2ADRB-HIVEHIVE EVOLUTION BLUETOOTH SPEAKER

FCC Notes:

CREATIVISION LIMITED Rm 2003, 20/F, 303 Hennessy Road, Wanchai, Hong Kong FCC Authorization Letter Number: CF304 Version: V03 Date: 01-08-2011 We, (the approval holder) Company name CREATIVISION LIMITED. Rm 2003, 20/F, 303 Hennessy Road, Wanchai, City Hong Kong Country China declare that the following representative (agent): Name (person) KAIT CHEN Company name WST Certification & Testing (HK) Limited Address 12/F., San Toi Building,137-139 Connaught Road Central, City Hong Kong, Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description HIVE EVOLUTION BLUETOOTH SPEAKER Type or Model(s) HIVE EVOLUTION, BL-291, KSHIVEEVOBK, KSHIVEEVOGM, KSHIVEEVOXX(XX = refer to color code) Tradename or Brand(s) Kitsound / Uchoice We also authorize Teleconformity (Mr. M. Koop, Manager Certification, Address: Rietven 31, 7534NH Enschede, the Netherlands) to apply and sign this application for certification, registration or filing on our behalf (as representative agent or certifier). Attestation: City and Country:Date:Name: (this must be a person) Function:Signature: (or official company stamp) HK, ChinaNov. 06, 2015Joe WongProject Executive

CREATIVISION LIMITED Rm 2003, 20/F, 303 Hennessy Road, Wanchai, Hong Kong FCC Confidentiality Request Number: CF303 Version: V05 Date: 21-05-2012 (Permanent or also called long term confidentiality is the normal method to keep certain docuements confidential, and may apply to schematics, block diagrams, operational description and bill of materials.) To: Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company nameCREATIVISION LIMITED. AddressRm 2003, 20/F, 303 Hennessy Road, Wanchai, CityHong Kong CountryChina request for this certification filing under: Grantee CodeProduct Number FCC ID:2ADRB-HIVE to maintain permanent confidentiality for the following documents submitted within this application: (please cross what is applicable, or add other documents, provide the file name and description) ExhibitFile NameDescription xOperational Descriptionexplaining the functioning of the block diagram xBlock Diagramsshowing the systematic building blocks of the EUT xSchematics Diagramsshowing components, their values and interconnection Bill of MaterialsList of components used on the PCB’s of the EUT Above materials crossed contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. The documents indicated as confidential above, are not publicly available elsewhere. Attestation: City and Country:Date:Name: (this must be a person) Function:Signature: (or official company stamp) Enschede, Netherlands 2015-11-10M. Koop (authorized) Manager

FCC ID LABEL: Label Location FCC ID: 2ADRB‐HIVE Product name: HIVE EVOLUTION BLUETOOTH SPEAKER Model No.: HIVE EVOLUTION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.

