ToturnofforrestartReddotmobileR50S M i c r o FCCCaution. §15.19Labellingrequirements. Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothe followingtwoconditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2) thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay causeundesiredoperation. §15.21Informationtouser. AnyChangesormodificationsnotexpresslyapprovedbythepartyresponsible forcompliancecouldvoidtheuser'sauthoritytooperatetheequipment. §15.105Informationtotheuser. Note:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClass Bdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedto providereasonableprotectionagainstharmfulinterferenceinaresidentialinstallation. Thisequipmentgeneratesusesandcanradiateradiofrequencyenergyand,ifnot installedandusedinaccordancewiththeinstructions,maycauseharmfulinterference toradiocommunications.However,thereisnoguaranteethatinterferencewillnot occurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferenceto radioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoff andon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthe followingmeasures: -Reorientorrelocatethereceivingantenna. -Increasetheseparationbetweentheequipmentandreceiver. -Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhich thereceiverisconnected. -Consultthedealeroranexperiencedradio/TVtechnicianforhelp. SpecificAbsorptionRate(SAR)information: ThisPHONEmeetsthegovernment'srequirementsforexposuretoradiowaves. Theguidelinesarebasedonstandardsthatweredevelopedbyindependent scientificorganizationsthroughperiodicandthoroughevaluationofscientific studies.Thestandardsincludeasubstantialsafetymargindesignedtoassurethe safetyofallpersonsregardlessofageorhealth. FCCRFExposureInformationandStatementTheSARlimitofUSA(FCC)is1.6 W/kgaveragedoveronegramoftissue.Devicetypes:R50L(FCCID:2ADNIR50L) hasalsobeentestedagainstthisSARlimit.ThehighestSARvaluereportedunderthis standardduringproductcertificationforuseattheearis0.40W/kgandwhen properlywornonthebodyis0.74W/kg.Thisdevicewastestedfortypicalbody-worn operationswiththebackofthehandsetkept1.0cmfromthebody.Tomaintain compliancewithFCCRFexposurerequirements,useaccessoriesthatmaintaina 1.0cmseparationdistancebetweentheuser'sbodyandthebackofthehandset. Theuseofbeltclips,holstersandsimilaraccessoriesshouldnotcontainmetallic componentsinitsassembly.Theuseofaccessoriesthatdonotsatisfythese requirementsmaynotcomplywithFCCRFexposurerequirements,andshouldbe avoided. Body-wornOperation Thisdevicewastestedfortypicalbody-wornoperations.TocomplywithRF exposurerequirements,aminimumseparationdistanceof1.0cmmustbemaintained betweentheuser’sbodyandthehandset,includingtheantenna.Third-partybelt-clips, holsters,andsimilaraccessoriesusedbythisdeviceshouldnotcontainanymetallic components.Body-wornaccessoriesthatdonotmeettheserequirementsmaynot complywithRFexposurerequirementsandshouldbeavoided.Useonlythesupplied oranapprovedantenna.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Worldlinks Communications, L.L.C. 2015/8/20 To: SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _____ Worldlinks Communications, L.L.C._____hereby authorize SIEMIC, Inc. to act as Certification Body for certifying for the following project(s): (Product description, model name) Phone, R50L FCC ID :2ADNIR50L Sincerely, Client’s signature Client’s name / title ： Elie Maloof/Manager Contact information / address 270 Center Drive Suite 230, Vernon Hills, IL. 60061

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Worldlinks Communications, L.L.C. 2015/08/20 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ADNIR50L We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description - e.g. Tune up Procedure - e.g. Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Elie Maloof/Manager Contact information / address: 270 Center Drive Suite 230, Vernon Hills, IL. 60061

Test Report 15070474-FCC-E Page 21 of 31 Annex B. EUT And Test Setup Photographs Annex B.i. Photograph: EUT External Photo Whole Package - Top View Adapter - Front View EUT - Front View EUT - Rear View Test Report 15070474-FCC-E Page 22 of 31 EUT - Top View EUT - Bottom View EUT - Left View EUT - Right View

