2ADMB-ALBERT-BTBT Device

Smart Robot albert Guide Book Guide Book Smart Robot albert Contents Play with albert Get Ready to Play with albert Get to Know albert Get to Know Get Ready to Play Play with Albert Service Service albert's Configuration Name and Function of Each Components albert's Hardware Name and Function of Each Component in Peripheral Devices albert's Remote Control albert's Story Glutton Alien Hurly-Burly Kids market Application Overview albert Doesn't Like This Install the Smart Robot Launcher Register the Robot and Peripheral Devices Get Ready to Play with albert Service Specification Warranty Card Precautions 04 05 Get to Know albert! Get to know my robot friend, albert. 06 albert’s Configuration Geniekids Touch Book 1 ~ 5 Word List 1 * Charging cable is not included. Please use Micro 5-Pin charger. Alien Mukkaebi Card (56 pcs) Hurly-Burly Kids market Smart pen & Stand albert's Main Body Smartphone Stand (Big, medium, small) Smart Dice ON 07 Front OID sensor Rear OID sensor Name and Function of Each Components Size (W x L x H): 11.5 cm x 11.6 cm x 12.8 cm / Weight: 250 g Eye LED Proximity sensor receiver Mobile phone stand (top) Mobile phone stand (bottom) Battery checkrer Right distant sensor Card reading sensor Left distant sensor Charging /Bluetooth indicator lamp Accessory fixation Power switch Side LED USB charging slot Power wheel Speaker Caster Mount stand on albert's front side depending on your smart phone size. The autonomic mode will begin six seconds after turning on a power switch of Albert. Control Albert by blocking the left and right proximity sensor with your hand. Power goes on when power button is moved to the right. Power goes off when power button is moved to the left. Connect your smart phone charger (Micro 5pin charger) to the charging terminal in the rear of robot main body and charge. Separate charger when red charging light in the front of robot main body goes off. Autonomic Mode Smart InstallationTurn on the power switch How to charge robot with a click Push and fix Lift and fix Charge slot Charging 08 albert’s Hardware Internal Sensor Proximity Sensor x 2, OID Sensor x 2, Acceleration Sensor Light Sensor, Temperature Sensor, Battery Level Sensor Wireless Auto Connection Bluetooth Battery Lasting Time Battery Lasting Time, 5 hours for Continuous Operation, 7 days for Standby (Lithium-Polymer Battery) Driving Part 2 Wheels, Speaker, Buzzer, Full-Color LED for Eye x 2, Card reading sensor Side LED x 2 Display Part Battery Indicator (Red) Bluetooth Indicator (Blue) Cradle Function Smart Phone Holding Name and Function of Each Component in Peripheral Devices 09 Smart Dice Name and Function of Each Component in Peripheral Devices Smart Pen Smart Pen is one of the peripheral devices of Smart Robot that reads 65,535 invisible codes printed in books or cards by using optical ID sensor. Smart Pen and Smart Robot are connected through Bluetooth communication. Smart Robot sends data of Smart Pen to the launcher and application. Smart Dice is one of the peripheral devices of Smart Robot that recognizes the spots on the dice. Smart Dice and Smart Robot are connected through Bluetooth communication. Smart Robot sends data of Smart Dice to the launcher and application. OID Sensor Bluetooth Indicator Botton Recharging Indicator Recharging Terminal Bluetooth Indicator Recharging Terminal Recharging Indicator 10 11 Get Ready to Play with albert! Get ready to make albert move! TIP 12 Install the Smart Robot Launcher. Smart Robot LauncherSmart Robot Launcher Search Smart Robot Launcher Download Touch Google Play Store .Search and touch Smart Robot Launcher. Touch Installation and down- load Launcher, and app will be installed on screen. Smart Robot Launcher Start Start Smart Robot Launcher and turn power on, and Robot will be recognized automatically. Do not skip ‘Search Robot that will be registered ‘ page. End Launcher and Robot and make recon- nection. Check if smart phone Bluetooth is turned on. 1 2 TIP TIP 13 Register the Robot and Peripheral Devices. Robot ConnectionPeripheral Device Registration Smart Pen RegistrationSmart Dice Registration Touch End after inputting the name, and screen will be moved to the wallpaper. Touch Robots tab on bottom of screen and register Smart Dice or Smart Pen in Periph- eral Device menu. Touch Registration button on bottom of screen and push Smart Pen button. Touch Registration button on bottom of screen. It will be automatically registered when Smart Dice is thrown 10 cm or higher in the air. If red light shows up when pushing Smart Pen button, it means that battery level is low. Therefore, charge it before use. Robot makes no sound or Robot makes no or slow movement after connection. Disconnect Robot, turn off both Smart Phone and Robot, and then make reconnection. TIP 14 Robot Deletion & Reconnection App Download Touch ‘Smart Robot Market’ on the wallpaper, and download and install the app in the market. Contents Use Touch the app in the folder created on the wallpaper, and use contents. Touch Robot tab on bottom and touch Recycle Bin, and Robot will be deleted. Adobe AIR Installation Search and install “Adobe AIR” in Google Play Store. If Robot does not work normally, check the battery or delete Robot and reconnect it. 1. Start albert app. 2. Installation page shows up automatically. 3. Start installation, and screen will move to Google Play Store. 4. Install Adobe AIR 5. Push Back button on smart phone and return to Smart Robot Launcher. 6. Now use the app. Get Ready to Play with albert 15 Peripherals Deletion & Reconnection Touch Robots tab on bottom and go to the Peripheral device registration menu. Touch the Recycle Bin but- ton on the top. This will delete the peripheral device. Recharging Problem Solution Tip! 1. Connect smart phone charger with albert or peripheral device. 2. When charging the battery of albert or peripheral device, battery lamp is turned red, and When charging is completed, the light is turned off. 1. Robot makes no or s…

