2ADQFMEP3AD10S1Remote Telemetry Communication Unit

U.S. patents and Foreign patents are pending on this product. © 2020 Worthington Industries Inc. 1/20 SMARTLID™ TANK MONITOR . The NEW Worthington Industries monitor-ready lid is designed to be more resistant, fit better and accommodate Worthington’s SmartLid™ tank monitor under the lid. 200 OLD WILSON BRIDGE ROAD COLUMBUS, OHIO 43085 P: 614.438.3013 Toll-free: 866.928.2657 [email protected] WORTHINGTONINDUSTRIES.COM/SMARTLID © 2020 Worthington Industries Inc. 10/20 U.S. patents and Foreign patents are pending on these products. WARNING: This product can expose you to chemicals including lead, which is known to the state of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov TECHNICAL SUPPORT [email protected] Worthingtonindustries.com/Smartlid Toll-free: 866.928.2657 U.S. patents and Foreign patents are pending on this product. © 2020 Worthington Industries Inc. 1/20 INSTALLATION INSTRUCTIONS MONITOR INSTALL MONITOR INSTALL - ON TANK © 2020 Worthington Industries Inc. 10/20 NOTES: 1. When monitoring multiple tanks that are connected (2x420s, 3x420s etc.), it is important to connect the monitor to the tank that’s showing the lowest level. If they’re equal, you should monitor the tank with the regulator. 2. Make sure gauge is screwed on and fastened properly. Ensure that the gauge is clean and free of dirt and debris. INSERT1SLIDE2SNAP3ROUTE4 INSERT1SLIDE2SNAP3ROUTE4 PLACE1INSERT2SECURE3ROUTE4 LID INSTALL INSTALLATION INSTRUCTIONS MONITOR REMOVAL MONITOR SPECIFICATIONS = INPUT ELECTRICAL SPECIFICATIONS DIMENSIONS OPTION REPORTING & OUTPUTS RADIO SPECIFICATIONS ENVIRONMENTAL SPECIFICATIONS CERTIFICATIONS Remote Ready Hall Effect Module, I2C, 4-20mAdc, 0-5 VDC, Temperature Tank level (5% variation) 0% to 100% 5 years IP68 Hybrid LTC 3.6 VDC 7.2 VDC 2.38 in 60.34 mm GPS (mobile tank) 6.28 in 159.62 mm 6 in 152.43 mm API 4G, LTE CAT1, CATM, NB IOT, 3G -40°F to 140°F -40°C to 60°C Network status Low battery Email (to supplier and/or consumer) Dual SIM Lead sensor status High/Excessive draw Raw data Bluetooth Battery status Fill Detection Online dashboard Temperature Client mobile app Reporting Relative humidity range Enclosure rating Warranty Battery Pack Height Width Depth Data Interface Technologies Operating & storage temp. range Monitors are third-party QPS Evaluation Services Inc. certified for use in hazardous locations Class, I, Division 2, Groups C&D T3; Class I, Zone 2, Group IIB T3; -40°C to 60°C Automated Testing This device complies with part 15 of the FCC Rules. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device is compliant with Industry Canada’s RSS standards for licence-exempt radio apparatuses. Authorized use depends on the following two conditions: (1) the device must not create radio interference, and (2) the device user must accept all radio interference, even if this interference could potentially impair its functioning. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/ TV technician for help. WARNING: This monitor has been tested and certified safe for use in Class I , Division 2, Groups C & D T3 hazardous locations. Changes or modifications to the unit must only be performed by an authorized technician. For outdoor use only. Explosion Hazard - Batteries must only be changed in an area free of ignitable concentrations. Do not open when an explosive atmosphere is present. Potential electrostatic charging hazard - wipe only with a damp cloth. BATTERY REPLACEMENT: Use ONLY the following Otodata replaceable battery packs: G0643- LF rated 7.2Vdc / 19Ah or G0249-LF, rated 7.2Vdc / 8.5Ah. Battery replacement is to be done ONLY when an explosive atmosphere is not present. This device provides non-incendive circuits to cable sensor assembly. Part Number: HE-LEAD-CIRC-6 or HE-LEAD-CIRC-6-RA or DH-LEAD- CIRC-6 U.S. patents and Foreign patents are pending on this product. © 2020 Worthington Industries Inc. 1/20 © 2020 Worthington Industries Inc. 10/20 REMOVE1PRESS2SLIDE3LIFT4 Brevets américains et étrangers de ce produit en instance. © 2020 Worthington Industries Inc. 1/20 INSTRUCTIONS DE MONTAGE MISE EN PLACE DU MONITEUR MISE EN PLACE DU MONITEUR - SUR LE RÉSERVOIR © 2020 Worthington Industries Inc. 10/20 REMARQUES 1. Lors de la surveillance de plusieurs réservoirs connectés (2 x 420s, 3 x 420s, etc.), il est important de brancher le moniteur au réservoir dont le niveau est le plus bas. Si les niveaux sont égaux, vous devriez surveiller le réservoir équipé du régulateur. 2. Vérifiez que la jauge est vissée et fixée correctement. Assurez-vous que la jauge est propre et exempte …

