2ADAP-SAA1FB1FRemote Controller

Split Air Conditioner . Thank you for choosing our product. If you have lost the Owner’s Manual, please contact the local agent or visit www.gree.com or sent email to [email protected] for electronic version. For proper operation, please read and keep this manual carefully. GWH09UC-D3DNA4A/I Models: GWH12UC-D3DNA4A/I GWH18UC-D3DNA4A/I GWH09UC-D3DNA4C/I GWH12UC-D3DNA4C/I GWH18UC-D3DNA4C/I Matching instructions Specialties note Matching of remote controller Please do the following operation within 2m from the unit. Matching is not needed anymore once it is done. During matching, please keep the remote controller and air conditioner under standby status. When the signal of remote controller can’t be received, please match the remote controller with the unit again. This model adopts RF remote control. The remote controller shall be matched with the air conditioner before operation, otherwise the remote control will be invalid. Before operation, please read the instructions in this page carefully and then do the corresponding matching operation. Note When the unit is under standby status, please get close to the air conditioner within 2m and then hold on pressing button for 3s. The remote controller and air conditioner will enter matching automatically. If matching is done, the unit will give out three sounds; if matching is failed, please get closer to the unit and arrange matching again. Humidify/Health Content Operation Notices Precautions............................................................................................................1 Parts name ........................................................................................................... 9 Screen Operation Guide Buttons on remote controller ................................................................................10 Introduction for buttons on remote controller ...................................................... 11 Function introduction for combination buttons ......................................................17 Operation guide ....................................................................................................18 Replacement of batteries in remote controller ......................................................18 Emergency operation ...........................................................................................27 Operation of Smart Control (Smart Phone, Tablet PC) ....................................... 19 Maintenance Clean and maintenance....................................................................................... 27 Malfunction Malfunction analysis ............................................................................................ 30 Installation Notice Installation dimension diagram ............................................................................ 34 Tools for installation ............................................................................................. 35 Selection of installation location .......................................................................... 35 Requirements for electric connection .................................................................. 36 Installation Installation of indoor unit...................................................................................... 37 Vacuum pumping ................................................................................................. 42 Leakage detection ............................................................................................... 42 Check after installation ........................................................................................ 43 Test and operation Test operation ...................................................................................................... 43 Attachment ......................................................................... 44 Pipe expanding method Configuration of connection pipe ....................................................................................... 46 Introduction for icons on display screen ...............................................................10 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. Explanation of Symbols Indicates a hazardous situation that, if not avoided, will result in death or serious injury. Indicates a hazardous situation that, if not avoided, could result in death or serious injury. Indicates a hazardous situation that, if not avoided, may result in minor or moderate injury. Indicates important but not hazard-related information, used to indicate risk of property damage. Indicates a hazard that would be assigned a signal word WARNING or CAUTION. Precautions WARNING Do not connect air conditioner to multi-purpose socket. This appliance can be used by children aged from 8 Operation and Maintenance If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. Do not spray water on indoor unit. It may cause electric shock or malfunction. Otherwise, it may cause fire hazard. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Do not wash the air conditioner with water to avoid electric shock. Aft…

Text truncated - open the document above for the full version.

