2AD8Y-15720Wireless Remote Controller

OptiBright TM + LED Light Owner’s Manual FIXTURE INSTALLATION INSTRUCTIONS 4. The light fixture will turn on to a standard setting and you can now program the fixture to your preferred settings using the included remote. (Initial standard setting is set to white LED, Blue LED and Purple RGB) REMOTE LAYOUT REMOTE INSTRUCTIONS Installing the Batteries 1. Remove the cover from the back of the remote. 2. Install 2 (AAA) batteries (included). 3. Close the cover – the remote is now be ready for use. Setting the Time 1. Press and hold for 3 seconds until you see the hour blinking 2. Use theand buttons to set the hour – ‘AM/PM’ will be displayed on the screen. 3. Press . The minutes will be blinking. Use theand buttons to set the minute. 4. Press . The time will be set. Programming Desired Color Options Set the fixture to the desired color combination by following the steps below: 1. Setting the White LEDs a. Press to turn the White LEDs on – ‘W’ will be displayed on the screen. b. Use theand buttons to adjust the color intensity of the White LEDs only. c. Press to turn the White LEDs off. 2. Setting the Blue LEDs a. Press to turn the Blue LEDs on – ‘B’ will be displayed on the screen. b. Use theand buttons to adjust the color intensity of the Blue LEDs only. c. Press to turn the Blue LEDs off. 3. Setting the RGB Color Option a. Press one of the 8 preset color options to turn the RGBs on – ‘RGB’ will be displayed on the screen. b. Use theand buttons to adjust the color intensity of the RGBs only. c. Press to turn the RGBs off. Note: To program different color intensities for each of the White, Blue and RGB’s – each specific color must be on by itself. If all three colors (or two) are on at the same time the intensity will be adjusted for all 3 colors to the same intensity. Ex: If you see ‘W’ on the screen and you use theand buttons, the color intensity will be set for only the White LEDs. If you see ‘W’ and ‘B’ on the screen at the same time and you use the and buttons, the color intensity will be set for the same amount for both the White AND Blue LEDs. 4. You are now ready to program the timer to your desired settings. Make sure your desired colors are in the ‘ON’ setting before you start programming. ‘W’, ‘B’ and ‘RGB’ should be displayed on the screen. Programming the Timer 1. Press and hold for 3 seconds until you see the hour blinking. 2. Press twice – you will see ‘W’ and ‘ON’ on the screen to set the White LEDs ON. 3. Use theand buttons to set the hour – ‘AM/PM’ will be displayed on the screen. 4. Press . The minutes will be blinking. Use theand buttons to set the minute. 5. Press – you will see ‘W’ and ‘OFF’ on the screen to set the White LEDs OFF. Repeat steps 3-4. 6. Press – you will see ‘B’ and ‘ON’ on the screen to set the Blue LEDs ON. Repeat steps 3 & 4. 7. Press – you will see ‘B’ and ‘OFF’ on the screen to set the Blue LEDs OFF. Repeat steps 3 & 4. 8. Press – you will see ‘RGB’ and ‘ON’ on the screen to set the RGBs ON. Repeat steps 3 & 4. 9. Press – you will see ‘RGB’ and ‘OFF’ on the screen to set the RGBs OFF. Repeat steps 3 & 4. 10. Press – your fixture is now programmed to your custom settings.  Note: If you don't want to set the LEDs to turn on/off you leave them both at 12:00AM. RGB Scroll Mode 1. Press to scroll through the different color options at different speeds. a. 25 – Color will change every 5 seconds. b. 50 – Color will change every 4 seconds. c. 75 – Color will change every 3 seconds. d. 100 – Color will stop scrolling and be set to the color you selected. FCC Certification This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help.

Central Aquatics (a division of Central Garden and Pet Company) FCC ID: 2AD8Y-15720 POWER OF ATTORNEY Date: July 02,2015 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Waltek Services (ShenZhen) Co., Ltd. (Philo Zhong) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Waltek Services (ShenZhen) Co., Ltd. (Philo Zhong) on our behalf shall have the same effect as acts of our own. This authorization expires on July 01,2016. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, Central Aquatics (a division of Central Garden and Pet Company)are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti- Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, Central Aquatics (a division of Central Garden and Pet Company) ................................................................................. Signature Andrew Hudson / Product Designer ................................................................................. Typed name and Title

