2ADIH-EPOC03Mobile BCI Headset, Gaming Interface

EPOC X User Manual 19/02/2020 EMOTIV EPOC X User Manual - Release 19/02/2020 Introduction3 Contents4 Technical Specification5 Safety Precautions6 Regulatory compliance7 Getting Started9 Get to know your headset10 User Interface12 USB Dongle13 Troubleshooting14 Further Saline Solution14 Storage15 2 Introduction EMOTIV designs consumer Brainwear headsets which allow researchers, commercial companies or quantified selfers learn more about their brains. EPOC X is the latest iteration of the award winning EPOC brand. It is a 14 channel headset with saline soaked felt electrode designed to replace the current EPOC+ and address issues faced by our customers. EPOC X has a rotating headband, new electrode design and updated radio to improve connectivity. The electrode placement has not changed but now you are able to refill the sensors without removing the headset. Product Highlights Rotating Headband <IMAGE> New Electrode Design <IMAGE> 3 4 Contents 1.Travel case + Sleeve a.Protect your headset when travelling and store all the accessories in the case. 2.EPOC X Headset 3.USB Dongle 4.Saline fluid sample 60ml a.The sample is contact lens solution 5.USB-C Charge Cable a.Reversible charge cable 6.Felt Pack - 80pcs a.EMOTIV has replaced the existing hydrator packs with standard a standard felt pack which contains 80pcs of felts that fit EPOC X and EPOC Flex. These are presented in a custom ziplock bag. 5 Technical Specification Number of Channels 14 (plus CMS/DRL references, P3/P4 locations 10-20 positions AF3, F7, F3, FC5, T7, P7, O1, O2, P8, T8, FC6, F4, F8, AF4 Sampling Method Sequential sampling. Single ADC Sampling Rate 128 SPS / 256 SPS (2048 Hz internal) EEG Resolution 14 bits 1 LSB = 0.51μV (16 bit ADC, 2 bits instrumental noise floor is discarded), settings can be changed to 16-bit Bandwidth 0.2 - 45Hz, digital notch filters at 50Hz and 60Hz Filtering Built-in digital 5th order Sinc filter Dynamic Range (input referred) 8400 uV(pp) Coupling Mode AC coupled Connectivity Proprietary 2.4GHz wireless, BLE and USB (Extender only) Battery Life Upto 9 hours (LiPo) Impedance Measurement Real-time contact quality using patented system Motion Sensor ICM-20948 Accelerometer 3-axis +/-4g Magnetometer 3-axis +/- 4900 uTesla Motion Sampling 32 / 64 Hz Motion Resolution 14 / 16-bit (User Defined) Quanterion Yes Sensor Material Ag/AgCl + Felt + Saline 6 Safety Precautions ●EPOC X is a consumer product; it is not intended to use for in-patient healthcare or in hazardous environments. ●EPOC X is designed for use at room temperature; rapid changes in temperature will affect the performance of the amplifiers and increase the noise floor. ●EPOC X uses saline based sensors and every effort has been made to protect the electronics from water ingress, however it is not waterproof. Please do not submerge your headset. ●WARNING​: EPOC X is powered by a Lithium-Polymer battery that is rated for operation in <45C environments. It is not user replaceable, please contact support if you suspect a fault or have any questions. ●WARNING​: Do not open the enclosure. Doing so will void the warranty and can damage the headset. ●WARNING​: Do not charge EPOC X while wearing the device. 7 Regulatory compliance EMOTIV products are intended to be used for research applications and personal use only. Our products are not sold as Medical Devices as defined in EU directive 93/42/EEC. Our products are not designed or intended to be used for diagnosis or treatment of disease. FCC ID Number ​2ADIH-EPOC03 ​and IC ID Number: ​12769A-EPOC03​. ​EMOTIV has tested EPOC X and confirms: This device complies with the radio equipment directive (2014/53/EU). This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or experienced person for help. ​This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1.This device may not cause interference. 2.This device must accept any interference, including interference that may cause undesired operation of the device. 8 L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1.L’appareil ne doit pas produire de brouillage; 2.L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Please Note: Changes or modifica…

Text truncated - open the document above for the full version.