Lable location

Test Report 15070474-FCC-E Page 23 of 31 Annex B.ii. Photograph: EUT Internal Photo Cover Off - Top View 1 Cover Off - Top View 2 Battery - Top View Battery - Bottom View Mainbard with Shielding - Front View Mainbard with Shielding - Rear View Test Report 15070474-FCC-E Page 24 of 31 Mainboard without shielding - Front View Mainbard without Shielding - Rear View LCD – Front View LCD – Rear View GSM/PCS/UMTS-FDD/LTE Antenna View WIFI/BT/BLE - Antenna View Test Report 15070474-FCC-E Page 25 of 31 GPS - Antenna View

RF EXPOSURE REPORT Report No.: 15070474-FCC-H2 Supersede Report No.: N/A Applicant Worldlinks Communications, L.L.C. Product Name PHONE Model No. R50L Serial No. N/A Test Standard FCC 2.1093.2014 Test Date July 30 to August 14, 2015 Issue Date August 21, 2015 Test Result Pass Fail Equipment complied with the specification Equipment did not comply with the specification Winnie Zhang Test Engineer David Huang Checked By This test report may be reproduced in full only Test result presented in this test report is applicable to the tested sample only Issued by: SIEMIC (SHENZHEN-CHINA) LABORATORIES Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’an District, Shenzhen, Guangdong China 518108 Phone: +86 0755 2601 4629801 Email: [email protected] Test Report 15070474-FCC-H2 Page 2 of 11 Laboratories Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management throughout a project. Our extensive experience with China, Asia Pacific, North America, European, and International compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Scope USA EMC, RF/Wireless, SAR, Telecom Canada EMC, RF/Wireless, SAR, Telecom Taiwan EMC, RF, Telecom, SAR, Safety Hong Kong RF/Wireless, SAR, Telecom Australia EMC, RF, Telecom, SAR, Safety Korea EMI, EMS, RF, SAR, Telecom, Safety Japan EMI, RF/Wireless, SAR, Telecom Singapore EMC, RF, SAR, Telecom Europe EMC, RF, SAR, Telecom, Safety Test Report 15070474-FCC-H2 Page 3 of 11 This page has been left blank intentionally. Test Report 15070474-FCC-H2 Page 4 of 11 CONTENTS 1. REPORT REVISION HISTORY ............................................................................................................................ 5 2. CUSTOMER INFORMATION ................................................................................................................................ 5 3. TEST SITE INFORMATION ................................................................................................................................... 5 4. EQUIPMENT UNDER TEST (EUT) INFORMATION ......................................................................................... 6 5. FCC §2.1093 - RADIOFREQUENCY RADIATION EXPOSURE EVALUATION: PORTABLE DEVICES. 9 5.1 RF EXPOSURE .......................................................................................................................................................... 9 5.2 TEST RESULT ......................................................................................................................................................... 