Operation of Smart Control (Smart Phone, Tablet PC) 9. Enter into the software interface again. Meanwhile, the short-distance remote control setting for your air conditioner is finished. 22 How to reset the AC WiFi module: Kindly remind: 1. The air conditioner WiFi function needs about 1 minute to start up. 2. The air conditioner has memory function. 3. Those models have no long-distance control. Turn unit off with the remote controller and disconnect the power of AC. Then re-connect the power. 1 minute later, press “WiFi” and “Mode” buttons simultaneously. If the AC gives out a beep sound, it means the WiFi module is successfully reset. Attention: Operation of the buttons is only effective in 2 minutes. Analysis on Common Network Setting Failure: 1. If short-distance control fails, please check the following items one by one! ·Make sure AC is power connected; ·Make sure AC’s WiFi function is turned on as normal; ·Make sure your phone’s WiFi selects the corresponding AC; ·Reset with the remote controller and then start setting again from step 3. 23 Operation of Smart Control (Smart Phone, Tablet PC) 1. Mode: It used for setting operation mode for air conditioner. You can select “Auto”, “Cooling”, “Drying”, “Fan” or “Heating” according to your requirement. Please refer to the part of remote controller for the detailed operation. 3. Fan Speed: It used for setting fan speed. Under cooling or heating mode, if the noise-customized function is turned on, adjust the fan speed and then the noise- -customized function will be turned off automatically. Please refer to the part of remote controller for detailed operation. 2. Temperature: It used for setting temperature. Set the indoor temperature according to your requirement. Function Introduction on Main Interface 24 Operation of Smart Control (Smart Phone, Tablet PC) 1. Preset: It’s with Timer On and Timer Off function. User can set Timer On and Timer Off according to actual individual requirement. 2.Functions: After entering setting interface, you can turn on or turn off Light, Purify, X-fan and Turbo functions and set Silent, Humidify, Air exchange and other modes. Please refer to the part of remote controller for the function instruction. Among that, Purify, Humidify, Air exchange functions can be set through equipping with special air purifier, humidifier. E-heater is not available for this unit. Key Functions Instruction of Application Software 3. Swing: During up&down swing and left&right swing, it’s the fixed angle swing when those two sliding blocks are combined together and full swing when they are separated. When setting up&down swing, the program will turn off regional swing function. However, no influence for regional swing when setting left&right swing. 25 Operation of Smart Control (Smart Phone, Tablet PC) 4. Advanced: After entering advanced interface, you can set Sleep curve, Regional Swing, Noise and Power saving. Regional Swing: After entering Regional Swing, user can set it according to the room size. Press “Air flow position” button and the user can adjust the fan-blowing area through moving the icon of air conditioner left and right according to the actual installation position of the unit. User can move the person icon among nine pane areas according to requirement to adjust the fan-blow area. The Regional Swing function can be turned off through up&down swing. The up&down swing in the Regional Swing is only valid under cooling and heating modes. The left&right swing area has relationship with the position of air conditioner set by mobile phone. The left&right swing position may be asymmetry, which is the normal phenomenon. “Avoid people” function can be turned on or turned off according to user’s personal experience. There may be deviation because of the installation position of air conditioner and the setting of parameters, which is the normal phenomenon. Sleep curve: Sleep curve includes DIY mode, Traditional mode, Expert mode and Siesta mode. Under DIY mode, you can set temperature and time. Under auto mode and fan mode, sleep curve function can’t be turned on. Only Traditional mode can be selected under dry mode. 26 Operation of Smart Control (Smart Phone, Tablet PC) Power saving: After energy saving navigation mode is turned on, the air conditioner will detect indoor temperature and outdoor temperature automatically. Meanwhile, the air conditioner will adjust frequency, fan speed and set tempera- ture automatically according to the load status for saving energy. Noise: The noise-customized function for indoor unit can be adjusted according to the actual individual requirement. The detailed adjustment range is different for different models, which is decided by indoor unit. 27 Emergency operation If remote controller is lost or damaged, please use auxiliary button to turn on or turn off the air conditioner. The operation in details are as below: air conditioner. When the air conditioner is turned on, it will operate under auto mode. aux. button panel Display panel Clean and maintenance ■ Turn off the air conditioner and disconnect the power before cleaning the air conditioner to avoid electric shock. ■ Do not wash the air conditioner with water to avoid electric shock. ■ Do not use volatile liquid to clean the air conditioner. Clean surface of indoor unit When the surface of indoor unit is dirty, it is recommended to use a soft dry cloth or wet cloth to wipe it. NOTICE: " Do not remove the panel when cleaning it. WARNING WARNING: Use insulated object to press the auto button Clean and maintenance 28 operation environment, clean frequency can be increased. WARNING 1 2 3 4 Open panel ! Use dust catcher or water to Open the panel into a certain angle(less than 60°, do not open the panel too forcibly) along the arrow direction from the two sides of panel. the water (below 45 ć ) to clean it, and then put it in a shady and cool place to dry.  Install the filter and then close the panel cover tightly.(Press the arrow (1) po…

Text truncated - open the document above for the full version.