Text truncated - open the document above for the full version.

21 You can enjoy a digging game in the middle of the story through the sensor on the bottom of the front side of albert. You can enjoy a puzzle game with albert. If your puzzle is correct or wrong, albert reacts in different ways. Do you want to know why my friend albert came to Earth? Enjoy various events and listen to albert’s story. albert’s Story 22 Check preparations! Geni Touch Book is started. Click book cover shaped icon and start app. Turn page and control volume with smart pen in albert volume control section. Start learning English with albert’s Story Telling Book. Story Telling Book 23 Select a certain word and word list will show up~ Click Game button and interesting game will start. Select Touch button and animation will show up on smart phone screen. After all pages end, interesting quiz that ask questions about book contents will show up. Select Quiz button on left top of book, and quiz will start. Quiz checks kids’ concentration on book contents and arouses kids’ interest in learning. Story Telling Touch smart pen on top menu on the right of page, albert reads the story of the corresponding page. English/Korean Translation Touch smart pen on second menu on the right of page, English-Korean or Korean-English translation will be made. Photo Taking Touch smart pen on third menu on the right of page, kid’s face will show up on story character in story. Start learning English with albert’s Story Telling Book. Story Telling Book 24 Prepare required things. (56 albert English Learning Cards) Select Game Method on the main screen and check how to use it. Install smart phone on albert and start Alien Mukkaebi in the launcher. Learn the game method and Select Start. albert eats vocabulary cards! Give albert the cards he wants and learn new vocabulary! Alien Mukkaebi 25 Insert the card you want under the belly of Albert. If Mukkaebi wants a certain card, find and give it to him. Mukkaebi reads the word and transforms himself. albert eats vocabulary cards! Give albert the cards he wants and learn new vocabulary! Alien Mukkaebi 26 Each player selects a shop. If albert wants a thing, insert the corresponding card under the belly of albert and sell it. After that, throw the dice, and albert will move to another shop. Insert the cash card and give the change. The player who sold things most will win the game. How about opening a store with albert and selling items? Let’s see who sells more! Hurly-Burly Kids market 27 Single Play Prepare the required things (smart phone, robot, smart dice, board+card) albert moves according to the number on the dice. Insert the corresponding card under the belly of albert. Install your smart phone on albert and start Hurly-Burly Kids market. After selling things, give the change. Select Single Play on the main screen. Throw another dice and sell things in another shop. If albert is ready, throw the dice. How about opening a store with albert and selling items? Let’s see who sells more! Hurly-Burly Kids market 28 Start Multi Play on the main screen.Select the number of players who will play Shop Game. The first player selects a shop. Move in front of the fruit shop according to the direction. The second and third players select a shop and move to it. The player who sold things most will win the game. Now start the game. How about opening a store with albert and selling items? Let’s see who sells more! Multi Play Kids market Application List 29 Blue SoccerRed Soccer M-gabbi card-2 Albert Contr ollerAlbert Stor y 1Albert Stor y 2Albert Stor y 3Albert Stor y 4Albert Stor y 5Smart Circus 1Smart Circus 2 My friend Albert Shopping GameM-gabbi card Board gameEnglish cards Geni Touch Book 1Geni Touch Book 2Geni Touch Book 3Geni Touch Book 4 Geni Touch Book 5 English story books Geni Touch Book 10Geni Touch Book 6Geni Touch Book 7Geni Touch Book 8Geni Touch Book 9 English story books English cards Basic-Package Contents A1-Package Contents Optional -Package Contents *You can see more Contents at Robot Market. 30 Smart Robot albert Please don’t throw or kick albert. Please don’t spill water or beverage on albert. Please handle albert with care when he is turned off. albert Doesn’t Like This! 31 Guide Book Do not use force to connect or disconnect your sma rtphone. The smartphone stand could break. The smart pen sensor is in the touch book. Please don’t tear or wrinkle the Touch Book. Please don’t spill liquid on the vocabulary cards and board or stain them. albert Doesn’t Like This! 32 33 Service 34 Consumers have the right to receive free-of-charge service during the 12 months period starting from the date of the purchase in the case of prod- uct failure during use. However, in the event of failure arising from misuse on consumer’s part or failure due to natural disaster, any service related to such failures will be charged even during the period of free service. * Warranty period for the battery is 6 months after the date of the purchase. Service at a cost In the event of following circumstances, consumer will be charged for any services provided even within the free service period. 1. Not product failure - Service charge will occur when service is requested and no malfunction or defect is found to be present. We strongly recommend all users to read the manual to become familiar with the product. 2. Failure by user’s misusage - Failure by unstable input power and connection with faulty devices. - Failure by inserting foreign substance into the robot. - Failure by accidental dropping and external shock on the robot. - Failure by disassembling robot at user’s own discretion and part missing arisin from user’s disassembly. - Exterior damage and deformation by using corrosive solution or liquid such as thinner and benzene. - Failure by not following cautions, warning articles described on the manual. - Failure by user’s mistake, misusage or failure caused by external factors. 3. Others - Failure by natural disaster (such as thunderbolt, fire, storm, flood, sea water,…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 5.0 Jan. 08, 2015 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, SK Telecom Co., Ltd. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (BT Device, albert-BT) FCC ID: 2ADMB-ALBERT-BT Sincerely, Client’s signature: Client’s name / title: Ji young Park / Manager Contact information / address: 82-2-6100-7346 / SK T-Tower, 65, Eulji-ro, Jung-gu, Seoul 100-999 South Korea

