2ADIH-INSIGHT01Dongle

Emotiv Insight User Manual Revision 1.0 June 2015 © Emotiv Inc, 2015 Before first use - check the parts are in the box - assemble the Insight - charge the Insight - obtain software - check operation - read safety warnings Assembling the Insight Step 1: Attach the rear arm to the Insight. Step 2: Attach the sensors to the arms. Charging the Insight Plug the cable into the Insight (see diagram) ensuring the connector is fully inserted. Attach the cable to an active USB port on your PC or a USB charger. Note the device requires 5V supply and will draw a maximum of 0.5A from the charge port. If plugged into a USB port on your PC, the Insight will check for the maximum available current from the port up to a limit of 0.5A. Note that if the port does not support extended power mode, Insight will draw 0.1A and will charge much more slowly. Try a different USB port if Insight takes more than 2 hours to reach full charge. Turning On the Headset The Insight’s power switch is above the charging port. A white light above the Emotiv logo indicates the headset is on. *** diagram Pairing the Headset Devices with Bluetooth(™) 4.0 SMART Low Energy (BTLE): The Insight can pair using BTLE. Make sure that your device’s Bluetooth connection is turned on. The headset should pair automatically. Note that not all Bluetooth 4.0 devices support the SMART (low energy) protocol. You may need to purchase an adaptor for use with some PCs and older Macs. See www.emotiv.com for recommended BTLE adaptors. Using an Emotiv Universal USB Receiver (OPTIONAL): Plug the receiver into your device’s USB port. There are two LEDs on the device which indicate connection status. When first plugged into the USB port, one green LED will flash slowly. When a headset is paired, that indicator LED will flicker rapidly and a second LED will glow continuously. If the second LED is blinking slowly the headset has passed out of range or switched off, and the receiver will wait to reestablish contact with the same headset. If you wish to pair that receiver with a different headset, unplug the receiver and re-insert it. If you have problems establishing contact, make sure all other receivers are unplugged, all local Bluetooth devices are currently turned off, then reinsert the receiver and try again. You may also try turning the headset off and on again to establish a connection. Emotiv Universal USB Receiver States: Fitting the Headset DO NOT spread the headset open to fit it. Gently slide the headset onto the head. The reference sensors, which are on the black arm, should make contact with the skin behind the ear. If necessary, gently bend the reference sensor arm so that the sensors make contact with the skin. The frontal sensors should be positioned about three finger widths above the eyebrows. Obtaining Good Contact Quality Placement of the reference arm is critical for successful operation. The reference arm is the black tab which sits directly behind the left ear. The arm is designed to bend and may be positioned to suit the user. The two sensors on the reference arm must make contact with the patch of bare skin directly behind the ear. The sensor should be positioned so that it follows the angle of the rear of the ear, sits flat and parallel on the skin and has light, but definite pressure so that it is not displaced by moving the head. The following figure shows the available adjustments and the recommended placement of the sensor. As the Insight sensors establish and maintain contact, it may take a minute or so for the signal quality to stabilize. If sensor indicators remain red or black, check that the sensors are making comfortable but firm contact with the scalp. Try parting the hair or gently working the sensor underneath the hair. Press and hold the sensor against the scalp for a few seconds to establish better contact quality. If the contact quality does not improve, try moistening the sensor with the rehydration solution. Although the majority of indicator lights should be green, the detections will usually tolerate input if a few sensors are orange or red, even with one or two black sensors depending on the detection and which sensors are missing. Adjust the reference sensors so that their indicator lights are green. Safety: Please note the following safety considerations: CHOKING HAZARD – detachable small parts. Keep away from small children. DO NOT attach the Insight to the charger or USB connector while in use. AWAYS remove the Insight during charging and avoid touching the sensors if fitted. Although unlikely, an insulation failure in the charger or USB source may cause the Insight to become live. Insight will automatically enter sleep mode while attached to the charger, so it is not possible to extend use while charging. Insight may be operated while charging ONLY when used in conjunction with the Emotiv Extender product. WARNING: Radio emissions may interfere with appliances and medical equipment including heart pacemakers and automated medical dosimetry systems. Use with caution. WARNING: Discontinue use if the system becomes uncomfortable to wear or if skin irritation occurs. Users are advised not to share sets of sensors to avoid cross-infection risks. Regulatory Requirements: USA: FCC Requirements Part 15 This device complies with Part 15 of the FCC Rules (CFR47). Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communic…

Text truncated - open the document above for the full version.