Text truncated - open the document above for the full version.

9280 Boul. de l’Acadie Montréal, Québec H4N 3C5 T: +1 (514) 745-8241 F: +1 (514) 745-8630 Attention: Application Examiner RE: Request for Confidentiality Applicant: Otodata Wireless Network Inc. FCC ID: 2ADQFMEP3AD10S1 To Whom It May Concern: Request is hereby submitted by Otodata Wireless Network Inc. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: • Schematics • Detailed Block Diagrams Rationale for request for confidentiality: Otodata Wireless Network Inc. has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Sincerely, Pascal Turcotte, ing., Eng. R&D Engineer & Certification Manager Otodata Wireless Network Inc.

9280 Boul. de l’Acadie Montréal, Québec H4N 3C5 T: +1 (514) 745-8241 F: +1 (514) 745-8630 October 13, 2020 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject:Limited Agency Agreement Otodata Wireless Network Inc. FCC ID: 2ADQFMEP3AD10S1 To Whom It May Concern: We, Otodata Wireless Nework Inc., hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for FCC ID number 2ADQFMEP3AD10S1 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is October 13, 2020. The Limited Agency Agreement expires on October 13, 2022, unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Pascal Turcotte, ing., Eng. R&D Engineer & Certification Manager Otodata Wireless Network Inc.

9280 Boul. de l’Acadie Montréal, Québec H4N 3C5 T: +1 (514) 745-8241 F: +1 (514) 745-8630 October 13, 2020 Intertek Testing Services NA Ltd. 70 Codman Hill Road Boxborough, MA 01719 Subject:Limited Agency Agreement Otodata Wireless Network Inc. FCC ID: 2ADQFMEP3AD10S1 We, Otodata Wireless Network Inc., hereby authorized Martin Mejorado of Intertek Testing Services NA ltd. to act as our Agent for the purpose of preparing application for FCC ID number 2ADQFMEP3AD10S1 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is October 13, 2020. The Limited Agency Agreement expires on October 13, 2022, unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Pascal Turcotte, ing., Eng. R&D Engineer & Certification Manager Otodata Wireless Network Inc.

9280 Boul. de l’Acadie Montréal, Québec H4N 3C5 T: +1 (514) 745-8241 F: +1 (514) 745-8630 January 28, 2021 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject:Limited Agency Agreement Otodata Wireless Network Inc. FCC ID: 2ADQFMEP3AD10S1 To Whom It May Concern: I, Jason M Gallovich, (Vice-President, Otodata Wireless Network Inc.), hereby authorize Pascal Turcotte, (RnD Engineer, Otodata Wireless Network Inc.) to conduct all activities, prepare and sign documents on my behalf for FCC ID number 2ADQFMEP3AD10S1 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is January 28, 2020. The Limited Agency Agreement expires on January 28, 2022, unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Jason M Gallovich Vice-President, Otodata Wireless Network Inc.

