TinyCon_CLI Var：V1.0.1 Date：2014/08/21 1 Ralinwi Nanjing electronic technology co., LTD. CLI Introduce CLI is a user terminal interface for TinyCon2005, which provides users a set of the command operation interface, convenient user testing and checking information. How to enable CLI Hardware connection CLI work on TinyCon2005 UART interface, so you need to TinyCon2005 UART interface and through the derivation of additional circuit or device connected to a computer；If you are using a TinyWiEV - 1000 development board, then TinyWiEV - 1000 development board has UART derivation, using a mini USB cable to connect to the computer. Enter CLI Enter CLI，Must make TinyWiEV - 1000 board dial switch to 1 (high level). In this case, the TinyCon2005 is powered on or reset automatically enter CLI mode, the terminal screen displays： ‘>’ i s the CLI command prompt，You can type the command after the prompt. TinyCon2005 after receiving the command began to perform, and returns the result. Hello！Tinycon2000L > 2 Ralinwi Nanjing electronic technology co., LTD. CLI Command introduce ？ Displays help information Grammar ？ Parameter Void ipconfig According to the network connection Settings. Grammar ipconfig Parameter Void Examples The following example shows the ipconfig command output >ipconfig ip addr: 192.168.2.115 netmask: 225.225.225.0 gateway: 192.168.2.1 dns1: 192.168.2.1 hwaddr: 64e425101106 3 Ralinwi Nanjing electronic technology co., LTD. ping Through to the other host sends the ICMP Echo Request to check whether the connection is normal. Grammar ping [target_name] [count] Parameter target_name：Specify the target name, IP address or host name. count：Specifies the number of Echo Request message to be sent.The default is 4. Examples The following example shows the output of the ping command： To ping the target address for 192.168.2.108 and sent 10 Echo Request message, input： reset system reset Grammar >ping 192.168.2.108 10 > ping 192.168.2.108 PING 192.168.2.108(192.168.2.108): 120(148) data bytes 128 bytes from 192.168.2.108: icmp_seq=1 time=24 ms 128 bytes from 192.168.2.108: icmp_seq=2 time=32 ms 128 bytes from 192.168.2.108: icmp_seq=3 time=26 ms 128 bytes from 192.168.2.108: icmp_seq=4 time=20 ms --- 192.168.2.108 ping statistics --- 4 packets transmitted, 4 received, 0% packet loss, time 102 ms 4 Ralinwi Nanjing electronic technology co., LTD. reset Parameter Void restore Restore the factory default Settings, and reset the system. Grammar restore Parameter Void info Displays information about the drive module. Grammar info Parameter Void Examples The following example shows the info command output： > info Model: TinyCon2000L SN: N/A MAC addr: 64.E4.25.10.11.06 Firmware: V0.1.0 Hardware: V0.5 5 Ralinwi Nanjing electronic technology co., LTD. iw iw is a set of commands used to dynamic configuration module of WLAN. iw connect With the given Parameter to connect an AP. Grammar iw connect <SSID, [key], [wep_key id ]> Parameter  SSID Specified SSID to connect AP, if there are Spaces among SSID is needed to use "" SSID included. For example：“test 123”.  [key] Set keys. if the security type for wep, Set keys type 5 or 13 ASCII characters; If the security type for wpa_psk, wpa2_psk input 8 ~ 63 ASCII characters.  [wep_key id] Set the wep key serial number, 0 ~ 3. Examples SSID to connect to the test, encryption mode to open AP, input： SSID to connect to the test, for WEP encryption mode, the key is 12345, AP wep_key id 0, input： >iw connect test >iw connect test 12345 0 6 Ralinwi Nanjing electronic technology co., LTD. SSID to connect to the test, encryption mode to connected wpa2-psk, key for 12345678 AP, input： iw disconnect Disconnect with the AP. Grammar iw disconnect Parameter Void Examples Need to disconnect from the current AP connection, input： iw ap create the AP mode Grammar iw ap <SSID> <channel> [<WPA2 PSK>] Parameter  SSID Specified to create AP SSID.  channel Specify to create AP channel. >iw connect test 12345678 >iw disconnect 7 Ralinwi Nanjing electronic technology co., LTD.  [WPA2 PSK] Specify to create AP key, this is optional. Don't use that encryption is open, if used, the encryption mode is WPA2, 8 ~ 63 ASCII characters must be entered. Examples Need to set the ssid to test, channel 1, encryption mode for the open AP, input： Need to set the ssid to test, channel 1, encryption mode is WPA2, the key is 12345678, input： iw scan Command equipment to perform scan, and return the scan results. Grammar iw scan Parameter Void Notes： This command will trigger device performs a scan;Command will block until the return to the scan results. Scan the format of the returned results BSSID RSSI SECURITY WPS-ID SSID Examples >iw ap test 1 >iw connect test 1 12345678 8 Ralinwi Nanjing electronic technology co., LTD. The following example shows the scan command output： iw rssi Show the current rssi. Grammar iw rssi Parameter Void Examples The following example shows the rssi output of commands： iw info Show the current configuration module of WLAN. Grammar iw info Parameter Void Examples > iw scan BSSID RSSI SECURITY WPS-ID SSID 00:22:c3:81:98:3a -94 WPA/WPA2 -1 New AP d4:ca:6d:87:28:ba -94 WPA/WPA2 -1 aibo 00:22:c3:81:96:24 -94 WPA/WPA2 -1 woxu wireless [3 : 3] >iw rssi RSSI=-60 9 Ralinwi Nanjing electronic technology co., LTD. The following example shows the info command output： iw sc Using simple_config to connect to the Internet Grammar iw sc Examples control module quick access networks with android APP , the result of the example below shows that this command： > iw info RSSI: -60 state: running op mode: station security: wpa2-psk SSID: aibo channel: 6 > iw sc SC Start [1]Perform channel-round scan *ch1*ch2*ch3*ch4*ch5*ch6*ch7*ch8*ch9*ch10*ch11 Start scan to learn AP's security mode: * 3 [AP Profile] ssid: New AP security: WPA2 password: 1234567899 Try to connect target AP +++++++ connected to New AP DHCP: Started netif_set_ipaddr: netif address being changed netif: IP address of interface…

