2ADIH-EPOC02Emotiv EPOC+ Neuroheadset

Includes headset and software setup information for your Emotiv EPOC neuroheadset. Emotiv EPOC User Manual brain computer interface technology 2 EMOTIV EPOC USER MANUAL | BRAIN COMPUTER INTERFACE TECHNOLOGY Table of Contents Quick Start Guide .............................................................................................................. 4 Introduction to Emotiv EPOC Neuro-technology Neuroheadset ....................................... 11 NEUROHEADSET FEATURES ............................................................................................................ 12 SAFETY .......................................................................................................................................... 13 REGULATORY REQUIREMENTS ......................................................................................................... 14 1.0 Getting Started.......................................................................................................... 16 2.0 Minimum Hardware and Software requirements ....................................................... 17 2.1 Charging the EPOC Neuroheadset Battery ............................................................... 17 2.2 Use of Saline Hydration Sensor Pack and Felt Inserts .............................................. 18 2.3 USB Transceiver Installation ..................................................................................... 20 2.4 EPOC Control Panel™ ............................................................................................. 20 2.5 Placement of Emotiv EPOC Neuroheadset on the Head ........................................... 21 2.6 EmoEngine Status Panel .......................................................................................... 21 2.7 User Status ............................................................................................................... 22 2.8 Sensor Contact Quality Display ................................................................................. 23 2.9 Neuroheadset Set-Up ............................................................................................... 24 3.0 Achieving Good Signal Quality .................................................................................. 25 3 EMOTIV EPOC USER MANUAL | BRAIN COMPUTER INTERFACE TECHNOLOGY 3.1 Expressiv™ Suite ...................................................................................................... 27 3.1.1 UNDERSTANDING THE EXPRESSIV SUITE PANEL DISPLAY ......................................................... 27 3.1.2 SENSITIVITY ADJUSTMENT PANEL .......................................................................................... 28 3.1.3 EMOKEY................................................................................................................................ 29 3.2 Affectiv™ Suite .......................................................................................................... 31 3.2.1 AFFECTIV SUITE INTRODUCTION ............................................................................................. 31 3.2.2 UNDERSTANDING THE AFFECTIV PANEL DISPLAY ..................................................................... 32 3.2.3 AFFECTIV SUITE DETECTION DETAILS ..................................................................................... 32 3.3 Cognitiv™ Suite ........................................................................................................ 33 3.3.1 COGNITIV SUITE INTRODUCTION ............................................................................................. 33 3.3.2 UNDERSTANDING THE COGNITIV PANEL DISPLAY ..................................................................... 34 3.3.3 COGNITIV TRAINING ............................................................................................................... 35 3.3.4 TRAINING NEUTRAL ................................................................................................................ 37 3.3.5 CLEAR TRAINING BUTTON ...................................................................................................... 38 3.3.6 COGNITIV TIPS ....................................................................................................................... 38 3.3.7 EMOKEY FOR COGNITIV ACTIONS ........................................................................................... 39 3.4 Mouse Emulator ........................................................................................................ 41 3.4.1 UNDERSTANDING THE MOUSE EMULATOR TAB ........................................................................ 41 3.4.2 MOUSE EMULATOR CONTROLS ............................................................................................... 42 4.0 Trouble Shooting and Help ....................................................................................... 43 4 EMOTIV EPOC USER MANUAL | BRAIN COMPUTER INTERFACE TECHNOLOGY Quick Start Guide Items in the EPOC Headset Kit Make sure all items are present in your kit before starting.  Headset Assembly with Rechargeable Lithium battery already installed  USB Transceiver Dongle  Hydration Sensor Pack with 16 Sensor Units  Saline solution  50/60Hz 100-250 VAC Battery Charger (US customers) or USB charger (non-US customers)  CD Installation Disk for Windows XP or Vista (for EPOC consumer headset. SDKs are delivered electronically) 5 EMOTIV EPOC USER MANUAL | BRAIN COMPUTER INTERFACE TECHNOLOGY Initial charging of headset Make sure the small switch on the rear underside of the headset is set to the “Off” position before starting. Plug the mini USB cable attached to the supplied battery charger into the slot at the top of the headset and to the USB port on your PC or the power cord into a 50 or 60 Hz 100-250 V electrical outlet. The Lithium battery can be recharged to 100% capacity in approximately 4 hours depending on the initial state of charge. Charging for 30…

Text truncated - open the document above for the full version.