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 3.0 Jan. 08, 2015 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ADMB-ALBERT-BT We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description - e.g. Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title: Ji young Park / Manager Contact information / address: 82-2-6100-7346 / SK T-Tower, 65, Eulji-ro, Jung-gu, Seoul 100-999 South Korea SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 3.0 Jan. 08, 2015 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: 2ADMB-ALBERT-BT To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days (please check one). - e.g. User Manual - e.g. Ext Photo - e.g. Int Photo - e.g. Test Photo The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Client’s signature: Client’s name / title: Ji young Park / Manager Contact information / address: 82-2-6100-7346 / SK T-Tower, 65, Eulji-ro, Jung-gu, Seoul 100-999 South Korea

SK Telecom Co., Ltd. SK T-Tower, 65, Eulji-ro, Jung-gu, Seoul 100-999 South Korea Date: Jan. 08, 2015 SIEMIC 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Letter of Authorization We, the undersigned, hereby authorize Harvey Sung of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCCID: 2ADMB-ALBERT-BT signing of all documents relating to these matters. Any and all acts carried out by Harvey Sung of DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from SK Telecom Co., Ltd. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Ji young Park Manager

FCCID: 2ADMB-ALBERT-BT Copyright Ⓒ 2015 DT&C Co., Ltd. Page 1 / 3 View 1 FCCID: 2ADMB-ALBERT-BT Copyright Ⓒ 2015 DT&C Co., Ltd. Page 2 / 3 View 2 FCCID: 2ADMB-ALBERT-BT Copyright Ⓒ 2015 DT&C Co., Ltd. Page 3 / 3 View 3

FCC ID: 2ADMB-ALBERT-BT Copyright Ⓒ 2015, DT&C Co., Ltd. FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included on this label. - The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the user's manual.

