2ADNIR-660Bluetooth headphone

OperationInstructionsforLBH1008 Introductionoffunction: Withnovelheadsetdesign,thisprductenjoyedamemorynecklaceandmagnetic earbudsreceiveingdesign.ThisproductsupportsBluetoothV3.0+EDR,A2DPandcall. Whichguaranteeshighfidelity,stableperformanceandexcellentcommunication effect. (图片) Introductiontofunctionalkeys: 1.Key[Volumeup/down]:Bluetoothmusicplaystatus;Pressingtheup/downkey, thevolumwillincreaseordecreaseaccordingly. 2.Key[Answer/hangup]:Whenthepoweron,thered&bluelightswillflashcoming intopairingmodel.Whencallin,pressittoanswerthecallorendthecallor holdingit2sectorefusethecall. Whenansweringacall,pressingandholdingitfor2sectoswitchbetweenthe modesofmobilephoneandBluetoothearphone. 3.Key[Play/pause]:Whenplaythemusic,pressingthekeytopausethemusicor pressthekeytoplaythemusic. 4.Key[Sonenext/last]:Whenplaythemusic,pressthekeytobeforwardor backward. 5.Key[ON/OFF]:MovetheswitchtopositionONtoenterthesatusofmatching,and red&bluelightswillflash; 6.MovetheswitchtoOFFtoshutdowntheearphone. FCC Information and Copyright This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC RF warning statement: the device has been evaluated to meet general RF exposure requirement , The device can be used in portable exposure condition without restriction.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Worldlinks Communications, L.L.C. 2014-11-22 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ___ Worldlinks Communications, L.L.C._ hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： Bluetooth headphone Trade Name： N/A Model Name： R-660 Serial Model： YX-BT-X6 FCC ID： 2ADNIR-660 Sincerely, Signature Name: Elie Maloof Title: Manager Address: 270 Centre Drive, Suite 230, Vernon Hills, IL 60061, USA

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Worldlinks Communications, L.L.C. 2014/11/22 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ADNIR-660 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Name: Elie Maloof Title: Manager Address: 270 Centre Drive, Suite 230, Vernon Hills, IL 60061, USA

Worldlinks Communications, L.L.C. Model Difference FCC ID: 2ADNIR-660 Model : R-660, YX-BT-X6 All the model are the same circuit and RF module,except the model name and colour.Regards, Client’s signature Signature Name: Elie Maloof Title: Manager Address: 270 Centre Drive, Suite 230, Vernon Hills, IL 60061, USA

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID LABELING AND LOCATION FCC ID Label Bluetooth headphone Model NO.: R-660 FCC ID: 2ADNIR-660 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Antenna Photo 7

FCC ID : 2ADNIR-660 RF EXPOSURE EVALUATION METHOD FCC ID: 2ADNIR-660 SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Maximum measured transmitter power. BT 3.0 1Mbps Test Channel Frequency (MHz) Peak Output Power (dBm) Peak Output Power (mW) CH00 2402 1.444 1.394 CH39 2441 1.867 1.537 CH78 2480 1.906 1.551 2Mbps CH00 2402 0.904 1.231 CH39 2441 1.401 1.381 CH78 2480 1.446 1.395 3Mbps CH00 2402 1.403 1.381 CH39 2441 1.807 1.516 CH78 2480 1.711 1.483 Remark: The best case gain of the antenna is 1.0dBi. 1.0 dBi logarithmic terms convert to numeric result is nearly 1.26 FCC ID : 2ADNIR-660 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)] BT 3.0 Te s t Channel Range tune up max power (dBm) [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance,mm)] [f(GHz)] Result Limit 1Mbps CH00 0~2 2.0 1.585 5 2.402 0.491 3 CH39 0~2 2.0 1.585 5 2.441 0.495 3 CH78 0~2 2.0 1.585 5 2.480 0.499 3 2Mbps CH00 0~2 2.0 1.585 5 2.402 0.491 3 CH39 0~2 2.0 1.585 5 2.441 0.495 3 CH78 0~2 2.0 1.585 5 2.480 0.499 3 3Mbps CH00 0~2 2.0 1.585 5 2.402 0.491 3 CH39 0~2 2.0 1.585 5 2.441 0.495 3 CH78 0~2 2.0 1.585 5 2.480 0.499 3 The test Result is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Conclusion: No SAR is required.