Declaration of Authorization We Name: Emotiv, Inc Address: 490 Post St, Suite 824 City: San Francisco CA 94102 Country: USA Declare that: Name (Representative Agent): Diana Williams Agent Company name: Compliance Testing, LLC Address: 1724 S. Nevada Way Mesa, AZ 85204 Country: USA is authorized to apply for Certification of the following products(s): Product description: EPOC Model 1.1 Neuroheadset Type Designation – FCC ID: 2ADIH-EPOC02 Trademark: Emotiv EPOC+ on our behalf. Date: March 5 th , 2015 Name: Geoffrey Mackellar Function: Chief Technology Officer Notes: (1): Required for FCC application. (2): For FCC it must be the Grantee Code “owner” or “authorized agent”. Emotiv Inc 490 Post Street, Suite 824 San Francisco, CA 94102 USA Emotiv Research Pty Ltd ABN 82 149 846 980 145/4 Cornwallis Street Eveleigh NSW 2015 Australia Email [email protected] URL www.emotiv.com

March 5 th , 2015 Compliance Testing LLC 1724 S. Nevada Way Mesa, AZ 85204 RE: CONFIDENTIALITY REQUEST FOR EMOTIC EPOC Model 1.1 FCC: 2ADIH-EPOC02 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the following documents required to be submitted with this application be permanently withheld from public review.  Block Diagram  Bill of Materials  Schematics  Theory of Operation These documents contain detailed system and equipment descriptions and related information about the product, which manufacturer/applicant considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, manufacturer/applicant feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Geoffrey Mackellar PhD Chief Technology Officer Emotiv Inc Phone: (415) 817 9885 Email: [email protected] Emotiv Inc 490 Post Street, Suite 824 San Francisco, CA 94102 USA Emotiv Research Pty Ltd ABN 82 149 846 980 145/4 Cornwallis Street Eveleigh NSW 2015 Australia Email [email protected] URL www.emotiv.com

Form: CB-7.2.1 Issued by: QM Issue Date: 9/22/2011 Page 1 of 2 Revised by: QM-JS Revised Date: 6/23/2014 L:\Project\2014\p14a0008-Emotiv Re\TCB Folder\RT's\CB-7.2.1 - Technical Review RT Form.docx CB-7.2.1 – Technical Review RT Form FCC ID: 2ADIH-EPOC02 IC ID: 12769A-EPOC02 CT Project: p14a0008 From: Shawn McMillen Date: 3/31/15 15.249 Please address 15.215 requirements. 1--It appears from the manual that this device can communicate with a computer and pass data. If so this device is subject to DoC as well as the FCC logo labeling requirements. Emotiv: 4/17/15 - Revised artwork for EPOC+ and Insight products including the FCC logo. My reading of the regulations you sent indicates that applying the FCC ID with certified test reports is a stronger condition than Declaration of Conformance. 2--Since this is a portable device SAR needs to be addressed. Ideally this device will be categorically excluded from routine SAR evaluation however the MPE report provided is incorrect since MPE is meant for devices operating >20cm from a body. Please address. CT-The Test Report has been updated 15.247 3--The Spectral density has not been addressed. CT-The test report has been updated. RSS-210 4--Please note that RSS-GEN no longer requires receiver spurious emissions for this type of device. CT- Noted 5--The form 750 needs to address the 15.249 equivalent radio for IC. In addition the form 750 is not signed. CT- Included additional form 750 for 15.249 radio 6--Once 15.215 is address please update the IC cross reference to include this. Form: CB-7.2.1 Issued by: QM Issue Date: 9/22/2011 Page 2 of 2 Revised by: QM-JS Revised Date: 6/23/2014 L:\Project\2014\p14a0008-Emotiv Re\TCB Folder\RT's\CB-7.2.1 - Technical Review RT Form.docx CT – Cross references have been updated Response by: Submitted by: Date:

Photographs ID 3-13 Photographs ID 3-14

PMS BLACK CB Reg No: JPTUV-029914 FCC ID: XUE-USBD01 Made in the Philippines USB 001 CB Reg No: JPTUV-029914 FCC ID: XUE-USBD01 Made in the Philippines USB 001 9.50 19.50 R1.80 Emotiv EPOC ™ Model 1.1 Emotiv EPOC ™ Model 1.0 1530 G813 C - EPOC+ Dongle Underside (No CTick or CE) 18.08.2014 PRINT ARTWORKPOSITIONAL OF ARTWORK Emotiv EPOC ™ Model 1.1 COLOUR SPECIFICATION - PMS BLACK CAUTION - CHOKING HAZARD Keep small parts away from children Do not wear headset while charging DO NOT PRINT THE RED LINE WORK. THIS IS FOR POSITIONAL LAYOUT ONLY. 14.00 29.00 PRINT ARTWORK POSITION OF ARTWORK 2230 G809 C - Insight Decal 09.04.2015 Emotiv Insight™ Model 1.0 Made in China CAUTION - CHOKING HAZARD Keep small parts away from children Do not wear headset while charging Emotiv Insight™ Model 1.0 Made in China PMS SILVER 877C PMS BLACK CAUTION - CHOKING HAZARD. Keep small parts away from children Do not wear headset while charging. IC ID: 12769A-EPOC02 FCC ID: 2ADIH-EPOC02 CAUTION - CHOKING HAZARD. Keep small parts away from children Do not wear headset while charging. IC ID: 12769A-EPOC02 FCC ID: 2ADIH-EPOC02 24 . 99 297.35 Emotiv EPOC ™ Model 1.1 Made in the Philippines Emotiv EPOC ™ Model 1.1 Made in the Philippines PRINT ARTWORK POSITIONAL OF ARTWORK 1530 G814 E - EPOC+ Head Band Decal 09.04.2015

Photographs ID 3-15 Photographs ID 3-16 Photographs ID 3-17 Photographs ID 3-18 Photographs ID 3-21 Photographs ID 3-22

p14a0008_FCC_Part 1.1310_Rev 1.0 Page 1 of 4 Test Report Prepared for: Emotiv Inc. Model: Emotiv EPOC Model 1.1 Description: EEG Neuroheadset for consumer use - Trademarked as EPOC+ Serial Number: N/A FCC ID: 2ADIH-EPOC02 To FCC Part 1.1310 Date of Issue: March 3, 2015 On the behalf of the applicant: Emotiv Inc. 490 Post Street Suite 824 San Francisco, CA 94102 Attention of: Geoffrey Mackellar, CTO Ph: (415) 828-9895 E-Mail: [email protected] Prepared By Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p14a0008 Alex Macon Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing All results contained herein relate only to the sample tested p14a0008_FCC_Part 1.1310_Rev 1.0 Page 2 of 4 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 November 25, 2014 Alex Macon Original Document p14a0008_FCC_Part 1.1310_Rev 1.0 Page 3 of 4 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer joint ISO-ILAC-IAF Communiqué dated January 2009) The tests results contained within this test report all fall within our scope of accreditation, unless below Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC Site Reg. #349717 IC Site Reg. #2044A-2 Non-accredited tests contained in this report: N/A EUT Description Model: Emotiv EPOC Model 1.1 Description: EEG Neuroheadset for consumer use - Trademarked as EPOC+ S/N: N/A Additional Information: None p14a0008_FCC_Part 1.1310_Rev 1.0 Page 4 of 4 MPE Evaluation This is a portable device used in Uncontrolled Exposure environment. Limits Uncontrolled Exposure 47 CFR 1.1310 Table 1, (B) 0.3-1.234 MHz: Limit [mW/cm²] = 100 1.34-30 MHz: Limit [mW/cm²] = (180/f²) 30-300 MHz: Limit [mW/cm²] = 0.2 300-1500 MHz: Limit [mW/cm²] = f/1500 1500-100,000 MHz Limit [mW/cm²] = 1.0 Test Data Test Frequency, MHz 2402 Power, Radiated, mW (P) 0.0302 Antenna Gain Isotropic 0dBi Antenna Gain Numeric (G) 1 Antenna Type integral Distance (R) 20 cm 푆= 푃∗퐺 4휋푟 2 Power Density (S) mw/cm 2 Power mW (P) Numeric Gain (G) Distance (r) cm 0.0000060083 0.0302 1 20 Power Density (S) =0.0000060083 Limit =(from above table) = 1.0 END OF TEST REPORT