FCCID: 2ADMB-ALBERT-BT Copyright Ⓒ 2015 DT&C Co., Ltd. Page 1 / 7 View 1 FCCID: 2ADMB-ALBERT-BT Copyright Ⓒ 2015 DT&C Co., Ltd. Page 2 / 7 View 2 FCCID: 2ADMB-ALBERT-BT Copyright Ⓒ 2015 DT&C Co., Ltd. Page 3 / 7 View 3 <MAIN PCB BT LE ANT> FCCID: 2ADMB-ALBERT-BT Copyright Ⓒ 2015 DT&C Co., Ltd. Page 4 / 7 View 4 FCCID: 2ADMB-ALBERT-BT Copyright Ⓒ 2015 DT&C Co., Ltd. Page 5 / 7 View 5 FCCID: 2ADMB-ALBERT-BT Copyright Ⓒ 2015 DT&C Co., Ltd. Page 6 / 7 View 6 <BT ANT> FCCID: 2ADMB-ALBERT-BT Copyright Ⓒ 2015 DT&C Co., Ltd. Page 7 / 7 View 7

MHz mm = Typical Power: ± =[/]*[√] =Thus SAR for this device is not required. [Threshold at 50 mm in step 1) + (test separation distance - 50 mm)·( f(MHz)/150)] mW [Threshold at 50 mm in step 1) + (test separation distance - 50 mm)·10] mW 5 Step 2-1) SAR test exclusion thresholds for 100MHz to 1500MHz at test separationn distances > 50 mm =N/A 0.01 ≤ 3, for 1g SAR Copyright Ⓒ 2015, DT&C Co., Ltd. Step 2-2) SAR test exclusion thresholds for 1500MHz to 6GHz at test separationn distances > 50 mm =N/A 2480 - Min. test separation distance = mW -14.96 -14.50dBm - Min. transmitting frequency = dB-15.50dBm1.00 dBmMeasured Output Power: 2ADMB-ALBERT-BT 0.042.48 5 - Max. power with turn-up tolerance =0.035 UsedStep 1) SAR test exclusion thresholds for 100MHz to 6GHz at test separationn distances ≤ 50 mm = [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] FCC ID : Standalone SAR test exclusion considerations(BT LE) January 29, 2015 MHz mm = Typical Power: ± =[/]*[√] =Thus SAR for this device is not required. [Threshold at 50 mm in step 1) + (test separation distance - 50 mm)·( f(MHz)/150)] mW [Threshold at 50 mm in step 1) + (test separation distance - 50 mm)·10] mW Copyright Ⓒ 2015, DT&C Co., Ltd. Step 2-2) SAR test exclusion thresholds for 1500MHz to 6GHz at test separationn distances > 50 mm =N/A 0.03 ≤ 3, for 1g SAR Step 2-1) SAR test exclusion thresholds for 100MHz to 1500MHz at test separationn distances > 50 mm =N/A Step 1) SAR test exclusion thresholds for 100MHz to 6GHz at test separationn distances ≤ 50 mm =Used [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] 0.0952.48 -11.50dBm1.00dB Measured Output Power:-10.81dBm - Min. test separation distance =5 - Max. power with turn-up tolerance =-10.50dBm0.089mW FCC ID : 2ADMB-ALBERT-BT Standalone SAR test exclusion considerations(BT) January 29, 2015 - Min. transmitting frequency =2480

