SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Mobiwire Mobiles (Ningbo) Co., Ltd 2014/11/17 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _____ Mobiwire Mobiles (Ningbo) Co., Ltd _____hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product description,: PCD QBar 3G FCC ID:2ADA4PCDQBAR3G Model: QBar 3G We affirm that between SIEMIC, Inc. and ____ Mobiwire Mobiles (Ningbo) Co., Ltd ___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities Sincerely, Client’s signature : Client’s name / title : Xu Leander / Manager Contact information / address NO.999, DACHENG EAST ROAD, FENGHUA CITY, ZHEJIANG, 315500 CHINA

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Mobiwire Mobiles (Ningbo) Co., Ltd 2014/11/17 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ADA4PCDQBAR3G We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - Tune up Procedure - BOM The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Xu Leander / Manager Contact information / address: NO.999, DACHENG EAST ROAD, FENGHUA CITY, ZHEJIANG, 315500 CHINA

Test Report 14070578-FCC-E1 Page 17 of 26 Annex B. EUT And Test Setup Photographs Annex B.i. Photograph: EUT External Photo Whole Package - Top View Adapter - Front View EUT - Front View EUT - Rear View Test Report 14070578-FCC-E1 Page 18 of 26 EUT - Top View EUT - Bottom View EUT - Left View EUT - Right View

33.6mm 52.8mm Modelo:PCD QBar 3G FCC ID: 2ADA4PCDQBAR3G 17mm 863215000000001 Made in China

label location

Test Report 14070578-FCC-E1 Page 19 of 26 Annex B.ii. Photograph: EUT Internal Photo Cover Off - Top View 1 Cover Off - Top View 2 Battery - Top View Battery - Bottom View LCD - Front View LCD - Rear View Test Report 14070578-FCC-E1 Page 20 of 26 Mainborad With Shielding - Front View Mainborad Without Shielding - Front View BT Antenna View GSM/PCS/UMTS-FDD Antenna View