Q1/21 TM6035_MEP3AD10S01_Markings_Nameplate_V2.docx RTLM Product Label Drawing ONLY FOR USE ON RTLM Model number: TM6035 (Not to scale) USE ONLY: Label Spec# 76656 (2mil White Polyester) UL File # MH17205 Height: 2.500” x Width: 3.250” Single row / Rounded corner - RESIN ONLY

RTLM Product Label Drawing ONLY FOR USE ON RTLM Model number: TM6035 Height: 2.500” x Width: 3.250” Single row / Rounded corner - RESIN ONLY

MEP3AD10S1 Operational Description The MEP3AD10S1 is a remote tank level monitoring device. It is intended to be powered by a non-rechargeable lithium battery pack for a predicted average lifetime of at least 15 years. The unit contains an LTE Cat. 1 certified cellular module (FCC ID: RI7LE910NAV2, IC: 5131A-LE910NAV2) which manages all cellular communications. A folded dipole antenna over a ground plane is used as main cellular antenna. Basic GPS functionality is also available to locate a lost unit or locate tanks that can be physically moved. The device reads the tank level sensor every few minutes. When a significant level change is detected, the microcontroller (MCU) activates the cellular module. The latter then attaches to the preferred network and reports the data to a server. If there is no level change after 24 hours, the unit performs a daily report using the same procedure. The MEP3AD10S1 uses low data volume: up to 100KB per month, but usually around 10KB per month. In the circuit, a load switch is used to power the external sensor. The sensor’s signal is then read by the MCU through one of its analog to digital converter. The MCU sends the data using the cellular module. They communicate via a serial port. The unit uses Bluetooth advertising to allow infield testing and diagnostics as well as enabling possible firmware upgrades. The MCU has an embedded 2.4GHz transceiver. The manufacturer provides the protocol stack for Bluetooth Low Energy. A 2.14dBi PCB antenna over a ground plane is used as Bluetooth antenna. During the activation of the cellular module, the Bluetooth advertising is disabled.