Declaration of Authorization We Name: Emotiv, Inc Address: 490 Post St, Suite 824 City: San Francisco CA 94102 Country: USA Declare that: Name (Representative Agent): Diana Williams Agent Company name: Compliance Testing, LLC Address: 1724 S. Nevada Way Mesa, AZ 85204 Country: USA is authorized to apply for Certification of the following products(s): Product description: Insight Model 1.0 Neuroheadset Type Designation – FCC ID: 2ADIH-INSIGHT01 Trademark: Emotiv Insight on our behalf. Date: April 29 th , 2015 Name: Geoffrey Mackellar Function: Chief Technology Officer Notes: (1): Required for FCC application. (2): For FCC it must be the Grantee Code “owner” or “authorized agent”. Emotiv Inc 490 Post Street, Suite 824 San Francisco, CA 94102 USA Emotiv Research Pty Ltd ABN 82 149 846 980 145/4 Cornwallis Street Eveleigh NSW 2015 Australia Email [email protected] URL www.emotiv.com

March 5 th , 2015 Compliance Testing LLC 1724 S. Nevada Way Mesa, AZ 85204 RE: CONFIDENTIALITY REQUEST FOR EMOTIV Insight Model 1.0 FCC: 2ADIH-INSIGHT01 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the following documents required to be submitted with this application be permanently withheld from public review.  Block Diagram  Bill of Materials  Schematics  Theory of Operation These documents contain detailed system and equipment descriptions and related information about the product, which manufacturer/applicant considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, manufacturer/applicant feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Geoffrey Mackellar PhD Chief Technology Officer Emotiv Inc Phone: (415) 817 9885 Email: [email protected] Emotiv Inc 490 Post Street, Suite 824 San Francisco, CA 94102 USA Emotiv Research Pty Ltd ABN 82 149 846 980 145/4 Cornwallis Street Eveleigh NSW 2015 Australia Email [email protected] URL www.emotiv.com

Form: CB-7.2.1 Issued by: QM Issue Date: 9/22/2011 Page 1 of 1 Revised by: QM-JS Revised Date: 6/23/2014 L:\Project\2015\p1530017-Emotiv Re\TCB Folder\RT's\CB-7.2.1 - Technical Review RT Form.docx CB-7.2.1 – Technical Review RT Form FCC ID: 2ADIH-INSIGHT01 IC ID: 12769A-INSIGHT01 CT Project: P1530017 From: Shawn Date: 07-09-2015 1--The RF exposure if for fixed/mobile however the headset is meant for portable use. CT – Updated RF exposure report. 2--In the 15.249 test report section 15.215 needs to be addressed. CT – Added 15.215 to test result summary within the test report. CT - Response by: Submitted by: Date:

COLOUR SPECIFICATION - PMS WHITE ON BLACK DO NOT PRINT THE RED LINE WORK. THIS IS FOR POSITIONAL LAYOUT ONLY. 17.70 31.20 PRINT ARTWORK POSITION OF ARTWORK 2230 G809 F- Insight Decal - Black 09.07.2015 Emotiv Insight™ Model 1.0 Made in China BLACK HEADSET DECAL Emotiv Insight™ Model 1.0 Made in China CAUTION - CHOKING HAZARD Keep small parts away from children Do not wear headset while charging FCC ID: 2ADIH-INSIGHT01 IC: 12769A-INSIGHT01 CAUTION - CHOKING HAZARD Keep small parts away from children Do not wear headset while charging FCC ID: 2ADIH-INSIGHT01 IC: 12769A-INSIGHT01

p1530017_FCC_Part 1.1310_Rev 2.0 Page 1 of 4 Test Report Prepared for: Emotiv Inc. Model: Insight Description: Wireless Neurological Headset Serial Number: N/A FCC ID: 2ADIH-INSIGHT01 To FCC Part 1.1310 Date of Issue: July 15, 2015 On the behalf of the applicant: Emotiv Inc. 490 Post Street Suite 824 San Francisco, CA 94102 Attention of: Geoffrey Mackellar, CTO Ph: (415) 828-9895 E-Mail: [email protected] Prepared By Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p14a0008 Alex Macon Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing All results contained herein relate only to the sample tested p1530017_FCC_Part 1.1310_Rev 2.0 Page 2 of 4 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 April 21, 2015 Alex Macon Original Document 2.0 July 15, 2015 Alex Macon Corrected category of device to portable. p1530017_FCC_Part 1.1310_Rev 2.0 Page 3 of 4 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer joint ISO-ILAC-IAF Communiqué dated January 2009) The tests results contained within this test report all fall within our scope of accreditation, unless below Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC Site Reg. #349717 IC Site Reg. #2044A-2 Non-accredited tests contained in this report: N/A EUT Description Model: Insight Description: Wireless Neurological Headset S/N: N/A Additional Information: None p1530017_FCC_Part 1.1310_Rev 2.0 Page 4 of 4 MPE Evaluation This is a portable headset device used in Uncontrolled Exposure environment. Measurement Result Tuned Frequency Conducted Peak Output power (100% Duty Cycle) RF Exposure Limit 2402 MHz 0.024 mW 3.0 This is a portable device as it is a hand-held transmitter paired with a receiver collar which is used in a dog training application. The SAR exclusion from KDB 447498 Appendix C being applied. Exclusion Ratio Formula 1 from Section 4.3.1 of KDB 447498 D01 [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, 25 where [(0.024)/(5)] * [[√2.402)] 0.0048 * 1.5498 = 0.0074 PER the exclusion requirement of KDB 447498 a SAR measurement is not necessary. END OF TEST REPORT

