2ADAP-CS532KAir Conditioner

Split Air Conditioner . Thank you for choosing our product. If you have lost the Owner’s Manual, please contact the local agent or visit www.gree.com or sent email to [email protected] for electronic version. For proper operation, please read and keep this manual carefully. GWH09UC-D3DNA4A/I Models: GWH12UC-D3DNA4A/I GWH18UC-D3DNA4A/I GWH09UC-D3DNA4C/I GWH12UC-D3DNA4C/I GWH18UC-D3DNA4C/I Matching instructions Specialties note Matching of remote controller Please do the following operation within 2m from the unit. Matching is not needed anymore once it is done. During matching, please keep the remote controller and air conditioner under standby status. When the signal of remote controller can’t be received, please match the remote controller with the unit again. This model adopts RF remote control. The remote controller shall be matched with the air conditioner before operation, otherwise the remote control will be invalid. Before operation, please read the instructions in this page carefully and then do the corresponding matching operation. Note When the unit is under standby status, please get close to the air conditioner within 2m and then hold on pressing button for 3s. The remote controller and air conditioner will enter matching automatically. If matching is done, the unit will give out three sounds; if matching is failed, please get closer to the unit and arrange matching again. Humidify/Health Content Operation Notices Precautions............................................................................................................1 Parts name ........................................................................................................... 9 Screen Operation Guide Buttons on remote controller ................................................................................10 Introduction for buttons on remote controller ...................................................... 11 Function introduction for combination buttons ......................................................17 Operation guide ....................................................................................................18 Replacement of batteries in remote controller ......................................................18 Emergency operation ...........................................................................................27 Operation of Smart Control (Smart Phone, Tablet PC) ....................................... 19 Maintenance Clean and maintenance....................................................................................... 27 Malfunction Malfunction analysis ............................................................................................ 30 Installation Notice Installation dimension diagram ............................................................................ 34 Tools for installation ............................................................................................. 35 Selection of installation location .......................................................................... 35 Requirements for electric connection .................................................................. 36 Installation Installation of indoor unit...................................................................................... 37 Vacuum pumping ................................................................................................. 42 Leakage detection ............................................................................................... 42 Check after installation ........................................................................................ 43 Test and operation Test operation ...................................................................................................... 43 Attachment ......................................................................... 44 Pipe expanding method Configuration of connection pipe ....................................................................................... 46 Introduction for icons on display screen ...............................................................10 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. Explanation of Symbols Indicates a hazardous situation that, if not avoided, will result in death or serious injury. Indicates a hazardous situation that, if not avoided, could result in death or serious injury. Indicates a hazardous situation that, if not avoided, may result in minor or moderate injury. Indicates important but not hazard-related information, used to indicate risk of property damage. Indicates a hazard that would be assigned a signal word WARNING or CAUTION. Precautions WARNING Do not connect air conditioner to multi-purpose socket. This appliance can be used by children aged from 8 Operation and Maintenance If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. Do not spray water on indoor unit. It may cause electric shock or malfunction. Otherwise, it may cause fire hazard. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Do not wash the air conditioner with water to avoid electric shock. Aft…

Text truncated - open the document above for the full version.

