TinyCon_AT Instruction 1 Ralinwi Nanjing Electronic Technology Co., Ltd. TinyCon_AT Instruction Ver:V1.1.4 Date:2015/06/10 TinyCon_AT Instruction 2 Ralinwi Nanjing Electronic Technology Co., Ltd. AT Introduce AT is a user terminal interface for TinyCon2005, which provides users a set of the command operation interface, convenient user testing and checking information. How to enable AT Hardware connection AT work on TinyCon2005 UART interface, so you need to TinyCon2005 UART interface and through the derivation of additional circuit or device connected to a computer;If you are using a TinyWiEV - 1000 development board, then TinyWiEV - 1000 development board has UART derivation, using a mini USB cable to connect to the computer. Enter AT Enter AT,Must make TinyWiEV - 1000 board dial switch to 1 (high level) or input “$$$”at UART interface. In this case, the TinyCon2005 is powered on or reset automatically enter AT mode. Note: WiFi module to enter configuration mode to enter $$$, frame wait time defaults value is 50 ms. When serial return OK by entering the AT (or at), into command mode. AT Command Introduce TINYCON S2W APP at OK AT OK TinyCon_AT Instruction 3 Ralinwi Nanjing Electronic Technology Co., Ltd. AT Command Classification TinyCon2005 AT instruction has five instruction set: l serial port control instruction set l WiFi interface instruction set l Network control instruction set l Auto connect instruction set l Other instruction set Serial port control instruction set AT instruction Description ATB UART parameters take effect after reset ATSn=p Set various adapter interface parameters ATB= Function: UART parameters take effect after reset. Format Settings ATB=<baudrate> [[,<databits>][,<parity>][,<stopbits>][,<flowcontrol>]] Parameter baudrate Baud rate: 115200(support 9600~921600) databits Data bits: 7(7bit) 8 (8bit) parity Parity: n(none) e(even parity) o(odd parity) stopbits Stop bits 1 (1 stop bit) 2 (2 stop bits) flowcontrol Flow control nfc (none) fc(hardware) Example: setting up the serial port parameters (baud rate 115200, the data bits of 8, no check, 1 stop bit, and none flow control) ATSn=p Function:Set various adapter interface parameters Format Settings ATSn=p Parameter n=0 to 2 0=auto frame length 1=auto frame wait time 2=auto frame interval p=parameter value Example: Set the frame trigger a length of 1400 ATB=115200,8,n,1,nfc OK ATS0=1400 OK TinyCon_AT Instruction 4 Ralinwi Nanjing Electronic Technology Co., Ltd. WiFi interface instruction set AT instruction Description at+wa Associate to specified SSID, optionally using specified security parameters. at+wd Disassociate from the current network. at+ws Network scan, returns list of found networks in the format. at+wcountry Set 802.11 country code. at+wphymode Set 802.11 PHY mode: at+wrssi=? Current RSSI as ASCII at+wsetting=? Adapter reports the current wireless settings to the serial host at+nstat=? Current wireless and network configuration. at+wap Create a network on specified channel (only open and WAP2-PSK supported). at+sc Start the simple-config process. Optionally specify the PIN code to protect the process. at+wa Function:Associate to specified SSID, optionally using specified security parameters. Format Settings at+wa=< ssid >[,<password>,<wep keyindex>] Parameter ssid specify the SSID to connect the AP password set the key, if the security type for wep type 5 or 13 ASCII characters; If the security type for wpa_psk, wpa2_psk input 8 ~ 32 ASCII characters. wep keyindex set the wep key SN,for 0 ~ 3。 Example: Join a AP ,SSID is rlwap, encryption for the open Example: Join a AP , SSID is sytest, the secret key for 123456789, encryption for wpa2 at+wa=rlwap Joining Network... Connected to rlwap DHCP: started IP address: 192.168.1.103 OK at+wa=sytest,123456789 Joining Network... Connected to sytest DHCP: started IP address: 192.168.2.158 OK TinyCon_AT Instruction 5 Ralinwi Nanjing Electronic Technology Co., Ltd. at+wd Function:Disassociate from the current network. Format Settings at+wd Example: at+ws Function:Network scan, returns list of found networks in the format. Format Settings at+ws Example: at+wcountry Function:Set 802.11 country code. Format Settings at+wcountry=< contry string> Parameter contry string : US The United States EU Europe JP Japan CN China Example: at+wd Disassociated OK at+ws Scanning... [1] c8:3a:35:49:04:e0 -42 1 6 WPA2 AES SC_TEST_AP [2] 08:10:79:11:cc:5e -44 2 6 Open rlwap [3] 00:22:c3:81:98:3a -52 1 6 WPA2 AES New AP [4] 14:75:90:09:42:26 -52 6 6 WPA2 AES sun [5] d4:ca:6d:87:28:ba -56 1 6 WPA2 AES aibo [6] b8:c7:5d:0c:5d:81 -62 11 6 WPA2 AES AppleYao [7] e4:d3:32:ac:a7:8e -62 11 6 Open testTCP [8] 64:e4:25:11:00:84 -74 1 6 WPA2 AES RLW_LED_64e42511084 [9] 64:e4:25:11:00:9d -84 1 6 WPA2 AES sunwenhaoudptest WLAN SCAN END at+wcountry=us OK TinyCon_AT Instruction 6 Ralinwi Nanjing Electronic Technology Co., Ltd. at+wphymode Function:Set 802.11 PHY code. Format Settings at+wphymode=n Parameter n: 1 802.11 b 3 802.11 b/g 11 802.11 b/g/n Example: set up to BG mode at+wrssi=? Function:Current RSSI as ASCII Format Settings at+wrssi=? Parameter none Example: at+wsetting=? Function:Adapter reports the current wireless settings to the serial host Format Settings at+wsetting=? Parameter None Example: at+nstat=? Function:Current wireless and network configuration. Format at+wphymode=3 OK at+wrssi=? -45 OK at+wsetting=? WMODE=STA SSID=rlwap CHANNEL=2 SECURITY=OPEN PASSWORD= OK TinyCon_AT Instruction 7 Ralinwi Nanjing Electronic Technology Co., Ltd. Settings at+nstat=? Parameter None Example: at+wap Function:Create a network on specified channel (only open and WAP2-PSK supported). Format Settings at+wap =<SSID>,<Channel>[,<WPA2Password >] Parameter ssid To create an AP SSID specified channel Channel Settings (1~13) password 8~32 ASCII character Example: set the AP ssid is sun, channel…
