Contents 1. Charging the battery 2. Audio player 3. Lock and unlock the keypad 4. Change to meeting profile 5.Camera 6.FM radio 7.How to control volume 8.Restore factory setting 1. Charging the battery: Unplug the charger from the outlet and the phone when not in use. Do not leave a fully-charged handset connected to a charger because overcharging may shorten the lifetime of the battery. If unused, a fully-charged battery will lose its charge over time. If the battery is completely discharged, the charging may not start immediately when you plug in the connector. Wait 10 to 15 minutes for the phone to begin charging. Use the battery only for its intended purpose. Never use any charger or battery that is damaged. Use only Entel Charger & Battery. Note: The actual operation time of a battery varies based on the operation mode, network strength in different places and talk time. 2. Audio player: The songs you store in the memory card will appear in the audio player. Please check if you have stored the songs in “My Music” folder. You should also check whether default storage is memory card. 3. Lock and unlock the keypad: Press * then“left soft key”to lock the keypad. Press“left soft key” then * to unlock the keypad. 4. Change to meeting profile in idle: Long press # to change the profile into meeting mode and long press # again to change the profile into normal mode. 5. Camera: Press the OK key to take photos and the photos will be stored in the phone. Press the left navigation key to Video recorder and press the right navigation key to camera again. 6. FM radio: Radio FM Press the OK key to open/close the FM radio. Press the up and down navigation key to move forword/backword 0.1MHz. Press the left and right navigation key to switch channel accroding to the channel list. . It will be exit FM radio interface when pressing the right soft key or the red key.And the FM will be run in the background. 7. How to control volume: When you call any number you can control your volume, press the up&down navigation key to adjust call volume. You can control the volume by pressing the * and # when you listening to the music ,FM radio or watching the videos. 8. Restore factory settings: Reset the phone to default values (factory settings). The phone password is required, which is "0000" by default La contraseña del teléfono se re quiere, que es "0000" por defecto. FCC Caution. § 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. § 15.21 Information to user. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. § 15.105 Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Body-worn Operation This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance of 1.5 cm must be maintained between the user’s body and the handset, including the antenna. Third-party belt-clips, holsters, and similar accessories used by this device should not contain any metallic components. Body-worn accessories that do not meet these requirements may not comply with RF exposure requirements and should be avoided. Use only the supplied or an approved antenna.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Mobiwire Mobile(NingBo) Co.,Ltd 2016-1-14 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Mobiwire Mobile(NingBo) Co.,Ltd hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product description : 3G feature phone model name: FCC ID: 2ADA4F1035 Sincerely, Client’s signature Client’s name / title : Xu Leander / Manager Contact information / : No.999 Dacheng East Road, Fenghua, Zhejiang, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template& Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (current) 4.0 5.0 Nov 19 2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 5.0 Mobiwire Mobile(NingBo) Co.,Ltd 2016-1-14 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ADA4F1035 Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - Block Diagram - Schematics - .Operational Description - Tune up Procedure - Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Xu Leander / Manager Contact information / : No.999 Dacheng East Road, Fenghua, Zhejiang, China

Date: 2016‐1‐14 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2ADA4F1035 To Whom It May Concern: This letter is to ascertain that Mobiwire Mobile(NingBo) Co., Ltd Product 3G feature phone has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab：Siemic Inc address：775 Montague Expressway，Milpitas California 95035， United States If you have any question or concerns, pls. contact us. Sincerely, Client’s signature: Client’s name / title : Xu Leander / Manager Contact information / : No.999 Dacheng East Road, Fenghua, Zhejiang, China

Test Report 15071290-FCC-E Page 21 of 30 Annex B. EUT And Test Setup Photographs Annex B.i. Photograph: EUT External Photo Whole Package View Adapter - Front View EUT - Front View EUT - Rear View Test Report 15071290-FCC-E Page 22 of 30 EUT - Top View EUT - Bottom View EUT - Left View EUT - Right View

MODELO: F1035 S/N:201512000001 FCC ID2ADA4F1035 IMEI NO. :000000000000001 IMEI NO.:000000000000001 handset label

Label location

Test Report 15071290-FCC-E Page 23 of 30 Annex B.ii. Photograph: EUT Internal Photo Cover Off - Top View 1 Cover Off - Top View 2 Battery - Front View Battery - Rear View Mainbard with Shielding - Front ViewMainbard without Shielding - Front View Test Report 15071290-FCC-E Page 24 of 30 Mainbard – Rear View LCD – Front View LCD – Rear View GSM/PCS/UMTS-FDD Antenna View BT - Antenna View