FCCID: 2ADMB-ALBERT-BT DTNC1412-05413 Report No.: DRTFCC1501-0015 TRF-RF-219(00)130701 Page2 / 33 Copyright ○ C 2015, DT&C Co., Ltd. Test Report Version Test Report No. Date Description DRTFCC1501-0015 Jan. 26, 2015 Initial issue FCCID: 2ADMB-ALBERT-BT DTNC1412-05413 Report No.: DRTFCC1501-0015 TRF-RF-219(00)130701 Page3 / 33 Copyright ○ C 2015, DT&C Co., Ltd. Table of Contents 1. GENERAL INFORMATION ........................................................ 4 2. EUT DESCRIPTION ................................................................... 4 3. SUMMARY OF TESTS ............................................................... 5 4. TEST METHODOLOGY ............................................................. 6 4.1 EUT CONFIGURATION ..................................................................................... 6 4.2 EUT EXERCISE ................................................................................................. 6 4.3 GENERAL TEST PROCEDURES ...................................................................... 6 4.4 DESCRIPTION OF TEST MODES ..................................................................... 6 5. INSTRUMENT CALIBRATION ................................................... 7 6. FACILITIES AND ACCREDITATIONS ........................................ 7 6.1 FACILITIES ........................................................................................................ 7 6.2 EQUIPMENT ...................................................................................................... 7 7. ANTENNA REQUIREMENTS ..................................................... 7 8. TEST RESULT ........................................................................... 8 8.1 6dB Bandwidth Measurement .......................................................................... 8 8.2 Maximum Peak Conducted Output Power .................................................... 11 8.3 Maximum Power Spectral Density. ................................................................ 14 8.4 Out of Band Emissions at the Band Edge/ Conducted Spurious Emissions17 8.5 Radiated Measurement. .................................................................................. 26 8.5.1 Radiated Spurious Emissions. .................................................................. 26 8.6 POWERLINE CONDUCTED EMISSIONS ........................................................ 29 8.7 Occupied Bandwidth ...................................................................................... 30 9. LIST OF TEST EQUIPMENT .................................................... 31 APPENDIX I ................................................................................. 32 APPENDIX II ................................................................................ 33 FCCID: 2ADMB-ALBERT-BT DTNC1412-05413 Report No.: DRTFCC1501-0015 TRF-RF-219(00)130701 Page4 / 33 Copyright ○ C 2015, DT&C Co., Ltd. 1. GENERAL INFORMATION Applicant : SK Telecom Co., Ltd. Address : SK T-Tower, 65, Eulji-ro, Jung-gu, Seoul 100-999 South Korea FCC ID : 2ADMB-ALBERT-BT EUT : BT Device Model : albert-BT Additional Model(s) : N/A Data of Test : 2014-12-09 ~ 2014-12-23 Contact person : Ji young Park 2. EUT DESCRIPTION Product BT Device Model Name albert-BT Power Supply DC 3.7 V Battery type Standard Battery: Lithium Ion Battery Frequency Range 2402 ~ 2480MHz (40 channels) Max. RF Output Power -14.96 dBm Modulation Type GFSK Antenna Specification Antenna Type: Internal Antenna Gain: 5.300 dBi(PK) FCCID: 2ADMB-ALBERT-BT DTNC1412-05413 Report No.: DRTFCC1501-0015 TRF-RF-219(00)130701 Page5 / 33 Copyright ○ C 2015, DT&C Co., Ltd. 3. SUMMARY OF TESTS FCC Part Section(s) RSS Section(s) Parameter Limit Test Condition Status Note 1 I. Transmitter Mode (TX) 15.247(a) RSS-210 [A8.2] 6 dB Bandwidth > 500 kHz Conducted C 15.247(b) RSS-210 [A8.4] Transmitter Output Power < 1Watt C 15.247(d) RSS-210 [A8.5] Out of Band Emissions / Band Edge 20dBc in any 100kHz BW C 15.247(e) RSS-210 [A8.2] Transmitter Power Spectral Density < 8dBm / 3kHz C - RSS Gen [6.6] Occupied Bandwidth (99%) RSS-Gen NA 15.205 15.209 RSS-210 [A8.5] General Field Strength Limits (Restricted Bands and Radiated Emission Limits) < FCC 15.209 limits Radiated C Note2 15.207 RSS-Gen [8.8] AC Conducted Emissions < FCC 15.207 limits AC Line Conducted NA Note3 15.203 - Antenna Requirements FCC 15.203 - C Note 1: C=Comply NC=Not Comply NT=Not Tested NA=Not Applicable Note 2: This test item was performed in each axis and the worst case data was reported. Note 3: The power supply of this device is only DC (Internal Battery) and Bluetooth LE function is disabled in charging status. FCCID: 2ADMB-ALBERT-BT DTNC1412-05413 Report No.: DRTFCC1501-0015 TRF-RF-219(00)130701 Page6 / 33 Copyright ○ C 2015, DT&C Co., Ltd. 4. TEST METHODOLOGY Generally the tests were performed according to the KDB558074 v03r02. And ANSI C63.10-2009 was used to reference appropriate EUT setup and maximizing procedures of radiated spurious emission and AC line conducted emission testing. 4.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 4.2 EUT EXERCISE The EUT was operated in the test mode to fix the TX frequency that was for the purpose of the measurements. According to its specifications, the EUT must comply with the requirements of the Section 15.207, 15.209 and 15.247 under the FCC Rules Part 15 Subpart C. 4.3 GENERAL TEST PROCEDURES Conducted Emissions According to the requirements in Section 6.2 of ANSI C63.10, the EUT is placed on the non-conductive table, which is 0.8 m above ground plane and the conducted emissions from the EUT are measured in the frequency range between 0.15 MHz and 30MHz using CISPR Quasi-peak and Average detector. Radiated Emissions The EUT is placed on a non-conductive table, which is …

Text truncated - open the document above for the full version.

FCC ID: 2ADMB-ALBERT-BT Copyright Ⓒ 2015, DT&C Co., Ltd. Test Setup photographs EUT Position: X-axis EUT Position: Y-axis EUT Position: Z-axis FCC ID: 2ADMB-ALBERT-BT Copyright Ⓒ 2015, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (0.009 ~ 30MHz) FCC ID: 2ADMB-ALBERT-BT Copyright Ⓒ 2015, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (below 1000MHz) FCC ID: 2ADMB-ALBERT-BT Copyright Ⓒ 2015, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (Above 1GHz)