Intertek 731 Enterprise Drive Lexington, KY 40510 Tel 859 226 1000 Fax 859 226 1040 www.intertek.com Otodata Wireless Network Inc. MPE REPORT SCOPE OF WORK MPE CALCULATION ON THE SMART LID NEEVO MONITOR REPORT NUMBER 104421615LEX-004 ISSUE DATE 2/10/2021 PAGES 11 DOCUMENT CONTROL NUMBER Non-Specific EMC Report Shell Rev. December 2017 © 2017 INTERTEK This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services NA, Inc. MPE TEST REPORT Report Number: 104421615LEX-004 Project Number: G104421615 Report Issue Date: 2/10/2021 Product Name: Smart Lid Neevo Monitor Standards: FCC Part 1.1310 Limits for Maximum Permissible Exposure (MPE) RSS-102 Issue 5 RF Field Strength Limits for Devices Used by the General Public Tested by: Client: Intertek Testing Services NA, Inc. 731 Enterprise Drive Lexington, KY 40510 USA Otodata Wireless Network Inc. 9280 Boul. De l’Acadie Montreal, QC H4N 3C5 Canada Report prepared by Report reviewed by Bryan Taylor, Team Leader Brian Lackey, Staff Engineer Evaluation For: Otodata Wireless Network Inc. Product: Smart Lid Neevo Monitor EMC Test Report Date: 2/10/2021 Non-Specific EMC Report Shell Rev. December 2017 Page 3 of 11 Report Number: 104421615LEX-004 Table of Contents 1 Introduction and Conclusion ..................................................................................................................... 4 2 Test Summary .......................................................................................................................................... 4 3 Client Information .................................................................................................................................... 5 4 Description of Equipment under Test and Variant Models .......................................................................... 6 5 FCC Limits ................................................................................................................................................ 7 6 RSS-102 Issue 5 Exposure Limits: ............................................................................................................... 8 7 Test Procedure ......................................................................................................................................... 9 8 Results: ................................................................................................................................................. 10 9 Revision History ..................................................................................................................................... 11 Evaluation For: Otodata Wireless Network Inc. Product: Smart Lid Neevo Monitor EMC Test Report Date: 2/10/2021 Non-Specific EMC Report Shell Rev. December 2017 Page 4 of 11 Report Number: 104421615LEX-004 1 Introduction and Conclusion The tests indicated in section 2.0 were performed on the product constructed as described in section 4.0. The remaining test sections are the verbatim text from the actual data sheets used during the investigation. These test sections include the test name, the specified test Method, a list of the actual Test Equipment Used, documentation Photos, Results and raw Data. No additions, deviations, or exclusions have been made from the standard(s) unless specifically noted. Based on the results of our investigation, we have concluded the product tested complies with the requirements of the standard(s) indicated. The results obtained in this test report pertain only to the item(s) tested. Intertek does not make any claims of compliance for samples or variants which were not tested. 2 Test Summary Section Test full name Result 8 FCC Part 1.1310 Limits for Maximum Permissible Exposure (MPE) (Limits for General Population / Uncontrolled Exposure) Pass RSS-102 Issue 5 RF Field Strength Limits (For Devices Used by the General Public) Pass Evaluation For: Otodata Wireless Network Inc. Product: Smart Lid Neevo Monitor, Model TM6035 MPE Report Date: 2/10/2021 Non-Specific EMC Report Shell Rev. December 2017 Page 5 of 11 Report Number: 104421615LEX-004 3 Client Information This product was tested at the request of the following: Client Information Client Name: Otodata Wireless Network Inc. Address: 9280 Boul. De l’Acadie Montreal, QC H4N 3C5 Canada Contact: Pascal Turcotte Telephone: (514) 673-0244 Email: [email protected] Manufacturer Information Manufacturer Name: Otodata Wireless Network Inc. Manufacturer Address: 9280 Boul. De l’Acadie Montreal, QC H4N 3C5 Canada Evaluation For: Otodata Wireless Network Inc. Product: Smart Lid Neevo Monitor, Model TM6035 MPE Report Date: 2/10/2021 Non-Specific EMC Report Shell Rev. December 2017 Page 6 of 11 Report Number: 104421615LEX-004 4 Description of Equipment under Test and Variant Models Equipment Under Test Product Name Smart Lid Neevo Monitor Model Number TM6035 Hardware Version C018 Software Version 2008 Supported Transmit Bands Bluetooth Low Energy 2402 – 2480MHz Receive Date 9/13/2020 Test Start Date 9/14/2020 Test End Date 9/24/2020 Device Received Condition Good Test Sample Type Production Rated Voltage 7.2VDC Battery Antenna PCB Tra…

Text truncated - open the document above for the full version.