Text truncated - open the document above for the full version.

DATE : Oct 25, 2014 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ADGHTINYCON Product Name: tiny embedded Wi-Fi module Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this Oct 25, 2014 Agency agreement expiration date: Usually Give 8 - 12 Months By: Zuokun Liang Signature Printed Title: Product Manager On behalf of : Ralinwi Nanjing Electronic Technology Co., Ltd. Telephone: +86-25-68520225

Statement We Ralinwi Nanjing Electronic Technology Co., Ltd. Hereby Declare that The product tiny embedded Wi-Fi module, models no. TinyCon2005, TinyCon2005-LS/LM/LG/LR are all identical in interior structure, electrical circuits and components, and just model names and appearance color are different for the marketing requirement. Your assistance on this matter is highly appreciated. Yours sincerely, Client’s signature: Client’s name / title: Zuokun Liang, Product Manager Contact information / Room 404,Building 6,No.6 Su Yuan Road, Xuanwu District Nanjing China

Product: tiny embedded Wi-Fi module Model: TinyCon2005, TinyCon2005-LS/LM/LG/LR FCC ID: tiny embedded Wi-Fi module Request for Modular Approval Attestation for tiny embedded Wi-Fi module (i) The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. Answer: Yes Modular has shielding on the top and bottom sides, and full copper covered PCB board is used at bottom of module. (ii) The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over-modulation. Answer: Yes The EUT has buffered data inputs; it is integrated in chip STM32F103xC (iii) The modular transmitter must have its own power supply regulation. Answer: Yes Answer: Yes The EUT interface provides 3.3VDC, and on board IC STM32F103xC has its own VCO inside. (iv) The modular transmitter must comply with the antenna and transmission system requirements of §§15.203,15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of §15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Answer: Yes The EUT meets the antenna requirements. It is Dipole antenna with revised polarity connector. Refer to the photo shown in test report. (v) The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in §15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see §15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any FCC ID 2ADGHTINYCON We ˈRalinwi Nanjing Electronic Technology Co., Ltd. apply single modular approval for According to 996369 D01 Module Equip Auth Guide v01r04 and 15.212 requirement: Intergral antenna is used Ceramic Antenna with gain -0.8dBi accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see §15.31(i)). Answer: Yes The device was tested with stand –alone configuration, the distance between module and other supporting equipment is larger than 10cm. The conducted emissions are done. Please see test report. (vi) The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. Answer: Yes The modular has a permanent fixed label, and below statement was listed in the User Manual; The host device must be labelled to display the FCC ID of the module ‘Contains FCC ID: 2ADGHTINYCON (vii) The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Answer: Yes The module comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee, Refer to test report and user manual . (viii) The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. Answer: Yes Transmitter meets MPE calculation of 47 CFR 1.1307 . Refer to MPE Reports and Refer to modular installation manual. This modular complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This modular must be installed and operated with a minimum distance of 20 cm between the radiator and user body. Dated this Oct 25, 2014 Agency agreement expiration date: Usually Give 8 - 12 Months By: Zuokun Liang Signature Printed Title: Product Manager On behalf of : Ralinwi Nanjing Electronic Technology Co., Ltd. Telephone: +86-25-68520225

FCC ID: 2ADGHTINYCON

FCC ID Label Location

Photo 1 Photo 2

Maximum Permissible Exposure FCC ID: 2ADGHTINYCON Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m normally can be maintained between the user and the device. (a) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times ︱E︱ 2 , ︱H︱ 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100000 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times ︱E︱ 2 , ︱H︱ 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100000 1.0 30 Note: f=frequency in MHz; *Plane-wave equivalent power density MPE Calculation Method E (V/m) = (30*P*G) 0.5 /d Power Density: Pd (W/m 2 ) = E 2 /377 E = Electric Field (V/m) P = Peak RF output Power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = (30*P*G) / (377*d 2 ) From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Calculated Result and Limit Worse case was recorded 802.11b Mode Antenna Gain (Numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 0.832 19.87 97.06 0.016 1 Compiles