SAR TEST REPORT Report No.: 15071290-FCC-H Supersede Report No.:N/A Applicant MOBIWIRE MOBILES (NINGBO) CO.,LTD Product Name 3G feature phone Model No. F1035 Standards FCC 47 CFR Part2(2.1093) ANSI/IEEE C95.1-1999 IEEE 1528-2013 & Published RF Exposure KDB Procedures Test Date December 30, 2015 to December 31, 2015 Issue Date January 20, 2016 Test Result PASS Equipment complied with the specification Equipment did not comply with the specification Wiky Jam Test Engineer David Huang Checked By This test report may be reproduced in full only Test result presented in this test report is applicable to the tested sample only Issued by: SIEMIC (SHENZHEN-CHINA) LABORATORIES Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’an District, Shenzhen, Guangdong China 518108 Phone: +86 0755 2601 4629801 Email: [email protected] Test Report 15071290-FCC-H Page 2 of 85 Laboratory Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management throughout a project. Our extensive experience with China, Asia Pacific, North America, European, and International compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Scope USA EMC, RF/Wireless, SAR, Telecom Canada EMC, RF/Wireless, SAR, Telecom Taiwan EMC, RF, Telecom, SAR, Safety Hong Kong RF/Wireless, SAR, Telecom Australia EMC, RF, Telecom, SAR, Safety Korea EMI, EMS, RF, SAR, Telecom, Safety Japan EMI, RF/Wireless, SAR, Telecom Singapore EMC, RF, SAR, Telecom Europe EMC, RF, SAR, Telecom, Safety Test Report 15071290-FCC-H Page 3 of 85 This page has been left blank intentionally. Test Report 15071290-FCC-H Page 4 of 85 CONTENTS 1 EUT INFORMATION ...................................................................................................................................................... 5 2 TECHNICAL DETAILS .................................................................................................................................................. 6 3 INTRODUCTION ........................................................................................................................................................... 7 4 SAR MEASUREMENT SETUP ....................................................................................................................................... 8 5 ANSI/IEEE C95.1 – 1999 RF EXPOSURE LIMIT ............................................................................................................ 19 6 SYSTEM AND LIQUID VERIFICATION ......................................................................................................................... 20 7 UNCERTAINTY ASSESSMENT ................................................................................................................................... 28 8 TEST INSTRUMENT ................................................................................................................................................... 31 9 OUTPUT POWER VERIFICATION ............................................................................................................................... 32 10 EXPOSURE CONDITIONS CONSIDERATION .............................................................................................................. 37 11 SAR TEST RESULTS .................................................................................................................................................. 38 12 SAR MEASUREMENT REFERENCES.......................................................................................................................... 42 ANNEX A CALIBRATION REPORTS .................................................................................................................................. 49 ANNEX B SAR SYSTEM PHOTOGRAPHS .......................................................................................................................... 82 ANNEX C SETUP PHOTOGRAPHS .................................................................................................................................... 83 Test Report 15071290-FCC-H Page 5 of 85 1 EUT INFORMATION EUT Information EUT Description 3G feature phone Model No F1035 Input Power Li-ion Battery Model: L6 Charging Voltage: 3.7V,800mAh,2.96Wh Limited charger voltage:4.2V Maximum Conducted Output Power to Antenna GSM 850 Voice : 33.16dBm PCS 1900 Voice :30.57 dBm WCDMA Band II(Class 3): 22.17dBm Highest Reported SAR Level(s) 1.27W/Kg 1g Head Tissue 1.08W/Kg 1g Body Tissue Classification Per Stipulated Test Standard Portable Device, Class B, No DTM Mode Multi-SIM N/A Co-located TX WWAN can transmit simultaneously with Bluetooth Antenna Separation distances 1.8cm - WWAN antenna-to-WIFI/Bluetooth antenna Antenna Type(s) PIFA Antenna(WWAN) Accessory N/A Equipment Class Highest Reported SAR ( W/kg) Head Body-Worn WWAN/PCE 1.27 1.08 Max Simultaneous sum SAR 1.53 Test Report 15071290-FCC-H Page 6 of 85 2 TECHNICAL DETAILS Purpose Compliance testing of 3G feature phone model OWNF1035 with stipulated standard Applicant / Client MOBIWIRE MOBILES (NINGBO) CO.,LTD No.999,Dacheng East Road,Fenghua City,Zhejiang Manufacturer MOBIWIRE MOBILES (NINGBO) CO.,LTD No.999,Dacheng East Road,Fenghua City,Zhejiang Laboratory performing the tests SIEMIC(Shenzhen-China) Laboratories Zone A, Floor 1, Building 2, Wan Ye Long Technology Park, South Side of Zhoushi Road, Bao'an District, Shenzhen 518108, Guangdong, P.R.C. Tel: +(86) 0755-26014629 VIP Line:950-4038-0435 Test report reference number 15071290-FCC-H Date EUT received December 29th , 2…