p1530017_FCC_Part 15.247_DTS_Rev 1.0 Page 1 of 24 Test Report Prepared for: Emotiv Inc. Model: Insight Description: Wireless Neurological Headset Serial Number: N/A FCC ID: 2ADIH-INSIGHT01 IC: 12769A-INSIGHT01 To FCC Part 15.247 DTS Date of Issue: April 30, 2015 On the behalf of the applicant: Emotiv Inc. 490 Post Street Suite 824 San Francisco, CA 94102 Attention of: Geoffrey Mackellar, CTO Ph: (415) 828-9895 E-Mail: [email protected] Prepared By Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 (480) 926-3100 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p1530017 Alex Macon Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing. All results contained herein relate only to the sample tested. p1530017_FCC_Part 15.247_DTS_Rev 1.0 Page 2 of 24 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 April 9, 2015 Alex Macon Original Document p1530017_FCC_Part 15.247_DTS_Rev 1.0 Page 3 of 24 Table of Contents Description Page Standard Test Conditions Engineering Practices 6 Peak Output Power 9 Radiated Spurious Emissions 10 Emissions at Band Edges 12 Occupied Bandwidth 16 Transmitter Power Spectral Density (PSD) 19 A/C Powerline Conducted Emission 22 Test Equipment Utilized 24 p1530017_FCC_Part 15.247_DTS_Rev 1.0 Page 4 of 24 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer to the joint ISO-ILAC-IAF Communiqué dated January 2009). The tests results contained within this test report all fall within our scope of accreditation, unless noted below. Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC Site Reg. #349717 IC Site Reg. #2044A-2 Non-accredited tests contained in this report: N/A p1530017_FCC_Part 15.247_DTS_Rev 1.0 Page 5 of 24 The applicant has been cautioned as to the following 15.21 - Information to User The user’s manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 15.27(a) - Special Accessories Equipment marked to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer without an additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. p1530017_FCC_Part 15.247_DTS_Rev 1.0 Page 6 of 24 Standard Test Conditions Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing: In accordance with ANSI C63.10-2009 and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104°F) unless the particular equipment requirements specified testing over a different temperature range. Also, unless otherwise indicated, the humidity levels were in the range of 10% to 90% relative humidity. Measurement results, unless otherwise noted, are worst-case measurements. Environmental Conditions Temperature (ºC) Humidity (%) Pressure (mbar) 24.2 – 25.3 28.7 – 32.4 964.5 – 967.7 EUT Description Model: Insight Description: Wireless Neurological Headset Serial Number: N/A Software: Nordic Semiconductor Master Control Panel Additional Information: The device is a Wireless Neurological Headset transceiver, which communicates to a USB transceiver connected to a personal computer. The link between the headset transceiver and USB transceiver transmits data continuously and is required for proper operation of the product. The device incorporates an integral antenna; all measurements are done by radiated means. EUT Operation during Tests The Client has provided several dongles to place the EUT in High Mid and Low channels and also a dongle for normal operation p1530017_FCC_Part 15.247_DTS_Rev 1.0 Page 7 of 24 Accessories: Qty Description Manufacturer Model S/N 1 Bluetooth Dongle Nordic Semiconductor PCA10000 N/A Cables: None Modifications: None 15.203: Antenna Requirement: X The antenna is permanently attached to the EUT The antenna uses a unique coupling The EUT must be professionally installed The antenna requirement does not apply p1530017_FCC_Part 15.247_DTS_Rev 1.0 Page 8 of 24 Test Reports Summary Specification Test Name Pass, Fail, N/A Comments 15.247(b)(3) Peak Output Power Pass 15.247(b) Conducted Spurious Emissions N/A All measurements are taken by radiated means 15.247(d), 15.209(a), 15.205 Radiated Spurious Emissions Pass 15.247(d), 15.209(a), 15.205 Emissions At Band Edges…

Text truncated - open the document above for the full version.

Test Setup Photos FCC ID: 2ADIH-INSIGHT01 IC: 12769A-INSIGHT01 RF Radiated #1 RF Radiated #2 Test Setup Photos FCC ID: 2ADIH-INSIGHT01 IC: 12769A-INSIGHT01 A/C Powerline Conduction #1 A/C Powerline Conduction #2