Shenzhen United Testing Technology Co., Ltd. Report No.: UNI-1410085 Page 1 of 100 FCC TEST REPORT Prepared For : Ralinwi Nanjing Electronic Technology Co., Ltd. Product Name: tiny embedded Wi-Fi module Model : TinyCon2005, TinyCon2005-LS/LM/LG/LR Prepared By : Shenzhen United Testing Technology Co., Ltd. 4F, Block B Unit 2, Jianxing Building, Chaguang Industry Area, Nanshan District, Shenzhen, China Tel: 86-755-86180996 Fax: 86-755-86180156 Test Date: October 13, 2014 to October 23, 2014 Date of Report : October 23, 2014 Report No.: UNI-1410085 Note: This report shall not be reproduced except in full, without the written approval of Shenzhen United Testing Technology Co., Ltd. This document may be altered or revised by Shenzhen United Testing Technology Co., Ltd. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample Shenzhen United Testing Technology Co., Ltd. Report No.: UNI-1410085 Page 2 of 100 TABLE OF CONTENTS 1.0 TEST CERTIFICATION............................................................................... 3 2.0 Test Equipment......................................................................................... 5 3.0 Technical Details........................................................................................ 6 4.0 Test Lab Details......................................................................................... 6 5.0 Power Line Conducted Emission Test............................................................ 7 5.1 Schematics of the Test................................................................................ 7 5.2 Test Method and Test Procedure................................................................... 7 5.3 Configuration of the EUT............................................................................ 7 5.4 EUT Operating Condition............................................................................ 8 5.5 Conducted Emission Limit........................................................................... 8 5.6 Test Result................................................................................................ 8 6.0 Radiated Emission test................................................................................ 11 6.1 Test Method and Test Procedure................................................................... 11 6.2 Configuration of the EUT............................................................................. 11 6.3 EUT Operation Condition............................................................................ 11 6.4 Radiated Emission Limit.............................................................................. 12 7.0 6dB Bandwidth Measurement....................................................................... 36 8.0 Maximum Peak Output Power...................................................................... 54 9.0 Power Spectral Density Measurement........................................................... 57 10.0 Out of Band Measurement.......................................................................... 76 11.0 Antenna Requirement................................................................................ 95 12.0 FCC ID Label............................................................................................ 96 13.0 Photo of Test Setup and EUT View................................................................ 97 Shenzhen United Testing Technology Co., Ltd. Report No.: UNI-1410085 Page 3 of 100 1 TEST CERTIFICATION Product: tiny embedded Wi-Fi module Model: TinyCon2005, TinyCon2005-LS/LM/LG/LR Applicant: Ralinwi Nanjing Electronic Technology Co., Ltd. Room 404,Building 6,No.6 Su Yuan Road, Xuanwu District Nanjing China Factory: Ralinwi Nanjing Electronic Technology Co., Ltd. Room 404,Building 6,No.6 Su Yuan Road, Xuanwu District Nanjing China Trade Mark: Tested: October 13, 2014 to October 23, 2014 Operational Frequency Range: IEEE 802.11b/g, 802.11n HT20: 2412-2462MHz IEEE 802.11n HT40 : 2422MHz-2452MHz Modulation Type: IEEE 802.11b : DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g : OFDM (64QAM, 16AQM, QPSK, BPSK) IEEE 802.11n HT20/40 : OFDM (64QAM, 16QAM, QPSK, BPSK) Channel Spacing IEEE 802.11b/g/n: 5MHz Air Data Rate IEEE 802.11b : 11, 5.5, 2, 1 Mbps IEEE 802.11g : 54, 48, 36, 24, 18, 12, 9, 6 Mbps IEEE 802.11n HT20 : 150, 117 ,104, 78, 65, 58.5, 52, 39, 26, 19.5, 13, 6 Mbps IEEE 802.11n HT40 : 150, 117 ,104, 78, 65, 58.5, 52, 39, 26, 19.5, 13, 6 Mbps Frequency Selection By software Channel Number IEEE 802.11b/g ,802.11n HT20 : 11 Channels IEEE 802.11n HT40 : 7 Channels Antenna: Ceramic antenna used. Gain -0.8dBi FCC ID: 2ADGHTINYCON Applicable Standards: FCC Part 15.247 The test report was prepared by Shenzhen United Testing Technology Co., Ltd. and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Shenzhen United Testing Technology Co., Ltd. Report No.: UNI-1410085 Page 4 of 100 Prepared by : Michael Su /Assistant Engineer Reviewer : Mike Yong/Supervisor Approved & Authorized Signer :  Hoffer Lau/ Manager Shenzhen United Testing Technology Co., Ltd. Report No.: UNI-1410085 Page 5 of 100 2.0 Test Eqipment Item Test Equipment Manufacturer Model No. Cal.Date (mm-dd-yy) Cal.Due date (mm-dd-yy) 1 3m Semi- Anechoic Chamber ZhongYu Electron 9.2(L)*6.2(W)* 6.4(H)June. 30 2014 June. 29 2015 2 Control Room ZhongYu Electron 6.2(L)*2.5(W)* 2.4(H)N/A N/A 3 EMI Test Receiver Rohde & Schwarz ESU26 Jul. 03 2014 Jul. 02 2015 4 BiConiLog Antenna SCHWARZBECK MESS-ELEKTRONIK VULB9163 Feb. 25 2014 Feb. 24 2015 5 Double -ridged waveguide horn SCHWARZBECK MESS-ELEKTRONIK 9120D-829 June 29 2014 June 28 2015 6 Horn Antenna ETS-LINDGREN 3160 June. 30 2014…