Page 1 of 37 Report No.: WST151109103-E FCC TEST REPORT Test report On Behalf of CREATIVISION LIMITED For HIVE EVOLUTION BLUETOOTH SPEAKER Model No.: HIVE EVOLUTION, BL-291, KSHIVEEVOBK, KSHIVEEVOGM, KSHIVEEVOXX(XX = refer to color code) FCC ID: 2ADRB-HIVE Prepared for : CREATIVISION LIMITED Rm 2003, 20/F, 303 Hennessy Road, Wanchai, Hong Kong Prepared By : Shenzhen WST Testing Technology Co., Ltd. 1F, No.9 Building,TGK Science & Technology Park, Yangtian Rd., NO.72 Bao'an Dist., Shenzhen, Guangdong, China. 518101 Date of Test: Oct. 29, 2015 ~ Nov. 05, 2015 Date of Report: Nov. 05, 2015 Report Number: WST151109103-E Page 2 of 37 Report No.: WST151109103-E TEST RESULT CERTIFICATION Applicant’s name ................. : CREATIVISION LIMITED Address ................................. : Rm 2003, 20/F, 303 Hennessy Road, Wanchai, Hong Kong Manufacture's Name ............ : DONGGUAN CITY YUANYU ELECTRONIC TECHNOLOGY CO., LIMITED Address ................................. : JINDUOGANG DEVELOPMENT ZONE, DATANG VILLAGE, DALINGSHAN TOWN, DONGGUAN CITY, GUANGDONG, CHINA Product description Trade Mark: Kitsound / Uchoice Product name ........................... : HIVE EVOLUTION BLUETOOTH SPEAKER Model and/or type reference : HIVE EVOLUTION, BL-291, KSHIVEEVOBK, KSHIVEEVOGM, KSHIVEEVOXX(XX = refer to color code) Standards ............................. : FCC Rules and Regulations Part 15 Subpart C Section 15.247 ANSI C63.4: 2014 This publication may be reproduced in whole or in part for non-commercial purposes as long as the WST Certification & Testing (HK) Limited is acknowledged as copyright owner and source of the material. WST Certification & Testing (HK) Limited takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of performance of tests ............. : Oct. 29, 2015 ~ Nov. 05, 2015 Date of Issue ........................................... : Nov. 05, 2015 Test Result ............................................... : Pass Testing Engineer : (Eric Xie) Technical Manager : (Dora Qin) Authorized Signatory : (Kait Chen) Page 3 of 37 Report No.: WST151109103-E Table of Contents Page 1. . Test Summary 5 1.1. Test Facility 6 1.2. Measurement Uncertainty 6 2. . General Information 7 2.1. General Description of EUT 7 2.2. Carrier Frequency of Channels 8 2.3. Description of Test Setup 8 2.4. Measurement Instruments List 9 3. . 6DB Bandwidth Measurement 11 3.1. Block Diagram of Test Setup 11 3.2 Limits 11 3.3 Test Procedure 11 3.4 Test Result 11 4 Maximum Peak Output Power 14 4.2 Limits 14 4.3 Test Procedure 14 4.4 Test Result 15 5 Power Spectral Density Measurement 17 5.2 Limits 17 5.3 Test Procedure 17 5.4 Test Result 17 6 Band Edge Compliance Test 20 6.2 Limits 20 6.3 Test Procedure 20 6.4 Test Result 21 7 Radiated Spurious Emission Test 25 7.2 Limits 26 7.3 Restricted bands of operation 26 7.4 Test Procedure 27 7.5 Test Result 28 8 Conducted Spurious Emission Compliance Test 30 8.2 Limits 30 8.3 Test Procedure 30 8.4 Test Result 30 Page 4 of 37 Report No.: WST151109103-E Table of Contents Page 9 AC Power Line Conducted Emission For Part 15 Section 15.207(A) 33 9.2 Limits 33 9.3 Test Procedure 33 9.4 Test Result 33 10 Antenna Requirement 35 11 Photograph of Test 36 Page 5 of 37 Report No.: WST151109103-E 1.. Test Summary FCC Rules Description of Test Result Section 15.247(a)2) 6dB Bandwidth Test Compliant Section 15.247(e) Power Spectral Density Test Compliant Section 15.247(b)(3) Maximum Peak Output Power Test Compliant Section 15.247(d) Band Edge Compliance Tes Compliant Section 15.247(d) Section 15.209) Radiated Spurious Emission Test Compliant Section 15.247(d) Conducted Spurious Emission Test Compliant Section 15.207 AC Power Line Conducted Emission Test Compliant Section 15.203 Antenna Requirement Compliant Page 6 of 37 Report No.: WST151109103-E 1.1. Test Facility Test Firm : Shenzhen WST Testing Technology Co., Ltd. Certificated by FCC, Registration No.: 939433 Address : 1F, No.9 Building,TGK Science & Technology Park, Yangtian Rd., NO.72 Bao'an Dist., Shenzhen, Guangdong, China. 518101 Tel : (86)755-33916437 Fax : (86)755-27822175 1.2. Measurement Uncertainty Measurement Uncertainty Conducted Emission Expanded Uncertainty =2.23dB, k=2 Radiated emission expanded uncertainty(9kHz-30MHz) = 3.08dB, k=2 Radiated emission expanded uncertainty(30MHz-1000MHz)= 4.42dB, k=2 Radiated emission expanded uncertainty(Above 1GHz) = 4.06dB, k=2 Page 7 of 37 Report No.: WST151109103-E 2.. General Information 2.1. General Description of EUT Equipment HIVE EVOLUTION BLUETOOTH SPEAKER Model Name HIVE EVOLUTION, BL-291, KSHIVEEVOBK, KSHIVEEVOGM, KSHIVEEVOXX(XX = refer to color code) Serial No / FCC ID 2ADRB-HIVE EVOLUTION Model Difference All the model are the same circuit and RF module,except the appearance colour, this report only test mode name: HIVE EVOLUTION Modulation Type GFSK Antenna Type Internal monopole Antenna Antenna Gain 0 dBi Operation frequency 2402-2480MHz Number of Channels 40 Power Source DC Voltage Power Rating DC 7.4V Adapter Model / Page 8 of 37 Report No.: WST151109103-E 2.2. Carrier Frequency of Channels Operation of EUT during testing Operating Mode The mode is used: Transmitting mode Low Channel: 2402MHz Middle Channel: 2442MHz High Channel: 2480MHz 2.3. Description of Test Setup Operation of EUT during testing Model 1 Model 2 Adapter EUT AC 120V/60Hz EUT Page 9 of 37 Report No.: WST151109103-E 2.4. Measurement Instruments List Item Equipment Manufacturer Model No.Serial No.Last Cal. Cal. Interval 1. EMI Receiver Rohde & Schwarz ESCI 100627 May 19, 2015 1 Year 2. LISN SchwarzBeck NSLK 81268126377May 19, 2015 1 Year 3. RF Switching UnitCompliance Direction RSU-M2 38303 May 19, 2015 1 Year 4. EMI Test Software ES-K1 Rohde & SchwarzN/A N/A N/A N/A 5. EMI Test Receiver Rohde & Schwarz ESCI 100627 May 19, 2015 1 Y…

Text truncated - open the document above for the full version.

Radiated Emission AC Power Line Conducted Emission