2020-03-02 Bay Area Compliance Lab (BACL) 1274 Anvilwood Ave. Sunnyvale, CA 94089 U.S.A RE: LETTER OF AUTHORIZATION To Whom It May Concern: I, Geoff Mackellar authorize Mark Irwin, Technical Project Manager of Emotiv Research Pty Ltd, to act as a signatory on my behalf in regard to certification of documents related to the certification of Emotiv products. Sincerely, Geoff Mackellar Chief Technical Officer Emotiv Inc Emotiv Inc 490 Post Street, Suite 824 San Francisco, CA 94102 USA Emotiv Research Pty Ltd ABN 82 149 846 980 Macquarie Incubator 8 Hadenfeld Ave Macquarie University NSW 2109 Australia Email [email protected] URL www.emotiv.com

FCC Confidential Authorization 2020-02-21 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2ADIH-EPOC03 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Emotiv Inc hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description As well as short-term 180 days confidential treatment of information accompanying this application as outlined below:  Internal Photos  User’s Manual  External Photos  Test Set-up Photos The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Recoverable Signature X Mark Irwin Technical Project Manager Signed by: Mark Irwin Emotiv Inc 490 Post Street, Suite 824 San Francisco, CA 94102 USA Emotiv Research Pty Ltd ABN 82 149 846 980 Macquarie Incubator 8 Hadenfeld Ave Macquarie University NSW 2109 Australia Email [email protected] URL www.emotiv.com

Emotiv Inc. FCC ID: 2ADIH-EPOC03, IC: 12769A-EPOC03 Annex B (Normative) – EUT External Photographs EUT External Photograph – Front View EUT External Photograph – Rear View 25mm Emotiv Inc. FCC ID: 2ADIH-EPOC03, IC: 12769A-EPOC03 EUT External Photograph – Bottom View EUT External Photograph – Left View Emotiv Inc. FCC ID: 2ADIH-EPOC03, IC: 12769A-EPOC03 EUT External Photograph – Right View EUT External Photograph – Antenna Location Antenna

Emotiv Inc. FCC ID: 2ADIH-EPOC03, IC: 12769A-EPOC03 Annex C (Normative) – EUT Internal Photographs EUT Internal – Main Connection EUT Internal – Right Side Open Case View Emotiv Inc. FCC ID: 2ADIH-EPOC03, IC: 12769A-EPOC03 EUT Internal – Radio PCB – Bottom View EUT Internal – Radio PCB – Top View Antenna Emotiv Inc. FCC ID: 2ADIH-EPOC03, IC: 12769A-EPOC03 EUT Internal – Right Analog PCB – Top View EUT Internal – Right Analog PCB – Bottom View Emotiv Inc. FCC ID: 2ADIH-EPOC03, IC: 12769A-EPOC03 EUT Internal – Left Analog PCB – Top View EUT Internal – Left Analog PCB – Bottom View Emotiv Inc. FCC ID: 2ADIH-EPOC03, IC: 12769A-EPOC03 EUT Internal – Battery