p14a0008_FCC_Part 15.247_DTS_Rev 2.0 Page 1 of 26 Test Report Prepared for: Emotiv Inc. Model: Emotiv EPOC Model 1.1 Description: EEG Neuroheadset for consumer use - Trademarked as EPOC+ Serial Number: N/A FCC ID: 2ADIH-EPOC02 To FCC Part 15.247 DTS Date of Issue: April 10, 2015 On the behalf of the applicant: Emotiv Inc. 490 Post Street Suite 824 San Francisco, CA 94102 Attention of: Geoffrey Mackellar, CTO Ph: (415) 828-9895 E-Mail: [email protected] Prepared By Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p14a0008 Alex Macon Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing. All results contained herein relate only to the sample tested. p14a0008_FCC_Part 15.247_DTS_Rev 2.0 Page 2 of 26 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 November 1, 2014 Alex Macon Original Document 2.0 April 9, 2015 Alex Macon Included Power Spectral Density data p14a0008_FCC_Part 15.247_DTS_Rev 2.0 Page 3 of 26 Table of Contents Description Page Standard Test Conditions Engineering Practices 6 Test Summary 8 Peak Output Power 9 Radiated Spurious Emissions 10 Emissions at Band Edges 12 Occupied Bandwidth 14 Transmitter Power Spectral Density (PSD) 18 A/C Powerline Conducted Emission 21 Receiver Spurious Emissions 24 Test Equipment Utilized 26 p14a0008_FCC_Part 15.247_DTS_Rev 2.0 Page 4 of 26 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer to the joint ISO-ILAC-IAF Communiqué dated January 2009). The tests results contained within this test report all fall within our scope of accreditation, unless noted below. Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC Site Reg. #349717 IC Site Reg. #2044A-2 Non-accredited tests contained in this report: N/A p14a0008_FCC_Part 15.247_DTS_Rev 2.0 Page 5 of 26 The applicant has been cautioned as to the following 15.21 - Information to User The user’s manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 15.27(a) - Special Accessories Equipment marked to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer without an additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. p14a0008_FCC_Part 15.247_DTS_Rev 2.0 Page 6 of 26 Standard Test Conditions Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing: In accordance with ANSI C63.10-2009 and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104°F) unless the particular equipment requirements specified testing over a different temperature range. Also, unless otherwise indicated, the humidity levels were in the range of 10% to 90% relative humidity. Measurement results, unless otherwise noted, are worst-case measurements. Environmental Conditions Temperature (ºC) Humidity (%) Pressure (mbar) 25.1 – 25.7 40.2 – 47.6 965.2 – 968.3 EUT Description Model: Emotiv EPOC Model 1.1 Description: EEG Neuroheadset for consumer use - Trademarked as EPOC+ Serial Number: N/A Software: Nordic Semiconductor Master Control Panel Additional Information: The device is a Wireless Neurological Headset transceiver, which communicates to a USB transceiver connected to a personal computer The link between the headset transceiver and USB transceiver transmits data continuously and is required for proper operation of the product. The device incorporates an integral antenna; all measurements are done by radiated means EUT Operation during Tests The Client has provided several dongles to place the EUT in High Mid and Low channels and also a dongle for normal operation p14a0008_FCC_Part 15.247_DTS_Rev 2.0 Page 7 of 26 Accessories: Qty Description Manufacturer Model S/N 3 USB Dongle Emotiv 1.0 N/A 1 Bluetooth Dongle Nordic Semiconductor PCA10000 N/A Cables: None Modifications: None 15.203: Antenna Requirement: X The antenna is permanently attached to the EUT The antenna uses a unique coupling The EUT must be professionally installed The antenna requirement does not apply p14a0008_FCC_Part 15.247_DTS_Rev 2.0 Page 8 of 26 Test Summary Specification Test Name Pass, Fail, N/A Comments 15.247(b)(3) Peak Output Power Pass 15.247(b) C…

Text truncated - open the document above for the full version.

Test Setup Photos FCC ID: 2ADIH-EPOC02 RF Radiated #1 RF Radiated #2 A/C Powerline Conduction #1 A/C Powerline Conduction #2