RF EXPOSURE REPORT Report No.: 14070578FCC-H2 Supersede Report No.: N/A Applicant Mobiwire Mobiles (Ningbo) Co., Ltd Product Name PCD QBar 3G Model No. QBar 3G Test Standard FCC 2.1093 Test Date November 06, 2014 Issue Date November 13, 2014 Test Result Pass Fail Equipment complied with the specification Equipment did not comply with the specification David Huang Test Engineer Alex Liu Checked By This test report may be reproduced in full only Test result presented in this test report is applicable to the tested sample only Issued by: SIEMIC (SHENZHEN-CHINA) LABORATORIES Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’an District, Shenzhen, Guangdong China 518108 Phone: +86 0755 2601 4629801 Email: [email protected] Test Report 14070578FCC-H2 Page 2 of 9 Laboratories Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management throughout a project. Our extensive experience with China, Asia Pacific, North America, European, and International compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Scope USA EMC, RF/Wireless, SAR, Telecom Canada EMC, RF/Wireless, SAR, Telecom Taiwan EMC, RF, Telecom, SAR, Safety Hong Kong RF/Wireless, SAR, Telecom Australia EMC, RF, Telecom, SAR, Safety Korea EMI, EMS, RF, SAR, Telecom, Safety Japan EMI, RF/Wireless, SAR, Telecom Singapore EMC, RF, SAR, Telecom Europe EMC, RF, SAR, Telecom, Safety Test Report 14070578FCC-H2 Page 3 of 9 This page has been left blank intentionally. Test Report 14070578FCC-H2 Page 4 of 9 CONTENTS 1. REPORT REVISION HISTORY ............................................................................................................................ 5 2. CUSTOMER INFORMATION ................................................................................................................................ 5 3. TEST SITE INFORMATION ................................................................................................................................... 5 4. EQUIPMENT UNDER TEST (EUT) INFORMATION ......................................................................................... 6 5. FCC §2.1093 - MAXIMUM PERMISSIBLE EXPOSURE ................................................................................... 8 5.1 RF EXPOSURE .......................................................................................................................................................... 8 5.2 TEST RESULT ........................................................................................................................................................... 9 Test Report 14070578FCC-H2 Page 5 of 9 1. Report Revision History Report No. Report Version Description Issue Date 14070578FCC-H2 NONE Original November 13, 2014 2. Customer information Applicant Name Mobiwire Mobiles (Ningbo) Co., Ltd Applicant Add NO.999, DACHENG EAST ROAD, FENGHUA CITY, ZHEJIANG, 315500 CHINA Manufacturer Mobiwire Mobiles (Ningbo) Co., Ltd Manufacturer Add NO.999, DACHENG EAST ROAD, FENGHUA CITY, ZHEJIANG, 315500 CHINA 3. Test site information Lab performing tests SIEMIC (Shenzhen-China) LABORATORIES Lab Address Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’an District, Shenzhen, Guangdong China 518108 FCC Test Site No. 718246 IC Test Site No. 4842E-1 Test Software Labview of SIEMIC version 2.0 Test Report 14070578FCC-H2 Page 6 of 9 4. Equipment under Test (EUT) Information Description of EUT: PCD QBar 3G Main Model: QBar 3G Serial Model: N/A Date EUT received: October 23, 2014 Test Date(s): November 06, 2014 Antenna Gain: UMTS-FDD Band V/GSM850: -1 dBi UMTS-FDD Band II /PCS1900: 0.2 dBi Bluetooth: -2 dBi Type of Modulation: GSM/GPRS: GMSK EGPRS: GMSK UMTS-FDD: QPSK Bluetooth: GFSK, π /4DQPSK, 8DPSK RF Operating Frequency (ies): GSM850 TX: 824.2 ~ 848.8 MHz; RX: 869.2 ~ 893.8 MHz PCS1900 TX: 1850.2 ~ 1909.8 MHz; RX: 1930.2 ~ 1989.8 MHz UMTS-FDD Band V TX: 826.4 ~ 846.6 MHz; RX: 871.4 ~ 891.6 MHz UMTS-FDD Band II TX:1852.4 ~ 1907.6 MHz; RX: 1932.4 ~ 1987.6 MHz Bluetooth: 2402-2480 MHz Number of Channels: GSM 850: 124CH PCS1900: 299CH Bluetooth: 79CH Port: Power Port, Earphone Port, USB Port Test Report 14070578FCC-H2 Page 7 of 9 Input Power: Battery: Model: BL-5C Spec: 3.7V 1000mAh Limited charger voltage: 4.2V Adapter: Model: PCD QBar 3G Input: AC 100-300V; 50/60Hz 0.12A Output: DC 5.0V; 550mA Trade Name : PCD GPRS/EGPRS Multi-slot class 8/10/12 FCC ID: 2ADA4PCDQBAR3G Test Report 14070578FCC-H2 Page 8 of 9 5. FCC §2.1093 - Maximum Permissible exposure 5.1 RF Exposure Standard Requirement: According to §15.247 (i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’ s guidelines. Routine SAR evaluation refers to that specifically required by § 2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to qualify for TCB approval. Test Report 14070578FCC-H2 Page 9 of 9 5.2 Test Result All The Minimum Test Distance is 5 mm Bluetooth Mode: Modulation CH Freq (MHz) Conducted Power (dBm) Tune Up Power (dBm) Tune Up Max Power (dBm) Result Limit GFSK Low 2402 -3.258 -2.8±1 -1.8 0.20 3 Mid 2441 -3.654 -3.6±1 -2.6 0.17 3 High 2480 -4.931 -4.9±1 -3.9 0.13 3 π /4 DQPSK Low 2402 -2.880 -2.8±1 -1.8 0.20 3 Mid 2441 -4.329 -3.6±1 -2.6 0.17 3 High 2480 -5.2…