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by A2LA*, NIST, or any agency of the Federal Government. * This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “*” (Rev.2) FCC PART 15, SUBPART C ISEDC RSS-247, ISSUE 2, FEBRUARY 2017 TEST AND MEASUREMENT REPORT For Emotiv Inc. 490 Post St., Suite 824, San Francisco, CA 94102, USA FCC ID: 2ADIH-EPOC03 IC: 12769A-EPOC03 R e p o r t T y p e : O r i gi n a l R e p o r t P r o d u c t T y p e: M o b i l e B C I H e a d s e t , G a mi n g I n t e r f a c e Prepared By: Matthew Riego de Dios Test Technician Report Number: R2002182-247 Report Issue Date: 2020-03-04 Reviewed By: Simon Ma RF Supervisor Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue, Sunnyvale, CA 94089, USA Tel: +1 (408) 732-9162, Fax: +1 (408) 732-9164 Emotiv Inc. FCC ID: 2ADIH-EPOC03, IC: 12769A-EPOC03 Report Number: R2002182-247 Page 2 of 44 FCC Part 15C/ISEDC RSS-247 Test Report DOCUMENT REVISION HISTORY Revision Number Report Number Description of Revision Date of Revision 0 R2002182-247 Original Report 2020-03-04 Emotiv Inc. FCC ID: 2ADIH-EPOC03, IC: 12769A-EPOC03 Report Number: R2002182-247 Page 3 of 44 FCC Part 15C/ISEDC RSS-247 Test Report TABLE OF CONTENTS 1 General Description ..................................................................................................................................................... 5 1.1 Product Description for Equipment Under Test (EUT) ...................................................................................... 5 1.2 Mechanical Description of EUT ......................................................................................................................... 5 1.3 Objective ............................................................................................................................................................. 5 1.4 Related Submittal(s)/Grant(s) ............................................................................................................................. 5 1.5 Test Methodology ............................................................................................................................................... 5 1.6 Measurement Uncertainty ................................................................................................................................... 6 1.7 Test Facility Registrations .................................................................................................................................. 6 1.8 Test Facility Accreditations ................................................................................................................................ 7 2 System Test Configuration.......................................................................................................................................... 9 2.1 Justification ......................................................................................................................................................... 9 2.2 EUT Exercise Software....................................................................................................................................... 9 2.3 Equipment Modifications.................................................................................................................................... 9 2.4 Local Support Equipment ................................................................................................................................... 9 2.5 Support Equipment ............................................................................................................................................. 9 2.6 Interface Ports and Cabling ................................................................................................................................. 9 3 Summary of Test Results ............................................................................................................................................ 10 4 FCC §15.203 & ISEDC RSS-Gen §6.8 - Antenna Requirements ............................................................................ 11 4.1 Applicable Standards ........................................................................................................................................ 11 4.2 Antenna Description ......................................................................................................................................... 11 5 FCC §2.1093 & ISEDC RSS-102 - RF Exposure ...................................................................................................... 12 5.1 Applicable Standards ........................................................................................................................................ 12 5.2 RF Exposure Evaluation Exemption for FCC ................................................................................................... 14 5.3 RF Exposure Evaluation Exemption for ISED ................................................................................................. 14 6 FCC §15.207 & ISEDC RSS-Gen §8.8 – AC Line Conducted Emissions ............................................................... 15 6.1 Applicable Standards ........................................................................................................................................ 15 6.2 Test Setup ......................................................................................................................................................... 15 6.3 Test Procedure .........................................................................................................…

Text truncated - open the document above for the full version.

Emotiv Inc. FCC ID: 2ADIH-EPOC03, IC: 12769A-EPOC03 Annex A (Normative) – Test Setup Photographs Radiated Spurious Emissions Test: Below 1 GHz – Front View Radiated Spurious Emissions Test: Below 1 GHz – Rear View Emotiv Inc. FCC ID: 2ADIH-EPOC03, IC: 12769A-EPOC03 Radiated Spurious Emissions Test: 1 – 18 GHz – 3 meters – Front View Radiated Spurious Emissions Test: 1 – 18 GHz – 3 meters – Rear View Emotiv Inc. FCC ID: 2ADIH-EPOC03, IC: 12769A-EPOC03 Radiated Spurious Emissions Test: 1 – 18 GHz – 1 meter – Front View Radiated Spurious Emissions Test: 1 – 18 GHz – 1 meter – Rear View Emotiv Inc. FCC ID: 2ADIH-EPOC03, IC: 12769A-EPOC03 Radiated Spurious Emissions Test: 18 – 26.5 GHz – 1 meter – Front View Radiated Spurious Emissions Test: 18 – 26.5 GHz – 1 meter – Rear View Emotiv Inc. FCC ID: 2ADIH-EPOC03, IC: 12769A-EPOC03 AC Line Conducted Test – Front View AC Line Conducted Test – Side View