FCC RADIO TEST REPORT-BT 3.0 FCC ID:2ADNIR-660 Product： Bluetooth headphone Trade Name： N/A Model Name： R-660 Serial Model： YX-BT-X6 Report No.： NTEK-2014NT10301863F Prepared for Worldlinks Communications, L.L.C. 270 Centre Drive, Suite 230, Vernon Hills, IL 60061, USA Prepared by NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 67 Report No.:NTEK-2014NT10301863F TEST RESULT CERTIFICATION Applicant’s name ................. : Worldlinks Communications, L.L.C. Address ................................. : 270 Centre Drive, Suite 230, Vernon Hills, IL 60061, USA Manufacture's Name ............ : SHENZHEN DA YI XIN TECHNOLOGY CO.,LTD. Address ................................. : 4/F, No 13, Ganglian Industrial Park, Hongxing Community, Songgang Street, Bao'an District, Shenzhen Product description Product name ........................... : Bluetooth headphone Model and/or type reference : R-660 Serial Model： YX-BT-X6 Standards ............................. : FCC Part15.247: 01 Oct. 2013 Test procedure ..............................ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 30 Oct. 2014 ~20 Nov. 2014 Date of Issue ........................................... : 20 Nov. 2014 Test Result ............................................... : Pass Testing Engineer : Denny Huang Technical Manager : (Brown Lu) Authorized Signatory : (Bill Yao) Page 3 of 67 Report No.:NTEK-2014NT10301863F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BELOW 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 4 . NUMBER OF HOPPING CHANNEL 25 4.1 APPLIED PROCEDURES / LIMIT 25 4.1.1 TEST PROCEDURE 25 4.1.2 DEVIATION FROM STANDARD 25 4.1.3 TEST SETUP 25 4.1.4 EUT OPERATION CONDITIONS 25 4.1.5 TEST RESULTS 26 5 . AVERAGE TIME OF OCCUPANCY 27 5.1 APPLIED PROCEDURES / LIMIT 27 Page 4 of 67 Report No.:NTEK-2014NT10301863F Table of Contents Page 5.1.1 TEST PROCEDURE 27 5.1.2 DEVIATION FROM STANDARD 27 5.1.3 TEST SETUP 28 5.1.4 EUT OPERATION CONDITIONS 28 5.1.5 TEST RESULTS 29 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 35 6.1 APPLIED PROCEDURES / LIMIT 35 6.1.1 TEST PROCEDURE 35 6.1.2 DEVIATION FROM STANDARD 35 6.1.3 TEST SETUP 35 6.1.4 EUT OPERATION CONDITIONS 35 6.1.5 TEST RESULTS 36 7 . BANDWIDTH TEST 42 7.1 APPLIED PROCEDURES / LIMIT 42 7.1.1 TEST PROCEDURE 42 7.1.2 DEVIATION FROM STANDARD 42 7.1.3 TEST SETUP 42 7.1.4 EUT OPERATION CONDITIONS 42 7.1.5 TEST RESULTS 43 8 . PEAK OUTPUT POWER TEST 49 8.1 APPLIED PROCEDURES / LIMIT 49 8.1.1 TEST PROCEDURE 49 8.1.2 DEVIATION FROM STANDARD 49 8.1.3 TEST SETUP 49 8.1.4 EUT OPERATION CONDITIONS 49 8.1.5 TEST RESULTS 50 9 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 56 9.1 DEVIATION FROM STANDARD 56 9.2 TEST SETUP 56 9.3 EUT OPERATION CONDITIONS 56 9.4 TEST RESULTS 57 10 . ANTENNA REQUIREMENT 65 10.1 STANDARD REQUIREMENT 65 10.2 EUT ANTENNA 65 11 . EUT TEST PHOTO 66 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 67 Report No.:NTEK-2014NT10301863F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 67 Report No.:NTEK-2014NT10301863F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 67 Report No.:NTEK-2014NT10301863F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Bluetooth headphone Trade Name N/A Model Name R-660 Serial Model YX-BT-X6 Model Difference All the model are the same circuit…