10 Test Report 15070474-FCC-H2 Page 5 of 11 1. Report Revision History Report No. Report Version Description Issue Date 15070474-FCC-H2 NONE Original August 21, 2015 2. Customer information Applicant Name Worldlinks Communications, L.L.C. Applicant Add 270 Center Drive Suite 230, Vernon Hills, IL. 60061 Manufacturer Shenzhen VSDREAM Technology Co., Ltd Manufacturer Add 4F, Headquarters Building, zhonghaixin Science&Technology Park,Bulan Road, Buji Ave, Longgang Dist., Shenzhen, Guangdong, China 3. Test site information Lab performing tests SIEMIC (Shenzhen-China) LABORATORIES Lab Address Zone A, Floor 1, Building 2 Wan Ye Long Technology Park South Side of Zhoushi Road, Bao’an District, Shenzhen, Guangdong China 518108 FCC Test Site No. 718246 IC Test Site No. 4842E-1 Test Software Radiated Emission Program-To Shenzhen v2.0 Test Report 15070474-FCC-H2 Page 6 of 11 4. Equipment under Test (EUT) Information Description of EUT: PHONE Main Model: R50L Serial Model: N/A Antenna Gain: GSM850: 0.08 dBi PCS1900: 0.8 dBi UMTS-FDD Band V: 0.08 dBi UMTS-FDD Band IV: 0.73 dBi UMTS-FDD Band II: 0.89 dBi Bluetooth/BLE: 0.93 dBi WIFI(2.4G): 0.93 dBi WIFI(5G): 1.82 dBi LTE Band 2: 0.88 dBi LTE Band 4: 0.75 dBi LTE Band 5: 0.07 dBi LTE Band 7: 1.42 dBi LTE Band 17: -1.73 dBi GPS:-0.32dBi Type of Modulation: GSM / GPRS: GMSK EGPRS: GMSK, 8PSK UMTS-FDD: QPSK, 16QAM 802.11a/b/g/n: DSSS, OFDM Bluetooth: GFSK, π /4DQPSK, 8DPSK BLE: GFSK LTE Band: QPSK, 16QAM GPS:BPSK RF Operating Frequency (ies): GSM850 TX: 824.2 ~ 848.8 MHz; RX: 869.2 ~ 893.8 MHz PCS1900 TX: 1850.2 ~ 1909.8 MHz; RX: 1930.2 ~ 1989.8 MHz UMTS-FDD Band V TX: 826.4 ~ 846.6 MHz; RX: 871.4 ~ 891.6 MHz UMTS-FDD Band IV TX:1712.4 ~ 1752.6 MHz; UMTS-FDD Band II TX:1852.4 ~ 1907.6 MHz; RX: 1932.4 ~ 1987.6 MHz WIFI:802.11b/g/n(20M): 2412-2462 MHz Test Report 15070474-FCC-H2 Page 7 of 11 WIFI:802.11n(40M): 2422-2452 MHz WIFI:802.11a,n(20,40M): 5150-5250 MH Bluetooth& BLE: 2402-2480 MHz LTE Band 2 TX: 1852.5 ~ 1907.5 MHz; RX : 1932.5 ~ 1987.5 MHz LTE Band 4 TX: 1712.5 ~ 1752.5 MHz; RX : 2112.5 ~ 2152.5 MHz LTE Band 5 TX: 826.5 ~ 846.5 MHz; RX : 871.5 ~ 891.5 MHz LTE Band 7 TX: 2502.5 ~ 2567.5 MHz; RX : 2622.5 ~ 2687.5 MHz LTE Band 17 TX: 706.5 ~ 713.5 MHz; RX : 736.5 ~ 743.5 MHz GPS RX:1575.42 MHz Number of Channels: GSM 850: 124CH PCS1900: 299CH UMTS-FDD Band V : 102CH UMTS-FDD Band IV: 202CH UMTS-FDD Band II : 277CH WIFI :802.11b/g/n(20M): 11CH WIFI :802.11n(40M): 7CH Bluetooth: 79CH BLE: 40CH GPS:1CH Port: Power Port, Earphone Port, USB Port Input Power: Battery: Model:AAP5-815 Standard Voltage:4.35V Rated Capacity:2150mAh Charging Voltage Limited: 4.35V Adapter: Model:KA25-0501000US Input: AC100-240V; 50/60Hz; 0.25A Output: DC 5.0V,1000mA Test Report 15070474-FCC-H2 Page 8 of 11 Trade Name : REDDOTMOBILE GPRS/EGPRS Multi-slot class 8/10/12 FCC ID: 2ADNIR50L Date EUT received: July 20, 2015 Date EUT received: July 29, 2015 Test Date(s): July 30 to August 14, 2015 Test Report 150704…