Intertek 731 Enterprise Drive Lexington, KY 40510 Tel 859 226 1000 Fax 859 226 1040 www.intertek.com Otodata Wireless Network Inc. TEST REPORT SCOPE OF WORK EMC TESTING – SMART LID NEEVO MONITOR REPORT NUMBER 104421615LEX-001.2 ISSUE DATE REVISED DATE 10/29/2020 2/10/2021 PAGES 51 DOCUMENT CONTROL NUMBER Non-Specific EMC Report Shell Rev. December 2017 © 2017 INTERTEK This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services NA, Inc. EMC TEST REPORT (FULL COMPLIANCE) Report Number: 104421615LEX-001.2 Project Number: G104421615 Report Issue Date: 2/10/2021 Model(s) Tested: Smart Lid Neevo Monitor Standards: Title 47 CFR Part 15.247 RSS-247 Issue 2 RSS-Gen Issue 5 Tested by: Client: Intertek Testing Services NA, Inc. 731 Enterprise Dr. Lexington, KY 40510 USA Otodata Wireless Network Inc. 9280 Boul. De l’Acadie Montreal, QC H4N 3C5 Canada Report prepared by Report reviewed by Bryan Taylor, Team Leader Brian Lackey, Staff Engineer Evaluation For: Otodata Wireless Network Inc. Product: Smart Lid Neevo Monitor EMC Test Report Date: 2/10/2021 Non-Specific EMC Report Shell Rev. December 2017 Page 3 of 51 Report Number: 104421615LEX-001.2 Table of Contents 1 Introduction and Conclusion ..................................................................................................................... 4 2 Test Summary .......................................................................................................................................... 4 3 Client Information .................................................................................................................................... 5 4 Description of Equipment under Test and Variant Models .......................................................................... 6 5 System Setup and Method ........................................................................................................................ 7 6 Receiver Spurious Emissions ..................................................................................................................... 8 7 Transmitter Spurious Emissions .............................................................................................................. 13 8 Output Power ........................................................................................................................................ 27 9 Occupied Bandwidth .............................................................................................................................. 29 10 Power Spectral Density ....................................................................................................................... 42 11 Conducted Spurious Emissions ............................................................................................................ 46 12 Antenna Requirement ........................................................................................................................ 50 13 Revision History ................................................................................................................................. 51 Evaluation For: Otodata Wireless Network Inc. Product: Smart Lid Neevo Monitor EMC Test Report Date: 2/10/2021 Non-Specific EMC Report Shell Rev. December 2017 Page 4 of 51 Report Number: 104421615LEX-001.2 1 Introduction and Conclusion The tests indicated in section 2.0 were performed on the product constructed as described in section 4.0. The remaining test sections are the verbatim text from the actual data sheets used during the investigation. These test sections include the test name, the specified test Method, a list of the actual Test Equipment Used, documentation Photos, Results and raw Data. No additions, deviations, or exclusions have been made from the standard(s) unless specifically noted. Based on the results of our investigation, we have concluded the product tested complies with the requirements of the standard(s) indicated. The results obtained in this test report pertain only to the item(s) tested. Intertek does not make any claims of compliance for samples or variants which were not tested. 2 Test Summary Section Test full name Result 6 Receiver Spurious Emissions (ANSI C63.4: 2014) Pass 7 Transmitter Spurious Emissions (FCC Part 15.247(d), RSS-247 Issue 2 § 5.5) Pass 8 Output Power (FCC Part 15.247(b)(3), RSS-247 Issue 2 § 5.4(d)) Pass 9 Occupied Bandwidth (FCC Part 15.247, RSS-247 Issue 2 § 5.2(a)) Pass 10 Power Spectral Density (FCC Part 15.247(e), RSS-247 Issue 2 § 5.2(b)) Pass 11 Conducted Spurious Emissions (FCC Part 15.247(d), RSS-247 Issue 2 § 5.5) Pass 12 Antenna Requirement (FCC Part 15.203, RSS-Gen Issue 5 § 6.8) Pass --- Conducted Emissions (ANSI C63.4: 2014) N/A 1 1 Not applicable since this device is battery powered and does not connect to the AC mains. Evaluation For: Otodata Wireless Network Inc. Product: Smart Lid Neevo Monitor EMC Test Report Date: 2/10/2021 Non-Specific EMC Report Shell Rev. December 2017 Page 5 of 51 Report Number: 104421615LEX-001.2 3 Client Information This product was tested at the request of the following: Client Information Client Name:…

Text truncated - open the document above for the full version.

Radiated Emissions (below 30MHz) Radiated Emissions (below 1GHz) Radiated Emissions (above 1GHz)