Operation of Smart Control (Smart Phone, Tablet PC) 9. Enter into the software interface again. Meanwhile, the short-distance remote control setting for your air conditioner is finished. 22 How to reset the AC WiFi module: Kindly remind: 1. The air conditioner WiFi function needs about 1 minute to start up. 2. The air conditioner has memory function. 3. Those models have no long-distance control. Turn unit off with the remote controller and disconnect the power of AC. Then re-connect the power. 1 minute later, press “WiFi” and “Mode” buttons simultaneously. If the AC gives out a beep sound, it means the WiFi module is successfully reset. Attention: Operation of the buttons is only effective in 2 minutes. Analysis on Common Network Setting Failure: 1. If short-distance control fails, please check the following items one by one! ·Make sure AC is power connected; ·Make sure AC’s WiFi function is turned on as normal; ·Make sure your phone’s WiFi selects the corresponding AC; ·Reset with the remote controller and then start setting again from step 3. 23 Operation of Smart Control (Smart Phone, Tablet PC) 1. Mode: It used for setting operation mode for air conditioner. You can select “Auto”, “Cooling”, “Drying”, “Fan” or “Heating” according to your requirement. Please refer to the part of remote controller for the detailed operation. 3. Fan Speed: It used for setting fan speed. Under cooling or heating mode, if the noise-customized function is turned on, adjust the fan speed and then the noise- -customized function will be turned off automatically. Please refer to the part of remote controller for detailed operation. 2. Temperature: It used for setting temperature. Set the indoor temperature according to your requirement. Function Introduction on Main Interface 24 Operation of Smart Control (Smart Phone, Tablet PC) 1. Preset: It’s with Timer On and Timer Off function. User can set Timer On and Timer Off according to actual individual requirement. 2.Functions: After entering setting interface, you can turn on or turn off Light, Purify, X-fan and Turbo functions and set Silent, Humidify, Air exchange and other modes. Please refer to the part of remote controller for the function instruction. Among that, Purify, Humidify, Air exchange functions can be set through equipping with special air purifier, humidifier. E-heater is not available for this unit. Key Functions Instruction of Application Software 3. Swing: During up&down swing and left&right swing, it’s the fixed angle swing when those two sliding blocks are combined together and full swing when they are separated. When setting up&down swing, the program will turn off regional swing function. However, no influence for regional swing when setting left&right swing. 25 Operation of Smart Control (Smart Phone, Tablet PC) 4. Advanced: After entering advanced interface, you can set Sleep curve, Regional Swing, Noise and Power saving. Regional Swing: After entering Regional Swing, user can set it according to the room size. Press “Air flow position” button and the user can adjust the fan-blowing area through moving the icon of air conditioner left and right according to the actual installation position of the unit. User can move the person icon among nine pane areas according to requirement to adjust the fan-blow area. The Regional Swing function can be turned off through up&down swing. The up&down swing in the Regional Swing is only valid under cooling and heating modes. The left&right swing area has relationship with the position of air conditioner set by mobile phone. The left&right swing position may be asymmetry, which is the normal phenomenon. “Avoid people” function can be turned on or turned off according to user’s personal experience. There may be deviation because of the installation position of air conditioner and the setting of parameters, which is the normal phenomenon. Sleep curve: Sleep curve includes DIY mode, Traditional mode, Expert mode and Siesta mode. Under DIY mode, you can set temperature and time. Under auto mode and fan mode, sleep curve function can’t be turned on. Only Traditional mode can be selected under dry mode. 26 Operation of Smart Control (Smart Phone, Tablet PC) Power saving: After energy saving navigation mode is turned on, the air conditioner will detect indoor temperature and outdoor temperature automatically. Meanwhile, the air conditioner will adjust frequency, fan speed and set tempera- ture automatically according to the load status for saving energy. Noise: The noise-customized function for indoor unit can be adjusted according to the actual individual requirement. The detailed adjustment range is different for different models, which is decided by indoor unit. 27 Emergency operation If remote controller is lost or damaged, please use auxiliary button to turn on or turn off the air conditioner. The operation in details are as below: air conditioner. When the air conditioner is turned on, it will operate under auto mode. aux. button panel Display panel Clean and maintenance ■ Turn off the air conditioner and disconnect the power before cleaning the air conditioner to avoid electric shock. ■ Do not wash the air conditioner with water to avoid electric shock. ■ Do not use volatile liquid to clean the air conditioner. Clean surface of indoor unit When the surface of indoor unit is dirty, it is recommended to use a soft dry cloth or wet cloth to wipe it. NOTICE: " Do not remove the panel when cleaning it. WARNING WARNING: Use insulated object to press the auto button Clean and maintenance 28 operation environment, clean frequency can be increased. WARNING 1 2 3 4 Open panel ! Use dust catcher or water to Open the panel into a certain angle(less than 60°, do not open the panel too forcibly) along the arrow direction from the two sides of panel. the water (below 45 ć ) to clean it, and then put it in a shady and cool place to dry.  Install the filter and then close the panel cover tightly.(Press the arrow (1) po…

Text truncated - open the document above for the full version.