The Label Sample for Model：15720 Model: 15720 FCC ID: 2AD8Y‐15720

The Label Sample for Model：15720 Model: 15720 FCC ID: 2AD8Y‐15720

Reference No.: WTF15S0527332E Page 20 of 22 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn 11.2 Model 15720- Internal View Reference No.: WTF15S0527332E Page 21 of 22 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn ANT Reference No.: WTF15S0527332E Page 22 of 22 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn RF module RF module ======End of Report======

Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn Page 1 of 22 TEST REPORT Reference No. .................... : WTF15S0527332E FCC ID ................................ : 2AD8Y-15720 Applicant ............................ : Central Aquatics (a division of Central Garden and Pet Company) Address .............................. : 5401 West Oakwood Park Dr. Manufacturer .................... : The same as above Address .............................. : The same as above Product Name .................... : Wireless Remote Controller Model No. ........................... : 15720 Standards........................... : FCC CFR47 Part 15 Section 15.231: 2014 Date of Receipt sample .... : May.27, 2015 Date of Test........................ : May.27 – Jun. 04, 2015 Date of Issue ...................... : Jun. 05, 2015 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Services (Shenzhen) Co., Ltd. Address: 1/F., Fukangtai Building, West Baima Road, Songgang Street, Baoan District, Shenzhen, Guangdong, China Tel :+86-755-83551033 Fax:+86-755-83552400 Compiled by: Approved by: Zero Zhou / Project Engineer Philo Zhong / Manager Reference No.: WTF15S0527332E Page 2 of 22 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn Page 2 of 22 2 Test Summary Test Items Test Requirement Result Conducted Emissions 15.207 PASS Radiated Spurious Emissions 15.205(a) 15.209 15.231(a) PASS Periodic Operation 15.231(a) PASS 20dB Bandwidth 15.231(c) PASS Antenna Requirement 15.203 PASS Reference No.: WTF15S0527332E Page 3 of 22 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn 3 Contents Page 1 COVER PAGE ...................................................................................................................................... 1 2 TEST SUMMARY ............................................................................................................................................. 2 3 CONTENTS ....................................................................................................................................................... 3 4 GENERAL INFORMATION ............................................................................................................................. 4 4.1 GENERAL DESCRIPTION OF E.U.T. ....................................................................................................... 4 4.2 DETAILS OF E.U.T. ................................................................................................................................ 4 4.3 TEST FACILITY ....................................................................................................................................... 4 5 EQUIPMENT USED DURING TEST ............................................................................................................. 5 5.1 EQUIPMENTS LIST ................................................................................................................................. 5 5.2 MEASUREMENT UNCERTAINTY .............................................................................................................. 5 5.3 TEST EQUIPMENT CALIBRATION ........................................................................................................... 5 6 RADIATED SPURIOUS EMISSIONS ............................................................................................................ 6 6.1 EUT OPERATION ................................................................................................................................... 6 6.2 TEST SETUP .......................................................................................................................................... 7 6.3 SPECTRUM ANALYZER SETUP .............................................................................................................. 8 6.4 TEST PROCEDURE ................................................................................................................................. 9 6.5 SUMMARY OF TEST RESULTS ............................................................................................................. 10 7 PERIODIC OPERATION ............................................................................................................................... 11 8 20DB BANDWIDTH ....................................................................................................................................... 13 8.1 TEST PROCEDURE ............................................................................................................................... 13 8.2 TEST RESULT ...................................................................................................................................... 13 9 ANTENNA REQUIREMENT ......................................................................................................................... 14 10 MODEL 15720 PHOTOGRAPHS OF TESTING ........................................................................................ 15 10.1 RADIATION EMISSION TEST SETUP ..................................................................................................... 15 11 PHOTOGRAPHS - CONSTRUCTIONAL DETAILS ................................................................................. 17 11.1 MODEL 15720- APPEARANCE VIEW ................................................................................................... 17 11.2 MODEL 15720- INTERNAL VIEW ......................................................................................................... 20 Reference No.: WTF15S0527332E Page 4 of 22 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn 4 Genera…

Text truncated - open the document above for the full version.

Reference No.: WTF15S0527332E Page 15 of 22 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn 10 Model 15720 Photographs of Testing 10.1 Radiation Emission Test Setup Below 30MHz From 30MHz to 1GHz Reference No.: WTF15S0527332E Page 16 of 22 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn Above 1GHz
