three meters unless the signal level is too low for measurement at that distance. If necessary, a pre-amplifier is used and/or the test is conducted at a closer distance. All readings are extrapolated back to the equivalent three meter reading using inverse sc…