THIS MUST BE SIGNED BY THE APPLICANT/AGENT AND SHOULD BE PLACED ON APPROPRIATE LETTERHEAD 022311 – 6 Request for Confidentiality Date: __2014-10-15__ ____ Subject: Confidentiality Request for: _____2ADAP-SAA1FB1F__ ______ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term ; Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term ; Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term ; Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ ______ Gree Electric Appliances, Inc. of Zhuhai _____ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180 ) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: ____ ___ _Linda Li___ (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 2 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

Report No: 140815007GZU-001 Issued: 2014-09-22 FCC ID: 2ADAP-SAA1FB1F Page 2 of 24 CONTENT TEST REPORT......................................................................................................................................... 1 CONTENT................................................................................................................................................. 2 1. General Description ...................................................................................................................... 3 1.1 Product Description......................................................................................................... 3 1.2 Related Submittal (s) / Grants....................................................................................... 3 1.3 Test Methodology............................................................................................................ 3 1.4 Test Facility....................................................................................................................... 3 1.5 Measurement Uncertainty.............................................................................................. 4 2. System Test Configuration ........................................................................................................... 5 2.1 Justification....................................................................................................................... 5 2.2 EUT Exercising Software................................................................................................ 5 2.3 Special Accessories........................................................................................................ 5 2.4 Equipment Modification.................................................................................................. 5 2.5 Support Equipment List and Description...................................................................... 5 3. Summary of Test Results .............................................................................................................. 6 3.1 Antenna Requirement..................................................................................................... 6 3.2 Conducted Emission....................................................................................................... 6 3.3 Radiated Emission........................................................................................................... 7 3.4 Bandedges Measurement............................................................................................ 15 4. Equipment List............................................................................................................................ 24 Report No: 140815007GZU-001 Issued: 2014-09-22 FCC ID: 2ADAP-SAA1FB1F Page 3 of 24 1. General Description 1.1 Product Description The equipment under test (EUT) is a transceiver remote controller of air conditioner at 2.425GHz, 2.450GHz and 2.475GHz. The EUT is powered by 2*1.5V/AAA battery. It sends the command of air conditioner function to the air conditioner. Antenna Type: PCB antenna. We tested the remote controller, model: SAA1FB1F, to determine if it was in compliance with the relevant FCC standards. We found that the unit met the requirements of FCC part 15.249 when tested as received. The worst case’s test data was presented in this test report. 1.2 Related Submittal (s) / Grants The FCC ID of corresponding transceiver for this transceiver is 2ADAP-CS532K. 1.3 Test Methodology Radiated emission measurements were performed according to the procedures in ANSI C63.10:2009. Radiated emission measurement was performed in semi-anechoic chamber room. For radiated emission measurement, preliminary scans were performed in the semi-anechoic chamber only to determine the worst case modes. All radiated tests were performed at an antenna to EUT distance of 3 meters, unless stated otherwise in the "Justification Section" of this Application. 1.4 Test Facility All of the tests are performed at: Intertek Testing Services Shenzhen Ltd. Guangzhou Branch. Block E, No.7-2 Guang Dong Software Science Park, Caipin Road, Guangzhou Science City, GETDD Guangzhou, China 510663. This test facility and site measurement data have been fully placed on file with the FCC, test firm registration number is 549654. Report No: 140815007GZU-001 Issued: 2014-09-22 FCC ID: 2ADAP-SAA1FB1F Page 4 of 24 Test setup figure Test setup figure 1.5 Measurement Uncertainty Radiated Emission: 3.79dB in the frequency range of 30MHz-200MHz, 3.62dB in the frequency range of 200MHz-1000MHz, 5.04dB in the frequency above 1GHz at a level of confidence of 95%. When determining the test conclusion, the Measurement Uncertainty of test has been considered. Or BiConiLog Antenna for test below 1GHz Report No: 140815007GZU-001 Issued: 2014-09-22 FCC ID: 2ADAP-SAA1FB1F Page 5 of 24 2. System Test Configuration 2.1 Justification The system was configured for testing in a typical fashion (as a customer would normally use it), and in the confines as outlined in ANSI C63.10:2009 The EUT was powered by 2*1.5V/AAA battery in the testing. Type of modulation: GFSK modulation, and only the worst data was reported in this report. The unit was operated standalone and placed in the center of the turntable. For maximizing emissions, the unit was placed in the center of the turntable, and the turntable was rotated through 360°, the antenna height was varied from 1 meter to 4 meters above the ground plane, and the antenna polarization was changed. This step by step procedure for maximizing emissions led to the data reported in Chapter 3. 2.2 EUT Exercising Software There was no special software to exercise the device. 2.3 Special Accessories No special accessories used. 2.4 Equipment Modification Any modifications installed previous to testing by Gree Electric Appliances, Inc. of Zhuhai will be incorporated in each production model sold/leased in the U…

Text truncated - open the document above for the full version.

Radiated Emission below 1GHz Radiated Emission above 1GHz
